Gravity Simon Game

LED-Matrix Simon Game with orientation-control (accelerometer ADXL335) and integrated sound.

IntermediateShowcase (no instructions)3,090

Things used in this project

Hardware components

Arduino Nano R3

LED Dot Matrix Display, Red

Resistor 475 ohm

Adafruit Analog Accelerometer: ADXL335

Tactile Switch, Top Actuated

Resistor 10k ohm

Speaker, Piezo

Solderless Breadboard Full Size

Story

Introduction

Simon Memory Game is an electronic board game invented by Ralph H. Baer and Howard J. Morrison launched in 1978 at Studio 54 in New York and also a symbol of the 70s and 80s pop culture. The gameplay is fairly simple: the device shows to the player a pattern of sounds and colored lights with different tempos, and the player needs to repeat the very same pattern pressing the lights in the correct order. Each round, the patterns become faster and more complex to follow.

Original Simon Game

Gravity Simon

This remake of the game uses an LED matrix to display 8 different patterns in the screen that are linked with 8 different musical notes (C3 to C4). After listening (and watching) a melody, the player needs to align the position of the breadboard with that from the listened melody to select an specific sound and then, click a button to record that sound. If they play all the sounds in the correct order the player wins the round and another level is loaded into the game.

Components and build

Before assemble all the components, it is important to identify the pin's identity in the LED matrix since both sides of the matrix contain column and row pins. All the columns have to be connected to the Arduino chip through 470 ohms resistors and both, column and row pins have to be connected to output pins in the chip.

The accelerometer (ADXL335) provides a reading of the gravity acceleration in each axis of the sensor. For this project, we only care about the angle that the z-axis projects into an horizontal plane. Therefore, we will use the reading of x and y inertial acceleration value and calculate the arctan of these two values to obtain the projection of z-axis. We will sample 10 values and average them to obtain a denoised result. We will power the sensor with 5V and connect the x and y pins to analog pins 6 and 7 since we only need to read these values.

Accelerometer detail and diagram

The button is connected with a pull-up resistor to pin 13 as a digital input due to the lack of space in the Arduino chip.

The speaker will be connected to any PWM pin in the chip so we can run it with the function tone/noTone() supplying the required sound frequency.

Code

The code makes use of numerous structs that allow the game to initialize the player status, the different game rounds, and also the state of the button every time the user pressed it. Each of the patterns displayed in the matrix are stored as an array of 8 byte elements where each element is an hexadecimal number that represents the LED to be light per row. This patterns are stored in an struct that also includes the in-screen time that each frame should be displayed, allowing us to build different animations with just a few patterns.

After creating some constant variables, the setup function initialize each component of the game: LED matrix, button, accelerometer, patterns, and the game (player's initial status and the different game rounds). The loop function calls the different modes of the game in order: introMode (an arrow that tells the user to press the button to start the game), readyMode (a backwards count), melodyMode (plays the melody), gameMode (checks the player's interactions for mistakes) and resultMode (shows a "correct" or "wrong" symbol to show the player's performance).

Auxiliary functions such as checking the game, read the position of the accelerometer, or the button, contain debouncing times to avoid noisy signals to trigger game changes.

We are also including a library with musical note frequencies for easy reference.

Code

// GRAVITY SIMON GAME
// This program will execute a remake version of Simon Game controlled with an
// accelerometer sensor and will display and play sounds accordingly to the
// orientation of the sensor.

// Created October 16, 2020
// by Policarpo Baquera
// Carnegie Mellon University
// More info at: https://create.arduino.cc/projecthub/plcrpbqr/gravity-simon-game-df5d00

/* //////////////////////////////////// ADXL335 SETUP //////////////////////////////////// */
#include "Arduino.h"
#include <math.h>
const byte pinX = A7;
const byte pinY = A6;
const int xMinVal = 289; const int yMinVal = 279; //const int zMinVal = 291;
const int xMaxVal = 424; const int yMaxVal = 416; //const int zMaxVal = 424;
int angle = 0;

/* //////////////////////////////////////// BUTTON /////////////////////////////////////// */
const byte pinButton = 13;

/* Struct to track and debounce the state of a push button switch */
typedef struct buttonTracker {
  int  lastReading;       // last raw value read
  long lastChangeTime;    // last time the raw value changed
  byte pin;               // the pin this is tracking changes on
  byte buttonState;       // debounced state of the button
} butt;

butt b;

