Servo Motor & Ultrasonic Sensor

Control the servo motor by using the ultrasonic sensor.

IntermediateShowcase (no instructions)133,452
Servo Motor & Ultrasonic Sensor

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
Breadboard (generic)
Breadboard (generic)
×1
Ultrasonic Sensor - HC-SR04 (Generic)
Ultrasonic Sensor - HC-SR04 (Generic)
×1
servo motor
×1
Jumper wires (generic)
Jumper wires (generic)
×9

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Schematics

schemetics of servo motor and ultra sonic sensor

Code

code of servo motor and ultra sonic sensor

EJS
#include <Servo.h>
Servo servo1;
int trigPin = 9;
int echoPin = 8;
long distance;
long duration;

void setup()
{
servo1.attach(7);
 pinMode(trigPin, OUTPUT);
 pinMode(echoPin, INPUT);// put your setup code here, to run once:
}

void loop() {
  ultra();
  servo1.write(0);
  if(distance <= 10){
  servo1.write(90);
  }
}

void ultra(){
  digitalWrite(trigPin, LOW);
  delayMicroseconds(2);
  digitalWrite(trigPin, HIGH);
  delayMicroseconds(10);
  digitalWrite(trigPin, LOW);
  duration = pulseIn(echoPin, HIGH);
  distance = duration*0.034/2;
  }
