vincent wong
Published © GPL3+

SmartQ Notification with Azure IOT Hub and Virtual Shields

Waiting hours in queue is history, SmarQ will update you the current queue status and alarm you when it is almost your turn to be served.

IntermediateShowcase (no instructions)2,758
SmartQ Notification with Azure IOT Hub and Virtual Shields

Things used in this project

Hardware components

Arduino MKR1000
Arduino MKR1000
×1
USB-A to Micro-USB Cable
USB-A to Micro-USB Cable
×1
HC-06 Bluetooth Module
×1

Software apps and online services

Arduino IDE
Arduino IDE
Visual Studio 2015
Microsoft Visual Studio 2015
Microsoft Azure
Microsoft Azure
Microsoft Windows Virtual Shields for Arduino
Microsoft Azure IoT Hub
Microsoft Notification Hubs

Hand tools and fabrication machines

Soldering iron (generic)
Soldering iron (generic)

Story

Read more

Schematics

Smart Queue Breadboard

Smart Queue Schematics

Code

MKR1000SmartQueueSpeech

C/C++
MKR1000 sketch
#include <ArduinoJson.h>

#include <VirtualShield.h>
#include <Text.h>
#include <Speech.h>
#include <Recognition.h>

#include <SPI.h>
#include <WiFi101.h>


VirtualShield shield;	          // identify the shield
Text screen = Text(shield);	  // connect the screen
Speech speech = Speech(shield);	  // connect text to speech
Recognition recognition = Recognition(shield);	  // connect speech to text

int queueNum = 0;

int LED_PIN = 8;

///*** WiFi Network Config ***///
char ssid[] = "yourNetwork"; //  your network SSID (name)
char pass[] = "secretPassword";    // your network password (use for WPA, or use as key for WEP)

///*** Azure IoT Hub Config ***///
//see: http://mohanp.com/  for details on getting this right if you are not sure.

char hostname[] = "YourIoTHubName.azure-devices.net";    // host name address for your Azure IoT Hub
char feeduri[] = "/devices/SmartQueueMKR1000/messages/events?api-version=2016-02-03"; //feed URI
char authSAS[] = "YourSharedAccessKey";

///*** Azure IoT Hub Config ***///

int status = WL_IDLE_STATUS;

WiFiSSLClient client;

String message;

void recognitionEvent(ShieldEvent* event)
{
  if (event->resultId > 0) {
  	digitalWrite(LED_PIN, recognition.recognizedIndex == 1 ? HIGH : LOW);
    screen.printAt(6, "Heard " + String(recognition.recognizedIndex == 1 ? "next" : "stop"));

    if (recognition.recognizedIndex == 1) {
      queueNum++;
      message =  "Currently serving queue #" + String(queueNum);
      screen.printAt(8, message);

      azureHttpRequest(message);
      //Serial.println();
      //Serial.println(message);
    }

  	recognition.listenFor("next,stop", false);	    // reset up the recognition after each event
  }
}

// when Bluetooth connects, or the 'Refresh' button is pressed
void refresh(ShieldEvent* event)
{
  // String message = "Hello Virtual Shields. Say the word 'on' or 'off' to affect the LED";
  String message = "Hello. Say the word 'next' to serve the next queue number.";

	screen.clear();
	screen.print(message);
  speech.speak(message);

	recognition.listenFor("next,stop", false);	// NON-blocking instruction to recognize speech
}

void setup()
{
	pinMode(LED_PIN, OUTPUT);
	pinMode(LED_PIN, LOW);

  //check for the presence of the shield:
  if (WiFi.status() == WL_NO_SHIELD) {
    // don't continue:
    while (true);
  }

  // attempt to connect to Wifi network:
  while (status != WL_CONNECTED) {
    status = WiFi.begin(ssid, pass);
    // wait 10 seconds for connection:
    delay(10000);
  }

  // set up a function to handle recognition events (turns auto-blocking off)
	recognition.setOnEvent(recognitionEvent);
  shield.setOnRefresh(refresh);

