Beginner’s Guide to PetaLinux 2025.2 on Arty Z7-20

Step-by-step PetaLinux setup on Arty Z7-20: from VM setup to running your first LED and switch application.

BeginnerProtip57
Beginner’s Guide to PetaLinux 2025.2 on Arty Z7-20

Things used in this project

Hardware components

Arty Z7-20
Digilent Arty Z7-20
×1

Software apps and online services

Vitis Unified Software Platform
AMD Vitis Unified Software Platform
Vivado Design Suite
AMD Vivado Design Suite
PetaLinux
AMD PetaLinux
Ubuntu
Ubuntu

Story

Read more

Code

helloworld_linux.c

C/C++
Code for PetaLinux
#include <stdio.h>
#include <unistd.h>
#include <fcntl.h>
#include <sys/mman.h>
#include <stdint.h>
#include <stdlib.h>

#define BASE_GPIO_ADDRESS 0x41200000
#define BASE_GPIO_SIZE    0x00034000   // enough to cover up to 0x41233000 + regs

#define BTN_BASE 0x00000
#define LED_BASE 0x11000
#define RGB_BASE 0x22000
#define SWS_BASE 0x33000

int main()
{
    int fd;
    uint8_t *virtual_base;

    volatile uint32_t *btn_addr;
    volatile uint32_t *led_addr;
    volatile uint32_t *rgb_addr;
    volatile uint32_t *sws_addr;

    uint32_t PushButton;
    uint32_t Switches;
    uint32_t RGBleds1;
    uint32_t RGBleds2;
    uint32_t RGBout;

    fd = open("/dev/mem", O_RDWR | O_SYNC);
    if (fd < 0) {
        perror("open");
        return 1;
    }

    virtual_base = mmap(NULL, BASE_GPIO_SIZE, PROT_READ | PROT_WRITE,
                        MAP_SHARED, fd, BASE_GPIO_ADDRESS);
    if (virtual_base == MAP_FAILED) {
        perror("mmap");
        close(fd);
        return 1;
    }

    btn_addr = (volatile uint32_t *)(virtual_base + BTN_BASE);
    led_addr = (volatile uint32_t *)(virtual_base + LED_BASE);
    rgb_addr = (volatile uint32_t *)(virtual_base + RGB_BASE);
    sws_addr = (volatile uint32_t *)(virtual_base + SWS_BASE);

    printf("Hello World\n");

    while (1)
    {
        PushButton = *btn_addr;
        Switches   = *sws_addr;

        *led_addr = PushButton;

        RGBleds1 = (Switches & 0x1) ? (PushButton & 0x7) : 0;
        RGBleds2 = (Switches & 0x2) ? ((PushButton & 0x7) << 3) : 0;

        RGBout = RGBleds1 | RGBleds2;
        *rgb_addr = RGBout;

        usleep(50000);
    }

    munmap(virtual_base, BASE_GPIO_SIZE);
    close(fd);
    return 0;
}

helloworld.c

C/C++
Bare metal code
#include <stdio.h>
#include "platform.h"
#include "xil_printf.h"
#include "xparameters.h"

/*
 * Memory-mapped AXI GPIO base addresses
 * These names must match your Vivado design / xparameters.h
 */
volatile unsigned long *BTN = (volatile unsigned long *)XPAR_AXI_GPIO_0_BASEADDR;
volatile unsigned long *LED = (volatile unsigned long *)XPAR_AXI_GPIO_1_BASEADDR;
volatile unsigned long *RGB = (volatile unsigned long *)XPAR_AXI_GPIO_2_BASEADDR;
volatile unsigned long *SWS = (volatile unsigned long *)XPAR_AXI_GPIO_3_BASEADDR;

int main()
{
    int PushButton;
    int Switches;
    int RGBleds1;
    int RGBleds2;
    int RGBout;

    init_platform();

    xil_printf("Hello World\r\n");

    while (1)
    {
        /* Read button and switch input registers */
        PushButton = BTN[0];
        Switches   = SWS[0];

        /* Show pushbutton value on normal LEDs */
        LED[0] = PushButton;

        /*
         * If switch 0 is ON, drive RGB LED 1
         * Use only lowest 3 bits of PushButton:
         * bit0 = R, bit1 = G, bit2 = B
         */
        if (Switches & 0x00000001)
        {
            RGBleds1 = (PushButton & 0x00000007);
        }
        else
        {
            RGBleds1 = 0;
        }

        /*
         * If switch 1 is ON, drive RGB LED 2
         * Same 3 button bits, shifted left by 3
         * so they go into bits 3..5
         */
        if (Switches & 0x00000002)
        {
            RGBleds2 = (PushButton & 0x00000007) << 3;
        }
        else
        {
            RGBleds2 = 0;
        }

        /* Combine both RGB LED values into one output register */
        RGBout = RGBleds1 + RGBleds2;
        RGB[0] = RGBout;
    }

    cleanup_platform();
    return 0;
}
