Data Processing for Patients with Alzheimer's

Using the Sensors of SensorTile, we'll make a processing of data for recognize regular moves in persons with Alzheimer's.

EasyProtip3 hours914
Data Processing for Patients with Alzheimer's

Things used in this project

Hardware components

STEVAL-STLKT01V1
STMicroelectronics STEVAL-STLKT01V1
×1

Software apps and online services

Firebase
Google Firebase
STMicroelectronics ST BlueMS

Story

Read more

Schematics

STEVAL-STLKT01V1

Code

Main program (default DEMO)

C/C++
/**
  ******************************************************************************
  * @file    main.c
  * @author  Central LAB
  * @version V1.0.0
  * @date    21-Nov-2016
  * @brief   Main program body
  ******************************************************************************
  * @attention
  *
  * <h2><center>&copy; COPYRIGHT(c) 2016 STMicroelectronics</center></h2>
  *
  * Licensed under MCD-ST Liberty SW License Agreement V2, (the "License");
  * You may not use this file except in compliance with the License.
  * You may obtain a copy of the License at:
  *
  *        http://www.st.com/software_license_agreement_liberty_v2
  *
  * Redistribution and use in source and binary forms, with or without modification,
  * are permitted provided that the following conditions are met:
  *   1. Redistributions of source code must retain the above copyright notice,
  *      this list of conditions and the following disclaimer.
  *   2. Redistributions in binary form must reproduce the above copyright notice,
  *      this list of conditions and the following disclaimer in the documentation
  *      and/or other materials provided with the distribution.
  *   3. Neither the name of STMicroelectronics nor the names of its contributors
  *      may be used to endorse or promote products derived from this software
  *      without specific prior written permission.
  *
  * THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"
  * AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
  * IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
  * DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE
  * FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
  * DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
  * SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
  * CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
  * OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE
  * OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
  *
  ******************************************************************************
  */

/* Includes ------------------------------------------------------------------*/
#include <stdio.h>
#include <math.h>
#include <limits.h>
#include "TargetFeatures.h"
#include "main.h"
#include "sensor_service.h"
#include "bluenrg_utils.h"

/* Private typedef -----------------------------------------------------------*/

/* Private define ------------------------------------------------------------*/

/* Imported Variables -------------------------------------------------------------*/
extern uint8_t set_connectable;
extern int connected;

extern TIM_HandleTypeDef TimHandle;
extern void CDC_TIM_PeriodElapsedCallback(TIM_HandleTypeDef *htim);

/* Exported Variables -------------------------------------------------------------*/

uint32_t ConnectionBleStatus  =0;

uint8_t BufferToWrite[256];
int32_t BytesToWrite;

TIM_HandleTypeDef TimCCHandle;

uint8_t bdaddr[6];

/* Private variables ---------------------------------------------------------*/
static volatile uint32_t HCI_ProcessEvent=0;
static volatile uint32_t SendEnv         =0;

/* Private function prototypes -----------------------------------------------*/
static void SystemClock_Config(void);

static void Init_BlueNRG_Custom_Services(void);
static void Init_BlueNRG_Stack(void);
static void InitTimers(void);
static void SendEnvironmentalData(void);

//uint8_t CDC_Fill_Buffer(uint8_t* Buf, uint32_t TotalLen){}

/**
  * @brief  Main program
  * @param  None
  * @retval None
  */
int main(void)
{
  uint32_t StartTime;

  /* STM32L4xx HAL library initialization:
  - Configure the Flash prefetch, instruction and Data caches
  - Configure the Systick to generate an interrupt each 1 msec
  - Set NVIC Group Priority to 4
  - Global MSP (MCU Support Package) initialization
  */
  HAL_Init();

  /* Configure the System clock */
  SystemClock_Config();

  /* Configure and disable all the Chip Select pins */
  Sensor_IO_SPI_CS_Init_All();

  InitTargetPlatform(TARGET_SENSORTILE);