  // begin() communication - you may specify a baud rate here, default is 115200
	shield.begin(9600);

  randomSeed(analogRead(0));
}

void loop()
{
  String response = "";
  char c;
  ///read response if WiFi Client is available
  while (client.available()) {
    c = client.read();
    response.concat(c);
  }

	shield.checkSensors();		    // handles Virtual Shield events.
}

// this method makes an HTTPS connection to the Azure IOT Hub Server:
void azureHttpRequest(String content) {

  // close any connection before send a new request.
  // This will free the socket on the WiFi shield
  client.stop();

  String messageId = String(random(300)) + String(millis());
  //Serial.println();
  //Serial.println(messageId);

  String contentType = "text/plain";
  String accept = "application/json";

  // if there's a successful connection:
  if (client.connect(hostname, 443)) {
    //make the GET request to the Azure IOT device feed uri
    client.print("POST ");  //Do a POST
    client.print(feeduri);  // On the feedURI
    client.println(" HTTP/1.1");
    client.print("Host: ");
    client.println(hostname);  //with hostname header
    // client.print("Accept: ");  // On the feedURI
    // client.println(accept);
    client.print("Authorization: ");
    client.println(authSAS);  //Authorization SAS token obtained from Azure IoT device explorer
    client.print("IoTHub-MessageId: ");
    client.println(messageId);
    client.println("Connection: close");
    client.print("IoTHub-app-messageType: ");
    client.println("interactive");

    client.print("Content-Type: ");
    client.println(contentType);
    client.print("Content-Length: ");
    client.println(content.length());
    client.println();
    client.println(content);

    client.println();

  }
  else {
    // if you couldn't make a connection:
    Serial.println();
    Serial.println("connection failed");
  }

}

MainPage.xaml

XML
MainPage.xaml of SmartQueueUniversalWindows app
<Page
    x:Class="SmartQueueUniversalWindows.MainPage"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:local="using:SmartQueueUniversalWindows"
    xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
    xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
    mc:Ignorable="d">

    <Grid Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
        <Image Source="Assets/StoreLogo.png" VerticalAlignment="Bottom" Margin="0,0,0,10" Height="50" Width="50"/>
        <TextBlock x:Name="textBlock" HorizontalAlignment="Left" Margin="10,10,10,10" TextWrapping="Wrap" Text="Waiting hours in queue for your turn to be attended is a waste of time.  SmartQ allows you to take a queue number with a press of button.   You can go away for a while to do other business in the middle of the waiting.  SmartQ will update you the current queue status and alarm you when it is almost your turn to be served." VerticalAlignment="Top" FontSize="20"/>
    </Grid>
</Page>

App.xaml.cs

C#
App.xaml.cs of SmartQueueUniversalWindows app
using System;
using System.Collections.Generic;
using System.IO;
using System.Linq;
using System.Runtime.InteropServices.WindowsRuntime;
using Windows.ApplicationModel;
using Windows.ApplicationModel.Activation;
using Windows.Foundation;
using Windows.Foundation.Collections;
using Windows.UI.Xaml;
using Windows.UI.Xaml.Controls;
using Windows.UI.Xaml.Controls.Primitives;
using Windows.UI.Xaml.Data;
using Windows.UI.Xaml.Input;
using Windows.UI.Xaml.Media;
using Windows.UI.Xaml.Navigation;

using Windows.Networking.PushNotifications;
using Microsoft.WindowsAzure.Messaging;
using Windows.UI.Popups;

namespace SmartQueueUniversalWindows
{
    /// <summary>
    /// Provides application-specific behavior to supplement the default Application class.
    /// </summary>
    sealed partial class App : Application
    {
        /// <summary>
        /// Initializes the singleton application object.  This is the first line of authored code
        /// executed, and as such is the logical equivalent of main() or WinMain().
        /// </summary>
        public App()
        {
            Microsoft.ApplicationInsights.WindowsAppInitializer.InitializeAsync(
                Microsoft.ApplicationInsights.WindowsCollectors.Metadata |
                Microsoft.ApplicationInsights.WindowsCollectors.Session);
            this.InitializeComponent();
            this.Suspending += OnSuspending;
        }

