Vitis-AI DPU-TRD for 2024.x with VIVADO and Kria/MPSoC

################################################################
# This is a generated script based on design: top
#
# Though there are limitations about the generated script,
# the main purpose of this utility is to make learning
# IP Integrator Tcl commands easier.
################################################################

namespace eval _tcl {
proc get_script_folder {} {
   set script_path [file normalize [info script]]
   set script_folder [file dirname $script_path]
   return $script_folder
}
}
variable script_folder
set script_folder [_tcl::get_script_folder]

################################################################
# Check if script is running in correct Vivado version.
################################################################
set scripts_vivado_version 2024.1
set current_vivado_version [version -short]

if { [string first $scripts_vivado_version $current_vivado_version] == -1 } {
   puts ""
   if { [string compare $scripts_vivado_version $current_vivado_version] > 0 } {
      catch {common::send_gid_msg -ssname BD::TCL -id 2042 -severity "ERROR" " This script was generated using Vivado <$scripts_vivado_version> and is being run in <$current_vivado_version> of Vivado. Sourcing the script failed since it was created with a future version of Vivado."}

   } else {
     catch {common::send_gid_msg -ssname BD::TCL -id 2041 -severity "ERROR" "This script was generated using Vivado <$scripts_vivado_version> and is being run in <$current_vivado_version> of Vivado. Please run the script in Vivado <$scripts_vivado_version> then open the design in Vivado <$current_vivado_version>. Upgrade the design by running \"Tools => Report => Report IP Status...\", then run write_bd_tcl to create an updated script."}

   }

   return 1
}

################################################################
# START
################################################################

# To test this script, run the following commands from Vivado Tcl console:
# source top_script.tcl

# If there is no project opened, this script will create a
# project, but make sure you do not have an existing project
# <./myproj/project_1.xpr> in the current working folder.

set list_projs [get_projects -quiet]
if { $list_projs eq "" } {
   create_project project_1 myproj -part xck26-sfvc784-2LV-c
   set_property BOARD_PART xilinx.com:kr260_som_som240_1_connector_kr260_carrier_som240_1_connector_som240_2_connector_kr260_carrier_som240_2_connector:part0:1.1 [current_project]
}


# CHANGE DESIGN NAME HERE
variable design_name
set design_name top

# This script was generated for a remote BD. To create a non-remote design,
# change the variable <run_remote_bd_flow> to <0>.

set run_remote_bd_flow 1
if { $run_remote_bd_flow == 1 } {
  # Set the reference directory for source file relative paths (by default
  # the value is script directory path)
  set origin_dir ./srcs

  # Use origin directory path location variable, if specified in the tcl shell
  if { [info exists ::origin_dir_loc] } {
     set origin_dir $::origin_dir_loc
  }

  set str_bd_folder [file normalize ${origin_dir}]
  set str_bd_filepath ${str_bd_folder}/${design_name}/${design_name}.bd

  # Check if remote design exists on disk
  if { [file exists $str_bd_filepath ] == 1 } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2030 -severity "ERROR" "The remote BD file path <$str_bd_filepath> already exists!"}
     common::send_gid_msg -ssname BD::TCL -id 2031 -severity "INFO" "To create a non-remote BD, change the variable <run_remote_bd_flow> to <0>."
     common::send_gid_msg -ssname BD::TCL -id 2032 -severity "INFO" "Also make sure there is no design <$design_name> existing in your current project."

     return 1
  }

  # Check if design exists in memory
  set list_existing_designs [get_bd_designs -quiet $design_name]
  if { $list_existing_designs ne "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2033 -severity "ERROR" "The design <$design_name> already exists in this project! Will not create the remote BD <$design_name> at the folder <$str_bd_folder>."}

     common::send_gid_msg -ssname BD::TCL -id 2034 -severity "INFO" "To create a non-remote BD, change the variable <run_remote_bd_flow> to <0> or please set a different value to variable <design_name>."

     return 1
  }

  # Check if design exists on disk within project
  set list_existing_designs [get_files -quiet */${design_name}.bd]
  if { $list_existing_designs ne "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2035 -severity "ERROR" "The design <$design_name> already exists in this project at location:
    $list_existing_designs"}
     catch {common::send_gid_msg -ssname BD::TCL -id 2036 -severity "ERROR" "Will not create the remote BD <$design_name> at the folder <$str_bd_folder>."}

     common::send_gid_msg -ssname BD::TCL -id 2037 -severity "INFO" "To create a non-remote BD, change the variable <run_remote_bd_flow> to <0> or please set a different value to variable <design_name>."

     return 1
  }

  # Now can create the remote BD
  # NOTE - usage of <-dir> will create <$str_bd_folder/$design_name/$design_name.bd>
  create_bd_design -dir $str_bd_folder $design_name
} else {

  # Create regular design
  if { [catch {create_bd_design $design_name} errmsg] } {
     common::send_gid_msg -ssname BD::TCL -id 2038 -severity "INFO" "Please set a different value to variable <design_name>."

     return 1
  }
}

current_bd_design $design_name

set bCheckIPsPassed 1
##################################################################
# CHECK IPs
##################################################################
set bCheckIPs 1
if { $bCheckIPs == 1 } {
   set list_check_ips "\
xilinx.com:ip:xlconcat:2.1\
xilinx.com:ip:proc_sys_reset:5.0\
xilinx.com:ip:zynq_ultra_ps_e:3.5\
xilinx.com:ip:dpuczdx8g:4.1\
xilinx.com:ip:clk_wiz:6.0\
"

   set list_ips_missing ""
   common::send_gid_msg -ssname BD::TCL -id 2011 -severity "INFO" "Checking if the following IPs exist in the project's IP catalog: $list_check_ips ."

   foreach ip_vlnv $list_check_ips {
      set ip_obj [get_ipdefs -all $ip_vlnv]
      if { $ip_obj eq "" } {
         lappend list_ips_missing $ip_vlnv
      }
   }

   if { $list_ips_missing ne "" } {
      catch {common::send_gid_msg -ssname BD::TCL -id 2012 -severity "ERROR" "The following IPs are not found in the IP Catalog:\n  $list_ips_missing\n\nResolution: Please add the repository containing the IP(s) to the project." }
      set bCheckIPsPassed 0
   }

}

if { $bCheckIPsPassed != 1 } {
  common::send_gid_msg -ssname BD::TCL -id 2023 -severity "WARNING" "Will not continue with creation of design due to the error(s) above."
  return 3
}

##################################################################
# DESIGN PROCs
##################################################################


# Hierarchical cell: hier_dpu_irq
proc create_hier_cell_hier_dpu_irq { parentCell nameHier } {

  variable script_folder

  if { $parentCell eq "" || $nameHier eq "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2092 -severity "ERROR" "create_hier_cell_hier_dpu_irq() - Empty argument(s)!"}
     return
  }

  # Get object for parentCell
  set parentObj [get_bd_cells $parentCell]
  if { $parentObj == "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2090 -severity "ERROR" "Unable to find parent cell <$parentCell>!"}
     return
  }

