Setting Up Raspberry Pi for ROS 2 With Docker

In this guide, I'll walk you through how I set up my Raspberry Pi 4 to run ROS 2 inside Docker containers without needing a monitor or keyboard. This headless setup has become my go-to approach for robotics projects where I want to remotely access and control the Pi.

Step 1: Installing Raspberry Pi OS Lite

Rather than repeating the basic installation steps here, I’ll direct you to follow the official Raspberry Pi documentation: Installing the Operating System

Here’s what I do differently for this setup:

1. I always choose Raspberry Pi OS Lite (64-bit) — no desktop environment means more resources for our containers

2. During the imaging process with the Raspberry Pi Imager, make sure to:

• Enable SSH in the advanced options (crucial for headless access)
• Set up my username and password
• Configure my WiFi credentials
• Set up my locale settings

I prefer the 64-bit Lite version because:

• It gives me better performance with containerized applications
• Uses less memory without the desktop environment
• Works perfectly with Docker and ROS 2 containers
• Feels more like a proper server setup

Step 2: First Boot and Getting Connected

Once I've flashed the SD Card:

• I insert it into my Raspberry Pi 4
• Connect the power supply and let it boot
• Wait about 2-3 minutes for the initial setup to complete
• The Pi automatically connects to my configured WiFi network

Step 3: Finding My Pi's IP Address

Since I'm running the Pi headless, I need to find out what IP address my Pi has been assigned. I use my Android phone for this.

My Android Network scanning approach:

1. I installed a network scanner application on my Android device. My favorites are:

• WOM WiFi by Network Scanner (easy-to-use)
• Network Scanner by First Row (simple and reliable)
• Fing by Fing Limited (feature-rich)

2. I make sure my phone is on the same WiFi network as my Pi

3. I run a network scan (using WOM WiFi) and look for:

• Hostname: "raspberrypi" (or whatever custom name I set)
• Manufacturer: "Raspberry Pi Foundation"
• MAC addresses startign with B8:27:EB, DC:A6:32 or E4:5F:01

4. I note down the IP address (something like 192.168.1.100)

Pro tip: I usually see my Pi appear in the scan within 1-2 minutes of booting. If it doesn't show up immediately, I wait a bit and scan again.

Step 4: SSH Connection - My Gateway to the Pi

Now comes the fun part - connecting to my Pi remotely!

From my Linux host machine (same for Mac machine)

I open Terminal and use the command:

ssh [my-username]@[pi-ip-address]

For example:

ssh pi@192.168.1.100

From my Windows machine

I can open Command Prompt or PowerShell and type:

ssh [my-username]@[pi-ip-address]

What happens on First Connection

1. I see a message about host authenticity:

The authenticity of host '192.168.1.100 (192.168.1.100)' can't be established.
ECDSA key fingerprint is SHA256:...
Are you sure you want to continue connecting (yes/no/[fingerprint])?

2. I type yes and hit Enter

3. I enter the password I set during the OS installation

4. Success! I see my Pi's command prompt:

pi@raspberrypi:~ $

Step 5: Initial Configuration - Setting Up My Environment

Once I'm connected, here's what I always do first:

Update Everything

sudo apt update && sudo apt upgrade -y

I grab a coffee while this runs - it usually takes a few minutes.

Configure Additional Interfaces

sudo raspi-config

I navigate through the menu to enable what I need:

• I2C (for sensors I might connect later)
• SPI (for various devices)
• Camera (if I plan to use the Pi camera)

For detailed information about all the configuration options available in raspi-config, check out the official documentation: Raspberry Pi Configuration

Install my Essential Tools

sudo apt install -y curl wget git vim nano htop

These are the tools I can't live without when working on Pi projects.