/* /////////////////////////////////////// SPEAKER /////////////////////////////////////// */
#include"pitches.h"
const byte pinSpeaker = 10;
const int SCALE[8] = {NOTE_C3, NOTE_D3, NOTE_E3, NOTE_F3, NOTE_G3, NOTE_A3, NOTE_B3, NOTE_C4};
const int readyMelody[4]   = {NOTE_C3, NOTE_C3, NOTE_C3, NOTE_C4};
const int correctMelody[2] = {NOTE_B3, NOTE_C4};
const int wrongMelody[4]   = {NOTE_D3, NOTE_CS3};

/* /////////////////////////////////////// DISPLAY /////////////////////////////////////// */
/* LED Matrix pin values */
const byte pin01 = 6;
const byte pin02 = 7;
const byte pin03 = 8;
const byte pin04 = 9;
const byte pin05 = 2;
const byte pin06 = 3;
const byte pin07 = 4;
const byte pin08 = 5;
const byte pin09 = A0;
const byte pin10 = A1;
const byte pin11 = A2;
const byte pin12 = A3;
const byte pin13 = 12;
const byte pin14 = 11;
const byte pin15 = A4;
const byte pin16 = A5;

/* Define cols and rows pin values for LED Matrix */
#define SIZE 8
const byte COLS[8] = {pin05, pin02, pin07, pin01, pin12, pin08, pin14, pin09};
const byte ROWS[8] = {pin13, pin03, pin04, pin10, pin06, pin11, pin15, pin16};
      byte CROW    =  0;

/* Struct for animation frames */
typedef struct {
  byte *p;       // Hex Pattern
  int t;         // Animation time
} pattern;

/* Patterns */
byte ARRp[8]     = {0x18, 0x3C, 0x7E, 0xDB, 0x18, 0x18, 0x18, 0x18};
byte GOp[8]      = {0x00, 0x66, 0x99, 0xB9, 0x89, 0x99, 0x66, 0x00};
byte THREEp[8]   = {0x00, 0x38, 0x04, 0x04, 0x38, 0x04, 0x38, 0x00};
byte TWOp[8]     = {0x00, 0x3C, 0x10, 0x08, 0x04, 0x24, 0x18, 0x00};
byte ONEp[8]     = {0x00, 0x08, 0x08, 0x08, 0x28, 0x18, 0x08, 0x00};
byte CORRECTp[8] = {0x00, 0x00, 0x10, 0x28, 0x44, 0x02, 0x00, 0x00};
byte WRONGp[8]   = {0x00, 0x42, 0x24, 0x18, 0x18, 0x24, 0x42, 0x00};
byte C1p[8]      = {0xFF, 0xFF, 0xFF, 0x81, 0x81, 0x81, 0x81, 0xFF};
byte D1p[8]      = {0xFF, 0x8F, 0x87, 0x83, 0x81, 0x81, 0x81, 0xFF};
byte E1p[8]      = {0xFF, 0x87, 0x87, 0x87, 0x87, 0x87, 0x87, 0xFF};
byte F1p[8]      = {0xFF, 0x81, 0x81, 0x81, 0x83, 0x87, 0x8F, 0xFF};
byte G1p[8]      = {0xFF, 0x81, 0x81, 0x81, 0x81, 0xFF, 0xFF, 0xFF};
byte A1p[8]      = {0xFF, 0x81, 0x81, 0x81, 0xC1, 0xE1, 0xF1, 0xFF};
byte B1p[8]      = {0xFF, 0xE1, 0xE1, 0xE1, 0xE1, 0xE1, 0xE1, 0xFF};
byte C2p[8]      = {0xFF, 0xF1, 0xE1, 0xC1, 0x81, 0x81, 0x81, 0xFF};

/* Frames and animations */
pattern ARR1;        // ARROW 0.8s frame
pattern ARR2;        // ARROW 0.2s frame
pattern ARR[2];      // ARROW 1.0s animation
pattern GO;          // GO    1s frame
pattern THREE;       // THREE 1s frame
pattern TWO;         // TWO   1s frame
pattern ONE;         // ONE   1s frame
pattern COUNT[4];    // COUNT 4s animation
pattern CORRECT;     // CORRECT 2s frame
pattern WRONG;       // WRONG   2s frame
pattern noteC1;
pattern noteD1;
pattern noteE1;
pattern noteF1;
pattern noteG1;
pattern noteA1;
pattern noteB1;
pattern noteC2;
pattern NOTES[8];

/* //////////////////////////////////////// GAME ///////////////////////////////////////// */
/* Game state */
enum modes{introMode, readyMode, melodyMode, gameMode, resultMode};
enum modes state;
byte currentMelody;
int  currentNote;

/* Game rounds */
typedef struct{
  byte *notes;
  int *duration;
  int len;
} game;

game game1;
game game2;
game game3;
game game4;
game gameCollection[4];

