8x LED Lighting by Sound

The short project for beginners to get some practice in using LED lighting with the sound sensor.

EasyFull instructions provided1 hour955
8x LED Lighting by Sound

Things used in this project

Hardware components

Arduino UNO & Genuino UNO
Arduino UNO & Genuino UNO
×1
Solderless Breadboard Full Size
Solderless Breadboard Full Size
×1
5 mm LED: Red
5 mm LED: Red
×3
5 mm LED: Yellow
5 mm LED: Yellow
×2
LED, Blue Green
LED, Blue Green
×2
Resistor 220 ohm
Resistor 220 ohm
×8
SparkFun Sound Detector (with Headers)
SparkFun Sound Detector (with Headers)
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Code

The code of project

C/C++
This is the code of 8x LED's system with a sound detector.
/*
 * Mantas Utka
*/

int ledPin1= 13; //Adding the LED's and sensor.
int ledPin2= 12;
int ledPin3= 11;
int ledPin4= 10;
int ledPin5= 9;
int ledPin6= 8;
int ledPin7= 7;
int ledPin8= 6;
int sensorPin= A0; //The sensor selecting as Analog pin. The Analog Pin is better for projects as this one.
int val = 0;

void setup(){
  pinMode(ledPin1, OUTPUT); //Selecting LEDs as outputs to push the results in LEDs of sound detector
  pinMode(ledPin2, OUTPUT);
  pinMode(ledPin3, OUTPUT);
  pinMode(ledPin4, OUTPUT);
  pinMode(ledPin5, OUTPUT);
  pinMode(ledPin6, OUTPUT);
  pinMode(ledPin7, OUTPUT);
  pinMode(ledPin8, OUTPUT);
  pinMode(sensorPin, INPUT); //Selecting the sensor as input to send results into Arduino
  Serial.begin (9600);
}

void loop (){
  val =analogRead(sensorPin);
  Serial.println (val);
  // when the sensor detects a signal, LED flashes

  //1
  if (val >= 127) {
    digitalWrite(ledPin1, HIGH); //selecting the values of LEDs to flash by detecting values of sound sensor.
  }
  else {
    digitalWrite(ledPin1, LOW);
  }

  //2
   if (val >= 378) {
    digitalWrite(ledPin2, HIGH);
  }
  else {
    digitalWrite(ledPin2, LOW);
  }

   //3
   if (val >= 505) {
    digitalWrite(ledPin3, HIGH);
  }
  else {
    digitalWrite(ledPin3, LOW);
  }

  //4
  if (val >= 632) {
    digitalWrite(ledPin4, HIGH);
  }
  else {
    digitalWrite(ledPin4, LOW);
  }

  //5
  if (val >= 759) {
    digitalWrite(ledPin5, HIGH);
  }
  else {
    digitalWrite(ledPin5, LOW);
  }

  //6
  if (val >= 886) {
    digitalWrite(ledPin6, HIGH);
  }
  else {
    digitalWrite(ledPin6, LOW);
  }

  //7
  if (val >= 980) {
    digitalWrite(ledPin7, HIGH);
  }
  else {
    digitalWrite(ledPin7, LOW);
  }

  //8
  if (val >= 1000) {
    digitalWrite(ledPin8, HIGH);
  }
  else {
    digitalWrite(ledPin8, LOW);
  }
}