Step 6: Preparing for Docker

Increasing Swap Space

For 4GB Pi models, I always increase the swap space:

sudo dphys-swapfile swapoff
sudo nano /etc/dphys-swapfile

I change CONF_SWAPSIZE=100 to CONF_SWAPSIZE=1024, then:

sudo dphys-swapfile setup
sudo dphys-swapfile swapon

Memory Split Configuration

sudo raspi-config

I go to Advanced Options -> Memory Split and set it to 16 since I'm not using graphics.

Step 7: Installing Docker - the Container Magic

Getting Docker Installed

I use the official Docker Installation script:

curl -fsSL https://get.docker.com -o get-docker.sh
sudo sh get-docker.sh

Adding myself to the Docker Group

This lets me run Docker commands without sudo:

sudo usermod -aG docker $USER

Starting Docker Services

sudo systemctl enable docker
sudo systemctl start docker

Testing my Installation

I log out and back in, then test:

docker --version
docker run hello-world

When I see "Hello from Docker!" I know everything's working perfectly.

Step 8: Adding Docker Compose

For managing multi-container applications:

sudo apt install -y python3-pip
sudo pip3 install docker-compose

I verify it worked:

docker-compose --version

Step 9: Setting Up VS Code Remote Development

One of my favorite ways to work with the Pi is through VS Code's Remote Explorer extension. This gives me a full IDE experience while the code actually runs on the Pi.

Installing the Remote SSH Extension

1. I open VS Code on my Computer

2. Go to the Extensions panel (Ctrl + Shift + X)

3. Search for "Remote-SSH" by Microsoft

4. Install the extension

Connecting to my Pi

1. I press Ctrl + Shift + P to open the command palette

2. Type "Remote-SSH: Connect to Host"

3. Enter my Pi's SSH connection: my-username@pi-ip-address (e.g., pi@192.168.1.100)

4. VS Code opens a new window connected to my Pi

What I get with this setup

• Full file explorer of my Pi's filesystem
• Integrated terminal running directly on the Pi
• Code editing with Intellisense and syntax highlighting
• Extension support for Python, Docker, and ROS development
• Git integration for version control

Pro tip: I can install extensions directly on the Pi through VS Code's interface. I usually install Python, Docker, and ROS Extensions for the best development experience.

For a comprehensive guide on VS Code extensions specifically for ROS development, check out this detailed article: Exploration of VS Code extensions for a ROS Developer.

When Things Go Wrong - My Troubleshooting Checklist

SSH won't connect

• I double-check that my Pi is actually powered ON and the LED is active
• I run another network scan to confirm the IP address
• I verify SSH is enabled by checking /boot/ssh exists
• I try connecting with verbose output: ssh -v my-username@pi-ip-address

VS Code Remote Connection Issues

• I make sure the SSH connection works first in the terminal
• I check that the Remote-SSH extension is properly installed
• I try restarting VS Code and reconnecting
• I verify my SSH config doesn't have conflicting entries

Network Issues

• I verify that my network credentials are correct
• If all else fails, I connect via Ethernet for the initial setup

Performance problems

• I monitor resources with htop to see what's eating CPU/memory
• I consider switching to an SSD via USB 3.0 for better performance
• I make sure my Pi has adequate cooling for long-running tasks

What's Coming Next

My Raspberry Pi 4 is now ready for serious ROS 2 development! In the next article, I'll show you how to build and run ROS 2 Docker containers specifically optimized for the Pi.

We'll cover:

• Creating custom ROS 2 Docker images for ARM64 architecture
• Setting up Docker Compose files for robotics projects
• Optimizing containers for Pi's resource constraints

My Final Thoughts

This headless setup with VS Code remote development has become my standard approach for Pi-based projects. The combination of Raspberry Pi OS Lite, Docker, and VS Code's remote capabilities gives me a lightweight yet powerful development environment that I can access from anywhere on my network.

The best part? I get the full desktop IDE experience while keeping the Pi running efficiently without a desktop environment. This setup provides the perfect foundation for the ROS 2 Docker containers we'll build in the next article.
