IoT Weather and UV lIight with LoRaWAN and The Thind

// Project : IoT Weather and Air Quality Station
// Board: RAK4631 (Nordic NRF52840)
// Base: RAK1907
// Sensors: BME680, LTR-390UV-01, Rain Sensor, PMSA003I
// Display: RAK1821 OLED
// LoRaWAN Platform: The Things Network

#include <Wire.h>
#include <Adafruit_Sensor.h>
#include <Adafruit_BME680.h>          // For BME680
#include <Adafruit_GFX.h>             // For OLED
#include <Adafruit_SSD1306.h>         // For OLED
#include <SparkFun_PMSA003I_Arduino_Library.h> // For PMSA003I
#include <Adafruit_LTR390.h>         // For LTR-390UV-01
#include <LoRaWan-RAK4631.h>          // LoRaWAN library for RAK4631
#include <SPI.h>

// LoRaWAN Configuration (OTAA) - REPLACE WITH YOUR THE THINGS NETWORK CREDENTIALS!
uint8_t nodeDeviceEUI[8] = {0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX}; // DevEUI
uint8_t nodeAppEUI[8] = {0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX};   // AppEUI / JoinEUI
uint8_t nodeAppKey[16] = {0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX, 0xXX}; // AppKey

// LoRaWAN region configuration (e.g., RAK_REGION_EU868, RAK_REGION_US915)
#define LORAWAN_REGION RAK_REGION_EU868
#define LORAWAN_DEVEUI nodeDeviceEUI
#define LORAWAN_APPEUI nodeAppEUI
#define LORAWAN_APPKEY nodeAppKey
#define LORAWAN_CHANNEL_MASK NULL
#define LORAWAN_PREAMBLE_LENGTH 8
#define LORAWAN_ADR_STATE LORAWAN_ADR_ON
#define LORAWAN_TX_POWER LORAWAN_TX_POWER_0
#define LORAWAN_DATARATE LORAWAN_DR_3
#define LORAWAN_PUBLIC_NETWORK true
#define LORAWAN_DUTYCYCLE_ON false // Set to true for production to comply with regulations
#define LORAWAN_APP_PORT 1          // LoRaWAN application port

// Sensor Pins
#define RAIN_SENSOR_PIN WB_A0 // Analog pin for the rain sensor
#define OLED_RESET -1         // Reset pin # (or -1 if sharing Arduino reset pin)
#define SCREEN_WIDTH 128      // OLED display width, in pixels
#define SCREEN_HEIGHT 64      // OLED display height, in pixels

// Sensor instances
Adafruit_BME680 bme;             // I2C
Adafruit_LTR390 ltr;             // I2C
PMSA003I airSensor;              // I2C for PMSA003I
Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, OLED_RESET); // I2C for OLED

// Variables to store sensor readings
float temperature, humidity, pressure, gas_resistance;
uint16_t pm1_0, pm2_5, pm10_0;
float uv_index, ambient_light;
bool is_raining;

void setup() {
  Serial.begin(115200);
  delay(100);
  Serial.println("Starting IoT Weather Station...");

  // Initialize I2C
  Wire.begin();

  // Initialize OLED
  if (!display.begin(SSD1306_SWITCHCAPVCC, 0x3C)) { // Address 0x3C for 128x64
    Serial.println(F("SSD1306 allocation failed"));
    for (;;); // Don't proceed, loop forever
  }
  display.display();
  delay(2000);
  display.clearDisplay();
  display.setTextSize(1);
  display.setTextColor(SSD1306_WHITE);
  display.setCursor(0, 0);
  display.println("Initializing...");
  display.display();

  // Initialize BME680
  if (!bme.begin(0x76)) { // Default I2C address for BME680
    Serial.println("Could not find BME680 sensor. Check connections!");
    display.clearDisplay(); display.setCursor(0, 0); display.println("BME680 Error!"); display.display();
    while (1);
  }
  bme.setTemperatureOversampling(BME680_OVERSAMPLING_8X);
  bme.setHumidityOversampling(BME680_OVERSAMPLING_4X);
  bme.setPressureOversampling(BME680_OVERSAMPLING_4X);
  bme.setIIRFilterSize(BME680_FILTER_SIZE_3);
  bme.setGasHeater(320, 150); // 320 C for 150 ms

