RC Renegades

# We took inspiration from the following sources for this code:
# User raja_961, "Autonomous Lane-Keeping Car Using Raspberry Pi and OpenCV". Instructables. URL: https://www.instructables.com/Autonomous-Lane-Keeping-Car-Using-Raspberry-Pi-and/
# Not Elecs: Autonomous Lane Keeping RC Car. URL: https://www.hackster.io/team-8-not-elecs/autonomous-lane-keeping-rc-car-b52ee7

import time
import RPi.GPIO as GPIO
from gpiozero import Servo
import cv2
import numpy as np
import math
import subprocess

#  SERVO SETUP
servo = Servo(19)

#  ESC SETUP
ESC_PIN = 18
GPIO.setmode(GPIO.BCM)
GPIO.setup(ESC_PIN, GPIO.OUT)
esc_pwm = GPIO.PWM(ESC_PIN, 50)
esc_pwm.start(0)

throttle_on = False

DUTY_NEUTRAL  = 7.5
DUTY_MAX_CAL  = 10.0
DUTY_MIN_CAL  = 5.0

# Speed control
# The car runs at different speeds depending on how straight it's going.
DUTY_STRAIGHT = 7.78   # throttle when error is small (going straight)
DUTY_TURNING  = 7.8   # throttle when turning
# Error threshold (degrees) below which we consider the car to be "going straight"
STRAIGHT_THRESHOLD = 10

#  THROTTLE CONTROL
def set_throttle(on, error=0):
    """
    Drive forward at a speed based on how straight we're going, or return to neutral if on=False.
    """
    global throttle_on
    if on:
        if abs(error) < STRAIGHT_THRESHOLD:
            duty = DUTY_STRAIGHT
        else:
            duty = DUTY_TURNING
        esc_pwm.ChangeDutyCycle(duty)

        speed_duty_vals.append(duty)  # data logging

    else:
        esc_pwm.ChangeDutyCycle(DUTY_NEUTRAL)
        speed_duty_vals.append(DUTY_NEUTRAL)  # data logging

    throttle_on = on

#  STEERING CONTROL
def set_servo_turn_amt(value):
    value = max(-1.0, min(1.0, value))
    servo.value = value
    steering_cmd_vals.append(value) # data logging


#  SPEED ENCODER
TARGET_MS = 80

def get_encoder_ms():
    try:
        result = subprocess.run(
            ['cat', '/sys/module/driver/parameters/diff'],
            capture_output=True, text=True
        )
        val = int(result.stdout.strip())
        return val if val > 0 else None
    except Exception:
        return None

#  LANE DETECTION
def detect_edges(frame):
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
    lower_blue = np.array([90, 120, 0],    dtype="uint8")
    upper_blue = np.array([120, 255, 255], dtype="uint8")
    mask = cv2.inRange(hsv, lower_blue, upper_blue)
    edges = cv2.Canny(mask, 50, 100)
    cv2.imshow("edges", edges)
    return edges


def detect_stop_sign(frame):
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
    lower_red1 = np.array([0, 100, 100], dtype="uint8")
    upper_red1 = np.array([10, 255, 255], dtype="uint8")
    lower_red2 = np.array([160, 100, 100], dtype="uint8")
    upper_red2 = np.array([180, 255, 255], dtype="uint8")
    mask1 = cv2.inRange(hsv, lower_red1, upper_red1)
    mask2 = cv2.inRange(hsv, lower_red2, upper_red2)
    mask = cv2.bitwise_or(mask1, mask2)
    num_red_px = cv2.countNonZero(mask)
    print("num_red_px:", num_red_px)
    return num_red_px >= 500

def region_of_interest(edges):
    height, width = edges.shape
    mask = np.zeros_like(edges)
    polygon = np.array([[
        (0,     height),
        (0,     height // 2),
        (width, height // 2),
        (width, height),
    ]], np.int32)
    cv2.fillPoly(mask, polygon, 255)
    cropped_edges = cv2.bitwise_and(edges, mask)
    cv2.imshow("roi", cropped_edges)
    return cropped_edges

def detect_line_segments(cropped_edges):
    rho = 1
    theta = np.pi / 180
    min_threshold = 10
    line_segments = cv2.HoughLinesP(
        cropped_edges, rho, theta, min_threshold,
        np.array([]), minLineLength=5, maxLineGap=0
    )
    return line_segments


def average_slope_intercept(frame, line_segments):
    lane_lines = []
    if line_segments is None:
        return lane_lines

