Project #30 - UNIHIKER - Fermion: MEMS Smoke Gas Detection

Project #30 - UNIHIKER - Fermion: MEMS Smoke Gas Detection Sensor - Mk04

BeginnerFull instructions provided1 hour56

Things used in this project

Hardware components

DFRobot UNIHIKER

DFRobot Fermion: MEMS Smoke Gas Detection Sensor

USB Battery Pack

DFRobot USB 3.1 Cable A to C

Software apps and online services

https://thonny.org/

Story

Project #30 - UNIHIKER - Fermion: MEMS Smoke Gas Detection Sensor - Mk04

https://www.donluc.com/?p=4120

https://youtu.be/Ui3bFs2u3xs

https://edu.dfrobot.com/makelog-314855.html

#DonLucElectronics #DonLuc #UNIHIKER #Smoke #Display #IoT #Project #Debian #Python #Thonny #Fritzing #Programming #Electronics #Microcontrollers #Consultant

Fermion: MEMS Smoke Gas Detection Sensor

Fermion: MEMS Smoke Gas Detection Sensor employs state-of-the-art microelectromechanical system (MEMS) technology, endowing the sensor with compact dimensions, low power consumption, minimal heat generation, short preheating time, and swift response recovery. The sensor can measure smoke concentration qualitatively and is suitable for smoke alarm and other application scenarios. Kindly remove the protective film before usage. It is advisable to preheat the module for at least 24 hours. Detection range: 10-1000 ppm.

DL2409Mk03

1 x UNIHIKER

1 x Fermion: MEMS Smoke Gas Detection Sensor

1 x USB Battery Pack

1 x USB 3.1 Cable A to C

UNIHIKER

ADC - 21

VIN - +5V

GND - GND

DL2409Mk03p

DL2409Mk03p.py

People can contact us:http://www.donluc.com/?page_id=1927

Teacher, Instructor, E-Mentor, R&D and Consulting

Programming Language
Microcontrollers (PIC, Arduino, Raspberry Pi, Arm, Silicon Labs, Espressif, Etc...)
IoT
Wireless (Radio Frequency, Bluetooth, WiFi, Etc...)
Robotics
Automation
Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
Unmanned Vehicles Terrestrial and Marine
Machine Learning
Artificial Intelligence (AI)
RTOS
Sensors, eHealth Sensors, Biosensor, and Biometric
Research & Development (R & D)
Consulting
Etc...

Luc Paquin – Curriculum Vitae - 2024

https://www.donluc.com/luc/

Web:https://www.donluc.com/

Facebook:https://www.facebook.com/neosteam.labs.9/

YouTube:https://www.youtube.com/@thesass2063

Twitter:https://twitter.com/labs_steam

Pinterest:https://www.pinterest.com/NeoSteamLabs/

Instagram:https://www.instagram.com/neosteamlabs/

DFRobot Luc.Paquin:https://edu.dfrobot.com/dashboard/makelogs

Hackster.io:https://www.hackster.io/neosteam-labs

LinkedIn:https://www.linkedin.com/in/jlucpaquin/

Don Luc

Code

DL2409Mk03p.py

"""
****** Don Luc Electronics © ******
Software Version Information
Project #30 - UNIHIKER - Fermion: MEMS Smoke Gas Detection Sensor - Mk04
30-04
DL2409Mk03.py
DL2409Mk03
1 x UNIHIKER
1 x Fermion: MEMS Smoke Gas Detection Sensor
1 x USB Battery Pack
1 x USB 3.1 Cable A to C

-*- coding: utf-8 -*-
"""
# Import the unihiker library
from unihiker import GUI

# Import the time library
import time

# Import the Board module from the pinpong.board package
from pinpong.board import Board

# Import all modules from the pinpong.extension.unihiker package
from pinpong.extension.unihiker import *

# Initialize the board by selecting the board type and port number;
# if not specified, the program will automatically detect it
Board().begin()

# Initialize pin 21 as analog input mode
# Fermion: MEMS Smoke Gas Detection Sensor
adc0 = Pin(Pin.P21, Pin.ANALOG)

# Instantiate the GUI class and create a gui object
gui = GUI()

# Display the initial background image 'DL2409Mk03p'
img = gui.draw_image(x=0, y=0, w=240, h=320, image='DL2409Mk03p.png')

# MEMS Smoke Gas
# Display the initial Fermion: MEMS Smoke Gas Detection Sensor valueSmoke
valueSmoke = gui.draw_text(x=30, y=151, text='0', font_size=18)

while True:

    # Fermion: MEMS Smoke Gas Detection Sensor
    # Read analog value
    AnalogSmokeSensor = adc0.read_analog()
    valueSmoke.config(text=AnalogSmokeSensor)

    # Delay for 1 second to keep the screen content displayed for a longer time
    time.sleep(1)