        /// <summary>
        /// Invoked when the application is launched normally by the end user.  Other entry points
        /// will be used such as when the application is launched to open a specific file.
        /// </summary>
        /// <param name="e">Details about the launch request and process.</param>
        protected override void OnLaunched(LaunchActivatedEventArgs e)
        {

#if DEBUG
            if (System.Diagnostics.Debugger.IsAttached)
            {
                this.DebugSettings.EnableFrameRateCounter = true;
            }
#endif

            Frame rootFrame = Window.Current.Content as Frame;

            // Do not repeat app initialization when the Window already has content,
            // just ensure that the window is active
            if (rootFrame == null)
            {
                // Create a Frame to act as the navigation context and navigate to the first page
                rootFrame = new Frame();

                rootFrame.NavigationFailed += OnNavigationFailed;

                if (e.PreviousExecutionState == ApplicationExecutionState.Terminated)
                {
                    //TODO: Load state from previously suspended application
                }

                // Place the frame in the current Window
                Window.Current.Content = rootFrame;
            }

            if (rootFrame.Content == null)
            {
                // When the navigation stack isn't restored navigate to the first page,
                // configuring the new page by passing required information as a navigation
                // parameter
                rootFrame.Navigate(typeof(MainPage), e.Arguments);
            }
            // Ensure the current window is active
            Window.Current.Activate();

            InitNotificationsAsync();
        }

        /// <summary>
        /// Invoked when Navigation to a certain page fails
        /// </summary>
        /// <param name="sender">The Frame which failed navigation</param>
        /// <param name="e">Details about the navigation failure</param>
        void OnNavigationFailed(object sender, NavigationFailedEventArgs e)
        {
            throw new Exception("Failed to load Page " + e.SourcePageType.FullName);
        }

        /// <summary>
        /// Invoked when application execution is being suspended.  Application state is saved
        /// without knowing whether the application will be terminated or resumed with the contents
        /// of memory still intact.
        /// </summary>
        /// <param name="sender">The source of the suspend request.</param>
        /// <param name="e">Details about the suspend request.</param>
        private void OnSuspending(object sender, SuspendingEventArgs e)
        {
            var deferral = e.SuspendingOperation.GetDeferral();
            //TODO: Save application state and stop any background activity
            deferral.Complete();
        }

        private async void InitNotificationsAsync()
        {
            var channel = await PushNotificationChannelManager.CreatePushNotificationChannelForApplicationAsync();

            var hub = new NotificationHub("<hub name>", "<connection string with listen access>");
            var result = await hub.RegisterNativeAsync(channel.Uri);

            // Displays the registration ID so you know it was successful
            if (result.RegistrationId != null)
            {
                // var dialog = new MessageDialog("Registration successful: " + result.RegistrationId);
                var dialog = new MessageDialog("Registration successful");
                dialog.Commands.Add(new UICommand("OK"));
                await dialog.ShowAsync();
            }

        }
    }
}

StoreEventProcessor.cs

C#
StoreEventProcessor.cs of ProcessDeviceToCloudMessages app
using System.IO;
using System.Diagnostics;
using System.Security.Cryptography;
using Microsoft.ServiceBus.Messaging;
using Microsoft.WindowsAzure.Storage;
using Microsoft.WindowsAzure.Storage.Blob;
using System.Threading.Tasks;
using System;
using System.Text;
using System.Collections.Generic;
using System.Linq;

namespace ProcessDeviceToCloudMessages
{
    class StoreEventProcessor : IEventProcessor
    {
        private const int MAX_BLOCK_SIZE = 1024;   // 4 * 1024 * 1024;
        public static string StorageConnectionString;
        public static string ServiceBusConnectionString;

        private CloudBlobClient blobClient;
        private CloudBlobContainer blobContainer;
        private QueueClient queueClient;

        private long currentBlockInitOffset;
        private MemoryStream toAppend = new MemoryStream(MAX_BLOCK_SIZE);

        private Stopwatch stopwatch;
        private TimeSpan MAX_CHECKPOINT_TIME = TimeSpan.FromSeconds(3);

        public StoreEventProcessor()
        {
            var storageAccount = CloudStorageAccount.Parse(StorageConnectionString);
            blobClient = storageAccount.CreateCloudBlobClient();
            blobContainer = blobClient.GetContainerReference("d2ctutorial");
            blobContainer.CreateIfNotExists();
            queueClient = QueueClient.CreateFromConnectionString(ServiceBusConnectionString, "d2ctutorial");
        }

