Smart Waste Bin Temperature Monitoring for Early Fire Detect

#include <LoRaWan-RAK4631.h> // LoRaWAN library for RAK4631
#include <SPI.h>
#include <Wire.h>
#include <Adafruit_Sensor.h>
#include <Adafruit_BME680.h> // For RAK1906 (uses BME680 sensor)

// LoRaWAN Join Settings
// You must obtain these values from your TheThingsNetwork (TTN) console.
String node_device_eui = "AC1F09FFFE0xxxx"; // <<< CHANGE THIS
String node_app_eui = "70B3D57ED000xxxx";   // <<< CHANGE THIS
String node_app_key = "XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX"; // <<< CHANGE THIS

// LoRaWAN Application Port
#define LORAWAN_APP_PORT 1

// Data Transmission Interval (in seconds)
#define SEND_INTERVAL_SEC 300 // Interval for sending sensor data (5 minutes)

// Sensor Object
Adafruit_BME680 bme; // RAK1906 (BME680) environmental sensor object

// Timer Variable
time_t lastSendTime = 0; // Last sensor data transmission time (millis())

void setup() {
  // Set internal LED as OUTPUT and turn it off initially
  pinMode(LED_BUILTIN, OUTPUT);
  digitalWrite(LED_BUILTIN, LOW);

  // Start serial communication (for debug messages)
  Serial.begin(115200);
  while (!Serial); // Wait for serial port to be ready
  Serial.println("Waste Bin Temperature Monitoring Starting...");

  // Start I2C communication (for BME680)
  Wire.begin();

  // Initialize RAK1906 (BME680) sensor
  // I2C address is typically 0x76 or 0x77.
  if (!bme.begin(0x76)) {
    Serial.println("RAK1906 BME680 not found, check connection!");
    while (1); // Stay in infinite loop if initialization fails
  }
  // High oversampling for temperature only
  bme.setTemperatureOversampling(BME680_OS_8X);
  // Other oversampling settings for humidity, pressure, or gas sensor are not needed for this project.
  Serial.println("RAK1906 BME680 successfully initialized.");

  // Initialize and configure LoRaWAN module
  api.lorawan.setMcuStatus(true);         // Set MCU status
  api.lorawan.setDeviceClass(CLASS_A);    // Set device class (Class A)
  api.lorawan.setRegion(EU868);           // Set LoRaWAN region (e.g., EU868 for Europe)
  api.lorawan.setDevEui(node_device_eui); // Set Device EUI
  api.lorawan.setAppEui(node_app_eui);   // Set Application EUI
  api.lorawan.setAppKey(node_app_key);   // Set Application Key
  api.lorawan.setConfirm(true);          // Use confirmed messages?
  api.lorawan.setAdaptiveDr(true);       // Use Adaptive Data Rate (ADR)?

  Serial.println("Attempting to join LoRaWAN network...");
  api.lorawan.join(); // Start LoRaWAN network join process

  // Initialize timer
  lastSendTime = millis();
}

void loop() {
  // Check LoRaWAN network connection status
  if (api.lorawan.queryNetworkStatus() == LORAWAN_JOINED) {
    // Check if it's time to send data
    if (millis() - lastSendTime > (SEND_INTERVAL_SEC * 1000)) {
      sendTemperatureData();    // Send temperature data
      lastSendTime = millis(); // Reset timer
    }
  } else {
    // If not connected to LoRaWAN network, try to join again
    Serial.println("Not connected to LoRaWAN network, trying to join again...");
    api.lorawan.join();
    delay(10000); // Wait 10 seconds before retrying
  }
}

// Function to read temperature data and send it via LoRaWAN
void sendTemperatureData() {
  Serial.println("Reading temperature data...");
  bme.performReading(); // Start BME680 reading
  float temperature = bme.temperature; // Get temperature value

  // Print read data to Serial Monitor
  Serial.printf("Temperature: %.2f C\n", temperature);

  // Package data into LoRaWAN payload (4 bytes float)
  uint8_t payload[4];
  memcpy(&payload[0], &temperature, sizeof(float)); // Temperature value

  Serial.println("Sending LoRaWAN data...");
  // Send payload to LoRaWAN network. Use LORAWAN_APP_PORT and send as confirmed message (true).
  api.lorawan.send(sizeof(payload), payload, LORAWAN_APP_PORT, true);
}

// LoRaWAN callback functions
// Downlink messages are not processed in this project, but empty functions are defined for library requirements.
void lorawan_rx_handler(lorawan_AppData_t* appData) {
  // You can process downlink messages here, but it's not used in this project
  Serial.printf("Downlink received (not expected in this project): Port %d, Length %d\n", appData->Port, appData->BuffSize);
}

void lorawan_has_joined_handler(void) {
  Serial.println("Successfully joined LoRaWAN network!");
  digitalWrite(LED_BUILTIN, HIGH); // Turn on internal LED after joining network
}

void lorawan_join_failed_handler(void) {
  Serial.println("LoRaWAN network join failed. Retrying...");
  digitalWrite(LED_BUILTIN, LOW); // Turn off internal LED if join fails
}

void lorawan_tx_handler(void) {
  Serial.println("LoRaWAN Tx Done!"); // Inform when data transmission is complete
}
