P.R.N.T. car

No need to move over, there's a new boss in town, and he can swiftly zig n' zag his way to the finish line autonomously!

IntermediateShowcase (no instructions)96
P.R.N.T. car

Things used in this project

Hardware components

Raspberry Pi 5
Raspberry Pi 5
×1
Webcam, Logitech® HD Pro
Webcam, Logitech® HD Pro
×1
Optical Speed Encoder
×1
Portable Charger
×1
DC motor (generic)
×1

Software apps and online services

OpenCV
OpenCV

Story

Read more

Code

finalproj.py

Python
This is the main file of our code.
import cv2
import numpy as np
import RPi.GPIO as GPIO
import time
import math
import os
import matplotlib.pyplot as plt


'''
The following code is inspired by:
User raja_961, "Autonomous Lane-Keeping Car Using Raspberry Pi and OpenCV".
Instructables. URL: https://www.instructables.com/Autonomous-Lane-Keeping-Car-Using-Raspberry-Pi-and/
'''
# Environment variable, used to remove errors with displaying
os.environ["QT_QPA_PLATFORM"] = "offscreen"


#Pin definitions
SPEED_PIN = 20
STEERING_PIN = 21


# Picture Sizing
frame_width = 160
frame_length = 88


#PWM freq
freq = 50


# PD constants
kp = 0.09
kd = kp * 0.5


# Speeds for motor control in nanosec
max_speed = 750000000
min_speed = 900000000


# Servo and Motor Functions

def GPIO_setup():
    '''
    Effects: Sets up the GPIO pins specified at the top of the file
    '''
    GPIO.setmode(GPIO.BCM)
    GPIO.setup(SPEED_PIN, GPIO.OUT)
    GPIO.setup(STEERING_PIN, GPIO.OUT)

def calibrate_esc(pwm):
    '''
    Input:
        - pwm: this should be our speed pwm
    Effects:
        - Calibrates the esc of the car
    '''
    pwm.ChangeDutyCycle(10)
    time.sleep(2)
    pwm.ChangeDutyCycle(5)
    time.sleep(2)
    pwm.ChangeDutyCycle(7.5)
    time.sleep(2)

def set_servo_angle(angle, pwm):
    '''
    Input:
        - pwm: a pwm object created by the GPIO library, should be the servo pin's pwm
        - angle: the angle between 0 and 180 the servo should be at. Foward is 90 degrees
    Effects:
        - sets the servo to the requested angle
    '''
    # Convert angle (0 to 180 degrees) to duty cycle (2.5% to 12.5%)
    duty_cycle = 2.5 + (angle / 18)
    pwm.ChangeDutyCycle(duty_cycle)
    time.sleep(1)  # Allow time for the servo to reach the position

def set_speed(pwm, speed_percent):
    '''
    Input:
        - pwm: a pwm object created by the GPIO library should be the speed pin's pwm
        - speed_percent: an number between 0-100 representing the percent of max speed we go
          to be calibrated after seeing the car move
    '''
    cycle = (speed_percent/75) + 7.5
    pwm.ChangeDutyCycle(cycle)

# Computer Vision Functions

def start_video():
    '''
    - Inputs: None
    - Outputs:
            - video: a cv2 video object, can be thought of as
            just the video captured from the camera at index 0
    - Effects: Allows us to start collecting video from the default camera
            at 320x240 resolution
    - Notes: The website recommends we lower the reolution if we want to
            increase the frame rate so if it is slow, change the function
    '''
    video = cv2.VideoCapture("/dev/video0", cv2.CAP_V4L2)
    video.set(cv2.CAP_PROP_FRAME_WIDTH,frame_width)
    video.set(cv2.CAP_PROP_FRAME_HEIGHT,frame_length)
    return video

def look_at_video(video):
    '''
    - Inputs:
            - video: a cv2 video object, can be thought of as
            just the video captured
    - Outputs:
            - frame: a single frame of our video
    - Effects:
            - retrieves a frame of video for us to process
            also returns an error if video capture has failed
    '''
    ret, frame = video.read()
    return frame

