How to Make a Location Tracker App

Build a real-time location tracker using Wia

Stream location data to the Wia Cloud Platform and subsequently display real-time location in an iPhone Application using the Wia iOS SDK. The project also comes with some simple project files to get you started.

Project Requirements

• Node.js and NPM must be installed. How to install Node.js on a Raspberry Pi.

• Raspberry Pi 2 or 3 Model B.

• A Wia account. You can create one for free here.

• Google Maps SDK must be installed.

Setting up the Wia Node.js SDK

• First thing you will want to do is to create a folder on your location device. Let's call it wia-location-device .

• Go into the folder and initialise the project by creating a package.json file using the command "npm init " (use defaults for everything).

• Install the Wia SDK using the command "npm install --save wia ".

• Your package.json file should look something like the code below.

{
    "name": "wia-location-device",
    "version": "1.0.0",
    "description": "",
    "main": "index.js",
    "scripts": {
        "test": "echo \"Error: no test specified\" && exit 1"
    },
    "author": "Your Name Here",
    "license": "ISC",
    "dependencies": {
        "wia": "^1.3.3"
    }
}

Creating your Location Tracking Device

• Go to the Wia dashboard and select Devices.

• From here, click on the + symbol and the Add New Device modal will appear.

• Enter 'Location Device ' as the name and click Add Device.

• Click on View device to go to the device's overview page.

Take a note of the device's secret key, we'll need this later.

Write code for the location tracking device

• We need to create a file for our program, let's call it index.js

• Copy the code from the example below add to the index.js file.

• Replace the device-secret-key on line 3 with your device's secret key that you made a note of earlier.

• Now to test that you have done your setup correctly, simply run node index.js

• Your device should have updated in the dashboard under the Location tab, with your sensor readings. You can also view in in real-time in the Debugger tab.

'use strict'
var wia = require('wia')('device secret key');
// collection of cities
var cities = [{"city":"Dublin","lat":53.349805,"lng":-6.260310},
            {"city":"London","lat":51.5013673,"lng":-0.1440787},
            {"city":"Paris","lat":48.8922431,"lng":2.2380753},
            {"city":"Toronto","lat":43.6426731,"lng":-79.3928402}];
// Using the MQTT stream
wia.stream.on('connect', function() {
console.log('Stream connected!');
// randomly choosing city location to publish
var random = Math.floor(Math.random() * 4);
var randomcity = cities[random];
// value to increment position
var diff = 0.0005;
// setting the interval at which to publish location i.e. every second
setInterval(function() {
  // function to publish location data
  wia.locations.publish(
      {
        "latitude": randomcity.lat + diff,
        "longitude": randomcity.lng + diff,
        "altitude": 2
      },
      function(err, published) {
          if (err) console.log(err);
          if (published) console.log("Location published.");
      }
  );
  diff += 0.0005;
}, 3500);
});
wia.stream.connect();

NOTE: You can replace the values of the 'randomcity' variable with values from a GPS module or any other location tracking modules.

Creating our iOS app

Before we get started, make sure you have the latest version of Xcode.

• Open Xcode and go to File > New > Project.

• Choose iOS > Single Page Application and click Next.

• Give it the product name "location-tracker-app ".

• Make sure that the language selected is Objective-C and the devices is set to iPhone.

• Uncheck Use Core Data, Include Unit Tests, and Include UI Tests checkboxes and click Next.

• Choose the repository where you want to create the project (Remember this repository location for later) and click Create.

Installing the Google Maps & Wia SDKs

• If you don't already have the CocoaPods tool, install it on macOS by running the command "sudo gem install cocoapods" from the terminal. For details, see the CocoaPods Getting Started guide.

• Next, navigate to your project directory in your terminal and run the command "nano Podfile".

• Insert code from the attached Podfile, and save the file.

• Next, run the command "pod install".

Get your Google Maps API key

• Go to the Google API Console.

• Create or select a project.

• Click Continue to enable the Google Maps SDK for iOS.