  # Make sure parentObj is hier blk
  set parentType [get_property TYPE $parentObj]
  if { $parentType ne "hier" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2091 -severity "ERROR" "Parent <$parentObj> has TYPE = <$parentType>. Expected to be <hier>."}
     return
  }

  # Save current instance; Restore later
  set oldCurInst [current_bd_instance .]

  # Set parent object as current
  current_bd_instance $parentObj

  # Create cell and set as current instance
  set hier_obj [create_bd_cell -type hier $nameHier]
  current_bd_instance $hier_obj

  # Create interface pins

  # Create pins
  create_bd_pin -dir O -from 0 -to 0 -type intr INTR
  create_bd_pin -dir I -from 0 -to 0 In0

  # Create instance: dpu_concat_irq_inner, and set properties
  set dpu_concat_irq_inner [ create_bd_cell -type ip -vlnv xilinx.com:ip:xlconcat:2.1 dpu_concat_irq_inner ]
  set_property CONFIG.NUM_PORTS {1} $dpu_concat_irq_inner


  # Create port connections
  connect_bd_net -net In0_1 [get_bd_pins In0] [get_bd_pins dpu_concat_irq_inner/In0]
  connect_bd_net -net dpu_concat_irq_inner_dout [get_bd_pins dpu_concat_irq_inner/dout] [get_bd_pins INTR]

  # Restore current instance
  current_bd_instance $oldCurInst
}

# Hierarchical cell: hier_dpu_ghp
proc create_hier_cell_hier_dpu_ghp { parentCell nameHier } {

  variable script_folder

  if { $parentCell eq "" || $nameHier eq "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2092 -severity "ERROR" "create_hier_cell_hier_dpu_ghp() - Empty argument(s)!"}
     return
  }

  # Get object for parentCell
  set parentObj [get_bd_cells $parentCell]
  if { $parentObj == "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2090 -severity "ERROR" "Unable to find parent cell <$parentCell>!"}
     return
  }

  # Make sure parentObj is hier blk
  set parentType [get_property TYPE $parentObj]
  if { $parentType ne "hier" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2091 -severity "ERROR" "Parent <$parentObj> has TYPE = <$parentType>. Expected to be <hier>."}
     return
  }

  # Save current instance; Restore later
  set oldCurInst [current_bd_instance .]

  # Set parent object as current
  current_bd_instance $parentObj

  # Create cell and set as current instance
  set hier_obj [create_bd_cell -type hier $nameHier]
  current_bd_instance $hier_obj

  # Create interface pins
  create_bd_intf_pin -mode Slave -vlnv xilinx.com:interface:aximm_rtl:1.0 DPU0_M_AXI_DATA0

  create_bd_intf_pin -mode Slave -vlnv xilinx.com:interface:aximm_rtl:1.0 DPU0_M_AXI_DATA1

  create_bd_intf_pin -mode Slave -vlnv xilinx.com:interface:aximm_rtl:1.0 DPU0_M_AXI_INSTR

  create_bd_intf_pin -mode Master -vlnv xilinx.com:interface:aximm_rtl:1.0 M_AXI_HP0_FPD

  create_bd_intf_pin -mode Master -vlnv xilinx.com:interface:aximm_rtl:1.0 M_AXI_HP1_FPD

  create_bd_intf_pin -mode Master -vlnv xilinx.com:interface:aximm_rtl:1.0 M_AXI_LPD


  # Create pins
  create_bd_pin -dir I -type clk CLK
  create_bd_pin -dir I -type clk GHP_CLK_I
  create_bd_pin -dir O -type clk GHP_CLK_O
  create_bd_pin -dir I -type rst GHP_RSTn
  create_bd_pin -dir I -type rst RSTn_INTC
  create_bd_pin -dir I -type rst RSTn_PERI

  # Create instance: dpu_intc_M_AXI_HP0_FPD, and set properties
  set dpu_intc_M_AXI_HP0_FPD [ create_bd_cell -type ip -vlnv xilinx.com:ip:axi_interconnect:2.1 dpu_intc_M_AXI_HP0_FPD ]
  set_property -dict [list \
    CONFIG.NUM_MI {1} \
    CONFIG.NUM_SI {1} \
  ] $dpu_intc_M_AXI_HP0_FPD


  # Create instance: dpu_intc_M_AXI_HP1_FPD, and set properties
  set dpu_intc_M_AXI_HP1_FPD [ create_bd_cell -type ip -vlnv xilinx.com:ip:axi_interconnect:2.1 dpu_intc_M_AXI_HP1_FPD ]
  set_property -dict [list \
    CONFIG.NUM_MI {1} \
    CONFIG.NUM_SI {1} \
  ] $dpu_intc_M_AXI_HP1_FPD


  # Create instance: dpu_intc_M_AXI_LPD, and set properties
  set dpu_intc_M_AXI_LPD [ create_bd_cell -type ip -vlnv xilinx.com:ip:axi_interconnect:2.1 dpu_intc_M_AXI_LPD ]
  set_property -dict [list \
    CONFIG.NUM_MI {1} \
    CONFIG.NUM_SI {1} \
  ] $dpu_intc_M_AXI_LPD


  # Create interface connections
  connect_bd_intf_net -intf_net DPU0_M_AXI_DATA0_1 [get_bd_intf_pins DPU0_M_AXI_DATA0] [get_bd_intf_pins dpu_intc_M_AXI_HP0_FPD/S00_AXI]
  connect_bd_intf_net -intf_net DPU0_M_AXI_DATA1_1 [get_bd_intf_pins DPU0_M_AXI_DATA1] [get_bd_intf_pins dpu_intc_M_AXI_HP1_FPD/S00_AXI]
  connect_bd_intf_net -intf_net DPU0_M_AXI_INSTR_1 [get_bd_intf_pins DPU0_M_AXI_INSTR] [get_bd_intf_pins dpu_intc_M_AXI_LPD/S00_AXI]
  connect_bd_intf_net -intf_net dpu_intc_M_AXI_HP0_FPD_M00_AXI [get_bd_intf_pins M_AXI_HP0_FPD] [get_bd_intf_pins dpu_intc_M_AXI_HP0_FPD/M00_AXI]
  connect_bd_intf_net -intf_net dpu_intc_M_AXI_HP1_FPD_M00_AXI [get_bd_intf_pins M_AXI_HP1_FPD] [get_bd_intf_pins dpu_intc_M_AXI_HP1_FPD/M00_AXI]
  connect_bd_intf_net -intf_net dpu_intc_M_AXI_LPD_M00_AXI [get_bd_intf_pins M_AXI_LPD] [get_bd_intf_pins dpu_intc_M_AXI_LPD/M00_AXI]