def convert_to_HSV(frame):
    '''
    Inputs:
        - frame: a raw frame returned by reading the video
    Ouputs:
        - hsv: a hue, saturation, value color space, basically the
            frame with colors differentiated
    Effects: allows the computer to 'see' color
    '''
    return cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)

def detect_blue_edges(hsv):
    '''
    Inputs:
        - hsv: a frame converted into a hue, saturation, value color space
    Outputs:
        - edges: the pixels of the frame that are deemed to be an edge
    Effects: gives us the edges of blue things in the frame
    '''
    lower_blue = np.array([90, 50, 0], dtype = "uint8") # lower limit of blue color
    upper_blue = np.array([150, 255, 255], dtype="uint8") # upper limit of blue color
    mask = cv2.inRange(hsv,lower_blue,upper_blue) # this mask will filter out everything but blue

    # detect edges
    edges = cv2.Canny(mask, 50, 100)
    cv2.imshow("edges",edges)
    return edges

def detect_red_pix(hsv):
    '''
    Inputs:
        - hsv: a frame converted into a hue, saturation, value color space
    Outputs:
        - a boolean indicating whether or not the camera detects 'bound'
        number of red pixels
    Effects: gives us if we are close enough to a red stop sign
    '''
    bound_perc = 25
    bound = (frame_length*frame_width)*(bound_perc/100)
    lower_red1 = np.array([  0, 50, 60], dtype="uint8")
    upper_red1 = np.array([ 10, 255, 255], dtype="uint8")
    lower_red2 = np.array([170, 50, 60], dtype="uint8")
    upper_red2 = np.array([180, 255, 255], dtype="uint8")
    mask1 = cv2.inRange(hsv, lower_red1, upper_red1)
    mask2 = cv2.inRange(hsv, lower_red2, upper_red2)
    mask = cv2.bitwise_or(mask1, mask2)


    # Counts the number of 'red' pixels
    num_red_px = cv2.countNonZero(mask)
    if(num_red_px >= bound):
        print("Red seen!")
        return True
    else:
        return False

def region_of_interest(edges):
    height, width = edges.shape # extract the height and width of the edges frame
    mask = np.zeros_like(edges) # make an empty matrix with same dimensions of the edges frame


    # only focus lower half of the screen
    # specify the coordinates of 4 points (lower left, upper left, upper right, lower right)
    polygon = np.array([[
        (0, height),
        (0,  height/2),
        (width , height/2),
        (width , height),
    ]], np.int32)


    cv2.fillPoly(mask, polygon, 255) # fill the polygon with blue color
    cropped_edges = cv2.bitwise_and(edges, mask)
    return cropped_edges

def detect_line_segments(cropped_edges):
    rho = 1
    theta = np.pi / 180
    min_threshold = 10
    line_segments = cv2.HoughLinesP(cropped_edges, rho, theta, min_threshold,
                                    np.array([]), minLineLength=5, maxLineGap=0)
    return line_segments

def make_points(frame, line):
    height, width, _ = frame.shape
    slope, intercept = line
    y1 = height  # bottom of the frame
    y2 = int(y1 / 2)  # make points from middle of the frame down


    if slope == 0:
        slope = 0.1


    x1 = int((y1 - intercept) / slope)
    x2 = int((y2 - intercept) / slope)


    return [[x1, y1, x2, y2]]

def average_slope_intercept(frame, line_segments):
    lane_lines = []


    if line_segments is None:
        print("no line segment detected")
        return lane_lines


    height, width,_ = frame.shape
    left_fit = []
    right_fit = []
    boundary = 1/3


    left_region_boundary = width * (1 - boundary)
    right_region_boundary = width * boundary


    for line_segment in line_segments:
        for x1, y1, x2, y2 in line_segment:
            if x1 == x2:
                # print("skipping vertical lines (slope = infinity)")
                continue


            fit = np.polyfit((x1, x2), (y1, y2), 1)
            slope = (y2 - y1) / (x2 - x1)
            intercept = y1 - (slope * x1)


            if slope < 0:
                if x1 < left_region_boundary and x2 < left_region_boundary:
                    left_fit.append((slope, intercept))
            else:
                if x1 > right_region_boundary and x2 > right_region_boundary:
                    right_fit.append((slope, intercept))


    left_fit_average = np.average(left_fit, axis=0)
    if len(left_fit) > 0:
        lane_lines.append(make_points(frame, left_fit_average))


    right_fit_average = np.average(right_fit, axis=0)
    if len(right_fit) > 0:
        lane_lines.append(make_points(frame, right_fit_average))


