Wheatley virtual companion robot

A little robot designed like Wheatley from the videogame Portal 2. The robot will act as a helpfull AI assistant.

IntermediateWork in progress10 hours254
Wheatley virtual companion robot

Things used in this project

Hardware components

Microphone Amplifier Breakout
Adafruit Microphone Amplifier Breakout
×1
Speaker: 0.25W, 8 ohms
Speaker: 0.25W, 8 ohms
×1
LED Light Bulb, Frosted GLS
LED Light Bulb, Frosted GLS
×1

Software apps and online services

Fusion
Autodesk Fusion

Hand tools and fabrication machines

PCBWay 3D Printing
PCBWay 3D Printing

Story

Read more

Custom parts and enclosures

Enclosure 3d model

I will use this model as a base design to modify to fit the needs of my robot and later print out for the robot encasing. This model was made by D3DARTM in sketchfab: https://sketchfab.com/3d-models/wheatley-core-from-portal-2-original-c1bdc8523a8849bd81d6aa901daa409f

Schematics

Circuit overview

A simple circuit diagram I made for my wheatly robot.
