Things used in this project

Hardware components:
Photon new
Particle Photon
×2
relay 5v
×1
honeywell magnetic Contact Switch
×2
386 00
DHT11 Temperature & Humidity Sensor
×1
Amazon echo dot
Amazon Alexa Echo Dot
×1
Software apps and online services:
Gawd2jnp51w1h1ccsulo
IFTTT Amazon Alexa service
Mobicle 1024
ControlEverything.com Mobicle
Hackster
ThingSpeak API

Schematics

Project Bread Board
Screen shot 2017 04 10 at 9 44 06 pm ppsrw6kfyy
Project Schematic
Screen shot 2017 04 10 at 9 43 57 pm ozopfaar6k
Schematic 2
Screen shot 2017 04 10 at 9 34 26 pm jp6w09rvrm

Code

GarageDoorArduino
Garage Door Code to wifi remote access
// This #include statement was automatically added by the Particle IDE.
#include "PietteTech_DHT/PietteTech_DHT.h"
// Code inspired by Prof. John Macalpine

 /*                           +-----+
 *                 +----------| USB |----------+
 *                 |          +-----+       *  |
 *  DHT11 V(in) -->| [ ] VIN           3V3 [ ] |<-- Relay VCC
 *                 | [ ] GND           RST [ ] |
 *                 | [ ] TX           VBAT [ ] |
 *                 | [ ] RX  [S]   [R] GND [ ] |<-- Relay GND
 *                 | [ ] WKP            D7 [ ] |
 *                 | [ ] DAC +-------+  D6 [ ] |
 *   Opensensor -->| [*] A5  |   *   |  D5 [ ] |
 * Closedsensor -->| [*] A4  |Photon |  D4 [*] |<-- DHT111 AM2301 Sensor
 *                 | [*] A3  |       |  D3 [ ] |
 *                 | [ ] A2  +-------+  D2 [ ] |
 *                 | [ ] A1             D1 [ ] |
 *                 | [ ] A0             D0 [*] |<-- Garage Door Switch Relay
 *                 |                           |
 *                  \    []         [______]  /
 *                   \_______________________/
 *
 *
 */

const String key = "HM51Z16VGAII6IX5"; //write key

//--------------Begin DHT------------------
// Example testing sketch for various DHT humidity/temperature sensors


#define DHTPIN D4     // what pin we're connected to

// Uncomment whatever type you're using!
#define DHTTYPE DHT11		// DHT 11

// Connect pin 1 (on the left) of the sensor to +5V
// Connect pin 2 of the sensor to whatever your DHTPIN is
// Connect pin 4 (on the right) of the sensor to GROUND
// Connect a 10K resistor from pin 2 (data) to pin 1 (power) of the sensor


//declaration
void dht_wrapper(); // must be declared before the lib initialization

// Lib instantiate
PietteTech_DHT DHT(DHTPIN, DHTTYPE, dht_wrapper);
// globals
unsigned int DHTnextSampleTime;	    // Next time we want to start sample
bool bDHTstarted;		    // flag to indicate we started acquisition
int n;                              // counter

//---------------End DHT-------------------


unsigned int particleinterval = 100;
unsigned int particlefuncinterval = 10000;
unsigned int ubiinterval = 15000;
unsigned int dhtinterval = 5000;

int garageDoorFunction(String command);

int rssival = 0;
int doorstatus = 1;
int doorcounter = 0;
int closedsensorpin = A4;
int opensensorpin = A5;
const int open = 0;
const int closed = 1;

// Define the pins we're going to call pinMode on
int led = D6;  // You'll need to wire an LED to this one to see it blink.
int led2 = D7; // This one is the built-in tiny one to the right of the USB jack


double analog1 = 0;
double analog2 = 0;
double analog1raw = 0;
double analog2raw = 0;
double garagetemp = 70;
double readtemp = 70;
double garagehumid = 0;


char publishString[40];
char doorpublishstring[40];
char doorstatusstring[40];

SYSTEM_MODE(SEMI_AUTOMATIC); //allows for control of Spark.connect() and Spark.process()

// This routine runs only once upon reset
Timer task50ms(50, dodoor);
Timer task10sec(10000,dopublish);
Timer task15sec(15000,updateThingspeak);
Timer taskdht(5000, readdht);

void setup() {
    task50ms.start();
    task10sec.start();
    task15sec.start();
    taskdht.start();

    pinMode(led, OUTPUT);
    pinMode(led2, OUTPUT);
    pinMode(A0, INPUT);
    pinMode(A1, INPUT);
    Serial1.begin(230400);   // open serial over USB
    //ip = {"IP:", WiFi.localIP()};
    //String ip = WiFi.localIP();

