Project 06 - DIG3602C

Vaughn Johnson UCF-Spring 2023-DIG3602C-Davis Project 06

BeginnerShowcase (no instructions)21
Project 06 - DIG3602C

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
Resistor 10k ohm
Resistor 10k ohm
×1
Buzzer
Buzzer
×1
Photo resistor
Photo resistor
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Schematics


Schematic

Code

p06_LightTheremin.ino

C/C++
int sensorValue;
// variable to calibrate low value
int sensorLow = 1023;
// variable to calibrate high value
int sensorHigh = 0;
// LED pin
const int ledPin = 13;

void setup() {
  // Make the LED pin an output and turn it on
  pinMode(ledPin, OUTPUT);
  digitalWrite(ledPin, HIGH);

  // calibrate for the first five seconds after program runs
  while (millis() < 5000) {
    // record the maximum sensor value
    sensorValue = analogRead(A0);
    if (sensorValue > sensorHigh) {
      sensorHigh = sensorValue;
    }
    // record the minimum sensor value
    if (sensorValue < sensorLow) {
      sensorLow = sensorValue;
    }
  }
  // turn the LED off, signaling the end of the calibration period
  digitalWrite(ledPin, LOW);
}

void loop() {
  //read the input from A0 and store it in a variable
  sensorValue = analogRead(A0);

  // map the sensor values to a wide range of pitches
  int pitch = map(sensorValue, sensorLow, sensorHigh, 50, 4000);

  // play the tone for 20 ms on pin 8
  tone(8, pitch, 20);

  // wait for a moment
  delay(10);
}
