SafeAlert for Children, Teens and the Elderly

You've heard of LifeAlert, but what about when a loved one, young or old, are out and about rather than at home? SafeAlert helps everywhere!

AdvancedWork in progress1,048
SafeAlert for Children, Teens and the Elderly

Story

Read more

Code

LinkIt_GPS_SafeAlert.ino

Arduino
Main .ino file, will report statistics on button presses to a service like IFTTT to perform various customizable actions.
/////////////////////////////////////////////////////////////////////////
// LinkIt One GPS SafeAlert Project - by Drew Alden for Hackster.io, 2015
/////////////////////////////////////////////////////////////////////////

// -- Includes-GPS --
    #include <LGPS.h>
// -- /Includes-GPS --

// -- Includes-Wifi --
    #include <LTask.h>
    #include <LWiFi.h>
    #include <LWiFiServer.h>
    #include <LWiFiClient.h>
// -- /Includes-Wifi --

/////////////////////////////////////////////////////////////////////////

// -- Globals-Wifi --
    /*
     WiFi Web Server - A simple web server that a repeated counter
     Change the macro WIFI_AP, WIFI_PASSWORD and WIFI_AUTH accordingly.
     created 13 July 2010 by dlf (Metodo2 srl) - modified 31 May 2012 by Tom Igoe - modified 20 Aug 2014 by MediaTek Inc.
    */
    #define WIFI_AP "wifi_ssid"
    #define WIFI_PASSWORD "wifi_password"
    #define WIFI_AUTH LWIFI_WPA  // choose from LWIFI_OPEN, LWIFI_WPA, or LWIFI_WEP according to your WiFi AP configuration

    LWiFiServer server(80);

    int loopCount = 0;
// -- /Globals-Wifi --

// -- Globals-GPS --
    gpsSentenceInfoStruct info;
    char buff[256];
// -- /Globals-GPS --

/////////////////////////////////////////////////////////////////////////

void setup() {
	//init Pins
	pinMode(13, OUTPUT);  //built-in blinky LED

// -- Init-Wifi --
	LWiFi.begin();
	Serial.begin(115200);

	// keep retrying until connected to AP
	Serial.println("Connecting to AP...");
	while (0 == LWiFi.connect(WIFI_AP, LWiFiLoginInfo(WIFI_AUTH, WIFI_PASSWORD)))
	{
		delay(1000);
	}
	Serial.println("Connected!");
	printWifiStatus();

	Serial.println("Start Server");
	server.begin();
	Serial.println("Server Started");
// -- /Init-Wifi --

// -- Init-GPS --
	//Serial.begin(115200);  //already done
	LGPS.powerOn();
	Serial.println("LGPS Powered on, waiting 3 secs...");
	delay(3000);
// -- /Init-GPS --

} //end of setup()

/////////////////////////////////////////////////////////////////////////

void loop() {
  // -- Loop-GPS --
    digitalWrite(13, HIGH); //processing started
    Serial.println("LGPS loop");
    LGPS.getData(&info);
    Serial.println((char*)info.GPGGA);
    parseGPGGA((const char*)info.GPGGA);
    digitalWrite(13, LOW); //processing ended
    delay(1000); //was 2000
  // -- /Loop-GPS --

  // -- Loop-Wifi --
    //delay(500);  //just did that
    loopCount++;
    LWiFiClient client = server.available();
    if (client)
    {
      Serial.println("new client");
      // an http request ends with a blank line
      boolean currentLineIsBlank = true;
      while (client.connected())
      {
        if (client.available())
        {
          // we basically ignores client request, but wait for HTTP request end
          int c = client.read();
          Serial.print((char)c);

          if (c == '\n' && currentLineIsBlank)
          {
            Serial.println("send response");
            // send a standard http response header
            client.println("HTTP/1.1 200 OK");
            client.println("Content-Type: text/html");
            client.println("Connection: close");  // the connection will be closed after completion of the response
            client.println("Refresh: 5");  // refresh the page automatically every 1 sec
            client.println();
            client.println("<!DOCTYPE HTML>");
            client.println("<html>");
            // output the value of each analog input pin
            client.print("gps info: ");
            client.print((char*)info.GPGGA); //loopCount
            client.println("<br />");
            client.println("this page refreshes every 5 secs.");
            client.println("</html>");
            client.println();
            break;
          }
          if (c == '\n')
          {
            // you're starting a new line
            currentLineIsBlank = true;
          }
          else if (c != '\r')
          {
            // you've gotten a character on the current line
            currentLineIsBlank = false;
          }
        }
      }
      // give the web browser time to receive the data
      delay(1000);

