Published August 20, 2018 © GPL3+

Computer Prank

Simblee BLE + Arduino Micro = FUN :-)

IntermediateWork in progress5 hours4,839

Things used in this project

Hardware components

Arduino Micro

SparkFun Simblee BLE Breakout - RFD77101

This is the RFD77201

Adafruit TXB0104 Bi-Directional Level Shifter

OpenBuilds Wire Cable - By the Foot

USB Male Type A Solder type

USB Male Type B Solderble

Software apps and online services

Arduino IDE

RFduino Simblee for Mobile App

Hand tools and fabrication machines

3D Printer (generic)

Story

The Project

Who doesn't like to do pranks? This project is very easy. Also if you are looking into rubber ducky's then this might also be what your looking for. I can see with this that you can uses this for good or evil. You could pare the Simblee with a SD card and make it send different keystrokes by reading a file and have it send the serial information to the Arduino Micro to do pre-programmed task buy reading the file but this is not the project. Plus, you could uses the Simblee com send to mulltiple simblee device and control up to 5 computers at one time.

For the people who don't know a rubber ducky is a keystroke injector. It acts like a keyboard or mouse to do a task. It can be used to do power shell scripts or command prompt commands or even program a file to be open like a.bat file.

Well the chip set that I used that is the Simblee is gone, but I am just posting it for what is worth. This was cool never got everything done with it that I would like.

The First Thing You Need

The Second Device -- TXB0104 Bi-Directional Level Shifter

The Last Device - BLE Wireless Device That Does All the Easy Work

Wiring the USB

Desoldering the Boards

Warning: if you do this and keep the iron on the board too long it could damage the board.

3D-Printed Parts

Wiring

The wiring is real easy the power will come from the Arduino Micro that will power the Simblee BLE with 3v3. The 5v power pin will be hooked up to 5v HV side of the TXB0104 and the 3v3 will be hooked up to the 3.6v LV side.

Code

#include "Keyboard.h"
#include "Mouse.h"

void setup() {
  // put your setup code here, to run once:
   Serial.begin(9600);
}

void loop() {
  // put your main code here, to run repeatedly:
  if (Serial.available() > 0) {
    int inByte = Serial.read();

      switch (inByte) {
      case '0':
         Keyboard.begin();
         Mouse.begin();
        Serial.println("OK,0");
         delay(2);
         Keyboard.press(0x80);
         Keyboard.press(0xB1);
         delay(6);
         Keyboard.releaseAll();
         Keyboard.print("ping www.yahoo.com -t");
         delay(6);
         Keyboard.press(0xB0);
         delay(6);
         Keyboard.releaseAll();
         delay(10000);
         Keyboard.press(0x80);
         Keyboard.press(0x63);
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end();
         Serial.println("END");
        break;

      case '1':
         Keyboard.begin();
         Mouse.begin();
         Serial.println("OK,1");
          delay(2);
         Keyboard.press(0x80); // Ctrl
         Keyboard.press(0xB1); // Esc
         delay(6);
         Keyboard.releaseAll();
         Keyboard.print("notepad");
         Keyboard.press(0xB0); //Enter
         delay(200);
         Keyboard.releaseAll();
         delay(1000);
         Keyboard.println("Hello Just to let you know I have control of your computer!");
         delay(500);
         Keyboard.press(0xB0);
         delay(6);
         Keyboard.releaseAll();
         Keyboard.println("I see you watching movies. ;-)");
         delay(2900);
         Keyboard.press(0x82); //ALT
         Keyboard.press(0x66); //f
         Keyboard.press(0x78); //x
         delay(6);
         Keyboard.releaseAll();
         Keyboard.press(0x82); //ALT
         Keyboard.press(0x6E); // n
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end();
         Serial.println("END");
        break;

