Blazing Fast YOLOv8 Edge Detection with reComputer&Hailo8-cL

import gi
gi.require_version('Gst', '1.0')
from gi.repository import Gst, GLib
import os
import argparse
import multiprocessing
import numpy as np
import setproctitle
import cv2
import time

import hailo
from hailo_common_funcs import get_numpy_from_buffer, disable_qos
from hailo_rpi_common import get_default_parser, QUEUE, get_caps_from_pad, GStreamerApp, app_callback_class

# -----------------------------------------------------------------------------------------------
# User defined class to be used in the callback function
# -----------------------------------------------------------------------------------------------
# iheritance from the app_callback_class
class user_app_callback_class(app_callback_class):
    def __init__(self):
        super().__init__()
        #self.new_variable = 42 # new variable example

    # def new_function(self): # new function example
    #     return "New function example text"

# Create an instance of the class
user_data = user_app_callback_class()

# -----------------------------------------------------------------------------------------------
# User defined callback function
# -----------------------------------------------------------------------------------------------

# This is the callback function that will be called when data is available from the pipeline
def app_callback(pad, info, user_data):
    # Get the GstBuffer from the probe info
    buffer = info.get_buffer()
    # Check if the buffer is valid
    if buffer is None:
        return Gst.PadProbeReturn.OK

    # using the user_data to count the number of frames
    user_data.increment()
    string_to_print = f"Frame count: {user_data.get_count()}\n"

    # Get the caps from the pad
    format, width, height = get_caps_from_pad(pad)

    # If the user_data.use_frame is set to True, we can get the video frame from the buffer
    frame = None
    if user_data.use_frame and format is not None and width is not None and height is not None:
        # get video frame
        frame = get_numpy_from_buffer(buffer, format, width, height)

    # get the detections from the buffer
    roi = hailo.get_roi_from_buffer(buffer)
    detections = roi.get_objects_typed(hailo.HAILO_DETECTION)

    # parse the detections
    for detection in detections:
        label = detection.get_label()
        bbox = detection.get_bbox()
        confidence = detection.get_confidence()
        if label == "person":
            string_to_print += (f"Detection: {label} {confidence:.2f}\n")
            # Pose estimation landmarks from detection (if available)
            landmarks = detection.get_objects_typed(hailo.HAILO_LANDMARKS)
            if len(landmarks) != 0:
                points = landmarks[0].get_points()
                left_eye = points[1]  # assuming 1 is the index for the left eye
                right_eye = points[2]  # assuming 2 is the index for the right eye
                # The landmarks are normalized to the bounding box, we also need to convert them to the frame size
                left_eye_x = int((left_eye.x() * bbox.width() + bbox.xmin()) * width)
                left_eye_y = int((left_eye.y() * bbox.height() + bbox.ymin()) * height)
                right_eye_x = int((right_eye.x() * bbox.width() + bbox.xmin()) * width)
                right_eye_y = int((right_eye.y() * bbox.height() + bbox.ymin()) * height)
                string_to_print += (f" Left eye: x: {left_eye_x:.2f} y: {left_eye_y:.2f} Right eye: x: {right_eye_x:.2f} y: {right_eye_y:.2f}\n")
                if user_data.use_frame:
                    # Add markers to the frame to show eye landmarks
                    cv2.circle(frame, (left_eye_x, left_eye_y), 5, (0, 255, 0), -1)
                    cv2.circle(frame, (right_eye_x, right_eye_y), 5, (0, 255, 0), -1)
                    # Note: using imshow will not work here, as the callback function is not running in the main thread

    if user_data.use_frame:
        # Convert the frame to BGR
        frame = cv2.cvtColor(frame, cv2.COLOR_RGB2BGR)
        user_data.set_frame(frame)

    print(string_to_print)
    return Gst.PadProbeReturn.OK



# This function can be used to get the COCO keypoints coorespondence map
def get_keypoints():
    """Get the COCO keypoints and their left/right flip coorespondence map."""
    keypoints = {
        'nose': 1,
        'left_eye': 2,
        'right_eye': 3,
        'left_ear': 4,
        'right_ear': 5,
        'left_shoulder': 6,
        'right_shoulder': 7,
        'left_elbow': 8,
        'right_elbow': 9,
        'left_wrist': 10,
        'right_wrist': 11,
        'left_hip': 12,
        'right_hip': 13,
        'left_knee': 14,
        'right_knee': 15,
        'left_ankle': 16,
        'right_ankle': 17,
    }

    return keypoints
#-----------------------------------------------------------------------------------------------
# User Gstreamer Application
# -----------------------------------------------------------------------------------------------

