#include <WiFi.h> // ESP32 WiFi library; needed to connect to the internet.
#include <HTTPClient.h> // for sending HTTP/HTTPS requests
#include <Wire.h> // for I2C communication
#include "RTClib.h" // library for DS3231 RTC
#include <WiFiClientSecure.h> // handles secure HTTPS connections for Twilio.
#include <Arduino.h>
#include <AsyncTCP.h>
#include <ESPAsyncWebServer.h>
AsyncWebServer server(80);
const char* ssid = "YOUR_WIFI_NETWORK";
const char* password = "YOUR_WIFI_PASSWORD";
const char* PARAM_INPUT_1="input1";
const char* PARAM_INPUT_2="input2";
const char* PARAM_INPUT_3="input3";
const char* PARAM_OTHER="othermed";
const char* accountSid = "YOUR_ACCOUNT_SID";
const char* authToken = "YOUR_AUTH_TOKEN";
const char* fromNumber = "+YOUR_TWILIO_NUMBER"; // include +
const char* toNumber = "+YOUR_PHONE_NUMBER"; // include +,country code
RTC_DS3231 rtc;
bool sendSMS();
String med = "";
String instr = "";
int alarmHour = -1;
int alarmMinute = -1;
const char index_html[] PROGMEM = R"rawliteral(
<!DOCTYPE HTML>
<html>
<head>
<title>ESP Input Form</title>
<meta name="viewport" content="width=device-width, initial-scale=1">
<script>
function handleMedChange(selectElem) {
var otherInput = document.getElementById('otherMedInput');
if (selectElem.value === 'Other') {
otherInput.style.display = 'inline';
otherInput.required = true;
} else {
otherInput.style.display = 'none';
otherInput.required = false;
}
}
</script>
</head>
<body>
<h2>Medicine Reminder</h2>
<form action="/get" method="GET"> // creating drop down list of medicine
<!-- Medicine name -->
medname:
<select name="input1" onchange="handleMedChange(this)">
<option value="">-- Select medicine --</option>
<option value="Metformin">Metformin</option>
<option value="Insulin">Insulin</option>
<option value="Aspirin">Aspirin</option>
<option value="Atorvastatin">Atorvastatin</option>
<option value="Metoprolol">Metoprolol</option>
<option value="levothyroxine">levothyroxine</option>
<option value="Other">Other</option>
</select>
<input
type="text"
id="otherMedInput"
name="otherMed"
placeholder="Enter medicine name"
style="display:none; margin-left:8px;"
>
<br><br>
<!-- Time -->
Time:
<input type="time" name="input2"> //input 2 =time
<br><br>
<!-- Instructions -->
Instructions: //input3=dropdown list of instructions
<select name="input3">
<option value="">-- Select instruction --</option>
<option value="before food">Before food</option>
<option value="after food">After food</option>
<option value="on empty stomach">Empty stomach</option>
<option value=" at bedtime">At bedtime</option>
</select>
<br><br>
<input type="submit" value="enter">
</form>
</body>
</html>
)rawliteral";
void notFound(AsyncWebServerRequest *request){
request->send(404, "text/plain", "Not found");
}
void setup() {
// put your setup code here, to run once:
Serial.begin(115200);
Wire.begin();
if (!rtc.begin()) {
Serial.println("Couldn't find RTC");
while (1);
}
rtc.adjust(DateTime(F(__DATE__), F(__TIME__)));
WiFi.mode(WIFI_STA);
WiFi.begin(ssid,password);
if (WiFi.waitForConnectResult()!=WL_CONNECTED){
Serial.print("WiFi failed");
return;
}
Serial.println();
Serial.print("IP adddress: ");
Serial.println(WiFi.localIP());
server.on("/", HTTP_GET, [](AsyncWebServerRequest *request){
request->send_P(200, "text/html", index_html);
});
server.on("/get", HTTP_GET, [] (AsyncWebServerRequest *request) {
String timeStr = "";
// GET input1 value on <ESP_IP>/get?input1=<inputMessage>
if (request->hasParam(PARAM_INPUT_1)) {
med = request->getParam(PARAM_INPUT_1)->value();
}
if (med == "Other" && request->hasParam(PARAM_OTHER)) {
med = request->getParam(PARAM_OTHER)->value();
}
if (request->hasParam(PARAM_INPUT_2)) {
String timeStr = request->getParam(PARAM_INPUT_2)->value(); //6:00
int colonIndex = timeStr.indexOf(':');
if (colonIndex != -1) {
alarmHour = timeStr.substring(0, colonIndex).toInt(); //6
alarmMinute = timeStr.substring(colonIndex + 1).toInt(); //0
}
}
if (request->hasParam(PARAM_INPUT_3)) {
instr = request->getParam(PARAM_INPUT_3)->value();
}
Serial.println("----- New entry -----");
Serial.println("Medicine: " + med);
Serial.println("Time: " + timeStr);
Serial.println("Hour: " + String(alarmHour) + ", Minute: " + String(alarmMinute));
Serial.println("Instructions (raw): " + instr);
Serial.println("---------------------");
String response = "Medicine reminder saved:<br>";
response += "Medicine: " + med + "<br>";
response += "Time: " + timeStr + "<br>";
response += "Instructions: " + instr + "<br><br>";
response += "<a href=\"/\">Return to Home Page</a>";
request->send(200, "text/html", response);
});
server.onNotFound(notFound);
server.begin();
}
void loop() {
DateTime now = rtc.now();
int currentHour = now.hour();
int currentMinute = now.minute();
int currentSecond = now.second();
Serial.printf("Time: %02d:%02d:%02d\n", currentHour, currentMinute, currentSecond);
Serial.print("Alarm set to: ");
Serial.print(alarmHour);
Serial.print(":");
Serial.println(alarmMinute);
if (alarmHour != -1 && alarmMinute != -1) { // only if user set a time
if (currentHour == alarmHour && currentMinute == alarmMinute && currentSecond < 10) {
Serial.println(" Alarm matched, calling sendSMS()");
bool ok = sendSMS();
if (ok) {
Serial.println("sendSMS() reported success.");
} else {
Serial.println("sendSMS() reported failure.");
}
delay(60000); // wait a minute so it doesn't spam
}
}
delay(10000); // check every 10 seconds
}
bool sendSMS(){
Serial.println("sendSMS() called");
if (WiFi.status() != WL_CONNECTED) {
Serial.println("WiFi not connected");
return false;
}
Serial.print("med = ");
Serial.println(med);
Serial.print("instr = ");
Serial.println(instr);
String messageBody = "Take " + med + " " + instr;
Serial.print("Final SMS text: ");
Serial.println(messageBody);
WiFiClientSecure client;
client.setInsecure();
HTTPClient https;
String url = "https://api.twilio.com/2010-04-01/Accounts/" + String(accountSid) + "/Messages.json";
if (!https.begin(client, url)) {
Serial.println("HTTP begin failed");
return false;
}
https.setAuthorization(accountSid, authToken);
https.addHeader("Content-Type", "application/x-www-form-urlencoded");
String body = "To=" + String(toNumber) + "&From=" + String(fromNumber) + "&Body=" + String(messageBody);
int code = https.POST(body);
if (code > 0) {
String resp = https.getString();
Serial.printf("HTTP %d\n%s\n", code, resp.c_str());
https.end();
return (code == 201 || code == 200);
} else {
Serial.printf("POST failed, error: %d\n", code);
https.end();
return false;
}
}
