Roger Alvarez
Published © GPL3+

Hospital baby Data stuff

A joined project between two high school students that shows the amount of babies born today by altering visual aspect of an art scene

IntermediateShowcase (no instructions)4 hours6
Hospital baby Data stuff

Things used in this project

Hardware components

SparkFun Solder-able Breadboard
SparkFun Solder-able Breadboard
×1
Photon 2
Particle Photon 2
×1
MAKERFACTORY Stepper-Motor VMA401
MAKERFACTORY Stepper-Motor VMA401
×1
WS2812B Digital RGB LED Flexi-Strip 144 LED - 1 Meter
Seeed Studio WS2812B Digital RGB LED Flexi-Strip 144 LED - 1 Meter
×1

Software apps and online services

Particle Build Web IDE
Particle Build Web IDE

Hand tools and fabrication machines

Premium Female/Male Extension Jumper Wires, 40 x 6" (150mm)
Premium Female/Male Extension Jumper Wires, 40 x 6" (150mm)
10 Pc. Jumper Wire Kit, 5 cm Long
10 Pc. Jumper Wire Kit, 5 cm Long

Story

Read more

Schematics

Rough Sketch of circuit diagram

Code

Art_Project_Thingy

C/C++
controls the stepper motor and the lights for the project. flash this to the photon 2 and create integrations in the particle integrations tab that collects data and replace the publish and subscribe parts of the code on lines 99 and 100 with your own.
// This #include statement was automatically added by the Particle IDE.
#include <Stepper.h>

// This #include statement was automatically added by the Particle IDE.
#include <neopixel.h>

// Include Particle Device OS APIs
#include "Particle.h"

// Let Device OS manage the connection to the Particle Cloud
SYSTEM_MODE(AUTOMATIC);

// IMPORTANT: Set pixel COUNT, PIN and TYPE
// MOSI pin MO
#define PIXEL_PIN SPI
#define PIXEL_COUNT 8
#define PIXEL_TYPE WS2812B

// motor controls
#define IN1 2
#define IN2 3
#define IN3 4
#define IN4 5

// Show system, cloud connectivity, and application logs over USB
// View logs with CLI using 'particle serial monitor --follow'
SerialLogHandler logHandler(LOG_LEVEL_INFO);
Adafruit_NeoPixel strip(PIXEL_COUNT, PIXEL_PIN, PIXEL_TYPE);
int maxStep=-5000;
int initmaxStep = 2048;
int lastStep = 0;
// Pins entered in sequence IN1-IN3-IN2-IN4 for proper step sequence
Stepper myStepper(initmaxStep, IN1, IN3 , IN2, IN4);

int oldTi=0;
int newTi=0;

// setup() runs once, when the device is first turned on

//Button Stuff
int butPin = 7;
int oldBut = 1;
int newBut = 1;

void setup() {
  // Put initialization like pinMode and begin functions here
  pinMode(1,OUTPUT);
  pinMode(butPin, INPUT_PULLUP);

  strip.begin();
  strip.show();
  Serial.begin(9600);
  for(int i=0;i<8;i++){
      strip.setPixelColor(i,255,255,255);
  }
  strip.show();

  while(Particle.disconnected()){}

  Serial.println("Particle connected to cloud!");
  myStepper.setSpeed(17);
  //myStepper.step(-5000);

  oldTi=(int) Time.now();
  //Serial.println("Working!");
  newTi=(int) Time.now();
  //delay(60000);
  //changeStuff(-1);
  /*int result = -1 * -2000;
  Serial.print("This Is The Result : ");
  Serial.print(result);*/

}

// loop() runs over and over again, as quickly as it can execute.
bool offBut=false;

void loop() {
  newBut=digitalRead(7);
  if(newBut==0 && oldBut==1){
      offBut=true;
      changeStuff(-1);
  }
  oldBut=newBut;

  //changeStuff(-1);
  // The core of your code will likely live here.
  //Particle.publish("Babies",getTime());
  //Particle.subscribe("hook-response/Babies", singleValueHandler);
  //changeStuff(1);
  //delay(120000);
  //Serial.println("Old Time: ");
  //Serial.print(oldTi);
  //Serial.println("New Time: ");
  //Serial.print(newTi);
  //   5 minute time check
  if((newTi - oldTi)>=30){
      if(offBut==false){
          Particle.publish("Babies",getTime());
          Particle.subscribe("hook-response/Babies", singleValueHandler);

      }
      //Serial.println("   Five Munites!!!    ");
      oldTi=newTi;
  }
  Serial.println("How many second passed: ");
  Serial.print(newTi-oldTi);
  newTi=(int) Time.now();
  delay(1000);

}

void singleValueHandler(const char *event, const char *data)
{
    String stock = data;
    double hee = stock.toFloat();
    Serial.print("    This is the market percent change:     ");
    Serial.println(hee);
    changeStuff(hee);
}

void changeStuff(double val){
    delay(500);
    Serial.print("made it to change stuff");
    double average = 1;
    double changeD = val/average;
    int changeI = changeD*100;
    if(changeI>100){
        changeI=100;
    }
    if(changeI<-100){
        changeI=-100;
    }
    Serial.print("Change percent: ");
    Serial.print(changeD);
    Serial.print("Int Change: ");
    Serial.print(changeI);
    Serial.print("MaxStep: ");
    Serial.print(maxStep);

    if(changeI>0){
        int ste =(maxStep*changeI);
        Serial.print("Steps: ");
        Serial.print(ste);
        ste=ste/100;
        Serial.print("ActualSteps: ");
        Serial.print(ste);
        Serial.print("Current Step: ");
        Serial.print((-1*lastStep));
        Serial.print("MoveStepsRelation: ");
        int stepRelation=ste+(-1*lastStep);
        Serial.print(stepRelation);
        myStepper.step(stepRelation);
        Serial.print("Reached");
        delay(500);
        lastStep=ste;
        for(int i=0;i<8;i++){
            strip.setPixelColor(i,255,255,255);
        }
        strip.show();
    }else{
        int lightc = ((255*changeI)/100);
        Serial.print("Blue and Green color: ");
        Serial.print(lightc);
        //decrease B and G in RGB
        for(int i=0;i<8;i++){
            strip.setPixelColor(i,255,lightc,lightc);
        }
        strip.show();
        //set stepper to origin
        Serial.print("current step on: ");
        Serial.print(lastStep);
        Serial.print("move step to set to origin: ");
        //What the line bellow should be: int test = (-1*lastStep);
        int test = (-1*lastStep);
        if(lastStep!=0){
            Serial.print(test);
            myStepper.step(test);
            lastStep=0;
        }

        Serial.println("This is last Step");
        Serial.print(test);
    }
    delay(500);
}

String getTime() {
    Time.zone(-6);
    int year = Time.year();
    int month = Time.month();
    int day = Time.day();
    String dayS = String(day);
    String monthS = String(month);
    if(day<10){
        dayS= "0"+String(day);
    }
    if(month<10){
        monthS= "0"+String(month);
    }
    String timeForm = String(year)+"-"+monthS+"-"+dayS;
    timeForm = "{\"minDate\":\"" + timeForm + "\"}";
    Serial.print(timeForm);
    return timeForm;
}

Credits

Roger Alvarez
2 projects • 0 followers
Thanks to Winnie, Technobly, and Ryan Orendorff.