/* Game melodies */
byte notes1[4] = {   0,    0,    4,    2};
int  durat1[4] = {1000, 1000, 1000, 1000};
byte notes2[5] = {   4,    1,    2,    5,    4};
int  durat2[5] = {1500,  500, 1000, 1000, 2000};
byte notes3[7] = {   1,    3,    1,    2,    0,    4,    7};
int  durat3[7] = { 800,  800,  800,  800,  800,  800,  800};
byte notes4[9] = {   0,    7,    6,    5,    4,    1,    2,    3,    4};
int  durat4[9] = {1000, 1000, 1500,  500,  500,  500,  500,  500, 1000};

/* Player status */
typedef struct playerTracker {
  byte lastReading;      // last raw value read
  long lastChangeTime;   // last time the raw value changed
  byte state;            // debounced state of the button
  bool success;
} player;

player p;

/* //////////////////////////////////////// SETUP //////////////////////////////////////// */
void setup() {
  // Button
  initButton(b, pinButton);
  // Accelerometer
  pinMode(pinX, INPUT);
  pinMode(pinY, INPUT);
  // Matrix setup and patterns
  initMatrix();
  initPatterns();
  initGame(p);
}

void initButton(butt &button, int pinButton) {
  pinMode(pinButton, INPUT);
  button.lastReading = digitalRead(pinButton);
  button.lastChangeTime = millis();
  button.pin = pinButton;
  button.buttonState = button.lastReading;
}

void initMatrix() {
  for(int i = 0; i < 8; i++) {
    pinMode(COLS[i], OUTPUT);
    pinMode(ROWS[i], OUTPUT);
  }
  for(int i = 0; i < SIZE; i++) {
    digitalWrite(COLS[i], LOW);
  }
  for(int i = 0; i < 8; i++) {
    digitalWrite(ROWS[i], HIGH);
  }
}

void initPatterns() {
  ARR1.p = ARRp; ARR1.t = 1000;
  ARR2.p = ARRp; ARR2.t = 500;
  ARR[0] = ARR1; ARR[1] = ARR2;
  GO.p = GOp; GO.t = 1000;
  THREE.p = THREEp; THREE.t = 1000;
  TWO.p = TWOp; TWO.t = 1000;
  ONE.p = ONEp; ONE.t = 1000;
  COUNT[0] = THREE; COUNT[1] = TWO; COUNT[2] = ONE; COUNT[3] = GO;
  CORRECT.p = CORRECTp; CORRECT.t = 2000;
  WRONG.p = WRONGp; WRONG.t = 2000;
  noteC1.p = C1p;
  noteD1.p = D1p;
  noteE1.p = E1p;
  noteF1.p = F1p;
  noteG1.p = G1p;
  noteA1.p = A1p;
  noteB1.p = B1p;
  noteC2.p = C2p;
  NOTES[0] = noteC1; NOTES[1] = noteD1; NOTES[2] = noteE1; NOTES[3] = noteF1;
  NOTES[4] = noteG1; NOTES[5] = noteA1; NOTES[6] = noteB1; NOTES[7] = noteC2;
}

void initGame(player &pl) {
  // Initialize the game
  state = introMode;
  currentMelody = 0;
  currentNote = 0;
  // Initialize player's status
  pl.lastReading = 0;
  pl.lastChangeTime = millis();
  pl.state = pl.lastReading;
  pl.success = false;       // false means the user has failed, true means he has succeed
  // Initialize game rounds and assign melodies
  game1.notes = notes1; game1.duration = durat1; game1.len = 4;
  game2.notes = notes2; game2.duration = durat2; game2.len = 5;
  game3.notes = notes3; game3.duration = durat3; game3.len = 7;
  game4.notes = notes4; game4.duration = durat4; game4.len = 9;
  gameCollection[0] = game1;
  gameCollection[1] = game2;
  gameCollection[2] = game3;
  gameCollection[3] = game4;
}