  STLBLE_PRINTF("\t(HAL %ld.%ld.%ld_%ld)\r\n"
        "\tCompiled %s %s"
#if defined (__IAR_SYSTEMS_ICC__)
        " (IAR)\r\n"
#elif defined (__CC_ARM)
        " (KEIL)\r\n"
#elif defined (__GNUC__)
        " (openstm32)\r\n"
#endif
         "\tSend Every %4dmS Temperature/Humidity/Pressure\r\n",
           HAL_GetHalVersion() >>24,
          (HAL_GetHalVersion() >>16)&0xFF,
          (HAL_GetHalVersion() >> 8)&0xFF,
           HAL_GetHalVersion()      &0xFF,
         __DATE__,__TIME__,
         uhCCR1_Val/10);

#ifdef ENABLE_USB_DEBUG_CONNECTION
  STLBLE_PRINTF("Debug Connection         Enabled\r\n");
#endif /* ENABLE_USB_DEBUG_CONNECTION */

#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
  STLBLE_PRINTF("Debug Notify Trasmission Enabled\r\n");
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */

  /* Initialize the BlueNRG */
  Init_BlueNRG_Stack();

  /* Initialize the BlueNRG Custom services */
  Init_BlueNRG_Custom_Services();

  /* initialize timers */
  InitTimers();

  StartTime = HAL_GetTick();
  /* Infinite loop */
  while (1){
    /* Led Blinking when there is not a client connected */
    if(!connected) {
      if(!TargetBoardFeatures.LedStatus) {
        if(HAL_GetTick()-StartTime > 1000) {
          LedOnTargetPlatform();
          TargetBoardFeatures.LedStatus =1;
          StartTime = HAL_GetTick();
        }
      } else {
        if(HAL_GetTick()-StartTime > 50) {
          LedOffTargetPlatform();
          TargetBoardFeatures.LedStatus =0;
          StartTime = HAL_GetTick();
        }
      }
    }

    /* handle BLE event */
    if(HCI_ProcessEvent) {
      HCI_ProcessEvent=0;
      HCI_Process();
    }

    /* Update the BLE advertise data and make the Board connectable */
    if(set_connectable){
      setConnectable();
      set_connectable = FALSE;
    }

    /* Environmental Data */
    if(SendEnv) {
      SendEnv=0;
      SendEnvironmentalData();
    }

    /* Wait for Interrupt */
    __WFI();
  }
}

/**
  * @brief  Output Compare callback in non blocking mode
  * @param  htim : TIM OC handle
  * @retval None
  */
void HAL_TIM_OC_DelayElapsedCallback(TIM_HandleTypeDef *htim)
{
  uint32_t uhCapture=0;

  /* TIM1_CH1 toggling with frequency = 2Hz */
  if(htim->Channel == HAL_TIM_ACTIVE_CHANNEL_1)
  {
    uhCapture = HAL_TIM_ReadCapturedValue(htim, TIM_CHANNEL_1);
    /* Set the Capture Compare Register value */
    __HAL_TIM_SET_COMPARE(&TimCCHandle, TIM_CHANNEL_1, (uhCapture + uhCCR1_Val));
    SendEnv=1;
  }
}

/**
  * @brief  Period elapsed callback in non blocking mode for Environmental timer
  * @param  htim : TIM handle
  * @retval None
  */
void HAL_TIM_PeriodElapsedCallback(TIM_HandleTypeDef *htim)
{
  if(htim == (&TimHandle)) {
    CDC_TIM_PeriodElapsedCallback(htim);
  }
}

/**
  * @brief  Send Environmetal Data (Temperature/Pressure/Humidity) to BLE
  * @param  None
  * @retval None
  */
static void SendEnvironmentalData(void)
{
  uint8_t Status;

#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
  if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
     BytesToWrite = sprintf((char *)BufferToWrite,"Sending: ");
     Term_Update(BufferToWrite,BytesToWrite);
  } else {
    STLBLE_PRINTF("Sending: ");
  }
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */

  /* Pressure,Humidity, and Temperatures*/
  if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_ENV)) {
    float SensorValue;
    int32_t PressToSend=0;
    uint16_t HumToSend=0;
    int16_t Temp2ToSend=0,Temp1ToSend=0;
    int32_t decPart, intPart;

      if(TargetBoardFeatures.HandlePressSensor) {
        if(BSP_PRESSURE_IsInitialized(TargetBoardFeatures.HandlePressSensor,&Status)==COMPONENT_OK) {
          BSP_PRESSURE_Get_Press(TargetBoardFeatures.HandlePressSensor,(float *)&SensorValue);
          MCR_BLUEMS_F2I_2D(SensorValue, intPart, decPart);
          PressToSend=intPart*100+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
          if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
            BytesToWrite = sprintf((char *)BufferToWrite,"Press=%ld ",PressToSend);
            Term_Update(BufferToWrite,BytesToWrite);
          } else {
            STLBLE_PRINTF("Press=%ld ",PressToSend);
          }
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
        }
      }

      if(TargetBoardFeatures.HandleHumSensor) {
        if(BSP_HUMIDITY_IsInitialized(TargetBoardFeatures.HandleHumSensor,&Status)==COMPONENT_OK){
          BSP_HUMIDITY_Get_Hum(TargetBoardFeatures.HandleHumSensor,(float *)&SensorValue);
          MCR_BLUEMS_F2I_1D(SensorValue, intPart, decPart);
          HumToSend = intPart*10+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
          if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
            BytesToWrite = sprintf((char *)BufferToWrite,"Hum=%d ",HumToSend);
            Term_Update(BufferToWrite,BytesToWrite);
          } else {
            STLBLE_PRINTF("Hum=%d ",HumToSend);
          }
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
        }
      }

      if(TargetBoardFeatures.NumTempSensors==2) {
        if(BSP_TEMPERATURE_IsInitialized(TargetBoardFeatures.HandleTempSensors[0],&Status)==COMPONENT_OK){
          BSP_TEMPERATURE_Get_Temp(TargetBoardFeatures.HandleTempSensors[0],(float *)&SensorValue);
          MCR_BLUEMS_F2I_1D(SensorValue, intPart, decPart);
          Temp1ToSend = intPart*10+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
          if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
            BytesToWrite = sprintf((char *)BufferToWrite,"Temp=%d ",Temp1ToSend);
            Term_Update(BufferToWrite,BytesToWrite);
          } else {
            STLBLE_PRINTF("Temp=%d ",Temp1ToSend);
          }
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
        }

        if(BSP_TEMPERATURE_IsInitialized(TargetBoardFeatures.HandleTempSensors[1],&Status)==COMPONENT_OK){
          BSP_TEMPERATURE_Get_Temp(TargetBoardFeatures.HandleTempSensors[1],(float *)&SensorValue);
          MCR_BLUEMS_F2I_1D(SensorValue, intPart, decPart);
          Temp2ToSend = intPart*10+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
          if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
            BytesToWrite = sprintf((char *)BufferToWrite,"Temp2=%d ",Temp2ToSend);
            Term_Update(BufferToWrite,BytesToWrite);
          } else {
            STLBLE_PRINTF("Temp2=%d ",Temp2ToSend);
          }
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
        }
      } else if(TargetBoardFeatures.NumTempSensors==1) {
        if(BSP_TEMPERATURE_IsInitialized(TargetBoardFeatures.HandleTempSensors[0],&Status)==COMPONENT_OK){
          BSP_TEMPERATURE_Get_Temp(TargetBoardFeatures.HandleTempSensors[0],(float *)&SensorValue);
          MCR_BLUEMS_F2I_1D(SensorValue, intPart, decPart);
          Temp1ToSend = intPart*10+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
          if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
            BytesToWrite = sprintf((char *)BufferToWrite,"Temp1=%d ",Temp1ToSend);
            Term_Update(BufferToWrite,BytesToWrite);
          } else {
            STLBLE_PRINTF("Temp1=%d ",Temp1ToSend);
          }
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
        }
      }
    Environmental_Update(PressToSend,HumToSend,Temp2ToSend,Temp1ToSend);
  }

#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
  if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
     BytesToWrite = sprintf((char *)BufferToWrite,"\r\n");
     Term_Update(BufferToWrite,BytesToWrite);
  } else {
    STLBLE_PRINTF("\r\n");
  }
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
}

/**
* @brief  Function for initializing timers for sending the information to BLE:
 *  - 1 for sending MotionFX/AR/CP and Acc/Gyro/Mag
 *  - 1 for sending the Environmental info
 * @param  None
 * @retval None
 */
static void InitTimers(void)
{
  uint32_t uwPrescalerValue;

  /* Timer Output Compare Configuration Structure declaration */
  TIM_OC_InitTypeDef sConfig;