  // Initialize PMSA003I
  // Ensure the PMSA003I is connected to the I2C bus (Wire)
  if (airSensor.begin(Wire)) {
    Serial.println("PMSA003I connected.");
  } else {
    Serial.println("Could not find PMSA003I sensor. Check connections!");
    display.clearDisplay(); display.setCursor(0, 0); display.println("PMSA003I Error!"); display.display();
    while (1);
  }

  // Initialize LTR-390UV-01
  if (!ltr.begin()) {
    Serial.println("Could not find LTR390 sensor. Check connections!");
    display.clearDisplay(); display.setCursor(0, 0); display.println("LTR390 Error!"); display.display();
    while (1);
  }
  ltr.setGain(LTR390_GAIN_3);
  ltr.setResolution(LTR390_RESOLUTION_18BIT);
  ltr.setMeasurementTime(LTR390_MEASUREMENTTIME_100MS);

  // Initialize rain sensor (analog pin)
  pinMode(RAIN_SENSOR_PIN, INPUT);

  // Initialize LoRaWAN
  Serial.println("Initializing LoRaWAN...");
  if (api.lorawan.init(LORAWAN_REGION) != true) {
    Serial.println("LoRaWAN init failed!");
    display.clearDisplay(); display.setCursor(0, 0); display.println("LoRaWAN Init Error!"); display.display();
    while (1);
  }

  api.lorawan.set_dev_eui(LORAWAN_DEVEUI);
  api.lorawan.set_app_eui(LORAWAN_APPEUI);
  api.lorawan.set_app_key(LORAWAN_APPKEY);
  api.lorawan.set_channel_mask(LORAWAN_CHANNEL_MASK);
  api.lorawan.set_preamble_length(LORAWAN_PREAMBLE_LENGTH);
  api.lorawan.set_adr_state(LORAWAN_ADR_STATE);
  api.lorawan.set_tx_power(LORAWAN_TX_POWER);
  api.lorawan.set_datarate(LORAWAN_DATARATE);
  api.lorawan.set_public_network_mode(LORAWAN_PUBLIC_NETWORK);
  api.lorawan.set_duty_cycle_mode(LORAWAN_DUTYCYCLE_ON); // Adjust for regional regulations

  // Join LoRaWAN network
  Serial.println("Attempting to join LoRaWAN network (OTAA)...");
  display.clearDisplay(); display.setCursor(0, 0); display.println("Joining LoRaWAN..."); display.display();
  if (api.lorawan.join()) {
    Serial.println("Joined LoRaWAN network successfully!");
    display.clearDisplay(); display.setCursor(0, 0); display.println("Joined LoRaWAN!"); display.display();
  } else {
    Serial.println("Failed to join LoRaWAN network. Retrying...");
    display.clearDisplay(); display.setCursor(0, 0); display.println("Join Failed!"); display.display();
    // In a real project, implement a retry mechanism with delay or low-power mode
    while (1);
  }
  delay(2000);
}

void loop() {
  readSensors();
  displayData();
  sendLoRaWANData();

  // Enter low-power mode to save battery
  Serial.println("Entering low-power mode...");
  api.system.sleep.all(60000); // Sleep for 60 seconds (60000 ms)
}

void readSensors() {
  Serial.println("Reading sensors...");

  // Read BME680
  if (!bme.performReading()) {
    Serial.println("Failed to read BME680.");
  } else {
    temperature = bme.temperature;
    humidity = bme.humidity;
    pressure = bme.pressure / 100.0; // hPa
    gas_resistance = bme.gas_resistance / 1000.0; // kOhms
    Serial.printf("Temp: %.2f C, Hum: %.2f %%, Pres: %.2f hPa, Gas: %.2f kOhms\n", temperature, humidity, pressure, gas_resistance);
  }

  // Read PMSA003I
  PMSA003I::pmsaData data;
  if (airSensor.read(&data)) {
    pm1_0 = data.PM1_0;
    pm2_5 = data.PM2_5;
    pm10_0 = data.PM10_0;
    Serial.printf("PM1.0: %d, PM2.5: %d, PM10.0: %d ug/m3\n", pm1_0, pm2_5, pm10_0);
  } else {
    Serial.println("Failed to read PMSA003I.");
  }