  # Create port connections
  connect_bd_net -net CLK_1 [get_bd_pins CLK] [get_bd_pins dpu_intc_M_AXI_HP0_FPD/ACLK] [get_bd_pins dpu_intc_M_AXI_HP0_FPD/S00_ACLK] [get_bd_pins dpu_intc_M_AXI_HP1_FPD/ACLK] [get_bd_pins dpu_intc_M_AXI_HP1_FPD/S00_ACLK] [get_bd_pins dpu_intc_M_AXI_LPD/ACLK] [get_bd_pins dpu_intc_M_AXI_LPD/S00_ACLK]
  connect_bd_net -net GHP_CLK_I_1 [get_bd_pins GHP_CLK_I] [get_bd_pins GHP_CLK_O] [get_bd_pins dpu_intc_M_AXI_HP0_FPD/M00_ACLK] [get_bd_pins dpu_intc_M_AXI_HP1_FPD/M00_ACLK] [get_bd_pins dpu_intc_M_AXI_LPD/M00_ACLK]
  connect_bd_net -net GHP_RSTn_1 [get_bd_pins GHP_RSTn] [get_bd_pins dpu_intc_M_AXI_HP0_FPD/M00_ARESETN] [get_bd_pins dpu_intc_M_AXI_HP1_FPD/M00_ARESETN] [get_bd_pins dpu_intc_M_AXI_LPD/M00_ARESETN]
  connect_bd_net -net RSTn_INTC_1 [get_bd_pins RSTn_INTC] [get_bd_pins dpu_intc_M_AXI_HP0_FPD/ARESETN] [get_bd_pins dpu_intc_M_AXI_HP1_FPD/ARESETN] [get_bd_pins dpu_intc_M_AXI_LPD/ARESETN]
  connect_bd_net -net RSTn_PERI_1 [get_bd_pins RSTn_PERI] [get_bd_pins dpu_intc_M_AXI_HP0_FPD/S00_ARESETN] [get_bd_pins dpu_intc_M_AXI_HP1_FPD/S00_ARESETN] [get_bd_pins dpu_intc_M_AXI_LPD/S00_ARESETN]

  # Restore current instance
  current_bd_instance $oldCurInst
}

# Hierarchical cell: hier_dpu_clk
proc create_hier_cell_hier_dpu_clk { parentCell nameHier } {

  variable script_folder

  if { $parentCell eq "" || $nameHier eq "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2092 -severity "ERROR" "create_hier_cell_hier_dpu_clk() - Empty argument(s)!"}
     return
  }

  # Get object for parentCell
  set parentObj [get_bd_cells $parentCell]
  if { $parentObj == "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2090 -severity "ERROR" "Unable to find parent cell <$parentCell>!"}
     return
  }

  # Make sure parentObj is hier blk
  set parentType [get_property TYPE $parentObj]
  if { $parentType ne "hier" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2091 -severity "ERROR" "Parent <$parentObj> has TYPE = <$parentType>. Expected to be <hier>."}
     return
  }

  # Save current instance; Restore later
  set oldCurInst [current_bd_instance .]

  # Set parent object as current
  current_bd_instance $parentObj

  # Create cell and set as current instance
  set hier_obj [create_bd_cell -type hier $nameHier]
  current_bd_instance $hier_obj

  # Create interface pins

  # Create pins
  create_bd_pin -dir I -type clk CLK
  create_bd_pin -dir O -type clk DPU_CLK
  create_bd_pin -dir O -type clk DSP_CLK
  create_bd_pin -dir O -type data LOCKED
  create_bd_pin -dir I -type rst RSTn
  create_bd_pin -dir O -from 0 -to 0 -type rst RSTn_DSP
  create_bd_pin -dir O -from 0 -to 0 -type rst RSTn_INTC
  create_bd_pin -dir O -from 0 -to 0 -type rst RSTn_PERI
  create_bd_pin -dir I -type ce clk_dsp_ce

  # Create instance: dpu_clk_wiz, and set properties
  set dpu_clk_wiz [ create_bd_cell -type ip -vlnv xilinx.com:ip:clk_wiz:6.0 dpu_clk_wiz ]
  set_property -dict [list \
    CONFIG.CLKOUT1_DRIVES {Buffer_with_CE} \
    CONFIG.CLKOUT1_MATCHED_ROUTING {true} \
    CONFIG.CLKOUT1_REQUESTED_OUT_FREQ {550} \
    CONFIG.CLKOUT2_MATCHED_ROUTING {true} \
    CONFIG.CLKOUT2_REQUESTED_OUT_FREQ {275} \
    CONFIG.CLKOUT2_USED {true} \
    CONFIG.CLK_OUT1_PORT {clk_dsp} \
    CONFIG.CLK_OUT2_PORT {clk_dpu} \
    CONFIG.PRIMITIVE {Auto} \
    CONFIG.RESET_TYPE {ACTIVE_LOW} \
    CONFIG.USE_LOCKED {true} \
    CONFIG.USE_RESET {true} \
  ] $dpu_clk_wiz


  # Create instance: rst_gen_clk, and set properties
  set rst_gen_clk [ create_bd_cell -type ip -vlnv xilinx.com:ip:proc_sys_reset:5.0 rst_gen_clk ]

  # Create instance: rst_gen_clk_dsp, and set properties
  set rst_gen_clk_dsp [ create_bd_cell -type ip -vlnv xilinx.com:ip:proc_sys_reset:5.0 rst_gen_clk_dsp ]

  # Create port connections
  connect_bd_net -net CLK_1 [get_bd_pins CLK] [get_bd_pins dpu_clk_wiz/clk_in1]
  connect_bd_net -net RSTn_1 [get_bd_pins RSTn] [get_bd_pins dpu_clk_wiz/resetn] [get_bd_pins rst_gen_clk/ext_reset_in] [get_bd_pins rst_gen_clk_dsp/ext_reset_in]
  connect_bd_net -net clk_dsp_ce_1 [get_bd_pins clk_dsp_ce] [get_bd_pins dpu_clk_wiz/clk_dsp_ce]
  connect_bd_net -net dpu_clk_wiz_clk_dpu [get_bd_pins dpu_clk_wiz/clk_dpu] [get_bd_pins DPU_CLK] [get_bd_pins rst_gen_clk/slowest_sync_clk]
  connect_bd_net -net dpu_clk_wiz_clk_dsp [get_bd_pins dpu_clk_wiz/clk_dsp] [get_bd_pins DSP_CLK] [get_bd_pins rst_gen_clk_dsp/slowest_sync_clk]
  connect_bd_net -net dpu_clk_wiz_locked [get_bd_pins dpu_clk_wiz/locked] [get_bd_pins LOCKED] [get_bd_pins rst_gen_clk/dcm_locked] [get_bd_pins rst_gen_clk_dsp/dcm_locked]
  connect_bd_net -net rst_gen_clk_dsp_peripheral_aresetn [get_bd_pins rst_gen_clk_dsp/peripheral_aresetn] [get_bd_pins RSTn_DSP]
  connect_bd_net -net rst_gen_clk_interconnect_aresetn [get_bd_pins rst_gen_clk/interconnect_aresetn] [get_bd_pins RSTn_INTC]
  connect_bd_net -net rst_gen_clk_peripheral_aresetn [get_bd_pins rst_gen_clk/peripheral_aresetn] [get_bd_pins RSTn_PERI]