  /* Compute the prescaler value to have TIM3 counter clock equal to 10 KHz */
  uwPrescalerValue = (uint32_t) ((SystemCoreClock / 10000) - 1);

  /* Set TIM1 instance (Motion)*/
  /* Set TIM1 instance */
  TimCCHandle.Instance = TIM1;
  TimCCHandle.Init.Period        = 65535;
  TimCCHandle.Init.Prescaler     = uwPrescalerValue;
  TimCCHandle.Init.ClockDivision = 0;
  TimCCHandle.Init.CounterMode   = TIM_COUNTERMODE_UP;
  if(HAL_TIM_OC_Init(&TimCCHandle) != HAL_OK)
  {
    /* Initialization Error */
    Error_Handler();
  }

 /* Configure the Output Compare channels */
 /* Common configuration for all channels */
  sConfig.OCMode     = TIM_OCMODE_TOGGLE;
  sConfig.OCPolarity = TIM_OCPOLARITY_LOW;

  /* Output Compare Toggle Mode configuration: Channel1 */
  sConfig.Pulse = uhCCR1_Val;
  if(HAL_TIM_OC_ConfigChannel(&TimCCHandle, &sConfig, TIM_CHANNEL_1) != HAL_OK)
  {
    /* Configuration Error */
    Error_Handler();
  }

}

/** @brief Initialize the BlueNRG Stack
 * @param None
 * @retval None
 */
static void Init_BlueNRG_Stack(void)
{
  const char BoardName[8] = {NAME_STLBLE,0};
  uint16_t service_handle, dev_name_char_handle, appearance_char_handle;
  int ret;
  uint8_t  hwVersion;
  uint16_t fwVersion;

#ifdef STATIC_BLE_MAC
  {
    uint8_t tmp_bdaddr[6]= {STATIC_BLE_MAC};
    int32_t i;
    for(i=0;i<6;i++)
      bdaddr[i] = tmp_bdaddr[i];
  }
#endif /* STATIC_BLE_MAC */

  /* Initialize the BlueNRG SPI driver */
  BNRG_SPI_Init();

  /* Initialize the BlueNRG HCI */
  HCI_Init();

  /* Reset BlueNRG hardware */
  BlueNRG_RST();

  /* get the BlueNRG HW and FW versions */
  getBlueNRGVersion(&hwVersion, &fwVersion);

  if (hwVersion > 0x30) {
    /* X-NUCLEO-IDB05A1 expansion board is used */
    TargetBoardFeatures.bnrg_expansion_board = IDB05A1;
  } else {
    /* X-NUCLEO-IDB0041 expansion board is used */
    TargetBoardFeatures.bnrg_expansion_board = IDB04A1;
  }

  /*
   * Reset BlueNRG again otherwise it will fail.
   */
  BlueNRG_RST();

#ifndef STATIC_BLE_MAC
  /* Create a Unique BLE MAC */
  {
    bdaddr[0] = (STM32_UUID[1]>>24)&0xFF;
    bdaddr[1] = (STM32_UUID[0]    )&0xFF;
    bdaddr[2] = (STM32_UUID[2] >>8)&0xFF;
    bdaddr[3] = (STM32_UUID[0]>>16)&0xFF;
    bdaddr[4] = (((STLBLE_VERSION_MAJOR-48)*10) + (STLBLE_VERSION_MINOR-48)+100)&0xFF;
    bdaddr[5] = 0xC0; /* for a Legal BLE Random MAC */
  }
#else /* STATIC_BLE_MAC */

  ret = aci_hal_write_config_data(CONFIG_DATA_PUBADDR_OFFSET,
                                  CONFIG_DATA_PUBADDR_LEN,
                                  bdaddr);
  if(ret){
     STLBLE_PRINTF("\r\nSetting Pubblic BD_ADDR failed\r\n");
     goto fail;
  }
#endif /* STATIC_BLE_MAC */

  ret = aci_gatt_init();
  if(ret){
     STLBLE_PRINTF("\r\nGATT_Init failed\r\n");
     goto fail;
  }

  if (TargetBoardFeatures.bnrg_expansion_board == IDB05A1) {
    ret = aci_gap_init_IDB05A1(GAP_PERIPHERAL_ROLE_IDB05A1, 0, 0x07, &service_handle, &dev_name_char_handle, &appearance_char_handle);
  } else {
    ret = aci_gap_init_IDB04A1(GAP_PERIPHERAL_ROLE_IDB04A1, &service_handle, &dev_name_char_handle, &appearance_char_handle);
  }

  if(ret != BLE_STATUS_SUCCESS){
     STLBLE_PRINTF("\r\nGAP_Init failed\r\n");
     goto fail;
  }