    # lane_lines is a 2-D array consisting the coordinates of the right and left lane lines
    # for example: lane_lines = [[x1,y1,x2,y2],[x1,y1,x2,y2]]
    # where the left array is for left lane and the right array is for right lane
    # all coordinate points are in pixels
    # print(slope)
    return lane_lines

def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6): # line color (B,G,R)
    line_image = np.zeros_like(frame)


    if lines is not None:
        for line in lines:
            for x1, y1, x2, y2 in line:
                cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)


    line_image = cv2.addWeighted(frame, 0.8, line_image, 1, 1)
    return line_image

def get_steering_angle(frame, lane_lines):
    height, width, _ = frame.shape


    if len(lane_lines) == 2: # if two lane lines are detected
        _, _, left_x2, _ = lane_lines[0][0] # extract left x2 from lane_lines array
        _, _, right_x2, _ = lane_lines[1][0] # extract right x2 from lane_lines array
        mid = int(width / 2)
        x_offset = (left_x2 + right_x2) / 2 - mid
        y_offset = int(height / 2)


    elif len(lane_lines) == 1: # if only one line is detected
        x1, _, x2, _ = lane_lines[0][0]
        x_offset = x2 - x1
        y_offset = int(height / 2)


    elif len(lane_lines) == 0: # if no line is detected
        x_offset = 0
        y_offset = int(height / 2)


    angle_to_mid_radian = math.atan(x_offset / y_offset)
    angle_to_mid_deg = int(angle_to_mid_radian * 180.0 / math.pi)
    steering_angle = angle_to_mid_deg + 90


    return steering_angle

def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5 ):
    heading_image = np.zeros_like(frame)
    height, width, _ = frame.shape


    steering_angle_radian = steering_angle / 180.0 * math.pi
    x1 = int(width / 2)
    y1 = height
    x2 = int(x1 - height / 2 / math.tan(steering_angle_radian))
    y2 = int(height / 2)


    cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)


    heading_image = cv2.addWeighted(frame, 0.8, heading_image, 1, 1)


    return heading_image

def get_speed_change():
    '''
    Inputs: none
    Outputs:
        - speed_change: a number representing the suggestion on how speed should be changed
    '''
    interval_str = open(interval_loc, "r")
    interval = int(interval_str.readline())
    interval_str.close()


    speed_change = 0
    if (interval <= max_speed):
        speed_change = -0.001
    elif (interval >= min_speed):
        speed_change = 0.001
    return speed_change


# Path to location of parameter from driver
interval_loc = "/sys/module/gpiod_driver/parameters/nl"


# Used to get times for PD calculation
lastTime = 0
lastError = 0
current = 7.8


# Used to keep track of what frame we are on
ctr = 0


# Used to keep track of which stop sign we are at
seen_stop = 0
start_time = 0


# Lists to keep track of values on a run for plotting
errors = []
derivatives = []
proportions = []
frames = []
turns = []
speeds = []


# Gets the GPIO pins ready
GPIO_setup()
pwm_speed = GPIO.PWM(SPEED_PIN, freq)
pwm_steer = GPIO.PWM(STEERING_PIN, freq)
pwm_speed.start(7.5)
pwm_steer.start(7.5)
calibrate_esc(pwm_speed)


# Starts the Camera
video = start_video()


try:
    while True:
        # Processes the video output to learn about the surroundings
        frame = look_at_video(video)
        hsv = convert_to_HSV(frame)
        edges = detect_blue_edges(hsv)
        roi = region_of_interest(edges)
        line_segments = detect_line_segments(roi)
        lane_lines = average_slope_intercept(frame,line_segments)
        lane_lines_image = display_lines(frame,lane_lines)
        steering_angle = get_steering_angle(frame, lane_lines)
        heading_image = display_heading_line(lane_lines_image,steering_angle)

        # Saves our image for debugging
        cv2.imwrite("hsv.jpg", hsv)
        cv2.imwrite("edges.jpg", edges)
        cv2.imwrite("roi.jpg", roi)
        cv2.imwrite("heading_image.jpg", heading_image)
        print("images saved!")