        Task IEventProcessor.CloseAsync(PartitionContext context, CloseReason reason)
        {
            Console.WriteLine("Processor Shutting Down. Partition '{0}', Reason: '{1}'.", context.Lease.PartitionId, reason);
            return Task.FromResult<object>(null);
        }

        Task IEventProcessor.OpenAsync(PartitionContext context)
        {
            Console.WriteLine("StoreEventProcessor initialized.  Partition: '{0}', Offset: '{1}'", context.Lease.PartitionId, context.Lease.Offset);

            if (!long.TryParse(context.Lease.Offset, out currentBlockInitOffset))
            {
                currentBlockInitOffset = 0;
            }
            stopwatch = new Stopwatch();
            stopwatch.Start();

            return Task.FromResult<object>(null);
        }

        async Task IEventProcessor.ProcessEventsAsync(PartitionContext context, IEnumerable<EventData> messages)
        {
            foreach (EventData eventData in messages)
            {
                byte[] data = eventData.GetBytes();

                if (eventData.Properties.ContainsKey("messageType") && (string)eventData.Properties["messageType"] == "interactive")
                {
                    var messageId = (string)eventData.SystemProperties["message-id"];

                    var queueMessage = new BrokeredMessage(new MemoryStream(data));
                    queueMessage.MessageId = messageId;
                    queueMessage.Properties["messageType"] = "interactive";
                    await queueClient.SendAsync(queueMessage);

                    WriteHighlightedMessage(string.Format("Received interactive message: {0}", messageId));
                    continue;
                }

                if (toAppend.Length + data.Length > MAX_BLOCK_SIZE || stopwatch.Elapsed > MAX_CHECKPOINT_TIME)
                {
                    await AppendAndCheckpoint(context);
                }
                await toAppend.WriteAsync(data, 0, data.Length);

                Console.WriteLine(string.Format("Message received.  Partition: '{0}', Data: '{1}'",
                  context.Lease.PartitionId, Encoding.UTF8.GetString(data)));
            }
        }

        private async Task AppendAndCheckpoint(PartitionContext context)
        {
            var blockIdString = String.Format("startSeq:{0}", currentBlockInitOffset.ToString("0000000000000000000000000"));
            var blockId = Convert.ToBase64String(ASCIIEncoding.ASCII.GetBytes(blockIdString));
            toAppend.Seek(0, SeekOrigin.Begin);
            byte[] md5 = MD5.Create().ComputeHash(toAppend);
            toAppend.Seek(0, SeekOrigin.Begin);

            var blobName = String.Format("iothubd2c_{0}", context.Lease.PartitionId);
            var currentBlob = blobContainer.GetBlockBlobReference(blobName);

            if (await currentBlob.ExistsAsync())
            {
                await currentBlob.PutBlockAsync(blockId, toAppend, Convert.ToBase64String(md5));
                var blockList = await currentBlob.DownloadBlockListAsync();
                var newBlockList = new List<string>(blockList.Select(b => b.Name));

                if (newBlockList.Count() > 0 && newBlockList.Last() != blockId)
                {
                    newBlockList.Add(blockId);
                    WriteHighlightedMessage(String.Format("Appending block id: {0} to blob: {1}", blockIdString, currentBlob.Name));
                }
                else
                {
                    WriteHighlightedMessage(String.Format("Overwriting block id: {0}", blockIdString));
                }
                await currentBlob.PutBlockListAsync(newBlockList);
            }
            else
            {
                await currentBlob.PutBlockAsync(blockId, toAppend, Convert.ToBase64String(md5));
                var newBlockList = new List<string>();
                newBlockList.Add(blockId);
                await currentBlob.PutBlockListAsync(newBlockList);

