This project is about connecting MCP23017 16-bit input/output port expander IC with Raspberry Pi by using I2C interface. In order to interact with the IC here, we have used Pi4J and JAVA.
MCP23017 Features:- 16-bit input/output port expander with interrupt output
- Cascadable for up to 8 devices on one bus
- 25mA sink/source capability per I/O
- Supports 100kHz, 400kHz and 1.7MHz I2C™ Compatible modes
Intro visual source: http://bit.ly/2jtWoHn
MCP23017 Details: http://bit.ly/2koAFzc
Links:- Buy Sensor (India)
- Buy Raspberry Pi (India)
