High-performance small FFT library for Versal AI Engine

Introduction

A few years ago I started working on a custom 16-point FFT for the AMD® Versal™ AI Engine (AIE). The goal of the project was to develop skills for creating custom AIE kernels using intrinsic functions and the AIE API. After creating the initial design I was able to use the Vitis™ tools to analyze performance and optimize for the AIE vector processor architecture. I was able to achieve 1.9 GSPS of throughput (complex 16-bit data) using a single AIE tile. I took the concepts learned during the 16-point FFT development and created 8-point, 32-point, and 64-point FFTs as well.

I thought it might be useful to share these designs with the community, so I created a library called FFTs for Fun (FFT4F).

Since the initial release of the code, I've added:

• Inverse FFT support
• Stream I/O support to reduce latency
• 32-bit data type support

Requirements

• AMD Vitis Unified IDE (2023.2 or later)
• Linux® based development environment
• Python® (for test automation and result validation)

Usage

Using the FFT4F library should be pretty straight-forward. Once the FFT4F repository is cloned it can be included in a project, and then an FFT4F subgraph can be instantiated in a system-level AIE graph.

Here's an AIE graph code example that shows how to instantiate a 16-point FFT that uses 2 input/output PLIO pairs.

#ifndef BASIC_GRAPH_H
#define BASIC_GRAPH_H

#include <adf.h>
#include <aie_api/aie.hpp>
#include <aie_api/aie_adf.hpp>
#include "fft4f/include/fft_graph.h"

using namespace adf;

class basic_graph : public graph
{
  public:
    input_plio  in0, in1;
    output_plio out0, out1;

    basic_graph()
    {
      in0  = input_plio::create("In0", plio_64_bits, "input_even.txt", 625);
      in1  = input_plio::create("In1", plio_64_bits, "input_odd.txt", 625);
      out0 = output_plio::create("Out0", plio_64_bits, "output_even.txt", 625);
      out1 = output_plio::create("Out1", plio_64_bits, "output_odd.txt", 625);

      connect<> (in0.out[0], g_fft.in[0]);
      connect<> (in1.out[0], g_fft.in[1]);
      connect<> (g_fft.out[0], out0.in[0]);
      connect<> (g_fft.out[1], out1.in[0]);

      g_fft.place_graph(6, 0); /* Place the graph starting at column 6, row 0 */
    }

  private:
    fft4f::fft_graph< 16,     // FFT Size
                      0x22,   // Number of IO
                      64,     // FFT frames per buffer (i.e. batch size)
                      1,      // Number of AIE Tiles to use
                      0x022,  // Scale factor
                      false,  // IFFT flag (true = IFFT, false = FFT)
                      false,  // Use Stream IO flag
                      cint16, // Input data type
                      cint16  // Internal & Output data types
                    > g_fft;
};

#endif

Copy the code above and save it to a file named basic_graph.h.

Next, create a testbench.cpp file with the following contents:

#include <adf.h>
#include "basic_graph.h"

using namespace adf;

basic_graph dut_graph;

int main(void)
{
  dut_graph.init();
  dut_graph.run(10);  /* Run for 10 iterations (10240 samples) */
  dut_graph.end();
  return 0;
}

Download the generate_data python script attached to this project, and run the script to generate random test data. On a Linux machine, the script can be executed with the command:

python3 generate_data.py 2 10240

Two files are generated with the command above: input_even.txt and input_odd.txt. Each file contains 5120 complex int16 samples.

Next, make sure to clone the FFT4F repository. The following Linux command can be used:

git clone https://gitlab.avnet.com/xilinx/versal/ai-engine/fft4f

We are now ready to compile the basic_graph for AIE simulation. Here's a few Linux commands to setup the Vitis environment, compile the AIE graph, and run AIE simulation:

source <Vitis tool install directory>/settings.sh

v++ -c --mode aie --target hw --platform xilinx_vck190_base_<version>_1 -I ./ -I fft4f/src --work_dir Work testbench.cpp

aiesimulator

NOTES:

• Replace <Vitis tool install directory> with the actual location of the Vitis tool install
• Replace <version> with the version of the tools being used; for example, 2024.2 would use a <version> value of 202420.

The AIE simulation will generate throughput measurements and report the MBytes/s processed. Here's an example of the simulator output:

--------------------------------------------------------------------------------
| Intf Type   | Port Name                          | Type  | Throughput(MBps)  |
--------------------------------------------------------------------------------
| plio        | In0                                | IN    | 4218.16           |
|             | In1                                | IN    | 4215.38           |
|             | Out0                               | OUT   | 3871.75           |
|             | Out1                               | OUT   | 3872.92           |

Each output sample is 4 Bytes (complex int16 data), so the throughput can be converted from Bytes to samples with the calculation:

2 x 3871 MBps / (4 Bytes/sample) = 1935 MSPS

Summary

I hope you find this project & FFT4F library useful. More details on using the FFT4F library along with throughput performance can be found at the project repository landing page at https://gitlab.avnet.com/xilinx/versal/ai-engine/fft4f.

Feel free to drop a comment with questions or suggestions on the FFT4F repo. I hope to expand the repository with new features in the future.
