The Magnificent M.E.G.G. Car

An amazing and reliable autonomous car using a Rapsberry Pi with speed encoder utilizing OpenCV to do lane recognition and detecting stops.

IntermediateFull instructions provided188

Things used in this project

Hardware components

Webcam, Logitech® HD Pro

Optical Speed Encoder

Portable Charger

Raspberry Pi 4 Model B

DC motor (generic)

Servo Motor

Software apps and online services

OpenCV

Hand tools and fabrication machines

Hot glue gun (generic)

Tape

Scissor, Electrician

Story

Introduction

This project is based on the requirements for the ELEC 424 final project to design and build an autonomous RC car that utilizes OpenCV to do image processing to allow for the detection of paths and stops. Furthermore, it was required to included speed encoding that would manage the speed of the car to stay constant. We had to utilize multiple hardware components, such as a servo motor, DC motor, and a Raspberry pi and encased them within the car. We were inspired by scripts from other projects and created a program that would be able to navigate the track in the FEP building. Since this was accomplished (as seen in the video below), we consider this project a success. We have references to all the resources that we used in the citations section.

The camera resolution used was 160x120. To arrive at this value produced video streams with different resolutions and concluded that 160x120 striked a good balance between processing time and enough details so that the OpenCV could produce good results from the images captured. For the PID, we chose 0.09 as the proportional gain (kp) and kp * 0.5 as the derivative gain (kd). We arrived at those calibrated constants through trial and error and verifying that these values yielded good results. However, we found that different hardware conditions (like battery charge) can demand different gains.

Our code utilizes a flag to indicate whether the first stop sign has been seen or not (passedFirstStopSign) and a function to identify the stop the stop sign (isRedFloorVisible()), which takes in the current frame from the webcam, converts it to the HSV color space, applies a red mask, and checks the percentage of red in the frame. Every 20 iterations of the while loop, if the flag is zero, the current the output of isRedFloorVisible() is collected; if the car is seeing the stop sign, it stops. Additionally, in order to prevent the car from seeing the first stop sign twice (and wrongfully identifying it as the final stop sign), our code concludes that it’s in fact seeing the final stop sign by checking both the passedFirstStopSign flag and whether enough time has passed since the first stop sign was seen.

Plots

Error, proportional response, and derivative response verse frame number for full run

Error, steering duty cycle, and speed duty cycle versus frame number for full run

Picture of Vehicle

RC Car

Video of the Car Making a Full Run

Video of a full run of the course with the RC Car

Citations

Raja_961:https://www.instructables.com/Autonomous-Lane-Keeping-Car-Using-Raspberry-Pi-and/

Team Big Brains: https://www.hackster.io/big-brains/big-brains-elec-424-final-project-team-11-53c862

Team Dreamhouse:https://www.hackster.io/team-elec424-dreamhouse/team-elec424-dreamhouse-c5ad62

# Team: Gregory Chekler, Giovanni Minatel Melo de Cerqueira, Matthew Karazincir, Emmanuel Zerefa
# Class: ELEC 424
# Final Project
# Fall 2025
#
#
# Code drawn from:
# https://www.hackster.io/colonel-hackers/autonomous-rc-car-elec-424-final-project-732fd1
# https://www.hackster.io/paul-walker/autonomous-rc-car-eebfb4?f=1
# https://www.hackster.io/really-bad-idea/autonomous-path-following-car-6c4992

# Import Packages
import cv2
import numpy as np
import matplotlib.pyplot as plt
import math
import sys
import time
import os
import board
import busio
import adafruit_mcp4728
import RPi.GPIO as GPIO

GPIO.setmode(GPIO.BCM) #specifies that we are using the GPIO pin numbering weve seen on diagrams in class


GPIO.setup(18, GPIO.OUT) #Initializes GPIO 18 as OUTPUT
GPIO.setup(19, GPIO.OUT) #Initializes GPIO 19 as OUTPUT

pwm_esc = GPIO.PWM(18, 50) #creates a PWM at GPIO 18 running at 50Hz
pwm_serv = GPIO.PWM(19, 50) #creates a PWM at GPIO 19 running at 50Hz

pwm_esc.start(7.5) #puts DC motor on neutral
pwm_serv.start(7.5) #sets servo motor straight