  # Restore current instance
  current_bd_instance $oldCurInst
}

# Hierarchical cell: hier_dpu
proc create_hier_cell_hier_dpu { parentCell nameHier } {

  variable script_folder

  if { $parentCell eq "" || $nameHier eq "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2092 -severity "ERROR" "create_hier_cell_hier_dpu() - Empty argument(s)!"}
     return
  }

  # Get object for parentCell
  set parentObj [get_bd_cells $parentCell]
  if { $parentObj == "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2090 -severity "ERROR" "Unable to find parent cell <$parentCell>!"}
     return
  }

  # Make sure parentObj is hier blk
  set parentType [get_property TYPE $parentObj]
  if { $parentType ne "hier" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2091 -severity "ERROR" "Parent <$parentObj> has TYPE = <$parentType>. Expected to be <hier>."}
     return
  }

  # Save current instance; Restore later
  set oldCurInst [current_bd_instance .]

  # Set parent object as current
  current_bd_instance $parentObj

  # Create cell and set as current instance
  set hier_obj [create_bd_cell -type hier $nameHier]
  current_bd_instance $hier_obj

  # Create interface pins
  create_bd_intf_pin -mode Master -vlnv xilinx.com:interface:aximm_rtl:1.0 M_AXI_HP0_FPD

  create_bd_intf_pin -mode Master -vlnv xilinx.com:interface:aximm_rtl:1.0 M_AXI_HP1_FPD

  create_bd_intf_pin -mode Master -vlnv xilinx.com:interface:aximm_rtl:1.0 M_AXI_LPD

  create_bd_intf_pin -mode Slave -vlnv xilinx.com:interface:aximm_rtl:1.0 S_AXI


  # Create pins
  create_bd_pin -dir I -type clk CLK
  create_bd_pin -dir I -type clk GHP_CLK_I
  create_bd_pin -dir O -type clk GHP_CLK_O
  create_bd_pin -dir I -type rst GHP_RSTn
  create_bd_pin -dir O -from 0 -to 0 -type intr INTR
  create_bd_pin -dir I -type rst RSTn
  create_bd_pin -dir I -type clk S_AXI_CLK
  create_bd_pin -dir I -type rst S_AXI_RSTn

  # Create instance: DPUCZDX8G, and set properties
  set DPUCZDX8G [ create_bd_cell -type ip -vlnv xilinx.com:ip:dpuczdx8g:4.1 DPUCZDX8G ]
  set_property -dict [list \
    CONFIG.ALU_LEAKYRELU {0} \
    CONFIG.ALU_PARALLEL_USER {4} \
    CONFIG.ARCH {4096} \
    CONFIG.ARCH_IMG_BKGRP {2} \
    CONFIG.CLK_GATING_ENA {1} \
    CONFIG.CONV_DSP_ACCU_ENA {1} \
    CONFIG.CONV_DSP_CASC_MAX {4} \
    CONFIG.CONV_RELU_ADDON {3} \
    CONFIG.CONV_WR_PARALLEL {1} \
    CONFIG.LOAD_AUGM {1} \
    CONFIG.SAVE_ARGMAX_ENA {1} \
    CONFIG.SFM_ENA {0} \
    CONFIG.S_AXI_CLK_INDEPENDENT {1} \
    CONFIG.TIMESTAMP_ENA {1} \
    CONFIG.TIME_DAY {29} \
    CONFIG.TIME_HOUR {13} \
    CONFIG.TIME_MONTH {4} \
    CONFIG.TIME_QUARTER {0} \
    CONFIG.TIME_YEAR {25} \
    CONFIG.URAM_N_USER {50} \
    CONFIG.VER_DPU_NUM {1} \
  ] $DPUCZDX8G


  # Create instance: hier_dpu_clk
  create_hier_cell_hier_dpu_clk $hier_obj hier_dpu_clk

  # Create instance: hier_dpu_ghp
  create_hier_cell_hier_dpu_ghp $hier_obj hier_dpu_ghp

  # Create instance: hier_dpu_irq
  create_hier_cell_hier_dpu_irq $hier_obj hier_dpu_irq

  # Create interface connections
  connect_bd_intf_net -intf_net Conn1 [get_bd_intf_pins M_AXI_HP0_FPD] [get_bd_intf_pins hier_dpu_ghp/M_AXI_HP0_FPD]
  connect_bd_intf_net -intf_net Conn2 [get_bd_intf_pins M_AXI_HP1_FPD] [get_bd_intf_pins hier_dpu_ghp/M_AXI_HP1_FPD]
  connect_bd_intf_net -intf_net Conn3 [get_bd_intf_pins M_AXI_LPD] [get_bd_intf_pins hier_dpu_ghp/M_AXI_LPD]
  connect_bd_intf_net -intf_net DPUCZDX8G_DPU0_M_AXI_DATA0 [get_bd_intf_pins DPUCZDX8G/DPU0_M_AXI_DATA0] [get_bd_intf_pins hier_dpu_ghp/DPU0_M_AXI_DATA0]
  connect_bd_intf_net -intf_net DPUCZDX8G_DPU0_M_AXI_DATA1 [get_bd_intf_pins DPUCZDX8G/DPU0_M_AXI_DATA1] [get_bd_intf_pins hier_dpu_ghp/DPU0_M_AXI_DATA1]
  connect_bd_intf_net -intf_net DPUCZDX8G_DPU0_M_AXI_INSTR [get_bd_intf_pins DPUCZDX8G/DPU0_M_AXI_INSTR] [get_bd_intf_pins hier_dpu_ghp/DPU0_M_AXI_INSTR]
  connect_bd_intf_net -intf_net S_AXI_1 [get_bd_intf_pins S_AXI] [get_bd_intf_pins DPUCZDX8G/S_AXI]

