i.MX RT1010 EVK RGB LED Matrix Driver

NXP i.MX RT1010 EVK RGB LED Matrix Driver

Drive a 32x32 RGB LED matrix with the NXP i.MX RT1010 EVK. Any matrix that is drop-in compatible with the Adafruit 1484 will work.

Full source code available on GitHub: https://github.com/nickbild/nxp_led_matrix_driver

Media

High resolution video available on YouTube.

Top view of the EVK. The strange looking wires are standard 22AWG copper wires wrapped in aluminum foil. The i.MX RT1010 EVK GPIOs switch very fast, so EMI shielding was a must to prevent spurious signals from producing unwanted visual artifacts on the matrix. That took more than a little debugging to sort out. :)

EVK connected to LED matrix:

EVK driving the matrix:

Some sample images. Taking images of an illuminated LED matrix is very difficult. It definitely looks better in person.

Use

• Clone my GitHub repo (git clone https://github.com/nickbild/nxp_led_matrix_driver.git), then import into a project in MCUXpresso IDE.
• Connect the GPIO pins to your LED matrix per the comments in source/led_matrix_driver.c:

// GPIO pin mappings.							// Header, Pin Number
#define pinR1 BOARD_USER_AD1_GPIO_PIN			  // J56, 14
#define pinG1 BOARD_USER_AD2_GPIO_PIN			  // J56, 16
#define pinB1 BOARD_USER_AD3_GPIO_PIN			  // J57, 10
#define pinR2 BOARD_USER_AD4_GPIO_PIN			  // J57, 8
#define pinG2 BOARD_USER_AD5_GPIO_PIN			  // J57, 6
#define pinB2 BOARD_USER_AD6_GPIO_PIN			  // J57, 12
#define pinOE BOARD_USER_AD7_GPIO_PIN			  // J26, 2
#define latch BOARD_USER_AD9_GPIO_PIN			  // J26, 4
#define pinClk BOARD_USER_AD10_GPIO_PIN			  // J26, 6
#define selectA BOARD_USER_AD14_GPIO_PIN		  // J26, 8
#define selectB BOARD_USER_2_GPIO_PIN			  // J57, 20
#define selectC BOARD_USER_9_GPIO_PIN			  // J56, 2
#define selectD BOARD_USER_10_GPIO_PIN			   // J56, 4

• Generate C data structure files containing graphic data. See details in "Create Graphics" section below.
• Prepare graphic data:

python3 data_generator/data_generator.py [data_file_1.c] ... [data_file_N.c]

1+ files may be supplied. If >1 files are supplied, an animation will be displayed on the matrix. The animation will cycle through images in the order they are given.

The script will produce output similar to this:

#define numImages 1  // >1 means animation.
#define changeImageFrames -1  // Animation control. Set to -1 to display a single image.  Larger number == longer delay between image changes.