    Particle.function("GarageDoor", garageDoorFunction);
    Particle.variable("analog1", &analog1, DOUBLE);  //variables update automatically. Max 4 per particle
    Particle.variable("doorcounter", doorcounter);
    //Particle.variable("doorstatus", &doorstatus, INT); //variables are viewable on mobicle
    Particle.variable("doorstatus", doorstatusstring, STRING); //variables are viewable on mobicle
    Particle.variable("garagetemp", &garagetemp, DOUBLE); //variables are viewable on mobicle
    Particle.variable("garagehumid", &garagehumid, DOUBLE); //variables are viewable on mobicle

    pinMode(opensensorpin, INPUT_PULLUP);
    pinMode(closedsensorpin, INPUT_PULLUP);

    pinMode(D0, OUTPUT);

    //Do DHTINIT
    pinMode(DHTPIN, INPUT_PULLUP); //sensor needs pullup resistor.
	//End DHTINIT

//-------------Begin UBIDOTS---------------
//    request.hostname = "things.ubidots.com";
//    request.port = 80;
//    request.path = "/api/v1.6/variables/"VARIABLE_ID"/values?token="TOKEN;
//--------------End UBIDOTS----------------
}

// This wrapper is in charge of calling
// mus be defined like this for the lib work
void dht_wrapper() {
    DHT.isrCallback();
}

void loop() {
    if (Particle.connected() == false){
            Particle.connect();
    }
    analog1raw = analogRead(A0);
    analog1 = (analog1 *63 +analog1raw *3.3/4095)/64;
    analog2raw = analogRead(A1);
    analog2 = (analog2 *63 +analog2raw *3.3/4095)/64;

    doDht();
}

void dopublish(){
    rssival = WiFi.RSSI();
    sprintf(publishString,"%d",rssival);

    Particle.publish("RSSI",publishString);
}

void readdht() {
    if (!bDHTstarted) {		// start the sample
    Serial.print("\n");
    Serial.print(n);
    Serial.print(": Retrieving information from sensor: ");
    DHT.acquire();
    bDHTstarted = true;
    }
}

void dodoor() {

        digitalWrite(led, !digitalRead(led));   // Turn ON the LED pins
        digitalWrite(led2, !digitalRead(led2));

        int opensense = digitalRead(opensensorpin);
        int closedsense = digitalRead(closedsensorpin);


        if (opensense == LOW) // high,0 = open door, low,1 = closed door
        {
            if (doorstatus == closed) //check the previous state, if closed, then generate an event
            {
                strcpy(doorpublishstring, "Open");
                Particle.publish("ON",doorpublishstring); // Publishing Open Event for second Photon
                doorcounter++;
            }
            doorstatus = open;
            strcpy(doorstatusstring, "Open"); //update particle variable.
        }
        else if (closedsense == LOW)
        {
            if (doorstatus == open) //check the previous state, if closed, then generate an event
            {
                strcpy(doorpublishstring, "Closed");
                Particle.publish("OFF",doorpublishstring); //Publishing Close Event for second Photon
                doorcounter++;
            }
            doorstatus = closed;
            strcpy(doorstatusstring, "Closed");  //update particle variable.
        }
            else
            {  //if door is neither closed or open, it is in "limbo"
                strcpy(doorstatusstring, "Limbo");  //update particle variable.
            }
}


/*******************************************************************************
 * Function Name  : garageDoor
 * Description    : based on door status, opens or closes the door
 * Input          : analog 5 - digital input.
 * Output         : digital 1 - relay to blip and open or close the door
 * Return         : Value of the pin (0 or 1) in INT type
                    Returns a negative number on failure
 *******************************************************************************/
int garageDoorFunction(String sesame)
{
    if(sesame.startsWith("C"))
	{
		if (doorstatus == open)
		{
	        pinMode(0, OUTPUT);
		    digitalWrite(0, 1);
		    delay(250);
		    digitalWrite(0, 0);
		return 1;
		}
	}
	else if (sesame.startsWith("O"))
		{
        if (doorstatus == closed)
		{
	        pinMode(0, OUTPUT);
		    digitalWrite(0, 1);
		    delay(250);
		    digitalWrite(0, 0);
		return 2;
		}
	}
	else if (sesame.startsWith("X"))
		{
        if (doorstatus == closed){
            return 999;
        } else
        return 123;
		}
	return -1;