# This class inherits from the hailo_rpi_common.GStreamerApp class

class GStreamerDetectionApp(GStreamerApp):
    def __init__(self, args, user_data):
        super().__init__(args, user_data)

        # Force USB Camera mode (Wed Camera /dev/video0)
        self.source_type = "usb"
        self.video_source = "/dev/video0"

        self.batch_size = 2
        self.network_width = 640
        self.network_height = 640
        self.network_format = "RGB"
        self.default_postprocess_so = os.path.join(self.postprocess_dir, 'libyolo_hailortpp_post.so')

        if args.network == "yolov6n":
            self.hef_path = os.path.join(self.current_path, './hailomodel/yolov6n.hef')
        elif args.network == "yolov8s":
            self.hef_path = os.path.join(self.current_path, './hailomodel/yolov8s_h8l.hef')
        elif args.network == "yolox_s_leaky":
            self.hef_path = os.path.join(self.current_path, './hailomodel/yolox_s_leaky_h8l_mz.hef')
        else:
            assert False, "Invalid network type"

        self.app_callback = app_callback

        nms_score_threshold = 0.3
        nms_iou_threshold = 0.45
        self.thresholds_str = f"nms-score-threshold={nms_score_threshold} nms-iou-threshold={nms_iou_threshold} output-format-type=HAILO_FORMAT_TYPE_FLOAT32"

        setproctitle.setproctitle("Hailo Detection App")
        self.create_pipeline()


    def get_pipeline_string(self):
        if (self.source_type == "rpi"):
            source_element = f"libcamerasrc name=src_0 auto-focus-mode=2 ! "
            source_element += f"video/x-raw, format={self.network_format}, width=1536, height=864 ! "
            source_element += QUEUE("queue_src_scale")
            source_element += f"videoscale ! "
            source_element += f"video/x-raw, format={self.network_format}, width={self.network_width}, height={self.network_height}, framerate=30/1 ! "

        elif (self.source_type == "usb"):
            source_element = f"v4l2src device={self.video_source} name=src_0 ! "
            source_element += f"video/x-raw, width=640, height=480, framerate=30/1 ! "
        else:
            source_element = f"filesrc location={self.video_source} name=src_0 ! "
            source_element += QUEUE("queue_dec264")
            source_element += f" qtdemux ! h264parse ! avdec_h264 max-threads=2 ! "
            source_element += f" video/x-raw,format=I420 ! "
        source_element += QUEUE("queue_scale")
        source_element += f" videoscale n-threads=2 ! "
        source_element += QUEUE("queue_src_convert")
        source_element += f" videoconvert n-threads=3 name=src_convert qos=false ! "
        source_element += f"video/x-raw, format={self.network_format}, width={self.network_width}, height={self.network_height}, pixel-aspect-ratio=1/1 ! "


        pipeline_string = "hailomuxer name=hmux "
        pipeline_string += source_element
        pipeline_string += "tee name=t ! "
        pipeline_string += QUEUE("bypass_queue", max_size_buffers=20) + "hmux.sink_0 "
        pipeline_string += "t. ! " + QUEUE("queue_hailonet")
        pipeline_string += "videoconvert n-threads=3 ! "
        pipeline_string += f"hailonet hef-path={self.hef_path} batch-size={self.batch_size} force-writable=true ! "
        pipeline_string += QUEUE("queue_hailofilter")
        pipeline_string += f"hailofilter function-name={self.post_function_name} so-path={self.default_postprocess_so} qos=false ! "
        pipeline_string += QUEUE("queue_hmuc") + " hmux.sink_1 "
        pipeline_string += "hmux. ! " + QUEUE("queue_hailo_python")
        pipeline_string += QUEUE("queue_user_callback")
        pipeline_string += f"identity name=identity_callback ! "
        pipeline_string += QUEUE("queue_hailooverlay")
        pipeline_string += f"hailooverlay ! "
        pipeline_string += QUEUE("queue_videoconvert")
        pipeline_string += f"videoconvert n-threads=3 qos=false ! "
        pipeline_string += QUEUE("queue_hailo_display")
        pipeline_string += f"fpsdisplaysink video-sink=ximagesink name=hailo_display sync={self.sync} text-overlay={self.options_menu.show_fps} signal-fps-measurements=true "
        print(pipeline_string)
        return pipeline_string

if __name__ == "__main__":
    parser = get_default_parser()
    args = parser.parse_args()
    app = GStreamerPoseEstimationApp(args, user_data)

    begin = time.time()
    app.run()
    end = time.time()
    print( "Total time: ", 727/ (end - begin))
