What does this do?
In this project, our goal was to create an autonomous RC car and Raspberry Pi 5 to move along a track lane (defined by two lines of blue tape), keeping control of speed and steering along the way. To do this, our system uses a webcam and OpenCV as computer vision to do image processing to determine how to keep within the lanes, turn corners, and stop when the ground is red.
This work draws from the following Instructable:
User raja_961, “Autonomous Lane-Keeping Car Using Raspberry Pi and OpenCV”. Instructables. URL: https://www.instructables.com/Autonomous-Lane-Keeping-Car-U sing-Raspberry-Pi-and/
And this existing 424 project:
Team Big Brains (Jerry Cai, Jiawen Wei, Lize Shao, Louie Lu), “Big Brains - ELEC 424 Final Project - Team 11”. Hackster. URL: https://www.hackster.io/big-brains/big-brains-elec-424-final-project-team-11-53c862#toc-steer-and-speed-voltage-plot-5
How we determined the resolution, proportional gain, and derivative gain
We determined the resolution of the camera by first realizing that it would need to be downscaled heavily for two reasons: 1) higher resolutions only very marginally helped image processing discern the lanes, if at all, and 2) the processing would be significantly faster at smaller resolutions. Eventually, we landed on a resolution of 160x120, which we found to give enough information while still performing image processing fast.
Our P-D controller used two parameters to automatically and continuously adjust the steering and speed of the car. To find good values for each, we started with just proportional gain at a small number of 0.01and derivative at zero. Once we were able to get it steering well with just proportional gain via looking at plots and retesting, we did a similar sort of tweaking process for the derivative gain, so that the janky oscillations would smooth out. Our final parameters for proportional gain and derivative gain were kp = 0.10 and kd = kp * 0.05, respectively.
How we handled stopping upon red paper
When coming across red paper, we wanted our autonomous car to stop. To do this, our system is constantly looking for red in the lower half of the camera. We used OpenCV functions to help detect red paper. After detecting the first stop paper, a boolean flag is set that marks whether we passed the first stop, and a delay is added for the next red-detection attempts. This delay prevents situations in which the system tries to mark the same red stop paper multiple times. That way, when reaching the second stop paper, the car detects red, and will finally come to a complete stop due to a conditional for the boolean flag (that was previously set at the first stop).
How we made our car so so so very baby-saferizz
Plots
Picture of vehicle with hardware
"""
This file makes use of code from the following sources:
User raja_961, Autonomous Lane-Keeping Car Using Raspberry
Pi and OpenCV. Instructables. URL:
https://www.instructables.com/Autonomous-Lane-Keeping-Car-U
sing-Raspberry-Pi-and/
Big Brains - ELEC 424 Final Project - Team 11. URL:
https://www.hackster.io/big-brains/big-brains-elec-424-final-project-team-11-53c862
"""
import time
import math
import RPi.GPIO as GPIO
import numpy as np
import cv2
import matplotlib.pyplot as plt # pip install matplotlib
GPIO.setmode(GPIO.BCM)
# ESC parameters
speedPin = 18
speed_pwm_hz = 50
speed_dc = 7.5
GPIO.setup(speedPin, GPIO.OUT)
speed = GPIO.PWM(speedPin, speed_pwm_hz)
speed.start(speed_dc)
# ESC speed control parameters
START_SPEED = 7.72
MAX_SPEED = 7.9
