Serial Arduino (Control the PWM)

Using your computer to control the PWM value in your Arduino.

IntermediateFull instructions provided12,245
Serial Arduino (Control the PWM)

Things used in this project

Story

Read more

Code

Untitled file

Arduino
byte brightness = 0;
const int LED = 11;
void setup()
{
  Serial.begin(9600);
}

void loop()
{
  Serial.println("enter brightness %");
  while(Serial.available()==0)
  {
    // không làm gì cả
  }
  while(Serial.available()>0)
  {
    char ch = Serial.read();
    if(ch >= '0' && ch <='255')
    {
    //chuyển từ ASCII sang số thập phân
    brightness = brightness*10 + ch - '0';
    delay(5);//chờ tín hiệu tiếp theo được truyền qua cổng serial
             //KHÔNG THỂ THIẾU. Hãy thử bỏ dòng này bạn sẽ thấy điều khác biệt!
    }
    else
    {
    Serial.print(ch);
    Serial.println(":not valid");
    brightness = 0;
    }
  }
  // chặn giá trị brightness trong khoảng [0,100]
  brightness = constrain(brightness,0,100);
  // in ra giá trị brightness
  Serial.print("brightness = ");
  Serial.println(brightness);
  // chuyển đổi từ giá trị brightness sang PWM
  byte value = map(brightness,0,100,0,255);
  // bật LED với giá trị xung PWM (duty cycle) nhận được
  analogWrite(LED,value);
  // reset biến brightness về giá trị 0
  //để tiếp tục tính toán
  brightness = 0;
}
