#include <ESP8266WiFi.h>
#include <WiFiManager.h>
#include <PubSubClient.h>
#include <EEPROM.h>
#include <Adafruit_NeoPixel.h>
// ======== Konfiguration ========
#define RESET_COUNTER_ADDR 300
#define AUTO_RESET_FLAG_ADDR 301
#define RESET_THRESHOLD 5
#define RESET_CLEAR_DELAY 10000
#define LED_PIN D2
#define LED_COUNT 10
#define BRIGHTNESS_PERCENT 5
WiFiClient espClient;
PubSubClient client(espClient);
Adafruit_NeoPixel strip(LED_COUNT, LED_PIN, NEO_GRB + NEO_KHZ800);
// ======== Globale Variablen ========
unsigned long resetStartTime;
char mqtt_server[40] = "192.168.1.10";
char mqtt_user[20] = "user";
char mqtt_pass[20] = "";
char mqtt_topic[50] = "akku/soc";
char mqtt_topic_color[50] = "akku/farbe";
char mqtt_topic_charging[50] = "akku/charging";
int mqtt_port = 1883;
bool shouldSaveConfig = false;
int soc = 0;
bool socReceived = false;
bool mqttConnected = false;
unsigned long lastSocUpdate = 0;
static unsigned long wifiDisconnectTime = 0;
const unsigned long SOC_TIMEOUT = 15000; // 15 Sekunden
bool blinkState = false;
int colorOverride = 0;
bool isCharging = false;
unsigned long knightRiderStart = 0;
unsigned long wifiDisconnectStart = 0;
bool knightRiderActive = false;
unsigned long knightRiderStartTime = 0;
// Farben
uint32_t COLOR_RED, COLOR_YELLOW, COLOR_GREEN, COLOR_OFF;
// ======== Hilfsfunktion für automatischen Reset ========
void doAutoRestart() {
Serial.println("Automatischer Neustart...");
EEPROM.write(AUTO_RESET_FLAG_ADDR, 1); // Flag setzen
EEPROM.commit();
delay(100);
ESP.restart();
}
// ======== Angepasste Reset-Counter-Prüfung ========
void checkMultipleReset() {
byte autoResetFlag = EEPROM.read(AUTO_RESET_FLAG_ADDR);
if (autoResetFlag == 1) {
Serial.println("Automatischer Reset erkannt, Zähler wird nicht erhöht.");
EEPROM.write(AUTO_RESET_FLAG_ADDR, 0); // Flag zurücksetzen
EEPROM.commit();
resetStartTime = millis();
return; // Kein Hochzählen
}
// Normaler Boot - Zähler erhöhen
byte counter = EEPROM.read(RESET_COUNTER_ADDR);
counter++;
EEPROM.write(RESET_COUNTER_ADDR, counter);
EEPROM.commit();
resetStartTime = millis();
Serial.print("Reset-Counter erhöht auf: ");
Serial.println(counter);
if (counter >= RESET_THRESHOLD) {
Serial.println("Reset-Schwelle erreicht, WiFi-Einstellungen werden zurückgesetzt.");
WiFiManager wm;
wm.resetSettings();
EEPROM.write(RESET_COUNTER_ADDR, 0);
EEPROM.commit();
delay(500);
ESP.restart();
}
}
void resetCounterResetTask() {
if (millis() - resetStartTime > RESET_CLEAR_DELAY) {
EEPROM.write(RESET_COUNTER_ADDR, 0);
EEPROM.commit();
resetStartTime = millis() + 99999999;
}
}
// ======== Restlicher Code ========
void callback(char* topic, byte* payload, unsigned int length) {
String t = String(topic);
String value;
for (unsigned int i = 0; i < length; i++) value += (char)payload[i];
if (t == mqtt_topic) {
soc = value.toInt();
socReceived = true;
lastSocUpdate = millis();
updateLEDs();
} else if (t == mqtt_topic_color) {
colorOverride = value.toInt();
} else if (t == mqtt_topic_charging) {
isCharging = (value.toInt() == 1);
}
Serial.print("MQTT empfangen auf Topic: ");
Serial.println(topic);
Serial.print("Payload als String: ");
Serial.println(value);
Serial.print("SOC als Integer: ");
Serial.println(soc);
}
void updateLEDs() {
strip.clear();
int ledsOn = map(soc, 0, 100, 0, LED_COUNT);
uint32_t color = COLOR_GREEN;
if (colorOverride == 1) color = COLOR_RED;
else if (colorOverride == 2) color = COLOR_YELLOW;
else if (colorOverride == 3) color = COLOR_GREEN;
else {
if (soc < 20) color = COLOR_RED;
else if (soc < 40) color = COLOR_YELLOW;
else color = COLOR_GREEN;
}
for (int i = 0; i < ledsOn; i++) {
strip.setPixelColor(i, color);
}
if (isCharging) {
bool phase = (millis() / 500) % 2;
int blinkLed = (ledsOn < LED_COUNT) ? ledsOn : (LED_COUNT - 1);
if (!phase) {
strip.setPixelColor(blinkLed, COLOR_OFF);
} else {
strip.setPixelColor(blinkLed, color);
}
}
strip.show();
}
void blinkErrorPattern() {
bool phase = (millis() / 500) % 2;
uint32_t c1 = phase ? COLOR_RED : COLOR_OFF;
uint32_t c2 = phase ? COLOR_YELLOW : COLOR_OFF;
for (int i = 0; i < LED_COUNT; i++) {
strip.setPixelColor(i, i % 2 == 0 ? c1 : c2);
}
strip.show();
}
void knightRiderEffect() {
static int pos = 0;
static int dir = 1;
static unsigned long lastUpdate = 0;
const int delayMs = 50;