# # Setup DAC
# i2c = busio.I2C(board.SCL, board.SDA)
# mcp4728 = adafruit_mcp4728.MCP4728(i2c, 0x64)


# Manage car behaviour
speed_encode = True
# Encoder
encoder_path = "/sys/module/gpiod_driver_encoder/parameters/encoder_val"
#encoder_target_rotation = 4046040
#encoder_rotation_variance = 1500000
#encoder_max_rotation = encoder_target_rotation + encoder_rotation_variance
encoder_max_rotation = 5000000 #max speed
encoder_min_rotation = 8500000 #min speed

# Camera
frame_width = 160
frame_height = 120
cam_idx = 0

# PD variables
kp = 0.09 ##proportional gain
kd = kp * 0.5 #derivative gain

# Speed Values
zero_speed = 7.5 # car is stopped
base_speed = 8.03 # car moves forward slowly
#speed_variance = 0.02 #just a test (this is a random value)
speed_change = 0.001
zero_turn = 7.5 # neutral steering

global_enc_vals = []

# Max number of loop
max_ticks = 4000

class NotSudo(Exception):
    pass

# def set_speed(speed):
#     # Set the speed of the car
#     mcp4728.channel_b.value = speed

# def set_turn(turn):
#     # Turn wheels
#     mcp4728.channel_a.value = turn

def reset_car():
    # set speed to zero and steering to neutral
    pwm_esc.ChangeDutyCycle(7.5) #puts DC motor on neutral
    pwm_serv.ChangeDutyCycle(7.5) #servo straight
    #print("Car: stopped & straightened")

def start_car():
    # Set speed to base speed and steering to neutral
    print("Car ready")
    pwm_esc.ChangeDutyCycle(base_speed) #puts DC motor on neutral
    pwm_serv.ChangeDutyCycle(7.5) #servo straight


def manage_speed():
    #print("I'm in manage_speed()!!!!!!")
    # Adjust the speed based on the speed encoder
    # read the file with encoder data
    f = open(encoder_path, "r")
    enc = int(f.readline()) #value frome encoder
    f.close()
    ret = enc #probably redundant

    global_enc_vals.append(enc)
    print("this is enc:")
    print(enc)
    # If within bounds (wait for car to start / stop)
    #ret = base_speed
    ret = 0 #no speed change
    if enc <= encoder_max_rotation: #too fast
        """
        # speed encode based on percentage
        enc_pct_rotation = (enc - (encoder_target_rotation - encoder_rotation_variance)) / (2 * encoder_rotation_variance)
        print("end_pct_rotation:")
        print(enc_pct_rotation)
        #ret = int(((speed_variance * 2) * abs(enc_pct_rotation - 1)) + (base_speed - speed_variance))
        ret_1 = int(((speed_variance * 2) * abs(enc_pct_rotation - 1)) + (base_speed - speed_variance))
        print("ret_1")
        print(ret_1)
        # # If speed from encoder is too fast, use base speed
        # if ret > base_speed:
        #     ret = base_speed
        """
        ret = -(speed_change) #reduce speed
    elif enc >= encoder_min_rotation: #too slow
        ret = (speed_change) #increase speed
    return ret

def wait(wait_time):
    # Wait for a period of time
    start_time = time.perf_counter() # start
    end_time = start_time + wait_time # end
    # loop until finished
    while (time.perf_counter() < end_time):
        pass
    return

def detect_edges(frame):
    # Detetct the blue lines
    # filter for blue lane lines
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)

    # This color values were adjusted from Paul Walker Team code
    lower_blue = np.array([90, 50, 50], dtype="uint8")
    upper_blue = np.array([130, 255, 255], dtype="uint8")

    # make mask
    mask = cv2.inRange(hsv, lower_blue, upper_blue)

    # Get edges
    edges = cv2.Canny(mask, 50, 100)
    return edges

def region_of_interest(edges):
    # Find region to look at
    height, width = edges.shape
    mask = np.zeros_like(edges)