  // Read LTR-390UV-01
  if (ltr.newData()) {
    uv_index = ltr.readUVI();
    ambient_light = ltr.readALS();
    Serial.printf("UV Index: %.2f, Ambient Light: %.2f\n", uv_index, ambient_light);
  } else {
    Serial.println("Failed to read LTR390!");
  }

  // Read rain sensor
  int rain_analog_val = analogRead(RAIN_SENSOR_PIN);
  is_raining = (rain_analog_val < 500); // Simple threshold: if value is low, it's raining
  Serial.printf("Rain Sensor: %d (Raining: %s)\n", rain_analog_val, is_raining ? "Yes" : "No");
}

void displayData() {
  display.clearDisplay();
  display.setCursor(0, 0);
  display.printf("Temp: %.1f C\n", temperature);
  display.printf("Hum: %.1f %%\n", humidity);
  display.printf("Pres: %.0f hPa\n", pressure);
  display.printf("PM2.5: %d ug/m3\n", pm2_5);
  display.printf("UV: %.1f\n", uv_index);
  display.printf("Rain: %s\n", is_raining ? "Yes" : "No");
  display.display();
}

void sendLoRaWANData() {
  // Create a buffer for the LoRaWAN payload
  // Using Cayenne LPP format for easy decoding in The Things Network
  // Ensure your Payload Formatter in TTN is set to "Cayenne LPP"
  uint8_t lpp_payload[50]; // Sufficient space for data
  uint8_t lpp_payload_size = 0;

  // Channel 1: Temperature (BME680)
  lpp_payload[lpp_payload_size++] = 1; // Channel
  lpp_payload[lpp_payload_size++] = LPP_TEMPERATURE;
  lpp_payload[lpp_payload_size++] = (uint8_t)(temperature * 2); // LPP_TEMPERATURE is 0.5 C/unit

  // Channel 2: Humidity (BME680)
  lpp_payload[lpp_payload_size++] = 2; // Channel
  lpp_payload[lpp_payload_size++] = LPP_HUMIDITY;
  lpp_payload[lpp_payload_size++] = (uint8_t)(humidity * 2); // LPP_HUMIDITY is 0.5 %/unit

  // Channel 3: Pressure (BME680)
  lpp_payload[lpp_payload_size++] = 3; // Channel
  lpp_payload[lpp_payload_size++] = LPP_BAROMETRIC_PRESSURE;
  // LPP_BAROMETRIC_PRESSURE is 2 hPa/unit, sent as 2 bytes
  lpp_payload[lpp_payload_size++] = (uint8_t)((uint16_t)(pressure / 2) >> 8);
  lpp_payload[lpp_payload_size++] = (uint8_t)((uint16_t)(pressure / 2) & 0xFF);

  // Channel 4: Gas Resistance (BME680) - Use LPP_ANALOG_INPUT for generic values (0.01 unit/unit)
  lpp_payload[lpp_payload_size++] = 4; // Channel
  lpp_payload[lpp_payload_size++] = LPP_ANALOG_INPUT;
  // Convert to int16 and scale by 100 for 2 decimal places
  int16_t gas_res_scaled = (int16_t)(gas_resistance * 100);
  lpp_payload[lpp_payload_size++] = (uint8_t)(gas_res_scaled >> 8);
  lpp_payload[lpp_payload_size++] = (uint8_t)(gas_res_scaled & 0xFF);

  // Channel 5: UV Index (LTR390) - Use LPP_ANALOG_INPUT (0.01 unit/unit)
  lpp_payload[lpp_payload_size++] = 5; // Channel
  lpp_payload[lpp_payload_size++] = LPP_ANALOG_INPUT;
  int16_t uv_scaled = (int16_t)(uv_index * 100);
  lpp_payload[lpp_payload_size++] = (uint8_t)(uv_scaled >> 8);
  lpp_payload[lpp_payload_size++] = (uint8_t)(uv_scaled & 0xFF);