MIN_SPEED = 7.7
# Steering parameters
steeringPin = 19
steering_pwm_hz = 50
steering_dc = 7.5
steering_right_dc = 9
steering_left_dc = 6
# Set up steering GPIO
GPIO.setup(steeringPin, GPIO.OUT)
steering = GPIO.PWM(steeringPin, steering_pwm_hz)
steering.start(steering_dc)
lastSteeringAngle = 90
# Optical encoder parameters
ELAPSED_MS_PATH = "/sys/module/gpiod_driver/parameters/elapsed_ms"
# Video parameters
ESC_KEY_CODE = 27
VIDEO_DEVICE_IDX = 0
VIDEO_WIDTH = 160
VIDEO_HEIGHT = 120
# PD variables
kp = 0.1 #started w 0.01
kd = kp * 0.05
lastTime = 0
lastError = 0
# arrays for making the final graphs
p_vals = []
d_vals = []
err_vals = []
speed_pwm = []
steer_pwm = []
# Steering control ############################################################
def set_steering(p, steering):
p.ChangeDutyCycle(steering)
# Reset steering to center position
def reset_steering(p):
p.ChangeDutyCycle(7.5)
# Map a value from one range to another
def map_value(value, in_min, in_max, out_min, out_max):
# Clamp input to avoid out-of-bound servo values
value = max(min(value, in_max), in_min)
return out_min + (float(value - in_min) / (in_max - in_min)) * (out_max - out_min)
###############################################################################
# ESC control #################################################################
def isRedFloorVisible(frame):
# Convert the frame to HSV color space
hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
# Define the lower and upper bounds for red color in HSV
lower_red1 = np.array([0, 120, 70])
upper_red1 = np.array([10, 255, 255])
lower_red2 = np.array([170, 120, 70])
upper_red2 = np.array([180, 255, 255])
# Create masks for red color
mask1 = cv2.inRange(hsv, lower_red1, upper_red1)
mask2 = cv2.inRange(hsv, lower_red2, upper_red2)
mask = cv2.bitwise_or(mask1, mask2)
# Apply morphological operations to clean up the mask
output = cv2.bitwise_and(frame, frame, mask=mask)
percentage_red = np.count_nonzero(mask) * 100 / np.size(mask)
return percentage_red > 5
###############################################################################
# ESC speed control ###########################################################
# Set the speed of the ESC
def set_esc(p, speed):
global speed_dc
speed_dc = speed
p.ChangeDutyCycle(speed)
# Reset the ESC to a neutral position - stop it
def reset_esc(p):
p.ChangeDutyCycle(7.5)
# Calibrate the ESC by setting it to full throttle and then neutral
def calibrate_esc(p):
print('Calibrating ESC...')
p.ChangeDutyCycle(10)
time.sleep(2)
p.ChangeDutyCycle(5)
time.sleep(2)
# Reset ESC to neutral position
reset_esc(p)
print('ESC calibration complete')
# Speed control functions ##################################################
def accelerate():
"""
Adjusts the speed parameters to increase velocity, if not at peak capacity.
Returns:
None: Provides update on velocity adjustments.
"""
global speed_dc
global MAX_SPEED
if speed_dc < MAX_SPEED:
speed_dc = min(speed_dc + 0.025, MAX_SPEED) # Enhance speed
set_esc(speed, speed_dc)
print(f"Velocity increment: Now at {speed_dc}")
else:
print("Peak velocity achieved.")
def decelerate():
"""
Modulates the speed parameters to reduce velocity, unless fully stopped.
Returns:
None: Delivers update on velocity reduction.
"""
global speed_dc
global MIN_SPEED
# Ensure speed does not go below the minimum threshold
if speed_dc > MIN_SPEED:
speed_dc = max(speed_dc - 0.025, MIN_SPEED) # Reduce speed
set_esc(speed, speed_dc)
print(f"Velocity decrement: Now at {speed_dc}")
else:
print("Complete standstill reached.")