__RODATA(Flash2) const unsigned short int brightnessR[numImages][32][32] = {{{0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {23, 23, 23, 0, 0, 0, 0, 0, 0, 23, 23, 12, 12, 0, 0, 0, 0, 0, 0, 0, 6, 6, 14, 14, 14, 14, 14, 14, 14, 0, 0, 0}, {23, 23, 23, 23, 0, 0, 0, 0, 0, 23, 23, 12, 12, 0, 0, 0, 0, 0, 0, 0, 6, 6, 14, 14, 14, 14, 14, 14, 14, 14, 0, 0}, {23, 23, 23, 23, 23, 0, 0, 0, 0, 23, 23, 12, 12, 0, 0, 0, 0, 0, 0, 0, 6, 6, 14, 14, 14, 14, 14, 14, 14, 14, 14, 0}, {23, 23, 23, 23, 23, 23, 0, 0, 0, 23, 23, 12, 12, 0, 0, 0, 0, 0, 0, 0, 6, 6, 14, 0, 0, 0, 0, 0, 14, 14, 14, 14}, {23, 23, 23, 23, 23, 23, 23, 0, 0, 23, 23, 12, 12, 12, 0, 0, 0, 0, 0, 6, 6, 6, 14, 0, 0, 0, 0, 0, 14, 14, 14, 14}, {23, 23, 23, 0, 23, 23, 23, 23, 0, 23, 23, 23, 23, 12, 12, 0, 0, 0, 6, 6, 14, 14, 14, 0, 0, 0, 0, 0, 14, 14, 14, 14}, {23, 23, 23, 0, 0, 23, 23, 23, 23, 23, 23, 23, 23, 12, 12, 0, 0, 0, 6, 6, 14, 14, 14, 14, 14, 14, 14, 14, 14, 14, 14, 0}, {23, 23, 23, 0, 0, 0, 23, 23, 23, 23, 23, 23, 12, 12, 0, 0, 0, 0, 0, 6, 6, 14, 14, 14, 14, 14, 14, 14, 14, 14, 0, 0}, {23, 23, 23, 0, 0, 0, 0, 23, 23, 23, 23, 12, 12, 12, 0, 0, 0, 0, 0, 6, 6, 6, 14, 14, 14, 14, 14, 14, 14, 0, 0, 0}, {23, 23, 23, 0, 0, 0, 0, 0, 23, 23, 23, 12, 12, 0, 0, 0, 0, 0, 0, 0, 6, 6, 14, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {23, 23, 23, 0, 0, 0, 0, 0, 0, 23, 23, 12, 12, 0, 0, 0, 0, 0, 0, 0, 6, 6, 14, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {23, 23, 23, 0, 0, 0, 0, 0, 0, 23, 23, 12, 12, 0, 0, 0, 0, 0, 0, 0, 6, 6, 14, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 40, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 40, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 40, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 40, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 40, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 40, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 40, 40, 40, 40, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {36, 0, 0, 0, 0, 0, 36, 0, 0, 36, 36, 0, 0, 36, 36, 36, 36, 36, 0, 36, 36, 0, 0, 0, 36, 0, 36, 0, 0, 0, 36, 0}, {36, 36, 0, 0, 0, 36, 36, 0, 36, 0, 0, 36, 0, 0, 0, 36, 0, 0, 0, 36, 0, 36, 0, 0, 36, 0, 0, 36, 0, 36, 0, 0}, {36, 0, 36, 0, 36, 0, 36, 0, 36, 0, 0, 36, 0, 0, 0, 36, 0, 0, 0, 36, 0, 0, 36, 0, 36, 0, 0, 0, 36, 0, 0, 0}, {36, 0, 0, 36, 0, 0, 36, 0, 36, 36, 36, 36, 0, 0, 0, 36, 0, 0, 0, 36, 0, 36, 0, 0, 36, 0, 0, 0, 36, 0, 0, 0}, {36, 0, 0, 0, 0, 0, 36, 0, 36, 0, 0, 36, 0, 0, 0, 36, 0, 0, 0, 36, 36, 0, 0, 0, 36, 0, 0, 0, 36, 0, 0, 0}, {36, 0, 0, 0, 0, 0, 36, 0, 36, 0, 0, 36, 0, 0, 0, 36, 0, 0, 0, 36, 0, 36, 0, 0, 36, 0, 0, 36, 0, 36, 0, 0}, {36, 0, 0, 0, 0, 0, 36, 0, 36, 0, 0, 36, 0, 0, 0, 36, 0, 0, 0, 36, 0, 0, 36, 0, 36, 0, 36, 0, 0, 0, 36, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}}};

