JACK is the Bot

A small autonomous car with the capability to stay within the blue lines on the lab floor and stop when encountering red construction paper.

IntermediateFull instructions provided3 days55
JACK is the Bot

Things used in this project

Hardware components

Raspberry Pi 5
Raspberry Pi 5
×1
Logitech C270 HD Webcam
×1
Portable Phone Charger
×1
RC Car Chassis
×1
Standard LCD - 16x2 White on Blue
Adafruit Standard LCD - 16x2 White on Blue
×1
Speed Encoder
×1
7.4V Li-poly battery
×2
Battery charging cable
×1
USB-A to Micro-USB Cable
USB-A to Micro-USB Cable
×1

Software apps and online services

OpenCV
OpenCV

Hand tools and fabrication machines

Cardboard Box
Tape, Clear
Tape, Clear
Scissor, Electrician
Scissor, Electrician

Story

Read more

Schematics

Raspberry Pi 5 BCM Pinout

This is the pinout we used for this project

Code

main.py

Python
Main program that runs the computer with computer vision to detect lanes, speed control based on the encoder, and PD steering control for lane-keeping
#  ============= REFERENCES =============
# 1- (Credit to Dreamhouse for putting together references 2, 3, and 4)https://www.hackster.io/team-elec424-dreamhouse/team-elec424-dreamhouse-c5ad62
# 2- (Computer Vision) https://www.instructables.com/Autonomous-Lane-Keeping-Car-Using-Raspberry-Pi-and/
# 3- (Main Loop Logic) https://www.hackster.io/really-bad-idea/autonomous-path-following-car-6c4992
# 4- (Stop detection/Driver) https://www.hackster.io/colonel-hackers/autonomous-rc-car-elec-424-final-project-732fd1
# 5- MEGG car: For the simplified encoder adjustment logic https://www.hackster.io/m-e-g-g/the-magnificent-m-e-g-g-car-28ec89

# Import Packages
import cv2
import numpy as np
import matplotlib.pyplot as plt
import math
import time
import os
import RPi.GPIO as GPIO

GPIO.setmode(GPIO.BCM) #Use Broadcom pin numbering system

#Setup pins as output
GPIO.setup(18, GPIO.OUT)
GPIO.setup(19, GPIO.OUT)

#Creates PWMs for speed and steering at 50Hz
speed = GPIO.PWM(18, 50)
steer = GPIO.PWM(19, 50)
speed.start(7.5) #Neutral (stop) speed
steer.start(7.5) #Neutral (straight) steer

#Constants for encoding (tuned to our car)
speed_encode = True

#  ============= ENCODER CONSTANTS =============
encoder_path = "/sys/module/gpiod_driver_encoder/parameters/encoder_val" #Accesses time lapsed measured by encoder
encoder_max_rotation = 6400000 #max speed
encoder_min_rotation = 8700000 #min speed

# Camera
frame_width = 160
frame_height = 120
cam_idx = 0

# PD Variables for Lanekeeping
kp = 0.07 #proportional gain
kd = kp * 0.5 #derivative gain

# Speed Values
zero_speed = 7.5
base_speed = 7.95 # Slowed to keep car stable
speed_change = 0.001 #How much speed is adjusted if encoder detects a discrepancy
zero_turn = 7.5

global_enc_vals = []

# Max number of loop
max_ticks = 4000

class NotSudo(Exception):
    pass

def reset_car():
    # Updated from the old Adafruit DAC syntax to use GPIO and PWM
    # set speed to zero and steering to neutral
    speed.ChangeDutyCycle(7.5) #puts DC motor on neutral
    steer.ChangeDutyCycle(7.5) #servo straight
    #print("Car: stopped & straightened")

def start_car():
    #Updated from the old Adafruit DAC syntax to use GPIO and PWM
    # Set speed to base speed and steering to neutral
    print("==== READY =====")
    speed.ChangeDutyCycle(base_speed) #puts DC motor on neutral
    steer.ChangeDutyCycle(7.5) #servo straight

def manage_speed():
    # Adjust the speed based on the speed encoder
    # read the sysfs parameter with the encoder data
    f = open(encoder_path, "r")
    enc = int(f.readline()) #value frome encoder
    f.close()
    ret = enc

    global_enc_vals.append(enc)

