Overflow Watertank detection System

Automatic Watertank overflow detection System

Hello Friends,

In this tutorial I am going to teach you how to make simple cost effective watertank overflow detection system.

Nowdays world is facing water shortage problems so as a responsible citizen we need to manage our water supply and to use it wisely. Many parts of globe are thrusted for even a single drop of water on the other hand metro cities like new york, Bijing, Tokyo, Mumbai, London using alot of water and very large amount of water wasted due to the overflow of water tank so I decided to make a simple and cost effective solution on this issue which can help us to alert about watertank overflow so we can turn off the valve or motor and it only costs you around 8-9$ very cost friendly isn't it?

Try this tutorial and let me know what issue you faced and if any suggestions drop comment below I would like to help you all.

Insert a tilt switch inside a smiley ball. You guys must be thinking why smiley ball needed that ball can easily float on water so when tank fills the tilt switch which we placed inside the ball goes from horizontal position to vertical position. Stick one wooden stick to the edge of tank and other end of stick to the smiley ball and make sure the end which sticked to tank edge is freely moving in upward downward direction and not horizontally.