      case '2':
        Keyboard.begin();
         Mouse.begin();
          Serial.println("OK,2");
          delay(2);
         Mouse.move(240,40);
         delay(6);
         Mouse.move(125,440);
         delay(6);
          Mouse.move(125,440);
         delay(10);
          Mouse.move(10,1000);
         delay(5);
          Mouse.move(0,-500);
         delay(3);
          Mouse.move(80,540);
         delay(1000);
          Mouse.move(1000,0);
         delay(1);
         Mouse.move(0,0);
         delay(1000);
         Mouse.end();
         Keyboard.end();
         Serial.println("END");
        break;

      case '3':
         Keyboard.begin();
         Mouse.begin();
          Serial.println("OK,3");
          delay(2);
         Keyboard.press(0x83); //Windows KEY
         Keyboard.press(0x64); //d
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end();
         Serial.println("END");
        break;
        /*
      case '4':
         Keyboard.begin();
         Mouse.begin();
          Serial.println(OK 1);
          delay(2);
         Keyboard.press(0x80);
         Keyboard.press(0xB1);
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end()
        break;
      case '5':
        Keyboard.begin();
         Mouse.begin();
          Serial.println(OK 1);
          delay(2);
         Keyboard.press(0x80);
         Keyboard.press(0xB1);
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end()
        break;
      case '6':
         Keyboard.begin();
         Mouse.begin();
          Serial.println(OK 1);
          delay(2);
         Keyboard.press(0x80);
         Keyboard.press(0xB1);
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end()
        break;
      case '7':
         Keyboard.begin();
         Mouse.begin();
          Serial.println(OK 1);
          delay(2);
         Keyboard.press(0x80);
         Keyboard.press(0xB1);
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end()
        break;
      case '8':
        Keyboard.begin();
         Mouse.begin();
          Serial.println(OK 1);
          delay(2);
         Keyboard.press(0x80);
         Keyboard.press(0xB1);
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end()
        break;
      case '9':
         Keyboard.begin();
         Mouse.begin();
          Serial.println(OK 1);
          delay(2);
         Keyboard.press(0x80);
         Keyboard.press(0xB1);
         delay(6);
         Keyboard.releaseAll();
         Mouse.end();
         Keyboard.end()
        break;
      case 'a':
         Keyboard.begin();
         Mouse.begin();

         Mouse.end();
         Keyboard.end()
        break;
      case 'b':
         Keyboard.begin();
         Mouse.begin();

         Mouse.end();
         Keyboard.end()
        break;
     case 'c':
         Keyboard.begin();
         Mouse.begin();

         Mouse.end();
         Keyboard.end()
        break;
     case 'd':
         Keyboard.begin();
         Mouse.begin();

         Mouse.end();
         Keyboard.end()
        break;
     case 'e':
         Keyboard.begin();
         Mouse.begin();

         Mouse.end();
         Keyboard.end()
        break;
     case 'f':
         Keyboard.begin();
         Mouse.begin();

         Mouse.end();
         Keyboard.end()
        break;
        */

   }
  }
}

/*
 * Prank Divice Oen
 * Date: 5/2/2018
 * Made by: theuser42
 * Decrption:
 *     This the the first code for the prank device help it
 *     be wireless using BLE
 */


#include <SimbleeForMobile.h>

uint8_t ui_button[16];

/*
 * Traditional Arduino setup routine
 *
 * Initialize the SimbleeForMobile environment.
 */
void setup() {
  Serial.begin(9600);
  // put your setup code here, to run once:
  SimbleeForMobile.deviceName = "CPU Prank";
  SimbleeForMobile.advertisementData = "Data";
  SimbleeForMobile.domain = "prank.simblee.com";
  // Begin Simblee UI
  SimbleeForMobile.begin();
}





/*
 * The traditional Arduino loop method
 *
 * Enable SimbleeForMobile functionality by calling the process method
 * each time through the loop. This method must be called regularly for
 * functionality to work.
 */
void loop() {
  // put your main code here, to run repeatedly:
  // process must be called in the loop for Simblee UI
  SimbleeForMobile.process();
}





/*
 * SimbleeForMobile UI callback requesting the user interface
 */
void ui()
{
  SimbleeForMobile.beginScreen();

