Shortest Path of Line Maze - Curved and Zig-zag Track

Traverse all path and find the shortest path from starting point to finish.

IntermediateShowcase (no instructions)9,653

Shortest Path of Line Maze - Curved and Zig-zag Track

Things used in this project

Hardware components

Arduino UNO

I got it installed on a line follower mobile robot, from Kokaro (Komunitas Kampung Robot) through Mr. Arief Andi Yudanarko from Pendidikan Elektronika Negeri Surabaya.

Software apps and online services

Arduino IDE

Story

Final Project of Bachelor's Degree in Informatics Engineering

This project is about a line follower mobile robot that is used to find the shortest path from the starting point to the end of maze. The track is made of black tape on a white surface. In this project we used a white backdrop. The difference between the maze of this project and the previous one is that we have to make this mobile robot works on a track with curved and zig-zag track. It was for the final project of my bachelor's degree that finished in July of 2014.

These are the videos that I have uploaded to YouTube:

Line Maze Solving - Curved and Zig-zag Track (Jalur Lengkung dan Zig-zag)

Line Maze Solving - Standard Line Maze (Belokan Persegi)

A paper about this project has been published in 2018 Seventh ICT International Student Project Conference (ICT-ISPC).

Date of Conference: 11-13 July 2018

Date Added to IEEE Xplore: 08 November 2018

DOI: 10.1109/ICT-ISPC.2018.8523975

Publisher: IEEE

Conference Location: Nakhonpathom, Thailand, Thailand

Link: https://ieeexplore.ieee.org/abstract/document/8523975

The Robot

Line Maze Solving - Curved and Zig-zag Track

// R. Joko Musridho
// Informatics Engineering – Faculty of Science and Technology
// UIN SUSKA RIAU
// Pekanbaru, Riau, Indonesia

// this was my Bachelor’s Degree final project (viva voce on July 22nd, 2014)


int sensor0 = A4; //leftmost sensor, pin A4
int sensor1 = A3;
int sensor2 = A2;
int sensor3 = A1;
int sensor4 = A0;// rightmost sensor, pin A0

int mata0; // mata means “eye”
int mata1;
int mata2;
int mata3;
int mata4;

int motorR = 4; //forward or reverse, pin 4
int onR = 5; //magnitude of the power for the motor
int onL = 6; //magnitude of the power for the motor
int motorL = 7; //forward or reverse, pin 7

int data;
unsigned char s[5]; //array for sensors

int pathlength; //variable to record the total of path length
int readpath; //variable to call the path record
char path[99]; //array for path record

int threshold = 990; //threshold between black/white

//led to show what the robot is recording (L/R/S/U)
int BLUEled = 13;
int GREENled = 12;
int YELLOWled = 11;

void strongright()
{
  analogWrite(onL, 255);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 105);
  digitalWrite(motorR, LOW);//to keep the robot on the line
}

void midright2()
{
  analogWrite(onL, 255);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 105);
  digitalWrite(motorR, HIGH);
}

void midright()
{
  analogWrite(onL, 255);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 125);
  digitalWrite(motorR, HIGH);
}

void softright()
{
  analogWrite(onL, 255);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 225);
  digitalWrite(motorR, HIGH);
}

void moveforward()
{
  analogWrite(onL, 255);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 255);
  digitalWrite(motorR, HIGH);
}

void softleft()
{
  analogWrite(onL, 225);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 255);
  digitalWrite(motorR, HIGH);
}

void midleft()
{
  analogWrite(onL, 125);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 255);
  digitalWrite(motorR, HIGH);
}

void midleft2()
{
  analogWrite(onL, 105);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 255);
  digitalWrite(motorR, HIGH);
}

void strongleft()
{
  analogWrite(onL, 105);
  digitalWrite(motorL, LOW);//to keep the robot on the line
  analogWrite(onR, 255);
  digitalWrite(motorR, HIGH);
}

void turnright()
{
  analogWrite(onL, 255);
  digitalWrite(motorL, HIGH);
  analogWrite(onR, 255);
  digitalWrite(motorR, LOW);
}

void turnleft()
{
  analogWrite(onL, 255);
  digitalWrite(motorL, LOW);
  analogWrite(onR, 255);
  digitalWrite(motorR, HIGH);
}

void righttillstraight()
{
  turnright();
  delay(500); //to be free from the line if there is a straight intersection (exit 2)
  readsensor();
  while (s[2]==0)
  {
    turnright();readsensor();
  }
}

void lefttillstraight()
{
  turnleft();
  delay(500); //to be free from the line if there is a straight intersection (exit 2)
  readsensor();
  while (s[2]==0)
  {
    turnleft();readsensor();
  }
}