    # only focus lower half of the screen
    polygon = np.array([[
        (0, height),
        (0, height / 2),
        (width, height / 2),
        (width, height),
    ]], np.int32)

    cv2.fillPoly(mask, polygon, 255)

    # Get region to look at
    cropped_edges = cv2.bitwise_and(edges, mask)

    return cropped_edges

def detect_line_segments(cropped_edges):
    # Find line segments

    # set constants
    rho = 1
    theta = np.pi / 180
    min_threshold = 10

    #get lines
    line_segments = cv2.HoughLinesP(cropped_edges, rho, theta, min_threshold,
                                    np.array([]), minLineLength=5, maxLineGap=150)

    return line_segments

def average_slope_intercept(frame, line_segments):
    # finding slope of the line
    lane_lines = []

    if line_segments is None:
        print("No line segments detected")

        return lane_lines

    # set boundries
    height, width, _ = frame.shape
    left_fit = []
    right_fit = []
    boundary = 1 / 3
    left_region_boundary = width * (1 - boundary)
    right_region_boundary = width * boundary

    # go through line segments and get line of best fit
    for line_segment in line_segments:
        for x1, y1, x2, y2 in line_segment:
            if x1 == x2:
                continue

            fit = np.polyfit((x1, x2), (y1, y2), 1)
            slope = (y2 - y1) / (x2 - x1)
            intercept = y1 - (slope * x1)

            if slope < 0:
                if x1 < left_region_boundary and x2 < left_region_boundary:
                    left_fit.append((slope, intercept))
            else:
                if x1 > right_region_boundary and x2 > right_region_boundary:
                    right_fit.append((slope, intercept))

    # take average line of best fit
    left_fit_average = np.average(left_fit, axis=0)
    if len(left_fit) > 0:
        lane_lines.append(make_points(frame, left_fit_average))

    right_fit_average = np.average(right_fit, axis=0)
    if len(right_fit) > 0:
        lane_lines.append(make_points(frame, right_fit_average))

    return lane_lines

def make_points(frame, line):
    # For getting visual of lines
    height, width, _ = frame.shape

    slope, intercept = line

    y1 = height  # bottom of the frame
    y2 = int(y1 / 2)  # make points from middle of the frame down

    if slope == 0:
        slope = 0.1

    x1 = int((y1 - intercept) / slope)
    x2 = int((y2 - intercept) / slope)

    return [[x1, y1, x2, y2]]

def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6):
    # Get visual of lines
    line_image = np.zeros_like(frame)

    if lines is not None:
        for line in lines:
            for x1, y1, x2, y2 in line:
                cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)

    line_image = cv2.addWeighted(frame, 0.8, line_image, 1, 1)

    return line_image

def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5):
    # Show a hedaing line
    heading_image = np.zeros_like(frame)
    height, width, _ = frame.shape

    steering_angle_radian = steering_angle / 180.0 * math.pi

    x1 = int(width / 2)
    y1 = height
    x2 = int(x1 - height / 2 / math.tan(steering_angle_radian))
    y2 = int(height / 2)

    cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)
    heading_image = cv2.addWeighted(frame, 0.8, heading_image, 1, 1)

    return heading_image

def get_steering_angle(frame, lane_lines):
    # Get the angle to steer towards
    height, width, _ = frame.shape

    if len(lane_lines) == 2:
        _, _, left_x2, _ = lane_lines[0][0]
        _, _, right_x2, _ = lane_lines[1][0]
        mid = int(width / 2)
        x_offset = (left_x2 + right_x2) / 2 - mid
        y_offset = int(height / 2)

    elif len(lane_lines) == 1:
        x1, _, x2, _ = lane_lines[0][0]
        x_offset = x2 - x1
        y_offset = int(height / 2)

    elif len(lane_lines) == 0:
        x_offset = 0
        y_offset = int(height / 2)

    angle_to_mid_radian = math.atan(x_offset / y_offset)
    angle_to_mid_deg = int(angle_to_mid_radian * 180.0 / math.pi)
    steering_angle = angle_to_mid_deg + 90