###############################################################################
# Image processing functions ##################################################
def detect_edges(frame):
# blue color detection
# blurred = cv2.GaussianBlur(frame, (5,5), 0)
hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
# cv2.imshow("HSV",hsv)
lower_blue = np.array([100,120,50], dtype="uint8")
upper_blue = np.array([140,255,255], dtype="uint8")
mask = cv2.inRange(hsv,lower_blue,upper_blue) # this mask will filter out everything but blue
kernel = cv2.getStructuringElement(cv2.MORPH_RECT, (5,5))
mask = cv2.morphologyEx(mask, cv2.MORPH_CLOSE, kernel, iterations=2)
mask = cv2.morphologyEx(mask, cv2.MORPH_OPEN, kernel, iterations=1)
#Do GaussianBlur using mask instead of frame
blurred = cv2.GaussianBlur(mask, (5,5), 0)
# cv2.imshow("mask",mask)
# detect edges
edges = cv2.Canny(mask, 50, 100)
# cv2.imshow("edges",edges)
return edges
def region_of_interest(edges):
height, width = edges.shape # extract the height and width of the edges frame
mask = np.zeros_like(edges) # make an empty matrix with same dimensions of the edges frame
# only focus lower half of the screen
# specify the coordinates of 4 points (lower left, upper left, upper right, lower right)
polygon = np.array([[
(0, height),
(0, height/2),
(width , height/2),
(width , height),
]], np.int32)
cv2.fillPoly(mask, polygon, 255) # fill the polygon with blue color
cropped_edges = cv2.bitwise_and(edges, mask)
# cv2.imshow("roi",cropped_edges)
return cropped_edges
# Detect line segments using Hough Transform
def detect_line_segments(cropped_edges):
rho = 1
theta = np.pi / 180
min_threshold = 10
line_segments = cv2.HoughLinesP(cropped_edges, rho, theta, min_threshold,
np.array([]), minLineLength=5, maxLineGap=0)
return line_segments
# Average slope and intercept of the detected line segments
def average_slope_intercept(frame, line_segments):
lane_lines = []
if line_segments is None:
# print("no line segment detected")
return lane_lines
# Initialize variables
height, width,_ = frame.shape
left_fit = []
right_fit = []
boundary = 1/3
# Define the boundaries for left and right regions
left_region_boundary = width * (1 - boundary)
right_region_boundary = width * boundary
for line_segment in line_segments:
for x1, y1, x2, y2 in line_segment:
if x1 == x2:
# print("skipping vertical lines (slope = infinity)")
continue
# Calculate the slope and intercept of the line segment
fit = np.polyfit((x1, x2), (y1, y2), 1)
slope = (y2 - y1) / (x2 - x1)
intercept = y1 - (slope * x1)
# check if the slope is within a reasonable range
if slope < 0:
if x1 < left_region_boundary and x2 < left_region_boundary:
left_fit.append((slope, intercept))
else:
if x1 > right_region_boundary and x2 > right_region_boundary:
right_fit.append((slope, intercept))
# find the average slope and intercept for left and right lane lines
left_fit_average = np.average(left_fit, axis=0)
if len(left_fit) > 0:
lane_lines.append(make_points(frame, left_fit_average))
# if no left lane line detected, use the last known left lane line
right_fit_average = np.average(right_fit, axis=0)
if len(right_fit) > 0:
lane_lines.append(make_points(frame, right_fit_average))
# lane_lines is a 2-D array consisting the coordinates of the right and left lane lines
# for example: lane_lines = [[x1,y1,x2,y2],[x1,y1,x2,y2]]
# where the left array is for left lane and the right array is for right lane
# all coordinate points are in pixels
return lane_lines
# Make points for the lane lines based on the slope and intercept
def make_points(frame, line):
height, width, _ = frame.shape
slope, intercept = line
y1 = height # bottom of the frame
y2 = int(y1 / 2) # make points from middle of the frame down
# check if the slope is too small, if so, set it to a small value
if slope == 0:
slope = 0.1