    # If within bounds (wait for car to start / stop)
    ret = 0 #no speed change
    if enc <= encoder_max_rotation: #Encoder time lapses are too short, car is too fast
        ret = -(speed_change) #reduce speed
    elif enc >= encoder_min_rotation: #too slow
        ret = (speed_change) #increase speed
    return ret

def wait(wait_time):
    # Wait for a period of time
    start_time = time.perf_counter() # start
    end_time = start_time + wait_time # end
    # loop until finished
    while (time.perf_counter() < end_time):
        pass
    return

def detect_edges(frame):
    # Detetct the blue lines
    # filter for blue lane lines
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)

    # This color values were adjusted from Paul Walker Team code
    lower_blue = np.array([90, 50, 50], dtype="uint8")
    upper_blue = np.array([130, 255, 255], dtype="uint8")

    # make mask
    mask = cv2.inRange(hsv, lower_blue, upper_blue)

    # Get edges
    edges = cv2.Canny(mask, 50, 100)
    return edges

def region_of_interest(edges):
    # Find region to look at
    height, width = edges.shape
    mask = np.zeros_like(edges)

    # only focus lower half of the screen
    polygon = np.array([[
        (0, height),
        (0, height / 2),
        (width, height / 2),
        (width, height),
    ]], np.int32)

    cv2.fillPoly(mask, polygon, 255)

    # Get region to look at
    cropped_edges = cv2.bitwise_and(edges, mask)

    return cropped_edges

def detect_line_segments(cropped_edges):
    # Find line segments

    # set constants
    rho = 1
    theta = np.pi / 180
    min_threshold = 10

    #get lines
    line_segments = cv2.HoughLinesP(cropped_edges, rho, theta, min_threshold,
                                    np.array([]), minLineLength=5, maxLineGap=150)

    return line_segments

def average_slope_intercept(frame, line_segments):
    # finding slope of the line
    lane_lines = []

    if line_segments is None:
        print("No line segments detected")

        return lane_lines

    # set boundaries
    height, width, _ = frame.shape
    left_fit = []
    right_fit = []
    boundary = 1 / 3
    left_region_boundary = width * (1 - boundary)
    right_region_boundary = width * boundary

    # go through line segments and get line of best fit
    for line_segment in line_segments:
        for x1, y1, x2, y2 in line_segment:
            if x1 == x2:
                continue

            fit = np.polyfit((x1, x2), (y1, y2), 1)
            slope = (y2 - y1) / (x2 - x1)
            intercept = y1 - (slope * x1)

            if slope < 0:
                if x1 < left_region_boundary and x2 < left_region_boundary:
                    left_fit.append((slope, intercept))
            else:
                if x1 > right_region_boundary and x2 > right_region_boundary:
                    right_fit.append((slope, intercept))

    # take average line of best fit
    left_fit_average = np.average(left_fit, axis=0)
    if len(left_fit) > 0:
        lane_lines.append(make_points(frame, left_fit_average))

    right_fit_average = np.average(right_fit, axis=0)
    if len(right_fit) > 0:
        lane_lines.append(make_points(frame, right_fit_average))

    return lane_lines

def make_points(frame, line):
    # For getting visual of lines
    height, width, _ = frame.shape

    slope, intercept = line

    y1 = height  # bottom of the frame
    y2 = int(y1 / 2)  # make points from middle of the frame down

    if slope == 0:
        slope = 0.1

    x1 = int((y1 - intercept) / slope)
    x2 = int((y2 - intercept) / slope)

    return [[x1, y1, x2, y2]]

def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6):
    # Get visual of lines
    line_image = np.zeros_like(frame)

    if lines is not None:
        for line in lines:
            for x1, y1, x2, y2 in line:
                cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)

    line_image = cv2.addWeighted(frame, 0.8, line_image, 1, 1)

    return line_image

def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5):
    # Show a hedaing line
    heading_image = np.zeros_like(frame)
    height, width, _ = frame.shape

    steering_angle_radian = steering_angle / 180.0 * math.pi

    x1 = int(width / 2)
    y1 = height
    x2 = int(x1 - height / 2 / math.tan(steering_angle_radian))
    y2 = int(height / 2)

    cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)
    heading_image = cv2.addWeighted(frame, 0.8, heading_image, 1, 1)

    return heading_image

def get_steering_angle(frame, lane_lines):
    # Get the angle to steer towards
    height, width, _ = frame.shape

    if len(lane_lines) == 2:
        _, _, left_x2, _ = lane_lines[0][0]
        _, _, right_x2, _ = lane_lines[1][0]
        mid = int(width / 2)
        x_offset = (left_x2 + right_x2) / 2 - mid
        y_offset = int(height / 2)

    elif len(lane_lines) == 1:
        x1, _, x2, _ = lane_lines[0][0]
        x_offset = x2 - x1
        y_offset = int(height / 2)

    elif len(lane_lines) == 0:
        x_offset = 0
        y_offset = int(height / 2)

    angle_to_mid_radian = math.atan(x_offset / y_offset)
    angle_to_mid_deg = int(angle_to_mid_radian * 180.0 / math.pi)
    steering_angle = angle_to_mid_deg + 90

    return steering_angle

def plot_pd(p_vals, d_vals, error, show_img=False):
    # Plot the proportional, derivative and error
    fig, ax1 = plt.subplots()
    t_ax = np.arange(len(p_vals))
    ax1.plot(t_ax, p_vals, '-', label="P values")
    ax1.plot(t_ax, d_vals, '-', label="D values")
    ax2 = ax1.twinx()
    ax2.plot(t_ax, error, '--r', label="Error")

    ax1.set_xlabel("Frames")
    ax1.set_ylabel("PD Value")
    ax2.set_ylim(-90, 90)
    ax2.set_ylabel("Error Value")

    plt.title("PD Values over time")
    fig.legend()
    fig.tight_layout()
    plt.savefig("pd_plot.png")

    if show_img:
        plt.show()
    plt.clf()

def plot_pwm(speed_pwms, turn_pwms, error, show_img=False):
    # Plot teh speed steering and the error
    fig, ax1 = plt.subplots()
    t_ax = np.arange(len(speed_pwms))
    ax1.plot(t_ax, speed_pwms, '-', label="Speed")
    ax1.plot(t_ax, turn_pwms, '-', label="Steering")
    ax2 = ax1.twinx()


    ax1.plot(t_ax, error / np.max(error), '--r', label="Error")

    ax1.set_xlabel("Frames")
    ax1.set_ylabel("Speed and Steer Duty Cycle")
    ax2.set_ylabel("Percent Error Value")

    plt.title("Speed and Steer Duty Cycle, and error v.s. time")
    fig.legend()
    plt.savefig("voltage_plot.png")

    if show_img:
        plt.show()
    plt.clf()

# adapted from hackster, changed to adhere to red HSV color segments
def isRedFloorVisible(image):
    """
    Detects whether or not the majority of a color on the screen is a particular color
    :param image:
    :param boundaries: [[color boundaries], [success boundaries]]
    :return: boolean if image satisfies provided boundaries, and an image used for debugging
    """
    # Convert to HSV color space
    hsv_img = cv2.cvtColor(image, cv2.COLOR_BGR2HSV)

    cv2.imwrite("redfloor.jpg", hsv_img)

    # parse out the color boundaries and the success boundaries
    # percentage was adjusted
    #percentage = 25
    percentage = 4.5 #red_threshold

    # lower and upper range for the lower part of red
    lower_red1 = np.array([0, 40, 60], dtype="uint8")
    upper_red1 = np.array([10, 255, 255], dtype="uint8")

    # lower and upper range for the upper part of red
    lower_red2 = np.array([170, 40, 60], dtype="uint8")
    upper_red2 = np.array([180, 255, 255], dtype="uint8")

    # create two masks to capture both ranges of red
    mask1 = cv2.inRange(hsv_img, lower_red1, upper_red1)
    mask2 = cv2.inRange(hsv_img, lower_red2, upper_red2)