}



/*******************************************************************************
 * Function Name  : updateThingspeak
 * Description    : sends variables to ts
 * Input          : doorstatus global variables
 * Output         : sends data to ts
 * Return         : void

 *******************************************************************************/
bool updateThingspeak()
{
    //delay (2000);
    static int count = 0;
    Serial.println(count++);
    int rssival = WiFi.RSSI();
    //sprintf(publishString,"%d",rssival);
    //bool success = Particle.publish("RSSI",publishString);

    //sprintf(publishString, "%1.4f", checkbattery());

      bool success = Particle.publish("thingSpeakWrite_All", +
     "{ \"1\": \"" + String(rssival) + "\"," +
       "\"2\": \"" + String(garagetemp) + "\"," +
       "\"3\": \"" + String(garagehumid) + "\"," +
       "\"4\": \"" + String(doorstatus) + "\"," +
       "\"5\": \"" + String(doorcounter) + "\"," +
       //"\"6\": \"" + String(analog1) + "\"," +
       //"\"7\": \"" + String(analog2) + "\"," +
       "\"k\": \"" + key + "\" }", 60, PRIVATE);
    return success; //if sent, then turn of the send flag, otherwise let it try again.

}

/*******************************************************************************
 * Function Name  : getDht
 * Description    : gets temp and humidity
 * Input          :
 * Output         :
 * Return         : void

 *******************************************************************************/
void doDht() {
    if (!DHT.acquiring()) {		// has sample completed?

	    // get DHT status
	    int result = DHT.getStatus();

	    Serial.print("Read DHT sensor: ");
	    switch (result) {
		case DHTLIB_OK:
		    Serial.println("OK");
		   	garagehumid = DHT.getHumidity();
            // Read temperature as Celsius
	        //garagetemp = DHT.getCelsius();
            // Read temperature as Farenheit
	        garagetemp = DHT.getFahrenheit();
	        break;
		case DHTLIB_ERROR_CHECKSUM:
		    Serial.println("Error\n\r\tChecksum error");
		    break;
		case DHTLIB_ERROR_ISR_TIMEOUT:
		    Serial.println("Error\n\r\tISR time out error");
		    break;
		case DHTLIB_ERROR_RESPONSE_TIMEOUT:
		    Serial.println("Error\n\r\tResponse time out error");
		    break;
		case DHTLIB_ERROR_DATA_TIMEOUT:
		    Serial.println("Error\n\r\tData time out error");
		    break;
		case DHTLIB_ERROR_ACQUIRING:
		    Serial.println("Error\n\r\tAcquiring");
		    break;
		case DHTLIB_ERROR_DELTA:
		    Serial.println("Error\n\r\tDelta time to small");
		    break;
		case DHTLIB_ERROR_NOTSTARTED:
		    Serial.println("Error\n\r\tNot started");
		    break;
		default:
		    Serial.println("Unknown error");
		    break;
	    }


        /*
	    Serial.print("Humidity (%): ");
	    Serial.println(DHT.getHumidity(), 2);

	    Serial.print("Temperature (oC): ");
	    Serial.println(DHT.getCelsius(), 2);

	    Serial.print("Temperature (oF): ");
	    Serial.println(DHT.getFahrenheit(), 2);

	    Serial.print("Temperature (K): ");
	    Serial.println(DHT.getKelvin(), 2);

	    Serial.print("Dew Point (oC): ");
	    Serial.println(DHT.getDewPoint());

	    Serial.print("Dew Point Slow (oC): ");
	    Serial.println(DHT.getDewPointSlow());
        */

	    n++;  // increment counter
	    bDHTstarted = false;  // reset the sample flag so we can take another
	}

	//Serial.println(Time.timeStr());
}
Garage Photon 2 SubscribeArduino
Code for subscription of an event from 1st Photon
//Code For subscribing the event from first photon

int led = D7;

void setup() {

    pinMode(led, OUTPUT);
    digitalWrite(led, LOW);
    Particle.subscribe("ON",anything, "200040000147353138383138"); // Recieving Open Event
    Particle.subscribe("OFF",anything2, "200040000147353138383138"); // Recieving Close Event
}
void anything(const char *event, const char *data)
{
    digitalWrite(led, HIGH);
}
void anything2(const char *event, const char *data)
{
    digitalWrite(led, LOW);
}
void loop() {

