import os, sys, io
import M5
from M5 import *
import m5ui
import lvgl as lv
from hardware import PWM
from hardware import Pin
import time
from hardware import I2C
from unit import Servos8Unit
page0 = None
switch0 = None
label0 = None
pwm19 = None
pwm27 = None
i2c0 = None
servos8_0 = None
import random
pitch = None
yaw = None
pulse = None
moving = None
def setup():
global page0, switch0, label0, pwm19, pwm27, i2c0, servos8_0, pitch, yaw, pulse, moving
M5.begin()
Widgets.setRotation(1)
m5ui.init()
page0 = m5ui.M5Page(bg_c=0xffffff)
switch0 = m5ui.M5Switch(x=92, y=79, w=132, h=66, bg_c=0xe7e3e7, bg_c_checked=0x2196f3, circle_c=0xffffff, parent=page0)
label0 = m5ui.M5Label("label0", x=66, y=44, text_c=0x000000, bg_c=0xffffff, bg_opa=0, font=lv.font_montserrat_14, parent=page0)
pitch = 80
yaw = 70
pwm19 = PWM(Pin(19), freq=50, duty=yaw)
pwm27 = PWM(Pin(27), freq=50, duty=pitch)
pulse = 1800
moving = True
switch0.set_state(lv.STATE.CHECKED, True)
i2c0 = I2C(0, scl=Pin(33), sda=Pin(32), freq=100000)
servos8_0 = Servos8Unit(i2c0, 0x25)
servos8_0.set_mode(3, 0)
servos8_0.set_mode(3, 1)
page0.screen_load()
def loop():
global page0, switch0, label0, pwm19, pwm27, i2c0, servos8_0, pitch, yaw, pulse, moving
M5.update()
yaw = random.randint(60, 80)
pitch = random.randint(78, 82)
pwm.duty(yaw)
pwm.duty(pitch)
time.sleep(1)
for pulse in range(1600, 2001, 10):
if not (switch0.has_state(lv.STATE.CHECKED)):
break
label0.set_text(str(pulse))
servos8_0.set_servo_pulse(pulse, 0)
servos8_0.set_servo_pulse(pulse, 1)
time.sleep_ms(40)
time.sleep(1.5)
for pulse in range(2000, 1599, -10):
if not (switch0.has_state(lv.STATE.CHECKED)):
break
label0.set_text(str(pulse))
servos8_0.set_servo_pulse(pulse, 0)
servos8_0.set_servo_pulse(pulse, 1)
time.sleep_ms(40)
time.sleep(1.5)
if __name__ == '__main__':
try:
setup()
while True:
loop()
except (Exception, KeyboardInterrupt) as e:
try:
m5ui.deinit()
from utility import print_error_msg
print_error_msg(e)
except ImportError:
print("please update to latest firmware")
