Building the Wooden BoardTo see how to build the physical board with detailed instructions and pictures click here.
Adding the Components to the BoardTo see how to add all components to the physical board with detailed instructions and pictures, click here.
Wiring the Components to the BeagleBone Green WirelessPin Connections by Component
Step 1: Ensure that python3 is installed on your BeagleBone. The way it gets installed may vary depending on what version of linux you are using.
Step 2 : On your BeagleBone, checkout the project repository under the Code section
git clone https://github.com/steffygm/ECE434_project
cd ECE434_project
Step 3: Run the install script to install all of the necessary libraries
./install.sh
How to UseGo into the project folder, run the setup script, and then run the paper_football program.
cd ECE434_project
./setup.sh
sudo python paper_football.py
HighlightsTo see how the advanced features of our project work, presented in an exhilarating way click here!
