Hardware components | ||||||
| × | 1 | ||||
| × | 1 | ||||
| × | 1 | ||||
| × | 1 | ||||
| × | 1 | ||||
| × | 1 | ||||
Software apps and online services | ||||||
|
First step is to set up google assistant on Pi. You can follow any guide for that and the latest custom wake word guide also should be fine. Click here for that guide.
Step 2After setting up google assistant, replace the pre-existing pushtotalk Python file using this. You can find the pushtotalk file in /home/pi/env/lib/python3.4/site-packages/googlesamples/assistant/grpc
directory.
Download this bash script to easily run the pushtotalk Python script. Make it executable by running the following command in the terminal:
sudo chmod +x /pathtothebashscript/gassist-start.sh
Replace the pathtothebashscript with the path where you have the bash file.
Step 4Connect your IR sensor to Raspberry Pi. The attached connection diagram is for HS0038 IR sensor. Pin configuration may change from sensor to sensor, so make the suitable wiring changes.
Step 5Download this IR Sensor Python script and run it. Point a remote at the IR sensor and press any desired button. Make a note of the value and change it in the code as indicated in the video.
Step 6Download this bash script and make it executable just like how its done in step 2.
Now start the Google Assistant script first, and then the IR script, using the bash files.
Please note that when you start the IR script for first time, the google assistant may get automatically triggered and may go on a listening loop until a query is made. So, as soon as you start the IR script make a query to stop the recording loop.
#!/bin/sh
/home/pi/env/bin/python3 -u /home/pi/env/lib/python3.4/site-packages/googlesamples/assistant/grpc/pushtotalk.py
import RPi.GPIO as GPIO
from time import time, sleep
GPIO_GASSIST =17
def setup():
GPIO.setmode(GPIO.BCM)
GPIO.setup(17, GPIO.OUT)
GPIO.output(GPIO_GASSIST, True)
GPIO.setup(18, GPIO.IN, pull_up_down=GPIO.PUD_DOWN)
def binary_aquire(pin, duration):
t0 = time()
results = []
while (time() - t0) < duration:
results.append(GPIO.input(pin))
return results
def on_ir_receive(pinNo, bouncetime=150):
data = binary_aquire(pinNo, bouncetime/1000.0)
if len(data) < bouncetime:
return
rate = len(data) / (bouncetime / 1000.0)
pulses = []
i_break = 0
for i in range(1, len(data)):
if (data[i] != data[i-1]) or (i == len(data)-1):
pulses.append((data[i-1], int((i-i_break)/rate*1e6)))
i_break = i
outbin = ""
for val, us in pulses:
if val != 1:
continue
if outbin and us > 2000:
break
elif us < 1000:
outbin += "0"
elif 1000 < us < 2000:
outbin += "1"
try:
return int(outbin, 2)
except ValueError:
return None
if __name__ == "__main__":
setup()
try:
print("IR Sensor Started")
while True:
print("Listening for IR Signal on GPIO 18")
GPIO.wait_for_edge(18, GPIO.FALLING)
code = on_ir_receive(18)
if code:
print(str((code)))
if code==58016:
GPIO.output(GPIO_GASSIST, False)
sleep(0.3)
GPIO.output(GPIO_GASSIST, True)
else:
pass
else:
print("Invalid code")
except KeyboardInterrupt:
pass
except RuntimeError:
pass
print("Stopping IR Sensor")
#!/bin/sh
sudo python /home/pi/GassistPi/custom-wakeword/Triggers/IR-Sensor.py
# Copyright (C) 2017 Google Inc.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
"""Sample that implements gRPC client for Google Assistant API."""
import json
import logging
import os.path
import RPi.GPIO as GPIO
import click
import grpc
import google.auth.transport.grpc
import google.auth.transport.requests
import google.oauth2.credentials
from google.assistant.embedded.v1alpha1 import embedded_assistant_pb2
from google.rpc import code_pb2
from tenacity import retry, stop_after_attempt, retry_if_exception
try:
from . import (
assistant_helpers,
audio_helpers
)
except SystemError:
import assistant_helpers
import audio_helpers
ASSISTANT_API_ENDPOINT = 'embeddedassistant.googleapis.com'
END_OF_UTTERANCE = embedded_assistant_pb2.ConverseResponse.END_OF_UTTERANCE
DIALOG_FOLLOW_ON = embedded_assistant_pb2.ConverseResult.DIALOG_FOLLOW_ON
CLOSE_MICROPHONE = embedded_assistant_pb2.ConverseResult.CLOSE_MICROPHONE
DEFAULT_GRPC_DEADLINE = 60 * 3 + 5
GPIO.setmode(GPIO.BCM)
GPIO.setup(17, GPIO.IN, pull_up_down=GPIO.PUD_UP)
GPIO.setup(24, GPIO.OUT)
GPIO.setup(27, GPIO.OUT)
class SampleAssistant(object):
"""Sample Assistant that supports follow-on conversations.