/* ///////////////////////////////////////// LOOP ///////////////////////////////////////// */
void loop() {
  if (state == introMode){
    introScreen();
    if (buttonPressed(b) == true) state = readyMode;
  }
  if (state == readyMode) {
    readyScreen();
    state = melodyMode;
  }
  if (state == melodyMode) {
    melodyScreen();
    state = gameMode;
  }
  if (state == gameMode) {
    gameScreen();
  }
  if (state == resultMode) {
    resultScreen();
    state = readyMode;
  }
}

void introScreen() {
  for (byte i = 0; i < 2; i++){
    unsigned long startTime = millis();
    while(ARR[i].t > ((millis() - startTime))) {
      if (i == 0) lightRow(ARR[i].p[CROW]);
      else lightRowDim(ARR[i].p[CROW]);
    }
  }
}

void readyScreen() {
  for (byte i = 0; i < 4; i++){
    tone(pinSpeaker, readyMelody[i]);
    unsigned long startTime = millis();
    while(COUNT[i].t > ((millis() - startTime))) {
      if ((COUNT[i].t - 400) < ((millis() - startTime))) noTone(pinSpeaker);
      lightRow(COUNT[i].p[CROW]);
    }
  }
}

void melodyScreen() {
  int   lenM       = gameCollection[currentMelody].len;
  byte* notesM     = gameCollection[currentMelody].notes;
  int*  durationM  = gameCollection[currentMelody].duration;
  for (byte i = 0; i < lenM; i++){
    tone(pinSpeaker, SCALE[notesM[i]]);
    unsigned long startTime = millis();
    while(durationM[i] > ((millis() - startTime))) {
      if ((durationM[i]- 100) < ((millis() - startTime))) noTone(pinSpeaker);
      lightRow(NOTES[notesM[i]].p[CROW]);
    }
  }
}

void gameScreen() {
  readAccel();
  readPos(p);
  if (buttonPressed(b) == false) {
    noTone(pinSpeaker);
    for (int i = 0; i < 8; i++){
      lightRowDim(NOTES[p.state].p[CROW]);
    }
  } else checkGame();
}

void resultScreen() {
  for (byte i = 0; i < 2; i++){
    unsigned long startTime = millis();
    if (p.success) {
      tone(pinSpeaker, correctMelody[i]);
      while(500 > ((millis() - startTime))) {
        lightRow(CORRECT.p[CROW]);
      }
    } else {
      tone(pinSpeaker, wrongMelody[i]);
      while(500 > ((millis() - startTime))) {
        lightRow(WRONG.p[CROW]);
      }
    }
  }
  noTone(pinSpeaker);
  delay(1000);
}

void checkGame(){
  byte note = gameCollection[currentMelody].notes[currentNote];
  if (p.state != note) {
    p.success = false;
    currentNote = 0;
    state = resultMode;
    delay(200);
    noTone(pinSpeaker);
    delay(50);
  } else if (p.state == note && currentNote == (gameCollection[currentMelody].len - 1)) {
    p.success = true;
    currentNote = 0;
    currentMelody = (currentMelody + 1) % 4;
    state = resultMode;
    delay(200);
    noTone(pinSpeaker);
    delay(50);
  } else {
    p.success = false;
    currentNote++;
  }
  while (digitalRead(b.pin) == true) {
    for (int i = 0; i < 8; i++){
      lightRow(NOTES[p.state].p[CROW]);
      tone(pinSpeaker, SCALE[p.state]);
    }
  }
}

bool buttonPressed(butt &button) {
  // Swith must stay stable this long (in msec) to register
  const long debounceTime = 50;
  // Default to no change until we find out otherwise
  boolean result = false;
  // Get the current raw reading from the switch
  int reading = digitalRead(button.pin);
  if (reading != button.lastReading) {
    button.lastChangeTime = millis();
    button.lastReading = reading;
  }
  if ((millis() - button.lastChangeTime) > debounceTime) {
    button.buttonState = reading;
    result = (button.buttonState == 1);
  }
  return result;
}

void readAccel() {
  int xRead = 0, yRead = 0;
  int  xAng = 0,  yAng = 0;
  int sampleSize = 4;
  for(int i = 0; i < sampleSize ; i++) {
    xRead += analogRead(pinX);
    yRead += analogRead(pinY);
    //zRead += analogRead(pinZ);
  }
  xRead = xRead / sampleSize;
  yRead = yRead / sampleSize;
  //zRead = zRead / sampleSize;
  xAng = map(xRead, xMinVal, xMaxVal, -90, 90);
  yAng = map(yRead, yMinVal, yMaxVal, -90, 90);
  //zAng = map(zRead, zMinVal, zMaxVal, -90, 90);
  //x = RAD_TO_DEG * (atan2(-yAng, -zAng) + PI);
  //y = RAD_TO_DEG * (atan2(-xAng, -zAng) + PI);
  angle = RAD_TO_DEG * (atan2(-yAng, -xAng) + PI);
  //Serial.print("angle = "); Serial.println(z);
}