# Calculate the x-coordinates of the points based on the slope and intercept
x1 = int((y1 - intercept) / slope)
x2 = int((y2 - intercept) / slope)
return [[x1, y1, x2, y2]]
# display lines on the frame
def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6): # line color (B,G,R)
line_image = np.zeros_like(frame)
# If no lines are detected, return the original frame
if lines is not None:
for line in lines:
for x1, y1, x2, y2 in line:
cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)
# Blend the line image with the original frame
line_image = cv2.addWeighted(frame, 0.8, line_image, 1, 1)
return line_image
# Get the steering angle based on the detected lane lines
def get_steering_angle(frame, lane_lines):
height, width, _ = frame.shape
# Calculate the steering angle based on the detected lane lines
if len(lane_lines) == 2:
_, _, left_x2, _ = lane_lines[0][0]
_, _, right_x2, _ = lane_lines[1][0]
mid = int(width / 2)
x_offset = (left_x2 + right_x2) / 2 - mid
y_offset = int(height / 2)
# If only one lane line is detected, use its x-coordinates to calculate the offset
elif len(lane_lines) == 1:
x1, _, x2, _ = lane_lines[0][0]
x_offset = x2 - x1
y_offset = int(height / 2)
# If no lane lines are detected, set offsets to zero
elif len(lane_lines) == 0:
x_offset = 0
y_offset = int(height / 2)
# Calculate the steering angle based on the offsets
angle_to_mid_radian = math.atan(x_offset / y_offset)
angle_to_mid_deg = int(angle_to_mid_radian * 180.0 / math.pi)
steering_angle = angle_to_mid_deg + 90
return steering_angle
# Display a heading line on the frame based on the steering angle
def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5):
heading_image = np.zeros_like(frame)
height, width, _ = frame.shape
# Calculate the end points of the heading line based on the steering angle
steering_angle_radian = steering_angle / 180.0 * math.pi
x1 = int(width / 2)
y1 = height
x2 = int(x1 - height / 2 / math.tan(steering_angle_radian))
y2 = int(height / 2)
# Draw the heading line on the heading image
cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)
heading_image = cv2.addWeighted(frame, 0.8, heading_image, 1, 1)
return heading_image
###############################################################################
# Plotting functions ##########################################################
def plot_pd(p_vals, d_vals, error, show_img=False):
# Plot the PD
fig, ax1 = plt.subplots()
t_ax = np.arange(len(p_vals))
ax1.plot(t_ax, p_vals, '-', label="P values")
ax1.plot(t_ax, d_vals, '-', label="D values")
ax2 = ax1.twinx()
ax2.plot(t_ax, error, '--r', label="Error")
# set the limits and labels
ax1.set_xlabel("Frames")
ax1.set_ylabel("PD Value")
ax2.set_ylim(-90, 90)
ax2.set_ylabel("Error Value")
# set the title and legend
plt.title("PD Values over time")
fig.legend()
fig.tight_layout()
plt.savefig("pd_plot.png")
if show_img:
plt.show()
plt.clf()
# Plot the PWM values for speed and steering
def plot_pwm(speed_pwms, turn_pwms, error, show_img=False):
# Plot the PWM
fig, ax1 = plt.subplots()
t_ax = np.arange(len(speed_pwms))
ax1.plot(t_ax, speed_pwms, '-', label="Speed PWM")
ax1.plot(t_ax, turn_pwms, '-', label="Steering PWM")
ax2 = ax1.twinx()
ax2.plot(t_ax, error, '--r', label="Error")
# set the limits and labels
ax1.set_xlabel("Frames")
ax1.set_ylabel("PWM Values")
ax2.set_ylabel("Error Value")
# set the title and legend
plt.title("PWM Values over time")
fig.legend()
plt.savefig("pwm_plot.png")
if show_img:
plt.show()
plt.clf()
###############################################################################
# Set up GPIO
calibrate_esc(speed)
# Set up video stream
print("Initializing video stream...")
video = cv2.VideoCapture(VIDEO_DEVICE_IDX)
video.set(cv2.CAP_PROP_FRAME_WIDTH, VIDEO_WIDTH)
video.set(cv2.CAP_PROP_FRAME_HEIGHT, VIDEO_HEIGHT)
print("Video stream initialized.")