                WriteHighlightedMessage(String.Format("Created new blob", currentBlob.Name));
            }

            toAppend.Dispose();
            toAppend = new MemoryStream(MAX_BLOCK_SIZE);

            // checkpoint.
            await context.CheckpointAsync();
            WriteHighlightedMessage(String.Format("Checkpointed partition: {0}", context.Lease.PartitionId));

            currentBlockInitOffset = long.Parse(context.Lease.Offset);
            stopwatch.Restart();
        }

        private void WriteHighlightedMessage(string message)
        {
            Console.ForegroundColor = ConsoleColor.Yellow;
            Console.WriteLine(message);
            Console.ResetColor();
        }
    }
}

Program.cs

C#
program.cs of ProcessDeviceToCloudMessages app
using Microsoft.ServiceBus.Messaging;
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;

namespace ProcessDeviceToCloudMessages
{
    class Program
    {
        static void Main(string[] args)
        {
            string iotHubConnectionString = "{iot hub connection string}";
            string iotHubD2cEndpoint = "messages/events";
            StoreEventProcessor.StorageConnectionString = "{storage connection string}";
            StoreEventProcessor.ServiceBusConnectionString = "{service bus send connection string}";

            string eventProcessorHostName = Guid.NewGuid().ToString();
            EventProcessorHost eventProcessorHost = new EventProcessorHost(eventProcessorHostName, iotHubD2cEndpoint, EventHubConsumerGroup.DefaultGroupName, iotHubConnectionString, StoreEventProcessor.StorageConnectionString, "messages-events");
            Console.WriteLine("Registering EventProcessor...");
            eventProcessorHost.RegisterEventProcessorAsync<StoreEventProcessor>().Wait();

            Console.WriteLine("Receiving. Press enter key to stop worker.");
            Console.ReadLine();
            eventProcessorHost.UnregisterEventProcessorAsync().Wait();
        }
    }
}

Program.cs

C#
Program.cs of ProcessD2CInteractiveMessages app
using Microsoft.Azure.NotificationHubs;
using Microsoft.ServiceBus.Messaging;
using System;
using System.Collections.Generic;
using System.IO;
using System.Linq;
using System.Text;
using System.Threading.Tasks;

namespace ProcessD2CInteractiveMessages
{
    class Program
    {
        static void Main(string[] args)
        {
            Console.WriteLine("Process D2C Interactive Messages app\n");

            string connectionString = "{service bus listen connection string}";
            QueueClient Client = QueueClient.CreateFromConnectionString(connectionString, "d2ctutorial");

            OnMessageOptions options = new OnMessageOptions();
            options.AutoComplete = false;
            options.AutoRenewTimeout = TimeSpan.FromMinutes(1);

            Client.OnMessage((message) =>
            {
                try
                {
                    var bodyStream = message.GetBody<Stream>();
                    bodyStream.Position = 0;
                    var bodyAsString = new StreamReader(bodyStream, Encoding.ASCII).ReadToEnd();

                    Console.WriteLine("Received message: {0} messageId: {1}", bodyAsString, message.MessageId);
                    SendNotificationAsync(bodyAsString);

                    message.Complete();
                }
                catch (Exception)
                {
                    Console.WriteLine("Message abandon!");
                    message.Abandon();
                }
            }, options);

            Console.WriteLine("Receiving interactive messages from SB queue...");
            Console.WriteLine("Press any key to exit.");
            Console.ReadLine();
        }

        private static async void SendNotificationAsync(String notification)
        {
            NotificationHubClient hub = NotificationHubClient
                .CreateClientFromConnectionString("<connection string with full access>", "<hub name>");
            var toast = @"<toast><visual><binding template=""ToastText01""><text id=""1"">" + notification + "</text></binding></visual></toast>";
            await hub.SendWindowsNativeNotificationAsync(toast);
        }
    }
}

Credits

vincent wong

vincent wong

80 projects • 202 followers

Comments