  # Create port connections
  connect_bd_net -net CLK_1 [get_bd_pins CLK] [get_bd_pins hier_dpu_clk/CLK]
  connect_bd_net -net DPUCZDX8G_dpu0_interrupt [get_bd_pins DPUCZDX8G/dpu0_interrupt] [get_bd_pins hier_dpu_irq/In0]
  connect_bd_net -net DPUCZDX8G_dpu_2x_clk_ce [get_bd_pins DPUCZDX8G/dpu_2x_clk_ce] [get_bd_pins hier_dpu_clk/clk_dsp_ce]
  connect_bd_net -net GHP_CLK_I_1 [get_bd_pins GHP_CLK_I] [get_bd_pins hier_dpu_ghp/GHP_CLK_I]
  connect_bd_net -net GHP_RSTn_1 [get_bd_pins GHP_RSTn] [get_bd_pins hier_dpu_ghp/GHP_RSTn]
  connect_bd_net -net RSTn_1 [get_bd_pins RSTn] [get_bd_pins hier_dpu_clk/RSTn]
  connect_bd_net -net S_AXI_CLK_1 [get_bd_pins S_AXI_CLK] [get_bd_pins DPUCZDX8G/s_axi_aclk]
  connect_bd_net -net S_AXI_RSTn_1 [get_bd_pins S_AXI_RSTn] [get_bd_pins DPUCZDX8G/s_axi_aresetn]
  connect_bd_net -net hier_dpu_clk_DPU_CLK [get_bd_pins hier_dpu_clk/DPU_CLK] [get_bd_pins DPUCZDX8G/m_axi_dpu_aclk] [get_bd_pins hier_dpu_ghp/CLK]
  connect_bd_net -net hier_dpu_clk_DSP_CLK [get_bd_pins hier_dpu_clk/DSP_CLK] [get_bd_pins DPUCZDX8G/dpu_2x_clk]
  connect_bd_net -net hier_dpu_clk_RSTn_DSP [get_bd_pins hier_dpu_clk/RSTn_DSP] [get_bd_pins DPUCZDX8G/dpu_2x_resetn]
  connect_bd_net -net hier_dpu_clk_RSTn_INTC [get_bd_pins hier_dpu_clk/RSTn_INTC] [get_bd_pins hier_dpu_ghp/RSTn_INTC]
  connect_bd_net -net hier_dpu_clk_RSTn_PERI [get_bd_pins hier_dpu_clk/RSTn_PERI] [get_bd_pins DPUCZDX8G/m_axi_dpu_aresetn] [get_bd_pins hier_dpu_ghp/RSTn_PERI]
  connect_bd_net -net hier_dpu_ghp_GHP_CLK_O [get_bd_pins hier_dpu_ghp/GHP_CLK_O] [get_bd_pins GHP_CLK_O]
  connect_bd_net -net hier_dpu_irq_INTR [get_bd_pins hier_dpu_irq/INTR] [get_bd_pins INTR]

  # Restore current instance
  current_bd_instance $oldCurInst
}


# Procedure to create entire design; Provide argument to make
# procedure reusable. If parentCell is "", will use root.
proc create_root_design { parentCell } {

  variable script_folder
  variable design_name

  if { $parentCell eq "" } {
     set parentCell [get_bd_cells /]
  }

  # Get object for parentCell
  set parentObj [get_bd_cells $parentCell]
  if { $parentObj == "" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2090 -severity "ERROR" "Unable to find parent cell <$parentCell>!"}
     return
  }

  # Make sure parentObj is hier blk
  set parentType [get_property TYPE $parentObj]
  if { $parentType ne "hier" } {
     catch {common::send_gid_msg -ssname BD::TCL -id 2091 -severity "ERROR" "Parent <$parentObj> has TYPE = <$parentType>. Expected to be <hier>."}
     return
  }

  # Save current instance; Restore later
  set oldCurInst [current_bd_instance .]

  # Set parent object as current
  current_bd_instance $parentObj


  # Create interface ports

  # Create ports

  # Create instance: dpu_concat_irq, and set properties
  set dpu_concat_irq [ create_bd_cell -type ip -vlnv xilinx.com:ip:xlconcat:2.1 dpu_concat_irq ]
  set_property CONFIG.NUM_PORTS {1} $dpu_concat_irq


  # Create instance: hier_dpu
  create_hier_cell_hier_dpu [current_bd_instance .] hier_dpu

  # Create instance: rst_gen_ghp, and set properties
  set rst_gen_ghp [ create_bd_cell -type ip -vlnv xilinx.com:ip:proc_sys_reset:5.0 rst_gen_ghp ]

  # Create instance: rst_gen_reg, and set properties
  set rst_gen_reg [ create_bd_cell -type ip -vlnv xilinx.com:ip:proc_sys_reset:5.0 rst_gen_reg ]