void turnaround()
{
  lefttillstraight();
}

void stop()
{
  analogWrite(onL, 0);
  digitalWrite(motorL, LOW);
  analogWrite(onR, 0);
  digitalWrite(motorR, LOW);
}

void lilmoveforward()
{
  moveforward();
  delay(150); // adjust based on your batteries power, new one would be stronger than the drained-out one, of course
  readsensor();
}

void ONforBLUEled()
{
  digitalWrite (BLUEled, HIGH); delay(25);
  digitalWrite (BLUEled, LOW);
}

void ONforGREENled()
{
  digitalWrite (GREENled, HIGH); delay(25);
  digitalWrite (GREENled, LOW);
}

void ONforYELLOWled()
{
  digitalWrite (YELLOWled, HIGH); delay(25);
  digitalWrite (YELLOWled, LOW);
}

void readsensor()
{
  //if declared outside, the sensor readings become “11111”
  mata0 = analogRead(sensor0);
  mata1 = analogRead(sensor1);
  mata2 = analogRead(sensor2);
  mata3 = analogRead(sensor3);
  mata4 = analogRead(sensor4);

//converting to digital
if (mata0 < threshold)
  {s[0] = 1;}
else
  {s[0] = 0;}

if (mata1 < threshold)
  {s[1] = 1;}
else
  {s[1] = 0;}

if (mata2 < threshold)
  {s[2] = 1;}
else
  {s[2] = 0;}

if (mata3 < threshold)
  {s[3] = 1;}
else
  {s[3] = 0;}

if (mata4 < threshold)
  {s[4] = 1;}
else
  {s[4] = 0;}

//change the sensor readings into a series of binary number
data=(s[0]*16)+(s[1]*8)+(s[2]*4)+(s[3]*2)+(s[4]*1);

//to display the sensor readings on serial monitor
Serial.print(s[0]);
Serial.print("   ");
Serial.print(s[1]);
Serial.print("   ");
Serial.print(s[2]);
Serial.print("   ");
Serial.print(s[3]);
Serial.print("   ");
Serial.print(s[4]);
Serial.println(" ");
}

//Intersection condition -------------- 0b00abcde
void condition()
{
 if (data==0b0000100)
   {moveforward();}
 else if (data==0b0000001)
   {
    strongright();
    readsensor();
    while (s[3]==0)
    {
      strongright();
      readsensor();
    }
   }
 else if (data==0b0000011)
   {midright2();}
 else if (data==0b0000010)
   {midright();}
 else if (data==0b0000110)
   {softright();}
 else if (data==0b0001100)
   {softleft();}
 else if (data==0b0001000)
   {midleft();}
 else if (data==0b0011000)
   {midleft2();}
 else if (data==0b0010000)
   {
    strongleft();
    readsensor();
    while (s[1]==0)
    {
     strongleft();
     readsensor();
    }
   }
 else //there is a right angle turn or intersection
   {
      if (data==0b0000000) //dead end
        {
          turnaround();
          path[pathlength]='U';pathlength++;//save U
          ONforYELLOWled();
        }
      else if (data==0b0011111) //T, +, end of maze
        {
          lilmoveforward();
          if (data==0b0000000)// T intersection
            {
              lilmoveforward(); //turning stabilizer
              righttillstraight();
              path[pathlength]='R';pathlength++;//save R
              ONforGREENled();
            }
          else if (data==0b0011111)//end of maze
            {
              stop(); //stopping the robot
              path[pathlength]='F';pathlength++;//save F

              //sign for the end of maze
              ONforBLUEled();delay(300);
              ONforBLUEled();delay(300);
              ONforYELLOWled();delay(300);
              ONforYELLOWled();delay(300);
              ONforGREENled();delay(300);
              ONforGREENled();delay(300);
              ONforBLUEled();ONforYELLOWled();ONforGREENled();

              shortpath(); //calculate the shortest path
              ONforBLUEled();ONforYELLOWled();ONforGREENled();

              //sign to prepare the robot (put it back) on the starting position
              ONforBLUEled();delay(300);
              ONforYELLOWled();delay(1000);
              ONforGREENled();delay(300);
              ONforGREENled();delay(300);
              ONforGREENled();delay(1000);

              shortestpath(); //move through the shortest path
            }
          else //ada garis ke arah lurus 00100 dll (+ intersection)
            {
              lilmoveforward(); //turning stabilizer
              righttillstraight();
              path[pathlength]='R';pathlength++;//save R
              ONforGREENled();
            }
        }
	//straight or right junction
      else if ((data==0b0000111)||(data==0b0001111))
        {
          lilmoveforward();lilmoveforward();
          if (data==0b0000000)//right only
            {
              lilmoveforward();
              righttillstraight();
            }
    else if (s[0]==0)
          	      {
              lilmoveforward();
              righttillstraight();
              path[pathlength]='R';pathlength++;//save R
              ONforGREENled();
            }
        }
//left or straight junction
      else if ((data==0b0011100)||(data==0b0011110))
        {
          lilmoveforward();lilmoveforward();
          if (data==0b0000000) //left only
            {
              lilmoveforward();
              lefttillstraight();
            }
        else if (s[4]==0) //there is a straight path
            {
              moveforward();
              path[pathlength]='S';pathlength++;//save S
              ONforBLUEled();
            }
         }
    }
}

