Remote Machine Health Monitoring for Predictive Maintenance

#include <WisBlock-api.h>      // For RAK WisBlock APIs
#include <TinyGsmClient.h>     // General header for TinyGSM library
#include <TinyGsmClientSIM7600.h> // Header for SIM7600/BG77 modem family used by RAK3372
#include <PubSubClient.h>      // For MQTT communication (with Azure IoT Hub)
#include <Wire.h>              // For I2C communication (for BME680)
#include <Adafruit_Sensor.h>   // Base class for Adafruit sensor libraries
#include <Adafruit_BME680.h>   // For RAK1906 (uses BME680 sensor)

// For RAK12027 Vibration Sensor
// If RAK12027 is a specific accelerometer (e.g., LIS3DH), you'll need to include its library (e.g., Adafruit LIS3DH) and initialize it.
// In this example, a simple analog vibration sensor reading and RMS calculation is shown.
// For a real project, refer to the RAK12027 datasheet or library.
#define VIBRATION_SENSOR_PIN WB_A1 // Example analog pin connected to vibration sensor

// Azure IoT Hub Settings
// These values must be obtained from your Azure IoT Hub and device registration.
const char* IOT_HUB_HOSTNAME = "YOUR_IOT_HUB_NAME.azure-devices.net"; // <<< CHANGE THIS
const char* DEVICE_ID = "YourMachineMonitorDevice"; // <<< CHANGE THIS (Unique device ID)
// SAS Token: Shared Access Signature (SAS) token generated for your Azure IoT Hub device.
// You need to securely generate and manage this token. It is often renewed by a cloud function.
const char* SAS_TOKEN = "SharedAccessSignature sr=YOUR_SHARED_ACCESS_SIGNATURE"; // <<< CHANGE THIS
const char* MQTT_USER = IOT_HUB_HOSTNAME "/" DEVICE_ID "/api-version=2021-04-12"; // Azure IoT Hub MQTT username
const char* MQTT_PASS = SAS_TOKEN; // Azure IoT Hub MQTT password (SAS token)
const char* MQTT_TOPIC = "devices/" DEVICE_ID "/messages/events/"; // Telemetry data sending topic

// GPRS connection information
const char apn[]  = "YOUR_APN";       // <<< CHANGE THIS (Your mobile operator's APN)
const char gprsUser[] = "";           // APN username (usually left blank)
const char gprsPass[] = "";           // APN password (usually left blank)

// Hardware Objects
TinyGsm modem(Serial1); // Serial port for RAK3372 modem (UART1)
TinyGsmClient client(modem); // TinyGSM client (TCP connection via modem)
PubSubClient mqttClient(client); // MQTT client

Adafruit_BME680 bme; // RAK1906 (BME680) environmental sensor object

// Timer Variables
long lastSendTime = 0;
const long sendInterval = 60000; // Data transmission interval: 1 minute (60 * 1000 ms)

void setup() {
  // Start serial communication (for debug messages)
  Serial.begin(115200);
  while (!Serial); // Wait for serial port to be ready
  Serial.println("Machine Health Monitoring Starting...");

  // Set vibration sensor pin as input
  pinMode(VIBRATION_SENSOR_PIN, INPUT);

  // Initialize RAK1906 (BME680) sensor
  Wire.begin(); // Start I2C communication
  if (!bme.begin(0x76)) { // I2C address is typically 0x76 or 0x77.
    Serial.println("RAK1906 BME680 not found, check connection!");
    while (1); // Stay in infinite loop if initialization fails
  }
  // Temperature oversampling setting for BME680
  bme.setTemperatureOversampling(BME680_OS_8X);
  Serial.println("RAK1906 BME680 successfully initialized.");

  // Initialize RAK3372 modem
  Serial1.begin(115200); // Set UART1 speed for RAK3372
  delay(100); // Small delay for modem to start
  Serial.println("Modem initializing...");
  modem.restart(); // Restart modem
  Serial.print("Modem Info: ");
  Serial.println(modem.getModemInfo()); // Get modem information