  # Create instance: zynq_ultra_ps_e_0, and set properties
  set zynq_ultra_ps_e_0 [ create_bd_cell -type ip -vlnv xilinx.com:ip:zynq_ultra_ps_e:3.5 zynq_ultra_ps_e_0 ]
  set_property -dict [list \
    CONFIG.CAN0_BOARD_INTERFACE {custom} \
    CONFIG.CAN1_BOARD_INTERFACE {custom} \
    CONFIG.CSU_BOARD_INTERFACE {custom} \
    CONFIG.DP_BOARD_INTERFACE {custom} \
    CONFIG.GEM0_BOARD_INTERFACE {custom} \
    CONFIG.GEM1_BOARD_INTERFACE {custom} \
    CONFIG.GEM2_BOARD_INTERFACE {custom} \
    CONFIG.GEM3_BOARD_INTERFACE {custom} \
    CONFIG.GPIO_BOARD_INTERFACE {custom} \
    CONFIG.IIC0_BOARD_INTERFACE {custom} \
    CONFIG.IIC1_BOARD_INTERFACE {custom} \
    CONFIG.NAND_BOARD_INTERFACE {custom} \
    CONFIG.PCIE_BOARD_INTERFACE {custom} \
    CONFIG.PJTAG_BOARD_INTERFACE {custom} \
    CONFIG.PMU_BOARD_INTERFACE {custom} \
    CONFIG.PSU_BANK_0_IO_STANDARD {LVCMOS18} \
    CONFIG.PSU_BANK_1_IO_STANDARD {LVCMOS18} \
    CONFIG.PSU_BANK_2_IO_STANDARD {LVCMOS18} \
    CONFIG.PSU_BANK_3_IO_STANDARD {LVCMOS18} \
    CONFIG.PSU_DDR_RAM_HIGHADDR {0xFFFFFFFF} \
    CONFIG.PSU_DDR_RAM_HIGHADDR_OFFSET {0x800000000} \
    CONFIG.PSU_DDR_RAM_LOWADDR_OFFSET {0x80000000} \
    CONFIG.PSU_IMPORT_BOARD_PRESET {} \
    CONFIG.PSU_MIO_0_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_0_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_0_SLEW {slow} \
    CONFIG.PSU_MIO_10_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_10_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_10_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_10_SLEW {slow} \
    CONFIG.PSU_MIO_11_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_11_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_11_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_11_SLEW {slow} \
    CONFIG.PSU_MIO_12_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_12_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_12_POLARITY {Default} \
    CONFIG.PSU_MIO_12_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_12_SLEW {slow} \
    CONFIG.PSU_MIO_13_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_13_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_13_POLARITY {Default} \
    CONFIG.PSU_MIO_13_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_13_SLEW {slow} \
    CONFIG.PSU_MIO_14_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_14_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_14_POLARITY {Default} \
    CONFIG.PSU_MIO_14_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_14_SLEW {slow} \
    CONFIG.PSU_MIO_15_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_15_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_15_POLARITY {Default} \
    CONFIG.PSU_MIO_15_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_15_SLEW {slow} \
    CONFIG.PSU_MIO_16_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_16_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_16_POLARITY {Default} \
    CONFIG.PSU_MIO_16_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_16_SLEW {slow} \
    CONFIG.PSU_MIO_17_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_17_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_17_POLARITY {Default} \
    CONFIG.PSU_MIO_17_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_17_SLEW {slow} \
    CONFIG.PSU_MIO_18_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_18_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_18_POLARITY {Default} \
    CONFIG.PSU_MIO_18_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_18_SLEW {slow} \
    CONFIG.PSU_MIO_19_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_19_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_19_POLARITY {Default} \
    CONFIG.PSU_MIO_19_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_19_SLEW {slow} \
    CONFIG.PSU_MIO_1_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_1_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_1_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_1_SLEW {slow} \
    CONFIG.PSU_MIO_20_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_20_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_20_POLARITY {Default} \
    CONFIG.PSU_MIO_20_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_20_SLEW {slow} \
    CONFIG.PSU_MIO_21_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_21_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_21_POLARITY {Default} \
    CONFIG.PSU_MIO_21_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_21_SLEW {slow} \
    CONFIG.PSU_MIO_22_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_22_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_22_POLARITY {Default} \
    CONFIG.PSU_MIO_22_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_22_SLEW {slow} \
    CONFIG.PSU_MIO_23_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_23_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_23_POLARITY {Default} \
    CONFIG.PSU_MIO_23_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_23_SLEW {slow} \
    CONFIG.PSU_MIO_24_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_24_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_24_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_24_SLEW {slow} \
    CONFIG.PSU_MIO_25_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_25_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_25_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_25_SLEW {slow} \
    CONFIG.PSU_MIO_26_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_26_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_27_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_27_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_27_SLEW {slow} \
    CONFIG.PSU_MIO_28_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_28_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_29_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_29_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_29_SLEW {slow} \
    CONFIG.PSU_MIO_2_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_2_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_2_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_2_SLEW {slow} \
    CONFIG.PSU_MIO_30_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_30_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_31_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_31_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_32_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_32_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_32_POLARITY {Default} \
    CONFIG.PSU_MIO_32_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_32_SLEW {slow} \
    CONFIG.PSU_MIO_33_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_33_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_33_POLARITY {Default} \
    CONFIG.PSU_MIO_33_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_33_SLEW {slow} \
    CONFIG.PSU_MIO_34_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_34_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_34_POLARITY {Default} \
    CONFIG.PSU_MIO_34_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_34_SLEW {slow} \
    CONFIG.PSU_MIO_35_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_35_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_35_SLEW {slow} \
    CONFIG.PSU_MIO_36_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_36_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_36_SLEW {slow} \
    CONFIG.PSU_MIO_37_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_37_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_38_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_38_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_38_SLEW {slow} \
    CONFIG.PSU_MIO_39_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_39_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_39_SLEW {slow} \