}
PIETTETECH_DHT CodeArduino
Code For DHT Sensor
it is already in Build.particle library
/*
 * FILE:        PietteTech_DHT.cpp
 * VERSION:     0.4
 * PURPOSE:     Spark Interrupt driven lib for DHT sensors
 * LICENSE:     GPL v3 (http://www.gnu.org/licenses/gpl.html)
 *
 * S Piette (Piette Technologies) scott.piette@gmail.com
 *      January 2014        Original Spark Port
 *      October 2014        Added support for DHT21/22 sensors
 *                          Improved timing, moved FP math out of ISR
 *      September 2016      Updated for Particle and removed dependency
 *                          on callback_wrapper.  Use of callback_wrapper
 *                          is still for backward compatibility but not used
 *
 *                          is still for backward compatibility but not used
 * ScruffR
 *      February 2017       Migrated for Libraries 2.0
 *                          Fixed blocking acquireAndWait()
 *                          and previously ignored timeout setting
 *
 * Based on adaptation by niesteszeck (github/niesteszeck)
 * Based on original DHT11 library (http://playgroudn.adruino.cc/Main/DHT11Lib)
 *
 *
 * With this library connect the DHT sensor to the following pins
 * Spark Core: D0, D1, D2, D3, D4, A0, A1, A3, A5, A6, A7
 * Particle  : any Pin but D0 & A5
 * See docs for more background
 *   https://docs.particle.io/reference/firmware/photon/#attachinterrupt-
 */

 /*
     Timing of DHT22 SDA signal line after MCU pulls low for 1ms
     https://github.com/mtnscott/Spark_DHT/AM2302.pdf

   - - - -            -----           -- - - --            ------- - -
          \          /     \         /  \      \          /
           +        /       +       /    +      +        /
            \      /         \     /      \      \      /
             ------           -----        -- - --------
  ^        ^                ^                   ^          ^
  |   Ts   |        Tr      |        Td         |    Te    |

     Ts : Start time from MCU changing SDA from Output High to Tri-State (Hi-Z)
          Spec: 20-200us             Tested: < 65us
     Tr : DHT response to MCU controlling SDA and pulling Low and High to
          start of first data bit
          Spec: 150-170us            Tested: 125 - 200us
     Td : DHT data bit, falling edge to falling edge
          Spec: '0' 70us - 85us      Tested: 60 - 110us
          Spec: '1' 116us - 130us    Tested: 111 - 155us
     Te : DHT releases SDA to Tri-State (Hi-Z)
          Spec: 45-55us              Not Tested
  */

#include "PietteTech_DHT.h"

#if !defined(word)
  // Thanks to Paul Kourany for this word type conversion function
uint16_t word(uint8_t high, uint8_t low) {
  uint16_t ret_val = low;
  ret_val += (high << 8);
  return ret_val;
}
#endif

/*
 * NOTE:  callback_wrapper is only here for backwards compatibility with v0.3 and earlier
 *        it is no longer used or needed
 */
PietteTech_DHT::PietteTech_DHT(uint8_t sigPin, uint8_t dht_type, void(*callback_wrapper)()) {
  begin(sigPin, dht_type);
  _firstreading = true;
}

/*
 * NOTE:  callback_wrapper is only here for backwards compatibility with v0.3 and earlier
 *        it is no longer used or needed
 */
void PietteTech_DHT::begin(uint8_t sigPin, uint8_t dht_type, void(*callback_wrapper)()) {
  _sigPin = sigPin;
  _type = dht_type;

  pinMode(sigPin, OUTPUT);
  digitalWrite(sigPin, HIGH);
  _lastreadtime = 0;
  _state = STOPPED;
  _status = DHTLIB_ERROR_NOTSTARTED;
}

int PietteTech_DHT::acquire() {
  // Check if sensor was read less than two seconds ago and return early
  // to use last reading
  unsigned long currenttime = millis();
  if (!_firstreading && ((currenttime - _lastreadtime) < 2000)) {
    // return last correct measurement, (this read time - last read time) < device limit
    return DHTLIB_ACQUIRED;
  }

  if (_state == STOPPED || _state == ACQUIRED) {
    /*
     * Setup the initial state machine
     */
    _firstreading = false;
    _lastreadtime = currenttime;
    _state = RESPONSE;

#if defined(DHT_DEBUG_TIMING)
    /*
     * Clear the debug timings array
     */
    for (int i = 0; i < 41; i++) _edges[i] = 0;
    _e = &_edges[0];
#endif

