A robotic arm is a type of mechanical arm, usually programmable, that is designed to move materials, parts, tools, or specialized devices through various types of programmed motions for the purpose of manufacturing, assembly, testing, inspection, and other tasks. Robotic arms are widely used in a variety of industries, including automotive, aerospace, electronics, food processing, and pharmaceuticals.
One of the main advantages of using a robotic arm is its ability to perform tasks with a high degree of accuracy and repeatability. This makes them well-suited for tasks that require precise movements, such as welding, painting, and packaging. In addition, robotic arms can work continuously for long periods of time without getting tired or making mistakes, which makes them an ideal choice for tasks that are too hazardous or tedious for humans to perform.
There are several different types of robotic arms, each with its own unique set of features and capabilities. The most common type is the articulated arm, which is made up of a series of interconnected joints that allow the arm to move in a wide range of directions. Other types of robotic arms include parallel arms, which are designed for high-speed movement, and cylindrical arms, which are best suited for tasks that require precise rotational movements.
So in this tutorial we are going to make and assemble the first type of robotic arm which we can control with the help of joystick and take make it move in various directions. Let’s build our robotic arm!
Components requiredRobotic Arm Kit
Mini USB cable.
alkaline batteries
Mini cross screwdriver.
USB –A to micro-USB cable
Dual Axis XY Joystick Module
- Software Required
- Arduino IDE
Part number included: 3, 4, 5, 6, 7, 8
Fix the servo motor with the help of M2.5 type screws and nuts. To fix all the parts mentioned above, we have used M3 type 10mm screws and nuts respectively.
TOP VIEW
SIDE VIEW
Part number included: 9, 10, 11, 12, 13, 14, 15, 16, 17
Screw all the parts as shown in the figure. Here you have to use M3 type 10 mm screws. Don’t over-tighten the screws. If needed you can also include spacers and M3 type 10 mm screws for extra space for nuts.
Part number included: 19, 20, 21, 22, 23, 24, 25, 26
For clipper assembly all the screws of M3 type 10mm are used.
Part number included: 1, 2
Fix the servo motor with the help of M2.5 type screws and nuts. To fix part number 1 and 2, we have used M3 type 25mm screws and nuts respectively.
Part number included: 18, 27
To attach the part number 18 and 27, we have to use M3 type 12mm screws and nuts respectively.
Clipper and Base mount are screwed together with the help of M3 type 10mm screws and nuts.
Final assembly looks like:


_yyq2DC6hLN.png)