  // Try to connect to GPRS network
  Serial.print("Connecting to GPRS network...");
  if (!modem.gprsConnect(apn, gprsUser, gprsPass)) {
    Serial.println("GPRS connection failed! Please check APN settings and SIM card.");
    while (true); // Stay in infinite loop if connection fails
  }
  Serial.println("GPRS connection successful!");

  // Set MQTT Callback (for Cloud-to-Device (C2D) messages)
  mqttClient.setCallback(mqttCallback);
  // Set MQTT server connection details (Azure IoT Hub)
  mqttClient.setServer(IOT_HUB_HOSTNAME, 8883); // TLS port for Azure IoT Hub is typically 8883

  connectMqtt(); // Try to connect to MQTT broker
  lastSendTime = millis(); // Initialize timer
}

void loop() {
  modem.maintainConnections(); // Keep GPRS connection active

  // Run MQTT client loop (to send and receive messages)
  if (!mqttClient.connected()) {
    connectMqtt(); // Try to reconnect if disconnected
  }
  mqttClient.loop();

  // Check if it's time to send data
  if (millis() - lastSendTime > sendInterval) {
    sendData();       // Send sensor data
    lastSendTime = millis(); // Reset timer
  }
}

// Function to manage connecting to MQTT broker
void connectMqtt() {
  Serial.print("Connecting to MQTT...");
  // Stay in loop until connection is successful
  while (!mqttClient.connected()) {
    // Connect to MQTT with device ID, username, and password (SAS token)
    // Username and password are in the format required by Azure IoT Hub.
    if (mqttClient.connect(DEVICE_ID, MQTT_USER, MQTT_PASS)) {
      Serial.println("connected.");
      // Subscribe to the relevant topic for Cloud-to-Device (C2D) messages
      mqttClient.subscribe("devices/" DEVICE_ID "/messages/devicebound/#");
    } else {
      Serial.print("failed, rc=");
      Serial.print(mqttClient.state()); // Print error code
      Serial.println(" trying again in 5 seconds");
      delay(5000); // Wait before retrying
    }
  }
}

// Callback function to process incoming messages (downlink) via MQTT
void mqttCallback(char* topic, byte* payload, unsigned int length) {
  Serial.print("Message Received from Cloud - Topic: ");
  Serial.println(topic);
  Serial.print("Message: ");
  for (int i = 0; i < length; i++) {
    Serial.print((char)payload[i]);
  }
  Serial.println();
  // You can add code here to make the device (e.g., relay, LED) react to incoming commands.
}

// Function to collect sensor data and send it to Azure IoT Hub
void sendData() {
  // Get temperature reading from RAK1906
  bme.performReading();
  float temperature = bme.temperature; // Temperature value

  // Read vibration data and calculate RMS value (simple example)
  // For a real vibration sensor (RAK12027), more advanced signal processing or
  // direct use of data provided by the sensor might be necessary.
  int numSamples = 100; // Number of samples
  long sumSq = 0;      // Sum of squares
  for (int i = 0; i < numSamples; i++) {
    int rawValue = analogRead(VIBRATION_SENSOR_PIN); // Read analog vibration value
    sumSq += (long)rawValue * rawValue; // Sum their squares
    delay(1); // Small delay between readings
  }
  float rmsVibration = sqrt((float)sumSq / numSamples); // Calculate RMS (Root Mean Square)

  // Print read data to Serial Monitor
  Serial.printf("Temperature: %.2f C, RMS Vibration: %.2f\n", temperature, rmsVibration);

  // Create a JSON formatted payload
  // This format can be easily processed by Azure IoT Hub.
  String jsonPayload = "{\"temperature\":";
  jsonPayload += String(temperature, 2); // 2 decimal places
  jsonPayload += ",\"rms_vibration\":";
  jsonPayload += String(rmsVibration, 2); // 2 decimal places
  jsonPayload += "}";

  Serial.print("Sending Data: ");
  Serial.println(jsonPayload);

  // Publish the created JSON payload to the relevant topic in Azure IoT Hub
  if (mqttClient.publish(MQTT_TOPIC, jsonPayload.c_str())) {
    Serial.println("Data successfully sent to Azure IoT Hub.");
  } else {
    Serial.println("Data sending failed!");
  }
}