      // close the connection:
      Serial.println("close connection");
      client.stop();
      Serial.println("client disconnected");
    }
  // -- /Loop-Wifi --

} //end of loop()

/////////////////////////////////////////////////////////////////////////

// -- Functions-Wifi --
void printWifiStatus()
{
  // print the SSID of the network you're attached to:
  Serial.print("SSID: ");
  Serial.println(LWiFi.SSID());

  // print your WiFi shield's IP address:
  IPAddress ip = LWiFi.localIP();
  Serial.print("IP Address: ");
  Serial.println(ip);

  Serial.print("subnet mask: ");
  Serial.println(LWiFi.subnetMask());

  Serial.print("gateway IP: ");
  Serial.println(LWiFi.gatewayIP());

  // print the received signal strength:
  long rssi = LWiFi.RSSI();
  Serial.print("signal strength (RSSI):");
  Serial.print(rssi);
  Serial.println(" dBm");
}
// -- /Functions-Wifi --



// -- Functions-GPS --
static unsigned char getComma(unsigned char num,const char *str)
{
  unsigned char i,j = 0;
  int len=strlen(str);
  for(i = 0;i < len;i ++)
  {
     if(str[i] == ',')
      j++;
     if(j == num)
      return i + 1;
  }
  return 0;
}

static double getDoubleNumber(const char *s)
{
  char buf[10];
  unsigned char i;
  double rev;

  i=getComma(1, s);
  i = i - 1;
  strncpy(buf, s, i);
  buf[i] = 0;
  rev=atof(buf);
  return rev;
}

static double getIntNumber(const char *s)
{
  char buf[10];
  unsigned char i;
  double rev;

  i=getComma(1, s);
  i = i - 1;
  strncpy(buf, s, i);
  buf[i] = 0;
  rev=atoi(buf);
  return rev;
}

void parseGPGGA(const char* GPGGAstr)
{
  /* Refer to http://www.gpsinformation.org/dale/nmea.htm#GGA
   * Sample data: $GPGGA,123519,4807.038,N,01131.000,E,1,08,0.9,545.4,M,46.9,M,,*47
   * Where:
   *  GGA          Global Positioning System Fix Data
   *  123519       Fix taken at 12:35:19 UTC
   *  4807.038,N   Latitude 48 deg 07.038' N
   *  01131.000,E  Longitude 11 deg 31.000' E
   *  1            Fix quality: 0 = invalid
   *                            1 = GPS fix (SPS)
   *                            2 = DGPS fix
   *                            3 = PPS fix
   *                            4 = Real Time Kinematic
   *                            5 = Float RTK
   *                            6 = estimated (dead reckoning) (2.3 feature)
   *                            7 = Manual input mode
   *                            8 = Simulation mode
   *  08           Number of satellites being tracked
   *  0.9          Horizontal dilution of position
   *  545.4,M      Altitude, Meters, above mean sea level
   *  46.9,M       Height of geoid (mean sea level) above WGS84
   *                   ellipsoid
   *  (empty field) time in seconds since last DGPS update
   *  (empty field) DGPS station ID number
   *  *47          the checksum data, always begins with *
   */
  double latitude;
  double longitude;
  int tmp, hour, minute, second, num ;
  if(GPGGAstr[0] == '$')
  {
    tmp = getComma(1, GPGGAstr);
    hour     = (GPGGAstr[tmp + 0] - '0') * 10 + (GPGGAstr[tmp + 1] - '0');
    minute   = (GPGGAstr[tmp + 2] - '0') * 10 + (GPGGAstr[tmp + 3] - '0');
    second    = (GPGGAstr[tmp + 4] - '0') * 10 + (GPGGAstr[tmp + 5] - '0');

    sprintf(buff, "UTC timer %2d-%2d-%2d", hour, minute, second);
    Serial.println(buff);

    tmp = getComma(2, GPGGAstr);
    latitude = getDoubleNumber(&GPGGAstr[tmp]);
    tmp = getComma(4, GPGGAstr);
    longitude = getDoubleNumber(&GPGGAstr[tmp]);
    sprintf(buff, "latitude = %10.4f, longitude = %10.4f", latitude, longitude);
    Serial.println(buff);

    tmp = getComma(7, GPGGAstr);
    num = getIntNumber(&GPGGAstr[tmp]);
    sprintf(buff, "satellites number = %d", num);
    Serial.println(buff);
  }
  else
  {
    Serial.println("Not get data");
  }
}
// -- /Functions-GPS --