Args:
conversation_stream(ConversationStream): audio stream
for recording query and playing back assistant answer.
channel: authorized gRPC channel for connection to the
Google Assistant API.
deadline_sec: gRPC deadline in seconds for Google Assistant API call.
"""
def __init__(self, conversation_stream, channel, deadline_sec):
self.conversation_stream = conversation_stream
# Opaque blob provided in ConverseResponse that,
# when provided in a follow-up ConverseRequest,
# gives the Assistant a context marker within the current state
# of the multi-Converse()-RPC "conversation".
# This value, along with MicrophoneMode, supports a more natural
# "conversation" with the Assistant.
self.conversation_state = None
# Create Google Assistant API gRPC client.
self.assistant = embedded_assistant_pb2.EmbeddedAssistantStub(channel)
self.deadline = deadline_sec
def __enter__(self):
return self
def __exit__(self, etype, e, traceback):
if e:
return False
self.conversation_stream.close()
def is_grpc_error_unavailable(e):
is_grpc_error = isinstance(e, grpc.RpcError)
if is_grpc_error and (e.code() == grpc.StatusCode.UNAVAILABLE):
logging.error('grpc unavailable error: %s', e)
return True
return False
@retry(reraise=True, stop=stop_after_attempt(3),
retry=retry_if_exception(is_grpc_error_unavailable))
def converse(self):
"""Send a voice request to the Assistant and playback the response.
Returns: True if conversation should continue.
"""
continue_conversation = False
self.conversation_stream.start_recording()
GPIO.output(27,GPIO.LOW)
GPIO.output(24,GPIO.HIGH)
logging.info('Recording audio request.')
def iter_converse_requests():
for c in self.gen_converse_requests():
assistant_helpers.log_converse_request_without_audio(c)
yield c
self.conversation_stream.start_playback()
# This generator yields ConverseResponse proto messages
# received from the gRPC Google Assistant API.
for resp in self.assistant.Converse(iter_converse_requests(),
self.deadline):
assistant_helpers.log_converse_response_without_audio(resp)
if resp.error.code != code_pb2.OK:
logging.error('server error: %s', resp.error.message)
break
if resp.event_type == END_OF_UTTERANCE:
logging.info('End of audio request detected')
self.conversation_stream.stop_recording()
if resp.result.spoken_request_text:
logging.info('Transcript of user request: "%s".',
resp.result.spoken_request_text)
logging.info('Playing assistant response.')
if len(resp.audio_out.audio_data) > 0:
GPIO.output(24,GPIO.LOW)
GPIO.output(27,GPIO.HIGH)
self.conversation_stream.write(resp.audio_out.audio_data)
if resp.result.spoken_response_text:
logging.info(
'Transcript of TTS response '
'(only populated from IFTTT): "%s".',
resp.result.spoken_response_text)
if resp.result.conversation_state:
self.conversation_state = resp.result.conversation_state
if resp.result.volume_percentage != 0:
self.conversation_stream.volume_percentage = (
resp.result.volume_percentage
)
if resp.result.microphone_mode == DIALOG_FOLLOW_ON:
continue_conversation = True
logging.info('Expecting follow-on query from user.')
elif resp.result.microphone_mode == CLOSE_MICROPHONE:
continue_conversation = False
GPIO.output(27,GPIO.LOW)
GPIO.output(24,GPIO.LOW)
logging.info('Finished playing assistant response.')
self.conversation_stream.stop_playback()
return continue_conversation
def gen_converse_requests(self):
"""Yields: ConverseRequest messages to send to the API."""
converse_state = None
if self.conversation_state:
logging.debug('Sending converse_state: %s',
self.conversation_state)
converse_state = embedded_assistant_pb2.ConverseState(
conversation_state=self.conversation_state,
)
config = embedded_assistant_pb2.ConverseConfig(
audio_in_config=embedded_assistant_pb2.AudioInConfig(
encoding='LINEAR16',
sample_rate_hertz=self.conversation_stream.sample_rate,
),
audio_out_config=embedded_assistant_pb2.AudioOutConfig(
encoding='LINEAR16',
sample_rate_hertz=self.conversation_stream.sample_rate,
volume_percentage=self.conversation_stream.volume_percentage,
),
converse_state=converse_state
)
# The first ConverseRequest must contain the ConverseConfig
# and no audio data.
yield embedded_assistant_pb2.ConverseRequest(config=config)
for data in self.conversation_stream:
# Subsequent requests need audio data, but not config.
yield embedded_assistant_pb2.ConverseRequest(audio_in=data)
@click.command()
@click.option('--api-endpoint', default=ASSISTANT_API_ENDPOINT,
metavar='<api endpoint>', show_default=True,
help='Address of Google Assistant API service.')
@click.option('--credentials',
metavar='<credentials>', show_default=True,
default=os.path.join(click.get_app_dir('google-oauthlib-tool'),
'credentials.json'),
help='Path to read OAuth2 credentials.')
@click.option('--verbose', '-v', is_flag=True, default=False,
help='Verbose logging.')
