Send Events from an ESP8266 to Wia

Hi All, Today we're going to look at sending data from an ESP8266 to Wia. This ESP8266 IoT demo will go through all the steps required to go from scratch all the way to publishing your own events and locations. Let's get started!

Create Your Wia Account

If you haven't already got one, click here to sign up.

Setup a Space

Once logged in, setup a new Space for your devices. I'm going to call mine 'My Devices'. When your Space is ready, you should see a screen like the one below.

Create a Device

Create a new Device by entering it's name in the panel. You will then be redirected to the Device Overview page. Here you will see the Device's secret key (it should start with d_sk ). Keep note of this, we're going to use it later.

Connecting to the Board

Note: If your board has a micro USB port, you can probably skip this step.

Connect your board to laptop/desktop via a USB to TTL cable/adapter. Here's a pinout showing the different connections.

Connections should be like this:

• ESP8266 ESP-01 <–> USB TTL

• GND - GND

• TX - RX

• RX - TX

• VCC - 3.3V (+)

• CH_PD - 3.3V (+)

• GPIO0 - GND (While flashing board)

Note: You may need to install FTDI drivers to make your device appear. Check with the manufacturer of your adapter for the latest versions. If you get stuck here, tweet us for support.

Setup Your Environment

Enter http://arduino.esp8266.com/stable/package_esp8266com_index.json into the Additional Board Manager URLs. If you need more than one, they can be separated with commas.

• Install the Arduino IDE. You can download it for Mac OS X, Windows and Linux here.

• Start the Arduino application and open Preferences.

Search for 'esp8266'. When found, click Install.

• Go to Tools > Board > Boards Manager.

Select your ESPP8266 board type by going to Tools > Board, then choosing your type. For this example I am using 'NodeMCU 1.0 (ESP-12E Module).

• Note: Check that Upload Speed is set to 115200 and the correct Port is selected.

Create the Sketch

• Click on File > New to create a new Sketch.

• Copy and paste the Publish Event example code below. You can also view it on GitHub here. In that directly you will see how to publish both Events and Locations.

/**
 * PublishEvent.ino
 *
 *  Created on: 09.01.2017
 *
 */
#include <Arduino.h>
#include <ESP8266WiFi.h>
#include <ESP8266WiFiMulti.h>
#include <ESP8266HTTPClient.h>
#define USE_SERIAL Serial
ESP8266WiFiMulti WiFiMulti;
const char* ssid     = "your-ssid";
const char* password = "your-password";
// get this from the wia dashboard. it should start with `d_sk`
const char* device_secret_key = "your-device-secret-key";
void setup() {
    USE_SERIAL.begin(115200);
    //USE_SERIAL.setDebugOutput(true);
    WiFi.mode(WIFI_STA);
    WiFiMulti.addAP(ssid, password);
}
void loop() {
    // wait for WiFi connection
    if((WiFiMulti.run() == WL_CONNECTED)) {
        HTTPClient http;
        USE_SERIAL.print("[HTTP] begin...\n");
        // configure wia rest api
        http.begin("http://api.wia.io/v1/events");
        USE_SERIAL.print("[HTTP] POST...\n");
        // set authorization token
        http.addHeader("Authorization", "Bearer " + String(device_secret_key));
        // set content-type to json
        http.addHeader("Content-Type", "application/json");
        // start connection and send HTTP headers. replace latitude and longitude with your gps coordinates
        int httpCode = http.POST("{\"name\":\"temperature\",\"data\":21.5}");
        // httpCode will be negative on error
        if(httpCode > 0) {
            // HTTP header has been send and Server response header has been handled
            USE_SERIAL.printf("[HTTP] POST... code: %d\n", httpCode);
            // file found at server
            if(httpCode == HTTP_CODE_OK) {
                String payload = http.getString();
                USE_SERIAL.println(payload);
            }
        } else {
            USE_SERIAL.printf("[HTTP] POST... failed, error: %s\n", http.errorToString(httpCode).c_str());
        }
        http.end();
    }
    delay(10000);
}

Replace the following values of the following variables:

• 'ssid' with your WiFi network name.

• 'password' with your WiFi network password.

• 'device_secret_key' with your device secret key from earlier (the one that begins with d_sk ).

Verify/Compile the code. If it runs correctly then go to Sketch > Upload to send it to your ESP8266.

That's it folks!

If you need any help with getting setup, tweet us or email support@wia.io