    # combining the masks
    mask = cv2.bitwise_or(mask1, mask2)

    # applying the mask
    output = cv2.bitwise_and(hsv_img, hsv_img, mask=mask)

    # save the output image
    cv2.imwrite("redfloormask.jpg", output)

    # calculating what percentage of image falls between color boundaries
    percentage_detected = np.count_nonzero(mask) * 100 / np.size(mask)
    # if the percentage percentage_detected is betweeen the success boundaries, we return true,
    # otherwise false for result
    result = percentage < percentage_detected
    if result:
        print(percentage_detected)
    return result, output


def main():
    #setup variables
    lastTime = 0
    lastError = 0
    SecondStopTick = 0


    # arrays for making the final graphs
    p_vals = [] # proportional
    d_vals = [] # Derivative
    err_vals_1 = [] # error
    err_vals_2 = [] # error #DELETE
    speed_vals = [] # speed values
    steer_vals = [] # steering values

    # set up video
    video = cv2.VideoCapture(cam_idx, cv2.CAP_V4L2)
    video.set(cv2.CAP_PROP_FRAME_WIDTH, frame_width)
    video.set(cv2.CAP_PROP_FRAME_HEIGHT, frame_height)

    #Starts car
    start_car()
    curr_speed = base_speed
    counter = 0

    passedFirstStopSign = False
    while counter < max_ticks:
           speed.ChangeDutyCycle(zero_speed)
           # manage video
           ret, original_frame = video.read()
           frame = cv2.resize(original_frame, (160, 120))

           # process the frame to determine the desired steering angle
           edges = detect_edges(frame)
           cv2.imshow("edges", edges)
           roi = region_of_interest(edges)
           line_segments = detect_line_segments(roi)
           lane_lines = average_slope_intercept(frame, line_segments)
           lane_lines_image = display_lines(frame, lane_lines)

           steering_angle = get_steering_angle(frame, lane_lines)
           heading_image = display_heading_line(lane_lines_image,steering_angle) #DELETE

           # calculate changes for PD
           now = time.time()
           dt = now - lastTime
           deviation = steering_angle - 90

           # PD Code
           error = deviation
           base_turn = 7.5
           proportional = kp * error
           derivative = kd * (error - lastError) / dt

           # take values for graphs
           p_vals.append(proportional)
           d_vals.append(derivative)
           err_vals_1.append(error)
           speed_vals.append(curr_speed)

           # determine actual turn to do
           turn_amt = base_turn + proportional + derivative
           steer_vals.append(turn_amt) #makes turn based on turn_amt
           steer.ChangeDutyCycle(turn_amt) #drives the DC motor (forward)

           # Stops if sees the red box
           if counter % 15: # looks every 20 ticks
                if not passedFirstStopSign:
                    isStopSign, floorSight = isRedFloorVisible(frame)

                    # Sees red box
                    if isStopSign:
                        wait(3)
                        passedFirstStopSign = True
                        SecondStopTick = counter

                # for last box (first sign was seen and enough time has passed)
                elif passedFirstStopSign and counter > SecondStopTick+70:
                    isStopSign, _ = isRedFloorVisible(frame)
                    if isStopSign:
                        #set_speed(zero_speed)
                        speed.ChangeDutyCycle(zero_speed)
                        print("Reached final stop")
                        break # Stop forever

           # speed encoding
           if speed_encode:
                if counter % 3 == 0: # Check every 3 ticks
                    # adjust speed
                    temp_speed = manage_speed() + curr_speed
                    if temp_speed != curr_speed:
                        speed.ChangeDutyCycle(temp_speed) #probably redundant
                        curr_speed = temp_speed

           speed.ChangeDutyCycle(curr_speed) #Go forward, this is base speed
           wait(0.023) # Run at speed for a short amount of time

           key = cv2.waitKey(1)
           if key == 27:
                break

           counter += 1

    # Reset car and close everything
    reset_car()
    video.release()
    cv2.destroyAllWindows()
    speed.stop()
    steer.stop()
    GPIO.cleanup()