#ifndef  STATIC_BLE_MAC
  ret = hci_le_set_random_address(bdaddr);

  if(ret){
     STLBLE_PRINTF("\r\nSetting the Static Random BD_ADDR failed\r\n");
     goto fail;
  }
#endif /* STATIC_BLE_MAC */

  ret = aci_gatt_update_char_value(service_handle, dev_name_char_handle, 0,
                                   7/*strlen(BoardName)*/, (uint8_t *)BoardName);

  if(ret){
     STLBLE_PRINTF("\r\naci_gatt_update_char_value failed\r\n");
    while(1);
  }

  ret = aci_gap_set_auth_requirement(MITM_PROTECTION_REQUIRED,
                                     OOB_AUTH_DATA_ABSENT,
                                     NULL, 7, 16,
                                     USE_FIXED_PIN_FOR_PAIRING, 123456,
                                     BONDING);
  if (ret != BLE_STATUS_SUCCESS) {
     STLBLE_PRINTF("\r\nGAP setting Authentication failed\r\n");
     goto fail;
  }

  STLBLE_PRINTF("SERVER: BLE Stack Initialized \r\n"
         "\t\tBoard type=%s HWver=%d, FWver=%d.%d.%c\r\n"
         "\t\tBoardName= %s\r\n"
         "\t\tBoardMAC = %x:%x:%x:%x:%x:%x\r\n\n",
         "SensorTile",
         hwVersion,
         fwVersion>>8,
         (fwVersion>>4)&0xF,
         (hwVersion > 0x30) ? ('a'+(fwVersion&0xF)-1) : 'a',
         BoardName,
         bdaddr[5],bdaddr[4],bdaddr[3],bdaddr[2],bdaddr[1],bdaddr[0]);

  /* Set output power level */
  aci_hal_set_tx_power_level(1,4);

  return;

fail:
  return;
}

/** @brief Initialize all the Custom BlueNRG services
 * @param None
 * @retval None
 */
static void Init_BlueNRG_Custom_Services(void)
{
  int ret;

  ret = Add_HWServW2ST_Service();
  if(ret == BLE_STATUS_SUCCESS) {
     STLBLE_PRINTF("HW      Service W2ST added successfully\r\n");
  } else {
     STLBLE_PRINTF("\r\nError while adding HW Service W2ST\r\n");
  }

  ret = Add_ConfigW2ST_Service();
  if(ret == BLE_STATUS_SUCCESS) {
     STLBLE_PRINTF("Config  Service W2ST added successfully\r\n");
  } else {
     STLBLE_PRINTF("\r\nError while adding Config Service W2ST\r\n");
  }
}

/**
* @brief  System Clock Configuration
* @param  None
* @retval None
*/
void SystemClock_Config(void)
{
  RCC_ClkInitTypeDef RCC_ClkInitStruct = {0};
  RCC_OscInitTypeDef RCC_OscInitStruct = {0};
  RCC_PeriphCLKInitTypeDef PeriphClkInitStruct = {0};

  __HAL_RCC_PWR_CLK_ENABLE();
  HAL_PWR_EnableBkUpAccess();

  /* Enable the LSE Oscilator */
  RCC_OscInitStruct.OscillatorType = RCC_OSCILLATORTYPE_LSE;
  RCC_OscInitStruct.LSEState = RCC_LSE_ON;
  if (HAL_RCC_OscConfig(&RCC_OscInitStruct) != HAL_OK){
    while(1);
  }

  /* Enable the CSS interrupt in case LSE signal is corrupted or not present */
  HAL_RCCEx_DisableLSECSS();