 SimbleeForMobile.beginScreen(WHITE);
  SimbleeForMobile.drawText(90,230, "KEYPAD", BLUE, 50);
  ui_button[0] = SimbleeForMobile.drawButton(0,300,80,"Ping");
  ui_button[1] = SimbleeForMobile.drawButton(0,350,80,"Note");
  ui_button[2] = SimbleeForMobile.drawButton(0,400,80,"Mouse");
  ui_button[3] = SimbleeForMobile.drawButton(0,450,80,"Hide Windows");

  ui_button[4] = SimbleeForMobile.drawButton(83,300,80,"4");
  ui_button[5] = SimbleeForMobile.drawButton(83,350,80,"5");
  ui_button[6] = SimbleeForMobile.drawButton(83,400,80,"6");
  ui_button[7] = SimbleeForMobile.drawButton(83,450,80,"7");

  ui_button[8] = SimbleeForMobile.drawButton(166,300,80,"8");
  ui_button[9] = SimbleeForMobile.drawButton(166,350,80,"9");
  ui_button[10] = SimbleeForMobile.drawButton(166,400,80,"10");
  ui_button[11] = SimbleeForMobile.drawButton(166,450,80,"11");

  ui_button[12] = SimbleeForMobile.drawButton(250,300,80,"12");
  ui_button[13] = SimbleeForMobile.drawButton(250,350,80,"13");
  ui_button[14] = SimbleeForMobile.drawButton(250,400,80,"14");
  ui_button[15] = SimbleeForMobile.drawButton(250,450,80,"15");


    SimbleeForMobile.setEvents(ui_button[0], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[1], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[2], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[3], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[4], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[5], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[6], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[7], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[8], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[9], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[10], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[11], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[12], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[13], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[14], EVENT_PRESS);
     SimbleeForMobile.setEvents(ui_button[15], EVENT_PRESS);
  SimbleeForMobile.endScreen();
}





/*
 * SimbleeForMobile event callback method
 */
void ui_event(event_t &event)
{
  if (event.id == ui_button[0] ){
    if (event.type == EVENT_PRESS){
      Serial.println(0);
    }
  }
    if (event.id == ui_button[1] ){
    if (event.type == EVENT_PRESS){
      Serial.println(1);
    }
  }
    if (event.id == ui_button[2] ){
    if (event.type == EVENT_PRESS){
      Serial.println(2);
    }
  }
    if (event.id == ui_button[3] ){
    if (event.type == EVENT_PRESS){
      Serial.println(3);
    }
  }
    if (event.id == ui_button[4] ){
    if (event.type == EVENT_PRESS){
      Serial.println(4);
    }
  }
    if (event.id == ui_button[5] ){
    if (event.type == EVENT_PRESS){
      Serial.println(5);
    }
  }
    if (event.id == ui_button[6] ){
    if (event.type == EVENT_PRESS){
      Serial.println(6);
    }
  }
    if (event.id == ui_button[7] ){
    if (event.type == EVENT_PRESS){
      Serial.println(7);
    }
  }
    if (event.id == ui_button[8] ){
    if (event.type == EVENT_PRESS){
      Serial.println(8);
    }
  }
    if (event.id == ui_button[9] ){
    if (event.type == EVENT_PRESS){
      Serial.println(9);
    }
  }
    if (event.id == ui_button[10] ){
    if (event.type == EVENT_PRESS){
      Serial.println("a");
    }
  }
    if (event.id == ui_button[11] ){
    if (event.type == EVENT_PRESS){
      Serial.println("b");
    }
  }  if (event.id == ui_button[12] ){
    if (event.type == EVENT_PRESS){
      Serial.println("c");
    }
  }
    if (event.id == ui_button[13] ){
    if (event.type == EVENT_PRESS){
      Serial.println("d");
    }
  }
    if (event.id == ui_button[14] ){
    if (event.type == EVENT_PRESS){
      Serial.println("e");
    }
  }
    if (event.id == ui_button[15] ){
    if (event.type == EVENT_PRESS){
      Serial.println("f");
    }
  }
}