    height, width, _ = frame.shape
    left_fit = []
    right_fit = []
    boundary = 1 / 3
    left_region_boundary = width * (1 - boundary)
    right_region_boundary = width * boundary

    for line_segment in line_segments:
        for x1, y1, x2, y2 in line_segment:
            if x1 == x2:
                continue
            slope = (y2 - y1) / (x2 - x1)
            intercept = y1 - (slope * x1)
            if slope < 0:
                if x1 < left_region_boundary and x2 < left_region_boundary:
                    left_fit.append((slope, intercept))
            else:
                if x1 > right_region_boundary and x2 > right_region_boundary:
                    right_fit.append((slope, intercept))

    if left_fit:
        lane_lines.append(make_points(frame, np.average(left_fit, axis=0)))
    if right_fit:
        lane_lines.append(make_points(frame, np.average(right_fit, axis=0)))

    return lane_lines
def make_points(frame, line):
    height, width, _ = frame.shape
    slope, intercept = line
    y1 = height
    y2 = int(y1 / 2)
    if slope == 0:
        slope = 0.1
    x1 = int((y1 - intercept) / slope)
    x2 = int((y2 - intercept) / slope)
    return [[x1, y1, x2, y2]]

def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6):
    line_image = np.zeros_like(frame)
    if lines is not None:
        for line in lines:
            for x1, y1, x2, y2 in line:
                cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)
    return cv2.addWeighted(frame, 0.8, line_image, 1, 1)

def get_steering_angle(frame, lane_lines):
    height, width, _ = frame.shape
    if len(lane_lines) == 2:
        _, _, left_x2,  _ = lane_lines[0][0]
        _, _, right_x2, _ = lane_lines[1][0]
        x_offset = (left_x2 + right_x2) / 2 - int(width / 2)
        y_offset = int(height / 2)
    elif len(lane_lines) == 1:
        x1, _, x2, _ = lane_lines[0][0]
        x_offset = x2 - x1
        y_offset = int(height / 2)
    else:
        x_offset = 0
        y_offset = int(height / 2)

    angle_to_mid_radian = math.atan(x_offset / y_offset)
    angle_to_mid_deg    = int(angle_to_mid_radian * 180.0 / math.pi)
    return angle_to_mid_deg + 90

def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5):
    heading_image = np.zeros_like(frame)
    height, width, _ = frame.shape
    steering_angle_radian = steering_angle / 180.0 * math.pi
    x1 = int(width / 2)
    y1 = height
    x2 = int(x1 - height / 2 / math.tan(steering_angle_radian))
    y2 = int(height / 2)
    cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)
    return cv2.addWeighted(frame, 0.8, heading_image, 1, 1)

#  CAMERA SETUP
def open_camera():
    for attempt in range(5):
        cap = cv2.VideoCapture(0)
        if cap.isOpened():
            cap.set(cv2.CAP_PROP_FRAME_WIDTH, 320)
            cap.set(cv2.CAP_PROP_FRAME_HEIGHT, 240)
            print(f"Camera opened on attempt {attempt+1}")
            return cap
        print(f"Camera attempt {attempt+1} failed, retrying...")
        time.sleep(1)
    return None

video = open_camera()
video.set(cv2.CAP_PROP_FRAME_WIDTH,  320)
video.set(cv2.CAP_PROP_FRAME_HEIGHT, 240)

#  PD CONTROLLER GAIN
kp = 0.39
kd = 0.04

STEERING_ALPHA = 0.4
last_turn_amt  = None

#  STOP SIGN STATE
stops        = 0
last_stopped = -1
COOLDOWN     = 20

#  DATA LOGGING
err_vals          = []
p_vals            = []
d_vals            = []
steering_pwm_data = []
speed_duty_vals   = []
steering_cmd_vals = []

#  MAIN LOOP SETUP
last_error  = 0
frame_count = 0
MAX_FRAMES  = 2000

#  ESC CALIBRATION + ARM
print("ESC ready. Starting self-driving loop. Press Esc to stop.")

last_cycle = time.time()
try:
    while frame_count < MAX_FRAMES:
        ret, frame = video.read()
        if not ret:
            print("Frame read failed, attempting reconnect...")
            video.release()
            time.sleep(1)
            video = open_camera()
            if video is None:
                print("Camera reconnect failed, exiting.")
                break
            last_cycle = time.time()
            last_error = 0
            last_turn_amt = None
            continue

        frame = cv2.flip(frame, 1)