time.sleep(3) # Allow time for camera window to open
# Start moving slowly
set_esc(speed, START_SPEED)
# TODO: Detect stop signs periodically
frame_counter = 0
# Booleans for handling stop light
passedFirstStopSign = False
secondStopSignTick = 0
# See if we've check the stop sign
stopSignCheck = 10
# The loop
while True:
# print("speed_dc: ", speed_dc)
ret, frame = video.read()
cv2.imshow("original", frame)
# Image processing for steering
edges = detect_edges(frame)
roi = region_of_interest(edges)
line_segments = detect_line_segments(roi)
'''
#5/1/25 Find the center between the lanes instead of tracking one
if line_segments is not None and len(line_segments) >= 2:
left_lane = min([line[0] for line in line_segments]) #left lane position
right_lane = max([line[2] for line in line_segments]) #right lane position
center_x = (left_lane + right_lane) / 2 #get center between lanes
steering_angle = get_steering_center(center_x, frame.shape[1]) #use frame width
else:
steering_angle = lastSteeringAngle
'''
# lastSteeringAngle = steering_angle #save steering angle
lane_lines = average_slope_intercept(frame,line_segments)
lane_lines_image = display_lines(frame,lane_lines)
steering_angle = get_steering_angle(frame, lane_lines)
heading_image = display_heading_line(lane_lines_image,steering_angle)
cv2.imshow("heading", heading_image)
# check for stop signs
frame_counter += 1
if frame_counter % stopSignCheck == 0:
if isRedFloorVisible(frame):
print("Red floor detected")
# If we haven't passed the first stop sign, stop
if not passedFirstStopSign:
time.sleep(1)
print("Stopping at 1st red")
reset_esc(speed)
time.sleep(4)
passedFirstStopSign = True
# Delay subsequent stop sign checks for some number of frames
secondStopSignTick = frame_counter + 500
set_esc(speed, START_SPEED)
# If we have passed the first stop sign, wait for a bit
elif frame_counter >= secondStopSignTick:
time.sleep(1)
print("Stopping at 2nd red")
reset_esc(speed)
break
# PD controller calculations
now = time.time()
dt = now - lastTime
deviation = steering_angle - 90 # deviation from non-turned wheels
# Error and PD adjustment
error = -deviation
base_turn = 0.0
proportional = kp * error
derivative = kd * (error - lastError) / dt
# Data for graphing
p_vals.append(proportional)
d_vals.append(derivative)
err_vals.append(error)
# Steering adjustments
turn_amt = base_turn + proportional + derivative
# Adjust steering based on calculated turn amount
turn_amt_mapped = map_value(
turn_amt,
in_min=-2.0, # raw minimum
in_max=2.0, # raw maximum
out_min=steering_right_dc, # servo left
out_max=steering_left_dc, # servo right
)
set_steering(steering, turn_amt_mapped)
print(f"PD error: {turn_amt}, steering duty cycle: {turn_amt_mapped}")
# Speed and steering updates for graphs
steer_pwm.append(turn_amt_mapped)
speed_pwm.append(speed_dc)
# Read encoder data for speed adjustments
time_diff_ms = 2
with open(ELAPSED_MS_PATH, "r") as r:
time_diff_ms = int(r.read())
if (time_diff_ms != 0):
print("time_diff: ", time_diff_ms)
# Adjust speed based on encoder feedback
if time_diff_ms >= 17:
# Accelerate
accelerate()
elif 5 < time_diff_ms < 17:
# Decelerate
decelerate()
# Update error values for PD control
lastError = error
lastTime = time.time()
# Wait to exit
key = cv2.waitKey(1)
if key == ESC_KEY_CODE:
break
# Cleanup
video.release()