    CONFIG.PSU_MIO_3_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_3_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_3_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_3_SLEW {slow} \
    CONFIG.PSU_MIO_40_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_40_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_40_SLEW {slow} \
    CONFIG.PSU_MIO_41_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_41_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_41_SLEW {slow} \
    CONFIG.PSU_MIO_42_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_42_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_42_SLEW {slow} \
    CONFIG.PSU_MIO_43_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_43_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_43_SLEW {slow} \
    CONFIG.PSU_MIO_44_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_44_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_45_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_45_PULLUPDOWN {disable} \
    CONFIG.PSU_MIO_46_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_46_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_47_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_47_PULLUPDOWN {disable} \
    CONFIG.PSU_MIO_48_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_48_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_49_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_49_PULLUPDOWN {disable} \
    CONFIG.PSU_MIO_4_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_4_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_4_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_4_SLEW {slow} \
    CONFIG.PSU_MIO_50_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_50_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_50_SLEW {slow} \
    CONFIG.PSU_MIO_51_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_51_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_51_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_51_SLEW {slow} \
    CONFIG.PSU_MIO_52_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_52_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_53_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_53_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_54_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_54_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_54_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_54_SLEW {slow} \
    CONFIG.PSU_MIO_55_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_55_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_56_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_56_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_56_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_56_SLEW {slow} \
    CONFIG.PSU_MIO_57_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_57_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_57_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_57_SLEW {slow} \
    CONFIG.PSU_MIO_58_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_58_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_58_SLEW {slow} \
    CONFIG.PSU_MIO_59_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_59_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_59_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_59_SLEW {slow} \
    CONFIG.PSU_MIO_5_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_5_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_5_SLEW {slow} \
    CONFIG.PSU_MIO_60_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_60_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_60_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_60_SLEW {slow} \
    CONFIG.PSU_MIO_61_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_61_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_61_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_61_SLEW {slow} \
    CONFIG.PSU_MIO_62_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_62_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_62_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_62_SLEW {slow} \
    CONFIG.PSU_MIO_63_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_63_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_63_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_63_SLEW {slow} \
    CONFIG.PSU_MIO_64_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_64_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_65_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_65_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_66_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_66_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_66_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_66_SLEW {slow} \
    CONFIG.PSU_MIO_67_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_67_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_68_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_68_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_68_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_68_SLEW {slow} \
    CONFIG.PSU_MIO_69_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_69_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_69_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_69_SLEW {slow} \
    CONFIG.PSU_MIO_6_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_6_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_6_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_6_SLEW {slow} \
    CONFIG.PSU_MIO_70_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_70_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_70_SLEW {slow} \
    CONFIG.PSU_MIO_71_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_71_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_71_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_71_SLEW {slow} \
    CONFIG.PSU_MIO_72_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_72_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_72_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_72_SLEW {slow} \
    CONFIG.PSU_MIO_73_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_73_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_73_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_73_SLEW {slow} \
    CONFIG.PSU_MIO_74_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_74_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_74_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_74_SLEW {slow} \
    CONFIG.PSU_MIO_75_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_75_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_75_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_75_SLEW {slow} \
    CONFIG.PSU_MIO_76_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_76_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_76_SLEW {slow} \
    CONFIG.PSU_MIO_77_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_77_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_77_SLEW {slow} \
    CONFIG.PSU_MIO_7_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_7_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_7_POLARITY {Default} \
    CONFIG.PSU_MIO_7_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_7_SLEW {slow} \
    CONFIG.PSU_MIO_8_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_8_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_8_POLARITY {Default} \
    CONFIG.PSU_MIO_8_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_8_SLEW {slow} \
    CONFIG.PSU_MIO_9_DRIVE_STRENGTH {4} \
    CONFIG.PSU_MIO_9_INPUT_TYPE {cmos} \
    CONFIG.PSU_MIO_9_PULLUPDOWN {pullup} \
    CONFIG.PSU_MIO_9_SLEW {slow} \
    CONFIG.PSU_MIO_TREE_PERIPHERALS {Quad SPI Flash#Quad SPI Flash#Quad SPI Flash#Quad SPI Flash#Quad SPI Flash#Quad SPI Flash#SPI 1#GPIO0 MIO#GPIO0 MIO#SPI 1#SPI 1#SPI 1#GPIO0 MIO#GPIO0 MIO#GPIO0 MIO#GPIO0\
MIO#GPIO0 MIO#GPIO0 MIO#GPIO0 MIO#GPIO0 MIO#GPIO0 MIO#GPIO0 MIO#GPIO0 MIO#GPIO0 MIO#I2C 1#I2C 1#PMU GPI 0#DPAUX#DPAUX#DPAUX#DPAUX#PMU GPI 5#GPIO1 MIO#GPIO1 MIO#GPIO1 MIO#PMU GPO 3#UART 1#UART 1#Gem 1#Gem\