• On the Credentials page, get an API key. Note: If you have a key with iOS restrictions, you may use that key. You can use the same key with any of your iOS applications within the same project.

• From the dialog displaying the API key, select Restrict key to set an iOS restriction on the API key.

• In the Restrictions section, select iOS apps, then enter your app's bundle identifier.

• Click Save.

• Your new iOS-restricted API key appears in the list of API keys for your project.

Add your Google Maps API key

• Go to the AppDelegate.m file and add the following code "@import GoogleMaps;" to the header of the file.

• Add the following to your application's didFinishLaunchingWithOptions method, replacing YOUR_API_KEY with your API key: [GMSServices provideAPIKey:@"YOUR_API_KEY"];

Update your Info.plist file

To declare the URL schemes used by the Google Maps SDK for iOS, add the following lines to your Info.plist:

<key>LSApplicationQueriesSchemes</key>
<array>
    <string>googlechromes</string>
    <string>comgooglemaps</string>
</array>

OR

Add them through the Xcode interface.

Writing the location tracking code

• Update your AppDelegate.m code with the code below, replacing the "maps api key" with your Google Maps API key.


#import "AppDelegate.h"
@import GoogleMaps;
@interface AppDelegate ()
@end
@implementation AppDelegate
- (BOOL)application:(UIApplication *)application didFinishLaunchingWithOptions:(NSDictionary *)launchOptions {
// Override point for customization after application launch.
[GMSServices provideAPIKey:@"maps api key"];
return YES;
}
@end

• Update your ViewController.h file to match the code below.

#import <UIKit/UIKit.h>
#import "Wia.h"
#import <GoogleMaps/GoogleMaps.h>
@interface ViewController : UIViewController <WiaClientDelegate>
@end

• Next, update your ViewController.m file match the code below.

#import "ViewController.h"
#import <GoogleMaps/GoogleMaps.h>
@interface ViewController ()
@property GMSMapView *mapView;
@property GMSCameraPosition *camera;
@property GMSMarker *marker;
@end
@implementation ViewController
- (void)viewDidLoad {
[super viewDidLoad];
[WiaClient debug:YES];
[[WiaClient sharedInstance] setDelegate:self];
[[WiaClient sharedInstance] initWithToken:@"Your user secret key"];
[[NSNotificationCenter defaultCenter] addObserverForName:@"WiaStreamConnect" object:nil queue:nil usingBlock:^(NSNotification * _Nonnull note) {
NSLog(@"CONNECTED TO STREAM");
[[WiaClient sharedInstance] subscribeToLocations:@{@"device": @"Your device id"}];
}];
[[WiaClient sharedInstance] connectToStream];
self.camera = [GMSCameraPosition cameraWithLatitude:0.000000
longitude:0.000000
zoom:16];
self.mapView = [GMSMapView mapWithFrame:CGRectZero camera:self.camera];
self.mapView.myLocationEnabled = YES;
self.view = self.mapView;
// Creates a marker in the center of the map.
self.marker = [[GMSMarker alloc] init];
self.marker.title = @"Location Device";
self.marker.map = self.mapView;
}
- (void)newLocation:(WiaLocation *)location {
CLLocationCoordinate2D coordinates;
coordinates.latitude = [location.latitude doubleValue];
coordinates.longitude = [location.longitude doubleValue];
GMSCameraUpdate *updatedCamera = [GMSCameraUpdate setTarget:coordinates zoom:13];
[self.mapView animateWithCameraUpdate:updatedCamera];
self.marker.position = CLLocationCoordinate2DMake([location.latitude doubleValue], [location.longitude doubleValue]);
}
@end

• Replace the "Your user secret key" placeholder with your user secret key which can be located in the Wia Dashboard in the My account > Security tab.

• Replace the Your device id placeholder with the device id of your device from the dashboard which can be found in the Device > Settings tab.

• Now, simply build your project and it should run smoothly.

Congratulations

You just build a location tracker app!
