Getting Started with skiiiD Editor

skiiiD Editor, Development Board Firmware IDE

skiiiD Editor is based on skiiiD(Firmware Development Engine). Now, it is compatible with Arduino UNO and MEGA with 70+ components.

Operating System

• macOS
• Windows

How to Install

Visit Website https://skiiid.io to download install client.

How to Use

Create Project

You will see the start page when you launch skiiiD. In this page, you can create or open a project and select your board.

Step1. Select new button on the left-upper side of start page or press ctrl+N.

Step2. Select a board to start a project.

Add Components

In order to develop firmware you need to select components.

Step1. Click Plus '+' button On right side of client

Step2. Select components from the provided lists

Component libraries will be updated constantly. Please visitRequest Library Pagefor requesting components.

Step3. When click a component, configure pins, check funcitions and further information about the component.

Step4. Click Add button right below of the window.

(Extra. Connection Alert Feature)

Make sure all component signs are green. If the dot color is yellow, other component already use the pin.

Step5. Essential Code to implement component's function is auto-filled.

Code Auto-Complete

If a component is properly added, write component name. Available functions(preset code) are listed on editor.

The code is created by skiiiD team. For further information please visitskiiiD Libraries Page

Miscellaneous

Find and Replace Feature

Press ctrl+F for find and replace panel. It is available to find a word and replace it.

Keyboard Shortcut

Text Editing

ctrl+XCMD+x Cut highlighted text

ctrl+CCMD+C Copy highlighted text

ctrl+VCMD+V Paste highlighted text

ctrl+ACMD+A Select all text

ctrl+FCMD+F Open find and replace panel

ctrl+SPACECMD+SPACE Open auto-complete list

Fold / Unfold

ctrl+KCMD+K Fold / Unfold

ctrl+Shift+KCMD+Shift+K Fold / Unfold all

Release Note

October 16, 2019 (v0.1.11)

- Stabilized the process about resource download.

October 10, 2019 (v0.1.10)

- Fixed the bug that skiiiD was not working right after auto-update.

October 07, 2019 (v0.1.9)

- Added the Neopixel module's library for Maker Faire Seoul 2019.

- Improved the UX about auto-complete.

September 25, 2019 (v0.1.8)

- Supported the multi-language for library's tooltip(English, Korean).

- Added the sub function that display parameters to auto-complete.

August 30, 2019 (v0.1.7)

- Supported the new board(Arduino Nano).

August 22, 2019 (v0.1.6)

- Modified the process of pin recommendation and setting.

August 05, 2019 (v0.1.5)

- Supported the mac version.

- Modified the process for serial port.

- Moved the cursor into loop function when new project.

- Added the board change function.

June 05, 2019 (v0.1.4)

Bugfix

- Segment module didn't display the zero number.
- Modified the typo and UI.

May 31, 2019 (v0.1.3)

Bugfix

- Project was empty when new project without board select.

Added the library

- Servo motor

May 29, 2019 (v0.1.2)

Bugfix

- Tooltip didn't disappear sometimes.

Added Libraries

- Gyroscope Module (MPU6050)

May 17, 2019 (v0.1.1)

Bugfix

- Error occurred when compile the dot-matrix module.

May 17, 2019 (v0.1.0)

- Beta version

P.S.

This is beta version and it is free now. We are working on components and boards libraries. Feel free to use it and welcome to feedback.

email : contact@skiiid.io

or visit https://skiiid.io/contact/ and Need help tab.