        #  Ends the loop on keyboard  interrupt
        key = cv2.waitKey(1)
        if key == 27:
            break

        #  variables for PD calculation
        now = time.time() # current time variable
        dt = now - lastTime
        deviation = steering_angle - 90

        # PD calculation
        error = deviation
        base_turn = 7.5
        proportional = kp * error
        derivative = kd * (error - lastError)/dt

        # Gets the new turn angle, ensures non-negative
        turn = base_turn + proportional + derivative
        if (turn < 0):
            turn = 0
        print("turn: ", turn)
        print("derivative: ", derivative)

        # Updates all the values for plotting
        errors.append(error)
        derivatives.append(derivative)
        proportions.append(proportional)
        turns.append(turn)
        speeds.append(current)
        frames.append(ctr)
        ctr+=1

        # The steering angle is chaned
        pwm_steer.ChangeDutyCycle(turn)

        # Every 10 frames we check to see if there is a stop sign
        if ((ctr % 10) == 0):
            # If we see the first stop sign, we wait a while before checking for the next
            if(detect_red_pix(hsv) and ((time.time() - start_time) > 10)):
                if(seen_stop):
                    break
                else:
                    pwm_speed.ChangeDutyCycle(7.5)
                    time.sleep(3)
                    seen_stop = 1
                    start_time = time.time()

        #  Every two frames we update what our speed should be with a minimum duty cycle of 7.72
        if ((ctr % 2) == 0):
            new_speed = current + get_speed_change()
            if (new_speed < 7.72):
                new_speed = 7.72
            pwm_speed.ChangeDutyCycle(new_speed)
            current = new_speed
            time.sleep(0.025)


finally:
    # Stops all video recording
    video.release()
    cv2.destroyAllWindows()
    # First figure
    # plt.figure()
    # plt.plot(frames, errors, label="errors")
    # plt.plot(frames, derivatives, label="derivatives")
    # plt.plot(frames, proportions, label="proportions")
    # plt.legend()
    # plt.savefig("PD_vals.png")
    # Plot the proportional, derivative and error
    fig, ax1 = plt.subplots()
    t_ax = np.arange(len(proportions))
    ax1.plot(t_ax, proportions, label="P values")
    ax1.plot(t_ax, derivatives, label="D values")
    ax2 = ax1.twinx()
    ax2.plot(t_ax, errors, label="Error", color='red')

    ax1.set_xlabel("Frame Number")
    ax1.set_ylabel("PD Value")
    ax2.set_ylim(-90, 90)
    ax2.set_ylabel("Error Value")

    plt.title("P and D Values with Error")
    fig.legend()
    # fig.tight_layout()
    plt.savefig("PD_vals.png")

    # Second figure
    # plt.figure()
    # plt.plot(frames, errors, label="errors")
    # plt.plot(frames, speeds, label="speeds")
    # plt.plot(frames, turns, label="turns")
    # plt.legend()
    # plt.savefig("Movement_vals.png")
    # Plot the speed steering and the error
    fig, ax1 = plt.subplots()
    t_ax = np.arange(len(speeds))
    ax1.plot(t_ax, speeds, label="Speed")
    ax1.plot(t_ax, turns, label="Turns")
    ax2 = ax1.twinx()

    ax2.plot(t_ax, errors, label="Error", color='red')

    ax1.set_xlabel("Frame Number")
    ax1.set_ylabel("Speed and Steering Duty Cycle")
    ax2.set_ylim(-90, 90)
    ax2.set_ylabel("Error Value")

    plt.title("Speed and Steering Duty Cycle with Error")
    fig.legend()
    plt.savefig("Movement_vals.png")

gpiod_driver.c

C/C++
Speed encoder driver
#include <linux/module.h>
#include <linux/of_device.h>
#include <linux/kernel.h>
#include <linux/gpio/consumer.h>
#include <linux/platform_device.h>
#include <linux/hrtimer.h>
#include <linux/ktime.h>
#include <linux/interrupt.h>
/* YOU WILL NEED OTHER HEADER FILES */


