Temp. And Humidity Sensor With A CR2032 For Over 1 Year!

Long-range wireless sensor based on Whisper Node capable of running for over a year on a single CR2032, transmitting data every 60 seconds.

IntermediateShowcase (no instructions)2 hours34,363
Temp. And Humidity Sensor With A CR2032 For Over 1 Year!

Things used in this project

Hardware components

Whisper Node
Ultra-low power Arduino with built-in RFM69 and capable of running on a single AA
×1
DHT11 Temperature & Humidity Sensor (4 pins)
DHT11 Temperature & Humidity Sensor (4 pins)
Cheap, not reliable and very slow!
×1
Coin Cell Battery CR2032
Coin Cell Battery CR2032
×1
Raspberry Pi 2 Model B
Raspberry Pi 2 Model B
×1
Resistor 10k ohm
Resistor 10k ohm
×1
Arduino UNO & Genuino UNO
Arduino UNO & Genuino UNO
×1
RFM69W sub-GHz Module
×1

Software apps and online services

Cloud IoT Core
Google Cloud IoT Core
Grafana
InfluxDB
Arduino IDE
Arduino IDE

Story

Read more

Schematics

Nordic Article about CR2032

High pulse drain impact on CR2032 coin cell battery capacity

TI Article about coin cells and peak current draw

Coin cells and peak current draw. Using capacitor to minimize voltage drops.

Internet Article on CR2032 and BLE

Study about the CR2032 in Bluetooth Low Energy applications.

Code

DHT11Node.ino

Arduino
Note this code is designed to run on the Whisper Node but can be adapted to any other AVR MCU. Also, it requires the Talk2 Library, Low-Power Library, RadioHead RFM69 Library and the DHT Adafruit Library as well. The last one has been modified to be more energy efficient - details can be found in the Article.
/*
 * Talk2 Example: DHT11 Sensor Node
 * http://talk2.wisen.com.au
 *
 * This example demonstrate how you can use the Talk2 Whisper Node to
 * read and send temperature and humidity data from a DHT11 (or DHT22)
 * to a Base node.
 *
 *  Copyright 2015-2016 by Mike Musskopf.
 *
 *  This program is free software: you can redistribute it and/or modify
 *  it under the terms of the GNU General Public License as published by
 *  the Free Software Foundation, either version 3 of the License, or
 *  (at your option) any later version.
 *
 *  This program is distributed in the hope that it will be useful,
 *  but WITHOUT ANY WARRANTY; without even the implied warranty of
 *  MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
 *  GNU General Public License for more details.
 *
 *  You should have received a copy of the GNU General Public License
 *  along with this program. If not, see <http://www.gnu.org/licenses/>.
 *
 */
#include <T2WhisperNode.h>
#include <LowPower.h>
#include <DHT.h>

// DHT 11
#define DHT_PWD_PIN A2 // We power the DHT11 via a MCU GPIO so we can control when it's up or not
#define DHT_DATA_PIN A1
#define DHT_TYPE DHT11
DHT dht(DHT_DATA_PIN, DHT_TYPE);

// SPI Flash
T2Flash myFlash;

// RFM69 Radio
#define RADIO_FREQUENCY 918.0
#define RADIO_TX_POWER 13
#define RADIO_ENCRYPTION_KEY { 0x00, 0x01, 0x02, 0x03, 0x04, 0x05, 0x06, 0x07, 0x08, 0x09, 0x0A, 0x0B, 0x0C, 0x0D, 0x0E, 0x0F }
RH_RF69 myRadio;
uint8_t radioBuf[(T2_MESSAGE_HEADERS_LEN + T2_MESSAGE_MAX_DATA_LEN)];

// T2 Message
T2Message myMsg;
#define nodeAddr 0x81
#define baseAddr 0x0a

void setup()
{
  // Serial
  Serial.begin(115200);
  Serial.println(F("Example: DHT11 Sensor Node"));

  Serial.println(F("Putting Radio and SPI Flash to Sleep"));
  // Radio - Initialize the radio and put it to sleep to save energy
  myRadio.init();
  myRadio.setModemConfig(RH_RF69::FSK_Rb250Fd250);
  myRadio.setFrequency(RADIO_FREQUENCY);
  uint8_t myRadioEncryptionKey[] = RADIO_ENCRYPTION_KEY;
  myRadio.setEncryptionKey(myRadioEncryptionKey);
  myRadio.setTxPower(RADIO_TX_POWER);
  myRadio.sleep();

  // Flash - We're not using, so just power it down to save energy
  myFlash.init(T2_WPN_FLASH_SPI_CS);
  myFlash.powerDown();