__RODATA(Flash2) const unsigned short int brightnessG[numImages][32][32] = {{{0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {11, 11, 11, 0, 0, 0, 0, 0, 0, 11, 11, 7, 7, 11, 0, 0, 0, 0, 0, 11, 7, 7, 19, 19, 19, 19, 19, 19, 19, 0, 0, 0}, {11, 11, 11, 11, 0, 0, 0, 0, 0, 11, 11, 7, 7, 11, 0, 0, 0, 0, 0, 11, 7, 7, 19, 19, 19, 19, 19, 19, 19, 19, 0, 0}, {11, 11, 11, 11, 11, 0, 0, 0, 0, 11, 11, 7, 7, 11, 11, 0, 0, 0, 11, 11, 7, 7, 19, 19, 19, 19, 19, 19, 19, 19, 19, 0}, {11, 11, 11, 11, 11, 11, 0, 0, 0, 11, 11, 7, 7, 11, 11, 11, 0, 11, 11, 11, 7, 7, 19, 0, 0, 0, 0, 0, 19, 19, 19, 19}, {11, 11, 11, 11, 11, 11, 11, 0, 0, 11, 11, 7, 7, 7, 11, 11, 11, 11, 11, 7, 7, 7, 19, 0, 0, 0, 0, 0, 19, 19, 19, 19}, {11, 11, 11, 0, 11, 11, 11, 11, 0, 11, 11, 11, 11, 7, 7, 11, 11, 11, 7, 7, 19, 19, 19, 0, 0, 0, 0, 0, 19, 19, 19, 19}, {11, 11, 11, 0, 0, 11, 11, 11, 11, 11, 11, 11, 11, 7, 7, 11, 11, 11, 7, 7, 19, 19, 19, 19, 19, 19, 19, 19, 19, 19, 19, 0}, {11, 11, 11, 0, 0, 0, 11, 11, 11, 11, 11, 11, 7, 7, 11, 11, 11, 11, 11, 7, 7, 19, 19, 19, 19, 19, 19, 19, 19, 19, 0, 0}, {11, 11, 11, 0, 0, 0, 0, 11, 11, 11, 11, 7, 7, 7, 11, 11, 0, 11, 11, 7, 7, 7, 19, 19, 19, 19, 19, 19, 19, 0, 0, 0}, {11, 11, 11, 0, 0, 0, 0, 0, 11, 11, 11, 7, 7, 11, 11, 0, 0, 0, 11, 11, 7, 7, 19, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {11, 11, 11, 0, 0, 0, 0, 0, 0, 11, 11, 7, 7, 11, 0, 0, 0, 0, 0, 11, 7, 7, 19, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {11, 11, 11, 0, 0, 0, 0, 0, 0, 11, 11, 7, 7, 11, 0, 0, 0, 0, 0, 11, 7, 7, 19, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 30, 30, 30, 30, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 30, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 30, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 30, 30, 30, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 30, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 30, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 30, 30, 30, 30, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {30, 0, 0, 0, 0, 0, 30, 0, 0, 30, 30, 0, 0, 30, 30, 30, 30, 30, 0, 30, 30, 0, 0, 0, 30, 0, 30, 0, 0, 0, 30, 0}, {30, 30, 0, 0, 0, 30, 30, 0, 30, 0, 0, 30, 0, 0, 0, 30, 0, 0, 0, 30, 0, 30, 0, 0, 30, 0, 0, 30, 0, 30, 0, 0}, {30, 0, 30, 0, 30, 0, 30, 0, 30, 0, 0, 30, 0, 0, 0, 30, 0, 0, 0, 30, 0, 0, 30, 0, 30, 0, 0, 0, 30, 0, 0, 0}, {30, 0, 0, 30, 0, 0, 30, 0, 30, 30, 30, 30, 0, 0, 0, 30, 0, 0, 0, 30, 0, 30, 0, 0, 30, 0, 0, 0, 30, 0, 0, 0}, {30, 0, 0, 0, 0, 0, 30, 0, 30, 0, 0, 30, 0, 0, 0, 30, 0, 0, 0, 30, 30, 0, 0, 0, 30, 0, 0, 0, 30, 0, 0, 0}, {30, 0, 0, 0, 0, 0, 30, 0, 30, 0, 0, 30, 0, 0, 0, 30, 0, 0, 0, 30, 0, 30, 0, 0, 30, 0, 0, 30, 0, 30, 0, 0}, {30, 0, 0, 0, 0, 0, 30, 0, 30, 0, 0, 30, 0, 0, 0, 30, 0, 0, 0, 30, 0, 0, 30, 0, 30, 0, 30, 0, 0, 0, 30, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}}};