1#Gem 1#Gem 1#Gem 1#Gem 1#Gem 1#Gem 1#Gem 1#Gem 1#Gem 1#Gem 1#MDIO 1#MDIO 1#USB 0#USB 0#USB 0#USB 0#USB 0#USB 0#USB 0#USB 0#USB 0#USB 0#USB 0#USB 0#USB 1#USB 1#USB 1#USB 1#USB 1#USB 1#USB 1#USB 1#USB 1#USB\
1#USB 1#USB 1#USB0 Reset#USB1 Reset} \
    CONFIG.PSU_MIO_TREE_SIGNALS {sclk_out#miso_mo1#mo2#mo3#mosi_mi0#n_ss_out#sclk_out#gpio0[7]#gpio0[8]#n_ss_out[0]#miso#mosi#gpio0[12]#gpio0[13]#gpio0[14]#gpio0[15]#gpio0[16]#gpio0[17]#gpio0[18]#gpio0[19]#gpio0[20]#gpio0[21]#gpio0[22]#gpio0[23]#scl_out#sda_out#gpi[0]#dp_aux_data_out#dp_hot_plug_detect#dp_aux_data_oe#dp_aux_data_in#gpi[5]#gpio1[32]#gpio1[33]#gpio1[34]#gpo[3]#txd#rxd#rgmii_tx_clk#rgmii_txd[0]#rgmii_txd[1]#rgmii_txd[2]#rgmii_txd[3]#rgmii_tx_ctl#rgmii_rx_clk#rgmii_rxd[0]#rgmii_rxd[1]#rgmii_rxd[2]#rgmii_rxd[3]#rgmii_rx_ctl#gem1_mdc#gem1_mdio_out#ulpi_clk_in#ulpi_dir#ulpi_tx_data[2]#ulpi_nxt#ulpi_tx_data[0]#ulpi_tx_data[1]#ulpi_stp#ulpi_tx_data[3]#ulpi_tx_data[4]#ulpi_tx_data[5]#ulpi_tx_data[6]#ulpi_tx_data[7]#ulpi_clk_in#ulpi_dir#ulpi_tx_data[2]#ulpi_nxt#ulpi_tx_data[0]#ulpi_tx_data[1]#ulpi_stp#ulpi_tx_data[3]#ulpi_tx_data[4]#ulpi_tx_data[5]#ulpi_tx_data[6]#ulpi_tx_data[7]#reset#reset}\
\
    CONFIG.PSU_PERIPHERAL_BOARD_PRESET {} \
    CONFIG.PSU_SD0_INTERNAL_BUS_WIDTH {8} \
    CONFIG.PSU_SD1_INTERNAL_BUS_WIDTH {8} \
    CONFIG.PSU_SMC_CYCLE_T0 {NA} \
    CONFIG.PSU_SMC_CYCLE_T1 {NA} \
    CONFIG.PSU_SMC_CYCLE_T2 {NA} \
    CONFIG.PSU_SMC_CYCLE_T3 {NA} \
    CONFIG.PSU_SMC_CYCLE_T4 {NA} \
    CONFIG.PSU_SMC_CYCLE_T5 {NA} \
    CONFIG.PSU_SMC_CYCLE_T6 {NA} \
    CONFIG.PSU_USB3__DUAL_CLOCK_ENABLE {1} \
    CONFIG.PSU_VALUE_SILVERSION {3} \
    CONFIG.PSU__ACPU0__POWER__ON {1} \
    CONFIG.PSU__ACPU1__POWER__ON {1} \
    CONFIG.PSU__ACPU2__POWER__ON {1} \
    CONFIG.PSU__ACPU3__POWER__ON {1} \
    CONFIG.PSU__ACTUAL__IP {1} \
    CONFIG.PSU__ACT_DDR_FREQ_MHZ {1066.656006} \
    CONFIG.PSU__AUX_REF_CLK__FREQMHZ {33.333} \
    CONFIG.PSU__CAN0_LOOP_CAN1__ENABLE {0} \
    CONFIG.PSU__CAN0__PERIPHERAL__ENABLE {0} \
    CONFIG.PSU__CAN1__PERIPHERAL__ENABLE {0} \
    CONFIG.PSU__CRF_APB__ACPU_CTRL__ACT_FREQMHZ {1333.333008} \
    CONFIG.PSU__CRF_APB__ACPU_CTRL__FREQMHZ {1333.333} \
    CONFIG.PSU__CRF_APB__ACPU_CTRL__SRCSEL {APLL} \
    CONFIG.PSU__CRF_APB__ACPU__FRAC_ENABLED {1} \
    CONFIG.PSU__CRF_APB__AFI0_REF_CTRL__ACT_FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI0_REF_CTRL__DIVISOR0 {2} \
    CONFIG.PSU__CRF_APB__AFI0_REF_CTRL__FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI0_REF_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__AFI0_REF__ENABLE {0} \
    CONFIG.PSU__CRF_APB__AFI1_REF_CTRL__ACT_FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI1_REF_CTRL__DIVISOR0 {2} \
    CONFIG.PSU__CRF_APB__AFI1_REF_CTRL__FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI1_REF_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__AFI1_REF__ENABLE {0} \
    CONFIG.PSU__CRF_APB__AFI2_REF_CTRL__ACT_FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI2_REF_CTRL__DIVISOR0 {2} \
    CONFIG.PSU__CRF_APB__AFI2_REF_CTRL__FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI2_REF_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__AFI2_REF__ENABLE {0} \
    CONFIG.PSU__CRF_APB__AFI3_REF_CTRL__ACT_FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI3_REF_CTRL__DIVISOR0 {2} \
    CONFIG.PSU__CRF_APB__AFI3_REF_CTRL__FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI3_REF_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__AFI3_REF__ENABLE {0} \
    CONFIG.PSU__CRF_APB__AFI4_REF_CTRL__ACT_FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI4_REF_CTRL__DIVISOR0 {2} \
    CONFIG.PSU__CRF_APB__AFI4_REF_CTRL__FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI4_REF_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__AFI4_REF__ENABLE {0} \
    CONFIG.PSU__CRF_APB__AFI5_REF_CTRL__ACT_FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI5_REF_CTRL__DIVISOR0 {2} \
    CONFIG.PSU__CRF_APB__AFI5_REF_CTRL__FREQMHZ {667} \
    CONFIG.PSU__CRF_APB__AFI5_REF_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__AFI5_REF__ENABLE {0} \
    CONFIG.PSU__CRF_APB__APLL_CTRL__FRACFREQ {1333.333} \
    CONFIG.PSU__CRF_APB__APLL_CTRL__SRCSEL {PSS_REF_CLK} \
    CONFIG.PSU__CRF_APB__APLL_FRAC_CFG__ENABLED {1} \
    CONFIG.PSU__CRF_APB__APM_CTRL__ACT_FREQMHZ {1} \
    CONFIG.PSU__CRF_APB__APM_CTRL__DIVISOR0 {1} \
    CONFIG.PSU__CRF_APB__APM_CTRL__FREQMHZ {1} \
    CONFIG.PSU__CRF_APB__DBG_FPD_CTRL__ACT_FREQMHZ {249.997498} \
    CONFIG.PSU__CRF_APB__DBG_FPD_CTRL__FREQMHZ {250} \
    CONFIG.PSU__CRF_APB__DBG_FPD_CTRL__SRCSEL {IOPLL} \
    CONFIG.PSU__CRF_APB__DBG_TRACE_CTRL__ACT_FREQMHZ {250} \
    CONFIG.PSU__CRF_APB__DBG_TRACE_CTRL__FREQMHZ {250} \
    CONFIG.PSU__CRF_APB__DBG_TRACE_CTRL__SRCSEL {IOPLL} \
    CONFIG.PSU__CRF_APB__DBG_TSTMP_CTRL__ACT_FREQMHZ {249.997498} \
    CONFIG.PSU__CRF_APB__DBG_TSTMP_CTRL__FREQMHZ {250} \
    CONFIG.PSU__CRF_APB__DBG_TSTMP_CTRL__SRCSEL {IOPLL} \
    CONFIG.PSU__CRF_APB__DDR_CTRL__ACT_FREQMHZ {533.328003} \
    CONFIG.PSU__CRF_APB__DDR_CTRL__FREQMHZ {1200} \
    CONFIG.PSU__CRF_APB__DDR_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__DPDMA_REF_CTRL__ACT_FREQMHZ {444.444336} \
    CONFIG.PSU__CRF_APB__DPDMA_REF_CTRL__FREQMHZ {600} \
    CONFIG.PSU__CRF_APB__DPDMA_REF_CTRL__SRCSEL {APLL} \
    CONFIG.PSU__CRF_APB__DPLL_CTRL__FRACFREQ {27.138} \
    CONFIG.PSU__CRF_APB__DPLL_CTRL__SRCSEL {PSS_REF_CLK} \
    CONFIG.PSU__CRF_APB__DP_AUDIO_REF_CTRL__ACT_FREQMHZ {24.242182} \
    CONFIG.PSU__CRF_APB__DP_AUDIO_REF_CTRL__FREQMHZ {25} \
    CONFIG.PSU__CRF_APB__DP_AUDIO_REF_CTRL__SRCSEL {RPLL} \
    CONFIG.PSU__CRF_APB__DP_AUDIO__FRAC_ENABLED {0} \
    CONFIG.PSU__CRF_APB__DP_STC_REF_CTRL__ACT_FREQMHZ {26.666401} \
    CONFIG.PSU__CRF_APB__DP_STC_REF_CTRL__FREQMHZ {27} \
    CONFIG.PSU__CRF_APB__DP_STC_REF_CTRL__SRCSEL {RPLL} \
    CONFIG.PSU__CRF_APB__DP_VIDEO_REF_CTRL__ACT_FREQMHZ {299.997009} \
    CONFIG.PSU__CRF_APB__DP_VIDEO_REF_CTRL__FREQMHZ {300} \
    CONFIG.PSU__CRF_APB__DP_VIDEO_REF_CTRL__SRCSEL {VPLL} \
    CONFIG.PSU__CRF_APB__DP_VIDEO__FRAC_ENABLED {0} \
    CONFIG.PSU__CRF_APB__GDMA_REF_CTRL__ACT_FREQMHZ {533.328003} \
    CONFIG.PSU__CRF_APB__GDMA_REF_CTRL__FREQMHZ {600} \
    CONFIG.PSU__CRF_APB__GDMA_REF_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__GPU_REF_CTRL__ACT_FREQMHZ {499.994995} \
    CONFIG.PSU__CRF_APB__GPU_REF_CTRL__FREQMHZ {600} \
    CONFIG.PSU__CRF_APB__GPU_REF_CTRL__SRCSEL {IOPLL} \
    CONFIG.PSU__CRF_APB__GTGREF0_REF_CTRL__ACT_FREQMHZ {-1} \
    CONFIG.PSU__CRF_APB__GTGREF0_REF_CTRL__DIVISOR0 {-1} \
    CONFIG.PSU__CRF_APB__GTGREF0_REF_CTRL__FREQMHZ {-1} \
    CONFIG.PSU__CRF_APB__GTGREF0_REF_CTRL__SRCSEL {NA} \
    CONFIG.PSU__CRF_APB__GTGREF0__ENABLE {NA} \
    CONFIG.PSU__CRF_APB__PCIE_REF_CTRL__ACT_FREQMHZ {250} \
    CONFIG.PSU__CRF_APB__SATA_REF_CTRL__ACT_FREQMHZ {250} \
    CONFIG.PSU__CRF_APB__TOPSW_LSBUS_CTRL__ACT_FREQMHZ {99.999001} \
    CONFIG.PSU__CRF_APB__TOPSW_LSBUS_CTRL__FREQMHZ {100} \
    CONFIG.PSU__CRF_APB__TOPSW_LSBUS_CTRL__SRCSEL {IOPLL} \
    CONFIG.PSU__CRF_APB__TOPSW_MAIN_CTRL__ACT_FREQMHZ {533.328003} \
    CONFIG.PSU__CRF_APB__TOPSW_MAIN_CTRL__FREQMHZ {533.33} \
    CONFIG.PSU__CRF_APB__TOPSW_MAIN_CTRL__SRCSEL {DPLL} \
    CONFIG.PSU__CRF_APB__VPLL_CTRL__FRACFREQ {27.138} \
    CONFIG.PSU__CRF_APB__VPLL_CTRL__SRCSEL {PSS_REF_CLK} \
    CONFIG.PSU__CRL_APB__ADMA_REF_CTRL__ACT_FREQMHZ {499.994995} \
    CONFIG.PSU__CRL_APB__ADMA_REF_CTRL__FREQMHZ {500} \
    CONFIG.PSU__CRL_APB__ADMA_REF_CTRL__SRCSEL {IOPLL} \
    CONFIG.PSU__CRL_APB__AFI6_REF_CTRL__ACT_FREQMHZ {500} \
    CONFIG.PSU__CRL_APB__AFI6_REF_CTRL__FREQMHZ {500} \
    CONFIG.PSU__CRL_APB__AFI6_REF_CTRL__SRCSEL {IOPLL} \
...

This file has been truncated, please download it to see its full contents.
