An interesting study recently demonstrated how a person's heart rate can be noninvasively monitored using Wi-Fi signals. It has been getting a lot of attention in the press, so I suspect a lot of people would like to try it out. But the paper is behind a paywall, and even if you do get your hands on it, it is difficult for most people to understand (let alone reproduce) the researchers' methods.
So I decided to take a crack at it. I got a copy of the paper and spent some time digging in and coding up a solution that more or less reproduces the work. Some details are not fully spelled out in the paper, and the team has not released either their code or data, so I cannot guarantee that my method matches it 100%. But while it may not be identical, it is at least quite close, and more importantly, it works. And I suspect most people are more interested in playing with a system that works than they are perfectly reproducing the Pulse-Fi methods to a T.
In the next section, I'll first give an overview of how Pulse-Fi works, then I'll describe my implementation of it.
Important Note:This system is not to be used as a medical device. It could provide false measurements, so it is only for educational use.
Thanks to Pranay Kocheta, Nayan Sanjay Bhatia, and Katia Obraczka for their work on Pulse-Fi, which inspired this project.
How It WorksAn overview of Pulse-FiTo measure heart rate without contact, a person must be positioned between two ESP32 microcontrollers. One of the devices transmits a steady stream of Channel State Information (CSI) packets, while the other receives the packets. The CSI packets provide detailed information that describes how the signal propagates from the transmitter to the receiver. Anything that interrupts the signal, like the movements of a person, alters the signal in measurable ways. This fact has been leveraged for applications like activity recognition in the past.
Heart beats also involve motion, although it is very subtle compared to what is seen in the types of activities, like walking, that activity recognition systems typically target. So to focus in on heart beats, the researchers came up with a multi-step data processing pipeline that looks like this:
This processed data is then fed into a multi-layer LSTM network that predicts heart rate.
I have an Adafruit HUZZAH32 and an ESP32-DevKitC v4, both with an ESP32-WROOM-32E microcontroller (these are what I had on hand; other ESP32 boards should work fine). They are placed several feet apart, and the measurement area is between them. One was flashed with the Espressif csi_send code, and the other with the Espressif csi_recv code. The source code was compiled and flashed to the devices using the IDF docker image, e.g.:
git clone https://github.com/espressif/esp-csi.git
docker pull espressif/idf
# Build csi_send
docker run --rm -v $PWD:~/project -w /project -u $UID -e HOME=/tmp -it espressif/idf
cd esp-csi/examples/get-started/csi_send
idf.py set-target esp32
idf.py flash -b 921600 -p /dev/ttyUSB0
exit
# Flash csi_send
docker run --rm -v $PWD:~/csi_hr/esp-csi/examples/get-started/csi_send/project -w /project espressif/idf:latest idf.py --port /dev/ttyUSB0 flash
# Build csi_recv
docker run --rm -v $PWD:~/project -w /project -u $UID -e HOME=/tmp -it espressif/idf
cd esp-csi/examples/get-started/csi_recv
idf.py set-target esp32
idf.py flash -b 921600 -p /dev/ttyUSB0
exit
# Flash csi_recv
docker run --rm -v $PWD:~/csi_hr/esp-csi/examples/get-started/csi_recv/project -w /project espressif/idf:latest idf.py --port /dev/ttyUSB0 flash
After flashing, the receiving device is connected to a computer via USB so that CSI information can be collected via a serial connection. I very significantly altered Espressif's csi_data_read_parse.py script. My new version is read_and_process_csi.py, and it eliminates the graphical interface, implements the five Pulse-Fi CSI data processing steps, then forwards the processed data into a trained LSTM model with the same architecture as the one in the paper to predict heart rate. It can be launched with:
python read_and_process_csi.py -p /dev/ttyUSB0
The script prints a steady stream of heart rate predictions to standard output.
Training the machine learning modelread_and_process_csi.py
can be put into a mode where it collects and processes CSI data and writes it to a text file (COLLECT_TRAINING_DATA = True
), rather than making heart rate predictions. Below is a chart showing processed CSI data for one subcarrier that was collected in this way. The heart beat signal is clearly visible.
This CSI data is paired with actual heart rate data collected using an Arduino Nano 33 IoT and a generic breakout board with a MAX30102 pulse oximetry and heart-rate monitor module (this sensor is only needed to collect training data). The Arduino code for the heart rate sensor is here. Data with varying heart rates will be needed, so some of the data should be collected during, or immediately after, exercise or other physical activity.
All of the data is then used in my training script that builds an LSTM model in TensorFlow with the following architecture:
main_input = keras.Input(shape=(100, 192), name='main_input')
layers = keras.layers.LSTM(64, return_sequences=True, name='lstm_1')(main_input)
layers = keras.layers.Dropout(0.2, name='dropout_1')(layers)
layers = keras.layers.LSTM(32, name='lstm_2')(layers)
layers = keras.layers.Dropout(0.2, name='dropout_2')(layers)
layers = keras.layers.Dense(16, activation='relu', name='dense_1')(layers)
hr_output = keras.layers.Dense(1, name='hr_output')(layers)
The model ingests 100 sequential CSI packets at a time in a sliding window. The average heart rate measured over that window is the value it is trained to predict. Once trained, the model is saved as csi_hr.keras
, which read_and_process_csi.py
loads and uses to predict heart rate.
- 1 x Adafruit HUZZAH32 (ESP32-WROOM-32E)
- 1 x ESP32-DevKitC v4 (ESP32-WROOM-32E)
- 1 x Arduino Nano 33 IoT
- 1 x Generic breakout board with MAX30102 pulse oximetry and heart-rate monitor module