  /* Enable MSI Oscillator and activate PLL with MSI as source */
  RCC_OscInitStruct.OscillatorType      = RCC_OSCILLATORTYPE_MSI;
  RCC_OscInitStruct.MSIState            = RCC_MSI_ON;
  RCC_OscInitStruct.HSICalibrationValue = RCC_MSICALIBRATION_DEFAULT;
  RCC_OscInitStruct.MSIClockRange       = RCC_MSIRANGE_11;
  RCC_OscInitStruct.PLL.PLLState        = RCC_PLL_ON;
  RCC_OscInitStruct.PLL.PLLSource       = RCC_PLLSOURCE_MSI;
  RCC_OscInitStruct.PLL.PLLM            = 6;
  RCC_OscInitStruct.PLL.PLLN            = 40;
  RCC_OscInitStruct.PLL.PLLP            = 7;
  RCC_OscInitStruct.PLL.PLLQ            = 4;
  RCC_OscInitStruct.PLL.PLLR            = 4;
  if (HAL_RCC_OscConfig(&RCC_OscInitStruct) != HAL_OK){
    while(1);
  }

  /* Enable MSI Auto-calibration through LSE */
  HAL_RCCEx_EnableMSIPLLMode();

  /* Select MSI output as USB clock source */
  PeriphClkInitStruct.PeriphClockSelection = RCC_PERIPHCLK_USB;
  PeriphClkInitStruct.UsbClockSelection = RCC_USBCLKSOURCE_MSI;
  HAL_RCCEx_PeriphCLKConfig(&PeriphClkInitStruct);

  /* Select PLL as system clock source and configure the HCLK, PCLK1 and PCLK2
  clocks dividers */
  RCC_ClkInitStruct.ClockType = (RCC_CLOCKTYPE_SYSCLK | RCC_CLOCKTYPE_HCLK | RCC_CLOCKTYPE_PCLK1 | RCC_CLOCKTYPE_PCLK2);
  RCC_ClkInitStruct.SYSCLKSource = RCC_SYSCLKSOURCE_PLLCLK;
  RCC_ClkInitStruct.AHBCLKDivider = RCC_SYSCLK_DIV1;
  RCC_ClkInitStruct.APB1CLKDivider = RCC_HCLK_DIV1;
  RCC_ClkInitStruct.APB2CLKDivider = RCC_HCLK_DIV1;
  if (HAL_RCC_ClockConfig(&RCC_ClkInitStruct, FLASH_LATENCY_4) != HAL_OK){
    while(1);
  }
}


/**
  * @brief This function provides accurate delay (in milliseconds) based
  *        on variable incremented.
  * @note This is a user implementation using WFI state
  * @param Delay: specifies the delay time length, in milliseconds.
  * @retval None
  */
void HAL_Delay(__IO uint32_t Delay)
{
  uint32_t tickstart = 0;
  tickstart = HAL_GetTick();
  while((HAL_GetTick() - tickstart) < Delay){
    __WFI();
  }
}

/**
  * @brief  This function is executed in case of error occurrence.
  * @param  None
  * @retval None
  */
void Error_Handler(void)
{
  /* User may add here some code to deal with this error */
  while(1){
  }
}

/**
 * @brief  EXTI line detection callback.
 * @param  uint16_t GPIO_Pin Specifies the pins connected EXTI line
 * @retval None
 */
void HAL_GPIO_EXTI_Callback(uint16_t GPIO_Pin)
{
  switch(GPIO_Pin){
    case BNRG_SPI_EXTI_PIN:
      HCI_Isr();
      HCI_ProcessEvent=1;
    break;
  }
}

#ifdef  USE_FULL_ASSERT
/**
  * @brief  Reports the name of the source file and the source line number
  *         where the assert_param error has occurred.
  * @param  file: pointer to the source file name
  * @param  line: assert_param error line source number
  * @retval None
  */
void assert_failed(uint8_t* file, uint32_t line)
{
  /* User can add his own implementation to report the file name and line number,
     ex: STLBLE_PRINTF("Wrong parameters value: file %s on line %d\r\n", file, line) */

  /* Infinite loop */
  while (1){
  }
}
#endif


/******************* (C) COPYRIGHT 2016 STMicroelectronics *****END OF FILE****/

Credits

Nedzib Sastoque Rangel

Nedzib Sastoque Rangel

5 projects • 7 followers
#UDistrital #UNal Electronics student, I love programming, domotic, create prototypes and learn new things

Comments