    /*
     * Set the initial values in the buffer and variables
     */
    for (int i = 0; i < 5; i++) _bits[i] = 0;
    _cnt = 7;
    _idx = 0;
    _hum = 0;
    _temp = 0;

    /*
     * Toggle the digital output to trigger the DHT device
     * to send us temperature and humidity data
     */
    pinMode(_sigPin, OUTPUT);
    digitalWrite(_sigPin, LOW);
    if (_type == DHT11)
      delay(18);                  // DHT11 Spec: 18ms min
    else
      delayMicroseconds(1500);    // DHT22 Spec: 0.8-20ms, 1ms typ
    pinMode(_sigPin, INPUT);        // Note Hi-Z mode with pullup resistor
                                    // will keep this high until the DHT responds.
    /*
     * Attach the interrupt handler to receive the data once the DHT
     * starts to send us data
     */
    _us = micros();
    attachInterrupt(_sigPin, &PietteTech_DHT::_isrCallback, this, FALLING);

    return DHTLIB_ACQUIRING;
  }
  else
    return DHTLIB_ERROR_ACQUIRING;
}

int PietteTech_DHT::acquireAndWait(uint32_t timeout) {
  acquire();
  uint32_t start = millis();
  while (acquiring() && (timeout == 0 || ((millis() - start) < timeout))) Particle.process();
  if (acquiring())
  {
    _status = DHTLIB_ERROR_RESPONSE_TIMEOUT;
  }
  return getStatus();
}

/*
 * NOTE:  isrCallback is only here for backwards compatibility with v0.3 and earlier
 *        it is no longer used or needed
 */
void PietteTech_DHT::isrCallback() { }

void PietteTech_DHT::_isrCallback() {
  unsigned long newUs = micros();
  unsigned long delta = (newUs - _us);
  _us = newUs;

  if (delta > 6000) {
    _status = DHTLIB_ERROR_ISR_TIMEOUT;
    _state = STOPPED;
    detachInterrupt(_sigPin);
    return;
  }
  switch (_state) {
  case RESPONSE:            // Spec: 80us LOW followed by 80us HIGH
    if (delta < 65) {      // Spec: 20-200us to first falling edge of response
      _us -= delta;
      break; //do nothing, it started the response signal
    } if (125 < delta && delta < 200) {
#if defined(DHT_DEBUG_TIMING)
      *_e++ = delta;  // record the edge -> edge time
#endif
      _state = DATA;
    }
    else {
      detachInterrupt(_sigPin);
      _status = DHTLIB_ERROR_RESPONSE_TIMEOUT;
      _state = STOPPED;
#if defined(DHT_DEBUG_TIMING)
      *_e++ = delta;  // record the edge -> edge time
#endif
    }
    break;
  case DATA:          // Spec: 50us low followed by high of 26-28us = 0, 70us = 1
    if (60 < delta && delta < 155) { //valid in timing
      _bits[_idx] <<= 1; // shift the data
      if (delta > 110) //is a one
        _bits[_idx] |= 1;
#if defined(DHT_DEBUG_TIMING)
      *_e++ = delta;  // record the edge -> edge time
#endif
      if (_cnt == 0) { // we have completed the byte, go to next
        _cnt = 7; // restart at MSB
        if (++_idx == 5) { // go to next byte, if we have got 5 bytes stop.
          detachInterrupt(_sigPin);
          // Verify checksum
          uint8_t sum = _bits[0] + _bits[1] + _bits[2] + _bits[3];
          if (_bits[4] != sum) {
            _status = DHTLIB_ERROR_CHECKSUM;
            _state = STOPPED;
          }
          else {
            _status = DHTLIB_OK;
            _state = ACQUIRED;
            _convert = true;
          }
          break;
        }
      }
      else _cnt--;
    }
    else if (delta < 10) {
      detachInterrupt(_sigPin);
      _status = DHTLIB_ERROR_DELTA;
      _state = STOPPED;
    }
    else {
      detachInterrupt(_sigPin);
      _status = DHTLIB_ERROR_DATA_TIMEOUT;
      _state = STOPPED;
    }
    break;
  default:
    break;
  }
}

void PietteTech_DHT::convert() {
  // Calculate the temperature and humidity based on the sensor type
  switch (_type) {
  case DHT11:
    _hum = _bits[0];
    _temp = _bits[2];
    break;
  case DHT22:
  case DHT21:
    _hum = word(_bits[0], _bits[1]) * 0.1;
    _temp = (_bits[2] & 0x80 ?
      -word(_bits[2] & 0x7F, _bits[3]) :
      word(_bits[2], _bits[3])) * 0.1;
    break;
  }
  _convert = false;
}

