Parking Sensor with Arduino

This parking sensor with Arduino is an easy project.

BeginnerShowcase (no instructions)1 hour30,443
Parking Sensor with Arduino

Things used in this project

Hardware components

Arduino UNO & Genuino UNO
Arduino UNO & Genuino UNO
×1
Buzzer
Buzzer
×1
Jumper wires (generic)
Jumper wires (generic)
×1
Ultrasonic Sensor - HC-SR04 (Generic)
Ultrasonic Sensor - HC-SR04 (Generic)
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Schematics

hardware

Code

hardware

C/C++
// 6 trig , 5 echo
#include <Ultrasonic.h>
Ultrasonic ultrasonic(6,5);// 6 trig , 5 echo


const int buzzer = 7; // pin buzzer

void setup(){
 pinMode(buzzer,OUTPUT);

}

void loop(){
 int dist = ultrasonic.Ranging(CM);
if (dist < 100) {
  tone(buzzer,1000);
     delay(40);
   noTone(buzzer);
     delay(dist*4);
   }
 delay(100);
}