    return steering_angle

def plot_pd(p_vals, d_vals, error, show_img=False):
    # Plot the proportional, derivative and error
    fig, ax1 = plt.subplots()
    t_ax = np.arange(len(p_vals))
    ax1.plot(t_ax, p_vals, '-', label="P values")
    ax1.plot(t_ax, d_vals, '-', label="D values")
    ax2 = ax1.twinx()
    ax2.plot(t_ax, error, '--r', label="Error")

    ax1.set_xlabel("Frames")
    ax1.set_ylabel("PD Value")
    ax2.set_ylim(-90, 90)
    ax2.set_ylabel("Error Value")

    plt.title("PD Values over time")
    fig.legend()
    fig.tight_layout()
    plt.savefig("pd_plot.png")

    if show_img:
        plt.show()
    plt.clf()

def plot_pwm(speed_pwms, turn_pwms, error, show_img=False):
    # Plot teh speed steering and the error
    fig, ax1 = plt.subplots()
    t_ax = np.arange(len(speed_pwms))
    ax1.plot(t_ax, speed_pwms, '-', label="Speed")
    ax1.plot(t_ax, turn_pwms, '-', label="Steering")
    ax2 = ax1.twinx()


    ax1.plot(t_ax, error / np.max(error), '--r', label="Error")

    ax1.set_xlabel("Frames")
    ax1.set_ylabel("Speed and Steer Duty Cycle")
    ax2.set_ylabel("Percent Error Value")

    plt.title("Speed and Steer Duty Cycle, and error v.s. time")
    fig.legend()
    plt.savefig("voltage_plot.png")

    if show_img:
        plt.show()
    plt.clf()

# adapted from hackster, changed to adhere to red HSV color segments
def isRedFloorVisible(image):
    """
    Detects whether or not the majority of a color on the screen is a particular color
    :param image:
    :param boundaries: [[color boundaries], [success boundaries]]
    :return: boolean if image satisfies provided boundaries, and an image used for debugging
    """
    # Convert to HSV color space
    hsv_img = cv2.cvtColor(image, cv2.COLOR_BGR2HSV)

    cv2.imwrite("redfloor.jpg", hsv_img)

    # parse out the color boundaries and the success boundaries
    # percentage was adjusted
    percentage = 25

    # lower and upper range for the lower part of red
    lower_red1 = np.array([0, 40, 60], dtype="uint8")
    upper_red1 = np.array([10, 255, 255], dtype="uint8")

    # lower and upper range for the upper part of red
    lower_red2 = np.array([170, 40, 60], dtype="uint8")
    upper_red2 = np.array([180, 255, 255], dtype="uint8")

    # create two masks to capture both ranges of red
    mask1 = cv2.inRange(hsv_img, lower_red1, upper_red1)
    mask2 = cv2.inRange(hsv_img, lower_red2, upper_red2)

    # combining the masks
    mask = cv2.bitwise_or(mask1, mask2)

    # applying the mask
    output = cv2.bitwise_and(hsv_img, hsv_img, mask=mask)

    # save the output image
    cv2.imwrite("redfloormask.jpg", output)

    # calculating what percentage of image falls between color boundaries
    percentage_detected = np.count_nonzero(mask) * 100 / np.size(mask)
    # if the percentage percentage_detected is betweeen the success boundaries, we return true,
    # otherwise false for result
    result = percentage < percentage_detected
    if result:
        print(percentage_detected)
    return result, output


def main():
    #setup variables
    lastTime = 0
    lastError = 0
    SecondStopTick = 0


    # arrays for making the final graphs
    p_vals = [] # proportional
    d_vals = [] # Derivative
    err_vals_1 = [] # error
    err_vals_2 = [] # error
    speed_vals = [] # speed values
    steer_vals = [] # steering values


    # set up video
    video = cv2.VideoCapture(cam_idx)
    video.set(cv2.CAP_PROP_FRAME_WIDTH, frame_width)
    video.set(cv2.CAP_PROP_FRAME_HEIGHT, frame_height)

    #Starts car
    start_car()
    curr_speed = base_speed
    counter = 0

    passedFirstStopSign = False
    while counter < max_ticks:
           print("beginning of measurement")
           pwm_esc.ChangeDutyCycle(zero_speed)
           # manage video
           ret, original_frame = video.read()
           frame = cv2.resize(original_frame, (160, 120))

