Published August 29, 2021

Toit with Magicbit

In this tutorial, we show you how to work Toit with Magicbit(ESP32).

BeginnerProtip1 hour363

Things used in this project

Hardware components

magicbit

Software apps and online services

Toit.io

Story

Toit is an end-to-end IoT software platform. Toit is also a new programming language tailored for embedded devices, and Toit provides powerful API endpoints such that your data can flow from your devices into your own IoT cloud system.

Toit offers a device dashboard where you can orchestrate and monitor your device fleet, and the Toit cloud allows for easy and flawless over-the-air firmware upgrade of your devices, as well as application deployment even if your devices are offline.

In this tutorial, we show you how to work Toit.io with Magicbit(ESP32).

Quick start

This guide will show you how to get a Toit account, install the Toit CLI locally, prepare your Magicbit(ESP32) microcontroller with the Toit firmware, and finally how to deploy a Toit app on your Magicbit.

Create a free Toit account to get access to the Toit cloud. Go to toit.io, click the Start Now button, and follow the sign-up instructions.

2. Connect the Magicbit with computer

First of all, you should Connect the Magicbit with a USB cable to your computer.

3. Connect the magicbit with Toit

On this page you can connect the Magicbit dev.board with Toit for that you should click Yes button,

then you can click yes,let's start button and select the COM Port,

1 / 3 • 01

4. Run program in magicbit

after that, you can click the code tab and copy-paste the below code here, Now you can click the Run on device button and run the code in Magicbit.

Reference: https://toit.io/

LED_Blink (Toit)

import gpio

// The red LED is connected to pin 17.
LED1 ::= gpio.Pin.out 17
// The green LED is connected to pin 18.
LED2 ::= gpio.Pin.out 18

main:
  // Note the double `::` on the next two lines.
  // Start a task that runs the my_task_1 function.
  task:: my_task_1
  // Start a second task that runs my_task_2.
  task:: my_task_2

my_task_1:
  while true:
    sleep --ms=500
    LED1.set 1
    sleep --ms=500
    LED1.set 0

my_task_2:
  while true:
    sleep --ms=123
    LED2.set 1
    sleep --ms=123
    LED2.set 0