cv2.destroyAllWindows()
reset_esc(speed)
reset_steering(steering)
GPIO.cleanup()
# Plot that shit
plot_pd(p_vals, d_vals, err_vals, True)
plot_pwm(speed_pwm, steer_pwm, err_vals, True)
#include <linux/module.h>
#include <linux/kernel.h>
#include <linux/init.h>
#include <linux/of_device.h>
#include <linux/platform_device.h>
#include <linux/gpio/consumer.h>
#include <linux/interrupt.h>
#include <linux/ktime.h>
#include <linux/fs.h>
#include <linux/device.h>
#include <linux/mod_devicetable.h>
#include <linux/moduleparam.h>
// Define the module parameters
static struct gpio_desc *button_gpio;
static unsigned int irq_number;
static ktime_t last_time;
static volatile s64 last_period_ns; //nanoseconds
static int elapsed_ms = 0;
module_param(elapsed_ms, int, 0644);
// sysfs attribute to show last measured period
static ssize_t speed_show(struct device *dev, struct device_attribute *attr, char *buf)
{
// Last year code resets to 0 when idle but idt we have to do that
return sprintf(buf, "%lld\n", last_period_ns);
}
static DEVICE_ATTR_RO(speed);
// Interrupt handler
static irqreturn_t button_irq_handler(int irq, void *dev_id)
{
ktime_t now = ktime_get();
last_period_ns = ktime_to_ns(ktime_sub(now, last_time));
elapsed_ms = (int)(last_period_ns / 1000000);
last_time = now;
pr_info("gpiod_driver: Detected encoder pulse, period = %lld ns\n", last_period_ns);
return IRQ_HANDLED;
}
// Probe function
static int encoder_probe(struct platform_device *pdev)
{
struct device *dev = &pdev->dev;
int ret;
dev_info(dev, "gpiod_driver: Probing device...\n");
// Get GPIO from device tree
button_gpio = devm_gpiod_get(dev, "button", GPIOD_IN);
if (IS_ERR(button_gpio)) {
dev_err(dev, "gpiod_driver: Failed to get button GPIO\n");
return PTR_ERR(button_gpio);
}
// Get IRQ number from GPIO
irq_number = gpiod_to_irq(button_gpio);
if (irq_number < 0) {
dev_err(dev, "gpiod_driver: Failed to get IRQ number\n");
return irq_number;
}
// Request IRQ
// Use IRQF_TRIGGER_FALLING to detect falling edge of the signal
ret = devm_request_irq(dev, irq_number, button_irq_handler, IRQF_TRIGGER_FALLING, "encoder_irq", NULL);
if (ret) {
dev_err(dev, "gpiod_driver: Failed to request IRQ\n");
return ret;
}
// Initialize last_time to current time
last_time = ktime_get();
// Create sysfs entry for speed
ret = device_create_file(dev, &dev_attr_speed);
if (ret) {
dev_err(dev, "gpiod_driver: Failed to create sysfs entry\n");
return ret;
}
// Set initial period to 0
dev_info(dev, "gpiod_driver: Probe successful\n");
return 0;
}
// Remove function
static void encoder_remove(struct platform_device *pdev)
{
struct device *dev = &pdev->dev;
device_remove_file(dev, &dev_attr_speed);
free_irq(irq_number, NULL);
dev_info(dev, "gpiod_driver: Driver removed\n");
}
// Device tree match table
static const struct of_device_id encoder_of_match[] = {
{ .compatible = "fun_overlay" },
{},
};
MODULE_DEVICE_TABLE(of, encoder_of_match);
// Platform driver structure
static struct platform_driver encoder_driver = {
.probe = encoder_probe,
.remove = encoder_remove,
.driver = {
.name = "slay_device_driver",
.of_match_table = encoder_of_match,
.owner = THIS_MODULE,
},
};
// Module initialization and cleanup
module_platform_driver(encoder_driver);
MODULE_LICENSE("GPL");
MODULE_AUTHOR("ELEC 424 Team 15");
MODULE_DESCRIPTION("Driver for RC Car");
Comments