if (millis() - lastUpdate < delayMs) return;
lastUpdate = millis();
strip.clear();
float percent = (float)pos / (float)(LED_COUNT - 1);
uint32_t color;
if (percent < 0.2) {
color = strip.Color(255, 0, 0);
} else if (percent < 0.4) {
color = strip.Color(255, 255, 0);
} else {
color = strip.Color(0, 255, 0);
}
strip.setPixelColor(pos, color);
strip.show();
pos += dir;
if (pos <= 0) dir = 1;
if (pos >= LED_COUNT - 1) dir = -1;
client.loop();
}
void reconnect() {
Serial.println("MQTT: Verbindung prüfen...");
WiFiClient testClient;
if (!testClient.connect(mqtt_server, mqtt_port)) {
Serial.println("MQTT-Server nicht erreichbar → Automatischer Neustart");
doAutoRestart();
}
testClient.stop();
Serial.print("MQTT verbinden... ");
String clientId = "ESP-" + String(ESP.getChipId());
if (client.connect(clientId.c_str(), mqtt_user, mqtt_pass)) {
Serial.println("erfolgreich");
client.subscribe(mqtt_topic);
client.subscribe(mqtt_topic_color);
client.subscribe(mqtt_topic_charging);
mqttConnected = true;
} else {
Serial.print("fehlgeschlagen, rc=");
Serial.print(client.state());
Serial.println(" → Automatischer Neustart");
doAutoRestart();
}
}
void saveConfigCallback() {
shouldSaveConfig = true;
}
void setup() {
Serial.begin(115200);
EEPROM.begin(512);
checkMultipleReset();
strip.begin();
strip.setBrightness((255 * BRIGHTNESS_PERCENT) / 100);
strip.show();
COLOR_RED = strip.Color(255, 0, 0);
COLOR_YELLOW = strip.Color(255, 100, 0);
COLOR_GREEN = strip.Color(0, 255, 0);
COLOR_OFF = strip.Color(0, 0, 0);
EEPROM.get(0, mqtt_server);
EEPROM.get(40, mqtt_user);
EEPROM.get(60, mqtt_pass);
EEPROM.get(80, mqtt_topic);
EEPROM.get(130, mqtt_port);
EEPROM.get(140, mqtt_topic_color);
EEPROM.get(190, mqtt_topic_charging);
WiFiManager wm;
wm.setSaveConfigCallback(saveConfigCallback);
char mqtt_port_str[6];
snprintf(mqtt_port_str, sizeof(mqtt_port_str), "%d", mqtt_port);
WiFiManagerParameter p_server("server", "MQTT Server", mqtt_server, 40);
WiFiManagerParameter p_user("user", "MQTT User", mqtt_user, 20);
WiFiManagerParameter p_pass("pass", "MQTT Passwort", mqtt_pass, 20);
WiFiManagerParameter p_topic("topic", "MQTT Topic SoC", mqtt_topic, 50);
WiFiManagerParameter p_port("port", "MQTT Port", mqtt_port_str, 6);
WiFiManagerParameter p_topic_color("topiccolor", "MQTT Topic Farbe", mqtt_topic_color, 50);
WiFiManagerParameter p_topic_charge("topiccharge", "MQTT Topic Laden", mqtt_topic_charging, 50);
wm.addParameter(&p_server);
wm.addParameter(&p_user);
wm.addParameter(&p_pass);
wm.addParameter(&p_topic);
wm.addParameter(&p_port);
wm.addParameter(&p_topic_color);
wm.addParameter(&p_topic_charge);
wm.setConfigPortalTimeout(600);
if (!wm.autoConnect("SoC-Light")) {
Serial.println("Verbindung fehlgeschlagen. Neustart...");
doAutoRestart();
}
strncpy(mqtt_server, p_server.getValue(), 40);
strncpy(mqtt_user, p_user.getValue(), 20);
strncpy(mqtt_pass, p_pass.getValue(), 20);
strncpy(mqtt_topic, p_topic.getValue(), 50);
strncpy(mqtt_topic_color, p_topic_color.getValue(), 50);
strncpy(mqtt_topic_charging, p_topic_charge.getValue(), 50);
mqtt_port = atoi(p_port.getValue());
if (shouldSaveConfig) {
EEPROM.put(0, mqtt_server);
EEPROM.put(40, mqtt_user);
EEPROM.put(60, mqtt_pass);
EEPROM.put(80, mqtt_topic);
EEPROM.put(130, mqtt_port);
EEPROM.put(140, mqtt_topic_color);
EEPROM.put(190, mqtt_topic_charging);
EEPROM.commit();
}
client.setServer(mqtt_server, mqtt_port);
client.setCallback(callback);
reconnect();
}
void loop() {
// MQTT-Verbindung prüfen
if (!client.connected()) {
reconnect();
} else {
client.loop();
}
// WLAN-Verbindung prüfen
if (WiFi.status() != WL_CONNECTED || WiFi.localIP().toString() == "0.0.0.0") {
Serial.println("WLAN-Verbindung verloren oder keine gültige IP → Automatischer Neustart");
doAutoRestart();
}
// Prüfen, ob SoC veraltet ist (älter als 15 Sekunden)
bool socTimedOut = (millis() - lastSocUpdate > SOC_TIMEOUT);
if (!socReceived || socTimedOut) {
knightRiderEffect();
if (knightRiderStartTime == 0) {
knightRiderStartTime = millis();
}
if (millis() - knightRiderStartTime > 60000) {
Serial.println("Timeout im KnightRider-Modus → Automatischer Neustart");
doAutoRestart();
}
return;
}
// Wenn gültiger SoC → KnightRider-Zeit zurücksetzen und normale Anzeige zeigen
knightRiderStartTime = 0;
updateLEDs();
resetCounterResetTask();
}