void readPos(player &pl) {
  // Player position must stay stable this long (in msec) to register
  const long debounceTime = 20;
  // Get the current raw reading from the accelerometer
  byte reading = 0;
  if (158 < angle && angle <= 203) reading = 0;
  if (203 < angle && angle <= 248) reading = 1;
  if (248 < angle && angle <= 293) reading = 2;
  if (293 < angle && angle <= 338) reading = 3;
  if (338 < angle || angle <=  23) reading = 4;
  if ( 23 < angle && angle <=  68) reading = 5;
  if ( 68 < angle && angle <= 113) reading = 6;
  if (113 < angle && angle <= 158) reading = 7;
  if (reading != pl.lastReading) {
    pl.lastChangeTime = millis();
    pl.lastReading = reading;
  }
  if ((millis() - pl.lastChangeTime) > debounceTime) {
    pl.state = reading;
  }
}

void lightRow(byte hex) {
  digitalWrite(ROWS[CROW], LOW);
  for(byte i = 0; i < 8; i++) {
    digitalWrite(COLS[i], (hex>>i) & 0x01);
  }
  for(byte i = 0; i < 8; i++) {
    digitalWrite(COLS[i], LOW);
  }
  digitalWrite(ROWS[CROW], HIGH);
  CROW = (CROW + 1) % SIZE;
}

void lightRowDim(byte hex) {
  digitalWrite(ROWS[CROW], LOW);
  for(byte i = 0; i < 8; i++) {
    digitalWrite(COLS[i], (hex>>i) & 0x01);
  }
  for(byte i = 0; i < 8; i++) {
    digitalWrite(COLS[i], LOW);
  }
  digitalWrite(ROWS[CROW], HIGH);
  delay(1);
  CROW = (CROW + 1) % SIZE;
}

#define NOTE_B0  31
#define NOTE_C1  33
#define NOTE_CS1 35
#define NOTE_D1  37
#define NOTE_DS1 39
#define NOTE_E1  41
#define NOTE_F1  44
#define NOTE_FS1 46
#define NOTE_G1  49
#define NOTE_GS1 52
#define NOTE_A1  55
#define NOTE_AS1 58
#define NOTE_B1  62
#define NOTE_C2  65
#define NOTE_CS2 69
#define NOTE_D2  73
#define NOTE_DS2 78
#define NOTE_E2  82
#define NOTE_F2  87
#define NOTE_FS2 93
#define NOTE_G2  98
#define NOTE_GS2 104
#define NOTE_A2  110
#define NOTE_AS2 117
#define NOTE_B2  123
#define NOTE_C3  131
#define NOTE_CS3 139
#define NOTE_D3  147
#define NOTE_DS3 156
#define NOTE_E3  165
#define NOTE_F3  175
#define NOTE_FS3 185
#define NOTE_G3  196
#define NOTE_GS3 208
#define NOTE_A3  220
#define NOTE_AS3 233
#define NOTE_B3  247
#define NOTE_C4  262
#define NOTE_CS4 277
#define NOTE_D4  294
#define NOTE_DS4 311
#define NOTE_E4  330
#define NOTE_F4  349
#define NOTE_FS4 370
#define NOTE_G4  392
#define NOTE_GS4 415
#define NOTE_A4  440
#define NOTE_AS4 466
#define NOTE_B4  494
#define NOTE_C5  523
#define NOTE_CS5 554
#define NOTE_D5  587
#define NOTE_DS5 622
#define NOTE_E5  659
#define NOTE_F5  698
#define NOTE_FS5 740
#define NOTE_G5  784
#define NOTE_GS5 831
#define NOTE_A5  880
#define NOTE_AS5 932
#define NOTE_B5  988
#define NOTE_C6  1047
#define NOTE_CS6 1109
#define NOTE_D6  1175
#define NOTE_DS6 1245
#define NOTE_E6  1319
#define NOTE_F6  1397
#define NOTE_FS6 1480
#define NOTE_G6  1568
#define NOTE_GS6 1661
#define NOTE_A6  1760
#define NOTE_AS6 1865
#define NOTE_B6  1976
#define NOTE_C7  2093
#define NOTE_CS7 2217
#define NOTE_D7  2349
#define NOTE_DS7 2489
#define NOTE_E7  2637
#define NOTE_F7  2794
#define NOTE_FS7 2960
#define NOTE_G7  3136
#define NOTE_GS7 3322
#define NOTE_A7  3520
#define NOTE_AS7 3729
#define NOTE_B7  3951
#define NOTE_C8  4186
#define NOTE_CS8 4435
#define NOTE_D8  4699
#define NOTE_DS8 4978
#define END -1

Credits

plcrpbqr

0 projects • 1 follower

Gravity Simon Game

Things used in this project

Hardware components

Story

Introduction

Gravity Simon

Components and build

Code

Schematics

Schematic

Code