    # save plots
    plot_pd(p_vals, d_vals, err_vals_1)
    plot_pwm(speed_vals, steer_vals, err_vals_1)

if __name__ == "__main__":
    main()

gpiod_driver_encoder.py

C/C++
This driver uses interrupts and button like logic to calculate the time interval between light flashes on the encoder; this is used to measure the actual speed of the car. The lapsed time value is constantly written to file that is later read by main.py for speed control.
#include <linux/module.h>
#include <linux/of_device.h>
#include <linux/of.h>
#include <linux/kernel.h>
#include <linux/gpio/consumer.h>
#include <linux/platform_device.h>
#include <linux/interrupt.h>
# include <linux/timekeeping.h>
# include <linux/ktime.h>
# include <linux/moduleparam.h>
/**
* AS CITED BY DREAMHOUSE GROUP:
* https://www.hackster.io/team-elec424-dreamhouse/team-elec424-dreamhouse-c5ad62
* Code from:  Haochen(Jason) Zhang, Ye Zhou, Konstantinos Alexopoulos
* Class: COMP 424 ELEC 424/553 001
* Final Project: Autonomous Car
* Fall 2023
*
* Interrupt code drawn from:
* https://github.com/Johannes4Linux/Linux_Driver_Tutorial/blob/main/11_gpio_irq/gpio_irq.c
**/



// Init variables
unsigned int irq_number;
static struct gpio_desc *my_enc;
static volatile u64 prev_time;
static volatile u64 curr_time;

static int encoder_val;
module_param(encoder_val, int, 0644);

// Interrupt Handler
static irqreturn_t gpio_irq_handler(int irq, void *dev_id) {

	// Ensure time difference between interrupts is greater than 1 ms
	int enc_val = gpiod_get_value(my_enc);
	curr_time = ktime_get_ns();
	unsigned long elapsed_time = curr_time - prev_time;
	if (enc_val == 1 && elapsed_time > 1000000) {
		prev_time = curr_time;
		encoder_val = elapsed_time;
		printk(KERN_INFO "irq_handler - timing detected: %lu", elapsed_time);
	}

	return IRQ_HANDLED;
}


// probe function
static int enc_probe(struct platform_device *pdev)
{
	//struct gpio_desc *my_btn;
	struct device *dev;
	dev = &pdev->dev;

	printk("enc_probe - RUNNING v5\n");

	// Get button
	my_enc = gpiod_get(dev, "lights2", GPIOD_IN);
	if(IS_ERR(my_enc)) {
		printk("enc_probe - could not gpiod_get_index 0 for btn\n");
		return -1;
	}

	// Setup interrupt & debounce
	irq_number = gpiod_to_irq(my_enc);
	gpiod_set_debounce(my_enc, 1000000);

	if(request_irq(irq_number, gpio_irq_handler, IRQF_TRIGGER_RISING, "my_gpio_irq", NULL) != 0){
		printk("Error!\nCan not request interrupt nr.: %d\n", irq_number);
		return -1;	}
	prev_time = ktime_get_ns();

	printk("enc_probe - SUCCESS\n");
	return 0;
}

// remove function
static void enc_remove(struct platform_device *pdev)
{
	free_irq(irq_number, NULL);
	printk("enc_remove - Freed interrupt & Removing\n");
	//return 0;
}

static struct of_device_id matchy_match[] = {
    { .compatible = "a_second_name", },
	{},
};

// platform driver object
static struct platform_driver my_driver = {
	.probe	 = enc_probe,
	.remove	 = enc_remove,
	.driver	 = {
	       .name  = "The Rock: this name doesn't even matter",
	       .owner = THIS_MODULE,
	       .of_match_table = matchy_match,
	},
};
module_platform_driver(my_driver);

MODULE_ALIAS("platform:my_driver");
MODULE_DESCRIPTION("424\'s finest");
MODULE_AUTHOR("MayaB, MichelleZ, FaithM, YurieH");
MODULE_LICENSE("GPL v2");

my_overlay.dts

C/C++
This is used to setup a device tree overlay to expose GPIO pin 5 to the kernel to detect light flashes from the speed encoder.
/dts-v1/;
/plugin/;

/ {
    fragment@0 {
        target-path ="/";
        __overlay__ {
            my_device_jerry {
                compatible = "a_second_name";
                lights2-gpios = <&gpio 5 0 >;
            };
        };
    };

};

Credits

Kelly Dahlin
1 project • 0 followers
Cindy Nguyen
1 project • 0 followers
Joanna Li
1 project • 0 followers
Annie Chen
0 projects • 0 followers
Thanks to raja_961.

Comments