  // DHT11
  digitalWrite(DHT_PWD_PIN, LOW);
  pinMode(DHT_PWD_PIN, OUTPUT);
  dht.begin();

  // Setup the Blue LED pin
  digitalWrite(T2_WPN_LED_1, LOW); // Set LED to Off
  pinMode(T2_WPN_LED_1, OUTPUT);   // Set LED pint to OUTPUT

}

uint8_t loopCount = 7;

void loop()
{

  // We only do something every 7 sleep cycles (7 * 8 = 56 seconds)
  if(loopCount == 7)
  {

    // Blue LED blink means we just wake up
    digitalWrite(T2_WPN_LED_1, HIGH);
    delay(5);
    digitalWrite(T2_WPN_LED_1, LOW);

    // Do some work!
    sendTestVoltage(1);
    sendTestVoltage(2);
    sendTempHumidity();

    loopCount = 0;

  }

  // Using Low-Power library to put the MCU to Sleep
  LowPower.powerDown(SLEEP_8S, ADC_OFF, BOD_OFF);
  loopCount++;

}

void sendTempHumidity()
{
  // Turn the Sensor ON
  digitalWrite(DHT_PWD_PIN, HIGH);

  // Read temperature as Celsius * 100 to remove any decimals
  // False, True means we don't want Fahrenheit and we want to force the reading.
  int16_t t = dht.readTemperature(false, true) * 100;

  // * 100 to remove any decimals. We do not force the reading, so we use the last info
  uint16_t h = dht.readHumidity() * 100;

  //Turn the Sensor OFF
  digitalWrite(DHT_PWD_PIN, LOW);

  /*
  // For Debbuging only
  Serial.println(t);
  Serial.println(h);
  delay(10);
  */

  // Prepare Temperature Message and send
  myMsg.cmd = 0x03; // Return Data
  myMsg.idx = 0x05; // HID and Sensors
  myMsg.sdx = 0x0a; // Temperature
  myMsg.data[0] = 0x01; // Operation Temp in Celcius * 100
  myMsg.data[1] = 0x01; // Sensor ID - we only have 1 in this case
  myMsg.data[2] = t >> 8;
  myMsg.data[3] = t;
  myMsg.len = 4; // Update length
  sendMessage();

  // Now change message details with the Humidity details and send it
  myMsg.cmd = 0x03; // Return Data
  myMsg.idx = 0x05; // HID and Sensors
  myMsg.sdx = 0x0b; // Humidity
  myMsg.data[0] = 0x01; // Operation Humidity in % * 100
  myMsg.data[1] = 0x01; // Sensor ID - we only have 1 in this case
  myMsg.data[2] = h >> 8;
  myMsg.data[3] = h;
  myMsg.len = 4; // Update length
  sendMessage();

}

void sendTestVoltage(uint8_t supply)
{
  uint16_t voltage = 0;

  // Get Voltage readings from supply/battery
  if(supply == 1)
  {
    voltage = T2Utils::readVoltage(T2_WPN_VBAT_VOLTAGE, T2_WPN_VBAT_CONTROL);
    myMsg.sdx = 0x64; // Battery
  }

  if(supply == 2)
  {
    voltage = T2Utils::readVoltage(T2_WPN_VIN_VOLTAGE, T2_WPN_VIN_CONTROL);
    myMsg.sdx = 0x65; // Supply
  }

  // Fill the message details and send it
  myMsg.cmd = 0x03; // Return Data
  myMsg.idx = 0x06; // Node Info
  myMsg.data[0] = 0x01; // Operation Last Reading
  myMsg.data[1] = 0x01; // Battery/Supply Index, if multiple supplies
  myMsg.data[2] = voltage >> 8;
  myMsg.data[3] = voltage;
  myMsg.len = 4; // Update length

  sendMessage();

}

void sendMessage()
{
  uint8_t radioBufLen = 0;

  // Prepare the Message headers
  myMsg.src = nodeAddr;
  myMsg.dst = baseAddr;

  // Encode Message and get the full length
  myMsg.getSerializedMessage(radioBuf, &radioBufLen);

  // Send it
  myRadio.send(radioBuf, radioBufLen);
  myRadio.waitPacketSent(100);
  myRadio.sleep();

}

Whisper Node Board

Documentation for the Whisper Node Board

Talk2 Arduino Library

Whisper Node Library

Low-Power Library

Library to control ATmega328p power modes/sleeping

DHT Adafruit LIbrary

Note that the original library is not very efficient. Look in the post the details how to replace "delays" with "sleeps" to save energy.