bool PietteTech_DHT::acquiring() {
  if (_state != ACQUIRED && _state != STOPPED)
    return true;
  return false;
}

int PietteTech_DHT::getStatus() {
  return _status;
}

float PietteTech_DHT::getCelsius() {
  DHT_CHECK_STATE;
  return _temp;
}

float PietteTech_DHT::getHumidity() {
  DHT_CHECK_STATE;
  return _hum;
}

float PietteTech_DHT::getFahrenheit() {
  DHT_CHECK_STATE;
  return _temp * 9 / 5 + 32;
}

float PietteTech_DHT::getKelvin() {
  DHT_CHECK_STATE;
  return _temp + 273.15;
}

/*
 * Added methods for supporting Adafruit Unified Sensor framework
 */
float PietteTech_DHT::readTemperature() {
  acquireAndWait();
  return getCelsius();
}

float PietteTech_DHT::readHumidity() {
  acquireAndWait();
  return getHumidity();
}

// delta max = 0.6544 wrt dewPoint()
// 5x faster than dewPoint()
// reference: http://en.wikipedia.org/wiki/Dew_point
double PietteTech_DHT::getDewPoint() {
  DHT_CHECK_STATE;
  double a = 17.271;
  double b = 237.7;
  double temp_ = (a * (double)_temp) / (b + (double)_temp) + log((double)_hum / 100);
  double Td = (b * temp_) / (a - temp_);
  return Td;
}

// dewPoint function NOAA
// reference: http://wahiduddin.net/calc/density_algorithms.htm
double PietteTech_DHT::getDewPointSlow() {
  DHT_CHECK_STATE;
  double a0 = (double) 373.15 / (273.15 + (double)_temp);
  double SUM = (double)-7.90298 * (a0 - 1.0);
  SUM += 5.02808 * log10(a0);
  SUM += -1.3816e-7 * (pow(10, (11.344*(1 - 1 / a0))) - 1);
  SUM += 8.1328e-3 * (pow(10, (-3.49149*(a0 - 1))) - 1);
  SUM += log10(1013.246);
  double VP = pow(10, SUM - 3) * (double)_hum;
  double T = log(VP / 0.61078); // temp var
  return (241.88 * T) / (17.558 - T);
}
Thingspeak IntergrationJSON
{
    "event": "thingSpeakWrite_",
    "url": "https://api.thingspeak.com/update",
    "requestType": "POST",
    "form": {
        "api_key": "{{k}}",
        "field1": "{{1}}",
        "field2": "{{2}}",
        "field3": "{{3}}",
        "field4": "{{4}}",
        "field5": "{{5}}",
        "field6": "{{6}}",
        "field7": "{{7}}",
        "field8": "{{8}}",
        "latitude": "{{a}}",
        "longitude": "{{o}}",
        "elevation": "{{e}}",
        "status": "{{s}}"
    },
    "mydevices": true,
    "noDefaults": true,
    "location": true
}

Credits

Replications

Did you replicate this project? Share it!

I made one

Love this project? Think it could be improved? Tell us what you think!

Give feedback

Comments

Similar projects you might like

Blynk GPS Tracker
Intermediate
  • 165
  • 4

Full instructions

Simple GPS tracker using a Particle Photon (or Electron) and an EM406 GPS module with location visible on Blynk app map.

Amazon Echo – Control IoT devices via HTTP
Intermediate
  • 263
  • 11

Full instructions

I am going to show how to use Amazon Echo to control IoT devices via HTTP protocol. Turning on/off a light bulb is an example.

Amazon Echo – Read Temperature and Humidity from Sensor
Intermediate
  • 323
  • 12

Full instructions

I am going to show how to use Amazon Echo to read temperature and humidity from sensor.

Pool Buddy
Intermediate
  • 1,778
  • 11

Work in progress

Monitor and log water quality (pH & ORP) and temperature from everywhere.

Smart Garden
Intermediate
  • 2,462
  • 19

Smart Garden is a plant environmental monitoring system.

Open your garage with Alexa and a Raspberry Pi
Intermediate
  • 13
  • 1

Protip

Run commands on your Raspberry Pi with Alexa and TRIGGERcmd. Example phrase: "Alexa, tell TRIGGER C M D to run door on garage"

ProjectsCommunitiesTopicsContestsLiveAppsBetaFree StoreBlogAdd projectSign up / Login
Feedback