// Timer variables
static struct hrtimer my_timer;
static ktime_t interval;
ktime_t press_times[2];
int press_num = 0;
ktime_t now;


/* YOU WILL HAVE TO DECLARE SOME VARIABLES HERE */
static struct gpio_desc *led_gpio;
static struct gpio_desc *button_gpio;
static int isr_num;


// Debouncing variables
static struct hrtimer debounce_time;
static bool debouncing = false;


static long nl = 0;
module_param(nl, long, 0644);


// Uses this timer to clear the debouncing state every 300ms
enum hrtimer_restart debounce_callback(struct hrtimer *timer)
{
   debouncing = false;
   return HRTIMER_NORESTART;
}


/* ADD INTERRUPT SERVICE ROUTINE HERE */
static irqreturn_t gpio_irq_handler(int irq, void *dev_id)
{
   // Does nothing if this is a debouncing press
   if (debouncing){
       return IRQ_HANDLED;
   }
   // Arms our debouncing variables
   debouncing = 1;
   hrtimer_start(&debounce_time, ktime_set(0, 300 * 1000000), HRTIMER_MODE_REL); // 300ms
   now = ktime_get();
   // Records the press time
   press_times[press_num] = now;
   // Sets the new interval when ready
   if(press_num){
       interval = ktime_sub(press_times[1], press_times[0]);
       s64 ns = ktime_to_ns(interval);
       nl = (long)ns;
       pr_info("%lld\n", (long long)ns);
   }else{

   }
   press_num = !press_num;


   return IRQ_HANDLED;
}


// probe function
static int led_probe(struct platform_device *pdev)
{
   // LHS is name of function header and RHS slide 35 of lecture 16
   struct device *dev = &pdev->dev;


   // Initialize the GPIO pins
   button_gpio = devm_gpiod_get(dev, "my_input", GPIOD_IN);


   // Initialize the ISR
   isr_num = gpiod_to_irq(button_gpio);
   devm_request_irq(dev, isr_num, gpio_irq_handler, IRQF_TRIGGER_FALLING, "my_isr", NULL);


   // Interval init
   interval = ktime_set(0, 500 * 1000000); // 500ms


   // Debounce timer init
   hrtimer_init(&debounce_time, CLOCK_MONOTONIC, HRTIMER_MODE_REL);
   debounce_time.function = debounce_callback;


   return 0;
}


// remove function
static int led_remove(struct platform_device *pdev)
{
   /* INSERT: Free the irq and print a message */
   devm_free_irq(&pdev->dev, isr_num, NULL);

   // Cancel the timers; pr_info is just printk with KERN_INFO
   int ret = hrtimer_cancel(&debounce_time);
   if (ret)
      pr_info("ISR Timer was active and has been cancelled\n");
   else
      pr_info("ISR Timer was not active\n");


   return 0;
}


static struct of_device_id matchy_match[] = {
   {.compatible = "mine"},
   {/* leave alone - keep this here (end node) */},
};


// platform driver object
static struct platform_driver adam_driver = {
   .probe   = led_probe,
   .remove  = led_remove,
   .driver  = {
          .name  = "The Rock: this name doesn't even matter",
          .owner = THIS_MODULE,
          .of_match_table = matchy_match,
   },
};


module_platform_driver(adam_driver);


MODULE_DESCRIPTION("424\'s finest");
MODULE_AUTHOR("Noah");
MODULE_LICENSE("GPL v2");
MODULE_ALIAS("platform:adam_driver");

mygpio.dts

C/C++
Device tree
/dts-v1/;
/plugin/;

/ {
    fragment@0 {
        target-path = "/";
        __overlay__ {
            noah {
                compatible = "mine";
                my_input-gpios = <&gpio 16 0 >;
            };
        };
    };

};

Credits

Paulina Arizpe-Romo
1 project • 0 followers
Tomi Kuye
2 projects • 0 followers
Renee Wrysinski
2 projects • 0 followers
Noah Villa
1 project • 0 followers

Comments