  // Channel 6: PM2.5 (PMSA003I) - Use LPP_UNITS or LPP_ANALOG_INPUT for integers
  // Since PM2.5 is usually an integer, we can send it directly as 2 bytes
  lpp_payload[lpp_payload_size++] = 6; // Channel
  lpp_payload[lpp_payload_size++] = LPP_ANALOG_INPUT; // Using ANALOG_INPUT for generic integer
  lpp_payload[lpp_payload_size++] = (uint8_t)(pm2_5 >> 8);
  lpp_payload[lpp_payload_size++] = (uint8_t)(pm2_5 & 0xFF);

  // Channel 7: Rain Sensor (Analog Value) - Use LPP_ANALOG_INPUT
  lpp_payload[lpp_payload_size++] = 7; // Channel
  lpp_payload[lpp_payload_size++] = LPP_ANALOG_INPUT;
  lpp_payload[lpp_payload_size++] = (uint8_t)(rain_sensor_value >> 8);
  lpp_payload[lpp_payload_size++] = (uint8_t)(rain_sensor_value & 0xFF);

  // Channel 8: Is Raining (Digital value)
  lpp_payload[lpp_payload_size++] = 8; // Channel
  lpp_payload[lpp_payload_size++] = LPP_DIGITAL_INPUT;
  lpp_payload[lpp_payload_size++] = is_raining ? 1 : 0;

  Serial.print("Sending LoRaWAN packet (Cayenne LPP): ");
  for (int i = 0; i < lpp_payload_size; i++) {
    Serial.printf("%02X ", lpp_payload[i]);
  }
  Serial.println();

  // Send the LoRaWAN packet
  // Port LORAWAN_APP_PORT (1), confirmation (true for confirmed, false for unconfirmed)
  if (api.lorawan.send(lpp_payload, lpp_payload_size, LORAWAN_APP_PORT, true) == 0) {
    Serial.println("LoRaWAN packet sent successfully.");
    display.clearDisplay(); display.setCursor(0, 0); display.println("Packet Sent!"); display.display();
  } else {
    Serial.println("Failed to send LoRaWAN packet.");
    display.clearDisplay(); display.setCursor(0, 0); display.println("Send Failed!"); display.display();
  }
}

// Example Payload Formatter (Decoder) for The Things Network (Custom Javascript)
// If you are using Cayenne LPP, TTN will automatically decode it.
// If you choose to send a custom binary payload (as in the original provided code's comments),
// you would use a decoder like this:
/*
function decodeUplink(input) {
  var data = {};
  var bytes = input.bytes;

  // Assuming a custom payload structure (matches the original provided code's comment):
  // Byte 0-1: Temperature (x100)
  // Byte 2-3: Humidity (x100)
  // Byte 4-5: Pressure (x10)
  // Byte 6-7: PM2.5
  // Byte 8: UV Index (x10)
  // Byte 9: Rain (0 or 1)
  // NOTE: This custom payload is different from the Cayenne LPP payload above.
  // Make sure your Arduino code's sendLoRaWANData() function matches your decoder.

  // The custom payload in the original provided code's comment has 12 bytes but byte 0 and 1 are empty.
  // And the array indexing is off. I'll adjust the decoder based on the assumed intention.

  // Decoder for the provided C++ payload structure in the original prompt (adjusted for common practice):
  // Byte 0: UV Index (x10)
  // Byte 1: Rain (0 or 1)
  // Byte 2-3: Temperature (x100)
  // Byte 4-5: Humidity (x100)
  // Byte 6-7: Pressure (x10)
  // Byte 8-9: PM2.5 (uint16)

  // This decoder assumes the custom payload structure you provided in the original C++ comment.
  // Please ensure the `sendLoRaWANData()` function in your Arduino code actually sends data
  // in this exact format if you intend to use this custom decoder.
  // If you use the Cayenne LPP code provided above, you don't need this custom decoder.

  data.uv_index = (bytes[0] / 10.0);
  data.is_raining = (bytes[1] === 1);
  data.temperature = ((bytes[2] << 8 | bytes[3]) / 100.0);
  data.humidity = ((bytes[4] << 8 | bytes[5]) / 100.0);
  data.pressure = ((bytes[6] << 8 | bytes[7]) / 10.0);
  data.pm2_5 = (bytes[8] << 8 | bytes[9]);

  return {
    data: data,
    warnings: [],
    errors: []
  };
}
*/