@click.option('--input-audio-file', '-i',
metavar='<input file>',
help='Path to input audio file. '
'If missing, uses audio capture')
@click.option('--output-audio-file', '-o',
metavar='<output file>',
help='Path to output audio file. '
'If missing, uses audio playback')
@click.option('--audio-sample-rate',
default=audio_helpers.DEFAULT_AUDIO_SAMPLE_RATE,
metavar='<audio sample rate>', show_default=True,
help='Audio sample rate in hertz.')
@click.option('--audio-sample-width',
default=audio_helpers.DEFAULT_AUDIO_SAMPLE_WIDTH,
metavar='<audio sample width>', show_default=True,
help='Audio sample width in bytes.')
@click.option('--audio-iter-size',
default=audio_helpers.DEFAULT_AUDIO_ITER_SIZE,
metavar='<audio iter size>', show_default=True,
help='Size of each read during audio stream iteration in bytes.')
@click.option('--audio-block-size',
default=audio_helpers.DEFAULT_AUDIO_DEVICE_BLOCK_SIZE,
metavar='<audio block size>', show_default=True,
help=('Block size in bytes for each audio device '
'read and write operation..'))
@click.option('--audio-flush-size',
default=audio_helpers.DEFAULT_AUDIO_DEVICE_FLUSH_SIZE,
metavar='<audio flush size>', show_default=True,
help=('Size of silence data in bytes written '
'during flush operation'))
@click.option('--grpc-deadline', default=DEFAULT_GRPC_DEADLINE,
metavar='<grpc deadline>', show_default=True,
help='gRPC deadline in seconds')
@click.option('--once', default=False, is_flag=True,
help='Force termination after a single conversation.')
def main(api_endpoint, credentials, verbose,
input_audio_file, output_audio_file,
audio_sample_rate, audio_sample_width,
audio_iter_size, audio_block_size, audio_flush_size,
grpc_deadline, once, *args, **kwargs):
"""Samples for the Google Assistant API.
Examples:
Run the sample with microphone input and speaker output:
$ python -m googlesamples.assistant
Run the sample with file input and speaker output:
$ python -m googlesamples.assistant -i <input file>
Run the sample with file input and output:
$ python -m googlesamples.assistant -i <input file> -o <output file>
"""
# Setup logging.
logging.basicConfig(level=logging.DEBUG if verbose else logging.INFO)
# Load OAuth 2.0 credentials.
try:
with open(credentials, 'r') as f:
credentials = google.oauth2.credentials.Credentials(token=None,
**json.load(f))
http_request = google.auth.transport.requests.Request()
credentials.refresh(http_request)
except Exception as e:
logging.error('Error loading credentials: %s', e)
logging.error('Run google-oauthlib-tool to initialize '
'new OAuth 2.0 credentials.')
return
# Create an authorized gRPC channel.
grpc_channel = google.auth.transport.grpc.secure_authorized_channel(
credentials, http_request, api_endpoint)
logging.info('Connecting to %s', api_endpoint)
# Configure audio source and sink.
audio_device = None
if input_audio_file:
audio_source = audio_helpers.WaveSource(
open(input_audio_file, 'rb'),
sample_rate=audio_sample_rate,
sample_width=audio_sample_width
)
else:
audio_source = audio_device = (
audio_device or audio_helpers.SoundDeviceStream(
sample_rate=audio_sample_rate,
sample_width=audio_sample_width,
block_size=audio_block_size,
flush_size=audio_flush_size
)
)
if output_audio_file:
audio_sink = audio_helpers.WaveSink(
open(output_audio_file, 'wb'),
sample_rate=audio_sample_rate,
sample_width=audio_sample_width
)
else:
audio_sink = audio_device = (
audio_device or audio_helpers.SoundDeviceStream(
sample_rate=audio_sample_rate,
sample_width=audio_sample_width,
block_size=audio_block_size,
flush_size=audio_flush_size
)
)
# Create conversation stream with the given audio source and sink.
conversation_stream = audio_helpers.ConversationStream(
source=audio_source,
sink=audio_sink,
iter_size=audio_iter_size,
sample_width=audio_sample_width,
)
with SampleAssistant(conversation_stream,
grpc_channel, grpc_deadline) as assistant:
# If file arguments are supplied:
# exit after the first turn of the conversation.
if input_audio_file or output_audio_file:
assistant.converse()
return
# If no file arguments supplied:
# keep recording voice requests using the microphone
# and playing back assistant response using the speaker.
# When the once flag is set, don't wait for a trigger. Otherwise, wait.
wait_for_user_trigger = not once
while True:
if wait_for_user_trigger:
input_state=GPIO.input(17)
if input_state == True:
continue
#click.pause(info='Press Enter to send a new request...')
continue_conversation = assistant.converse()
# wait for user trigger if there is no follow-up turn in
# the conversation.
wait_for_user_trigger = not continue_conversation
# If we only want one conversation, break.
if once and (not continue_conversation):
break
if __name__ == '__main__':
main()
Comments