        #  Lane detection pipeline
        edges = detect_edges(frame)
        roi = region_of_interest(edges)
        line_segments = detect_line_segments(roi)
        lane_lines = average_slope_intercept(frame, line_segments)
        lane_lines_image = display_lines(frame, lane_lines)
        steering_angle = get_steering_angle(frame, lane_lines)
        heading_image = display_heading_line(lane_lines_image, steering_angle)
        cv2.imshow("heading", heading_image)

        #  PD steering controller
        now = time.time()
        dt = now - last_cycle
        dt = max(0.001, min(dt, 0.1))

        deviation = steering_angle - 90
        error = -deviation
        proportional = kp * error
        derivative = kd * (error - last_error) / dt

        err_vals.append(error)
        p_vals.append(proportional)
        d_vals.append(derivative)
        steering_pwm_data.append(proportional + derivative)

        #  Throttle speed varies with how straight we're going
        # Pass current error so set_throttle can pick the right duty cycle.
        if not throttle_on:
            set_throttle(True, error)
        else:
            # Update duty cycle every frame even when already on
            set_throttle(True, error)
        #  Stop sign check (every 3rd frame)
        if frame_count % 3 == 0:
            if detect_stop_sign(frame):
                now_t = time.time()
                if last_stopped == -1 or (now_t - last_stopped) > COOLDOWN:
                    time.sleep(1)
                    stops += 1
                    set_throttle(False)
                    last_stopped = now_t
                    print(f"STOP #{stops} detected!")
                    if stops == 1:
                        print("Waiting 3 seconds then resuming...")
                        time.sleep(3)
                        set_throttle(True, 0)
                    elif stops >= 2:
                        print("Final stop reached. Exiting.")
                        break
                    last_cycle = time.time()
                    last_error = 0
                    last_turn_amt = None
                    continue

        #  Compute and apply steering
        raw_turn = proportional + derivative
        if abs(error) < 5:
            raw_turn = 0
        raw_turn = max(-1.0, min(0.5, raw_turn))

        if last_turn_amt is None:
            last_turn_amt = raw_turn

        turn_amt = STEERING_ALPHA * last_turn_amt + (1 -
                                                     STEERING_ALPHA) * raw_turn
        last_turn_amt = turn_amt

        speed_mode = "STRAIGHT" if abs(
            error) < STRAIGHT_THRESHOLD else "TURNING"
        print(
            f"Frame: {frame_count} | Err: {error:.1f} | Turn: {turn_amt:.3f} | Speed: {speed_mode}"
        )
        set_servo_turn_amt(turn_amt * 1.28)

        last_error = error
        last_cycle = now
        frame_count += 1

        key = cv2.waitKey(1)
        if key == 27:
            break

finally:
    print("Shutting down...")
    set_throttle(False)
    set_servo_turn_amt(0)
    esc_pwm.ChangeDutyCycle(DUTY_NEUTRAL)
    esc_pwm.stop()
    GPIO.cleanup()
    video.release()
    cv2.destroyAllWindows()

    # Verify all lists are the same length before plotting
    # We use the minimum length to avoid "x and y must have same first dimension" errors
    min_len = min(len(err_vals), len(steering_cmd_vals), len(speed_duty_vals), len(p_vals))

    frames = np.arange(min_len)
    d_err = np.array(err_vals[:min_len])
    d_steer = np.array(steering_cmd_vals[:min_len])
    d_speed = np.array(speed_duty_vals[:min_len])

    print(f"Plotting {min_len} data points...")

    import matplotlib
    matplotlib.use('Agg')
    import matplotlib.pyplot as plt

    # Plot 1: Error + Steering + Speed
    plt.figure(figsize=(10, 6))
    plt.plot(frames, d_err, label="Error (deg)")
    plt.plot(frames, d_steer, label="Steering Cmd (-1 to 1)")
    plt.plot(frames, d_speed, label="Speed Duty Cycle")
    plt.xlabel("Frame")
    plt.ylabel("Value")
    plt.legend()
    plt.title("Vehicle Control State")
    plt.grid(True)
    plt.savefig("plot1.png")
    plt.close()

    # Plot 2: PD Breakdown
    plt.figure(figsize=(10, 6))
    plt.plot(frames, d_err, label="Error", alpha=0.5)
    plt.plot(frames, p_vals[:min_len], label="Proportional (Kp)")
    plt.plot(frames, d_vals[:min_len], label="Derivative (Kd)")
    plt.xlabel("Frame")
    plt.legend()
    plt.title("PID Controller Performance")
    plt.grid(True)
    plt.savefig("plot2.png")
    plt.close()

    print("Plots saved successfully as plot1.png and plot2.png")