void shortpath() //calculate the shortest path
{
  //because (..F) is the last and there is no U recorderd before F
  int x = (pathlength-2);

  while (x > 0)
  {
    if (path[x]=='U')
      {
        if (path[x-1]=='L' && path[x+1]=='L')
          {path[x-1]='S';path[x]='O';path[x+1]='O';}
        else if (path[x-1]=='L' && path[x+1]=='S')
          {path[x-1]='R';path[x]='O';path[x+1]='O';}
        else if (path[x-1]=='R' && path[x+1]=='R')
          {path[x-1]='S';path[x]='O';path[x+1]='O';}
        else if (path[x-1]=='R' && path[x+1]=='S')
          {path[x-1]='L';path[x]='O';path[x+1]='O';}
        else if (path[x-1]=='S' && path[x+1]=='L')
          {path[x-1]='R';path[x]='O';path[x+1]='O';}
        else if (path[x-1]=='S' && path[x+1]=='R')
          {path[x-1]='L';path[x]='O';path[x+1]='O';}
        else if (path[x-1]=='L' && path[x+1]=='R')
          {
            path[x-1]='U';path[x]='O';path[x+1]='O';

          }
        else if (path[x-1]=='R' && path[x+1]=='L')
          {
            path[x-1]='U';path[x]='O';path[x+1]='O';
            if
          }
        else if (path[x-1]=='S' && path[x+1]=='S')
          {
            path[x-1]='U';path[x]='O';path[x+1]='O';

          }
        //---------------------------------------
        x--;
      }
    else
    	{x--;}
  }
}

void shortestpath()
{
 readsensor();
 if (data==0b0000100)
   {moveforward();}
 else if (data==0b0000001)
   {
    strongright();
    readsensor();
    while (s[3]==0)
    {
      strongright();
      readsensor();
    }
   }
 else if (data==0b0000011)
   {midright2();}
 else if (data==0b0000010)
   {midright();}
 else if (data==0b0000110)
   {softright();}
 else if (data==0b0001100)
   {softleft();}
 else if (data==0b0001000)
   {midleft();}
 else if (data==0b0011000)
   {midleft2();}
 else if (data==0b0010000)
   {
    strongleft();
    readsensor();
    while (s[1]==0)
    {
     strongleft();
     readsensor();
    }
   }
 else
     //right or straight
     if ((data==0b0000111)||(data==0b0001111))
      {
        lilmoveforward();
        if (data==0b0000000)//right only
          {
            lilmoveforward();
            righttillstraight();
          }
        else //there is a straight path
          {
            choosepath();
          }
      }
    //left or straight
    else if ((data==0b0011100)||(data==0b0011110))
      {
        lilmoveforward();
        if (data==0b0000000) //left only
          {
            lilmoveforward();
            lefttillstraight();
          }
        else //there is a straight path
          {
            choosepath();
          }
      }
    //T, +, or END OF MAZE
    else if  (data==0b0011111)
      {
        choosepath();
      }
  shortestpath();
}

void choosepath()//to get rid of the effect of “path[]==0” in the record
{
  if (path[readpath]=='F')
    {
      stop();finish();
    }
  else if (path[readpath]=='R')
    {
      ONforGREENled();
      righttillstraight();
    }
  else if (path[readpath]=='S')
    {
      ONforGREENled();ONforBLUEled();
      moveforward();delay(200);
    }
  else if (path[readpath]=='L')
    {
      ONforGREENled();ONforYELLOWled();
      lefttillstraight();
    }
  else if (path[readpath]=='O')
    {
      readpath++;choosepath();
    }
  readpath++;
  shortestpath();
}

void finish()
{
  ONforBLUEled();delay(100);
  ONforYELLOWled();delay(100);
  ONforGREENled();delay(100);
  finish();
}

void setup()
{
  Serial.begin(9600);
  pinMode(motorR, OUTPUT);
  pinMode(motorL, OUTPUT);
  pinMode(onR, OUTPUT);
  pinMode(onL, OUTPUT);
  pinMode(BLUEled, OUTPUT);
  pinMode(YELLOWled, OUTPUT);
  pinMode(GREENled, OUTPUT);
  analogReference(INTERNAL);
}

void loop()
{
 readsensor();
 condition();
}