__RODATA(Flash2) const unsigned short int brightnessB[numImages][32][32] = {{{0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {1, 1, 1, 0, 0, 0, 0, 0, 0, 1, 1, 5, 5, 32, 0, 0, 0, 0, 0, 32, 4, 4, 3, 3, 3, 3, 3, 3, 3, 0, 0, 0}, {1, 1, 1, 1, 0, 0, 0, 0, 0, 1, 1, 5, 5, 32, 0, 0, 0, 0, 0, 32, 4, 4, 3, 3, 3, 3, 3, 3, 3, 3, 0, 0}, {1, 1, 1, 1, 1, 0, 0, 0, 0, 1, 1, 5, 5, 32, 32, 0, 0, 0, 32, 32, 4, 4, 3, 3, 3, 3, 3, 3, 3, 3, 3, 0}, {1, 1, 1, 1, 1, 1, 0, 0, 0, 1, 1, 5, 5, 32, 32, 32, 0, 32, 32, 32, 4, 4, 3, 0, 0, 0, 0, 0, 3, 3, 3, 3}, {1, 1, 1, 1, 1, 1, 1, 0, 0, 1, 1, 5, 5, 5, 32, 32, 32, 32, 32, 4, 4, 4, 3, 0, 0, 0, 0, 0, 3, 3, 3, 3}, {1, 1, 1, 0, 1, 1, 1, 1, 0, 1, 1, 1, 1, 5, 5, 32, 32, 32, 4, 4, 3, 3, 3, 0, 0, 0, 0, 0, 3, 3, 3, 3}, {1, 1, 1, 0, 0, 1, 1, 1, 1, 1, 1, 1, 1, 5, 5, 32, 32, 32, 4, 4, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 0}, {1, 1, 1, 0, 0, 0, 1, 1, 1, 1, 1, 1, 5, 5, 32, 32, 32, 32, 32, 4, 4, 3, 3, 3, 3, 3, 3, 3, 3, 3, 0, 0}, {1, 1, 1, 0, 0, 0, 0, 1, 1, 1, 1, 5, 5, 5, 32, 32, 0, 32, 32, 4, 4, 4, 3, 3, 3, 3, 3, 3, 3, 0, 0, 0}, {1, 1, 1, 0, 0, 0, 0, 0, 1, 1, 1, 5, 5, 32, 32, 0, 0, 0, 32, 32, 4, 4, 3, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {1, 1, 1, 0, 0, 0, 0, 0, 0, 1, 1, 5, 5, 32, 0, 0, 0, 0, 0, 32, 4, 4, 3, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {1, 1, 1, 0, 0, 0, 0, 0, 0, 1, 1, 5, 5, 32, 0, 0, 0, 0, 0, 32, 4, 4, 3, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 50, 50, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 50, 0, 50, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 50, 0, 0, 50, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 50, 0, 0, 50, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 50, 0, 0, 50, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 50, 0, 50, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 50, 50, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}, {0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}}};

• Copy the above output into source/led_matrix_driver.c, between the comments:

/*******************************************************************************
 * Data to Display - Paste graphics data BELOW this comment.
 ******************************************************************************/

[**** INSERT OUTPUT HERE ****]

/*******************************************************************************
 * END of Data to Display - Paste graphics data ABOVE this comment.
 ******************************************************************************/

• Transfer the code to the i.MX RT1010 EVK. NXP has some great documentation if needed:

https://www.nxp.com/document/guide/getting-started-with-i-mx-rt1010-evaluation-kit:GS-MIMXRT1010-EVK

Create Graphics

The easiest way to create graphics for the matrix is to use piskelapp.com:

• Create a new 32x32 sprite.
• Use Export as C File. This file can directly be used with the included script, data_generator/data_generator.py.
• It's not required, but you may also want to Save as .piskel so you can edit your graphic later.