           # process the frame to determine the desired steering angle
           edges = detect_edges(frame)
           cv2.imshow("edges", edges)
           roi = region_of_interest(edges)
           line_segments = detect_line_segments(roi)
           lane_lines = average_slope_intercept(frame, line_segments)
           lane_lines_image = display_lines(frame, lane_lines)

           steering_angle = get_steering_angle(frame, lane_lines)
           heading_image = display_heading_line(lane_lines_image,steering_angle)

           # calculate changes for PD
           now = time.time()
           dt = now - lastTime
           deviation = steering_angle - 90

           # PD Code
           error = deviation
           base_turn = 7.5
           proportional = kp * error
           derivative = kd * (error - lastError) / dt

           # Get Speed voltage
           #speed_voltage = curr_speed*(3.3/65535)


           # take values for graphs

           p_vals.append(proportional)
           d_vals.append(derivative)


           err_vals_1.append(error)
           speed_vals.append(curr_speed)




           # determine actual turn to do
           turn_amt = base_turn + proportional + derivative

           # makes trun based on turn_amt
           # Inspiration for sigmoid from Team Colonel Hackers
           #turn_amt = int(1/(1 + np.exp(0.32*(turn_amt -9.4)))*65535)
           #steer_voltage = turn_amt* (3.3/65535)
           #if counter % 3 == 0:
           steer_vals.append(turn_amt)

        #    print("#####")
        #    print(turn_amt)
        #    print(proportional)
        #    print(derivative)
           pwm_serv.ChangeDutyCycle(turn_amt) #drives the DC motor (forward)

           # Stops if sees the red box
           if counter % 20: # looks every 20 ticks
                if not passedFirstStopSign:
                    isStopSign, floorSight = isRedFloorVisible(frame)

                    # Sees red box
                    if isStopSign:
                        wait(3)
                        passedFirstStopSign = True
                        SecondStopTick = counter

                # for last box (first sign was seen and enough time has passed)
                elif passedFirstStopSign and counter > SecondStopTick+100:
                    isStopSign, _ = isRedFloorVisible(frame)
                    if isStopSign:
                        #set_speed(zero_speed)
                        pwm_esc.ChangeDutyCycle(zero_speed)
                        print("Reached final stop")
                        break # Stop forever

           # speed encoding
           if speed_encode:
                #print("print encode loop")
                if counter % 3 == 0: # Check every 3 ticks

                    # adjust speed
                    temp_speed = manage_speed() + curr_speed
                    print("this is temp_speed")
                    print(temp_speed)
                    if temp_speed != curr_speed:
                        #set_speed(temp_speed)
                        pwm_esc.ChangeDutyCycle(temp_speed) #probably redundant
                        curr_speed = temp_speed

           pwm_esc.ChangeDutyCycle(curr_speed) #drives the DC motor (forward) #w/o encoder, curr_speed is base speed
           print("current pwm:")
           print(curr_speed)
           wait(0.023) # Run at speed for a short amount of time

           key = cv2.waitKey(1)
           if key == 27:
                break

           counter += 1

    # Reset car and close everything
    reset_car()
    video.release()
    cv2.destroyAllWindows()

    # save plots
    plot_pd(p_vals, d_vals, err_vals_1)


    # print("dimensions")
    # print(speed_vals)
    # print(steer_vals)
    # print(err_vals_1)
    # print("length of arrays")
    # print(len(speed_vals))
    # print(len(steer_vals))
    # print(len(err_vals_1))
    # print("####")


    print("dimensions")
    print(speed_vals)
    print(steer_vals)
    print(err_vals_1)
    # print("length of arrays")
    # print(len(speed_vals))
    # print(len(steer_vals))
    # print(len(err_vals_1))
    # print("####")

    #plot_pwm(global_enc_vals, steer_vals, err_vals_2) #recording encoder
    plot_pwm(speed_vals, steer_vals, err_vals_1)



if __name__ == "__main__":
    main()

#include <linux/module.h>
#include <linux/of_device.h>
#include <linux/kernel.h>
#include <linux/gpio/consumer.h>
#include <linux/platform_device.h>
#include <linux/interrupt.h>
#include <linux/timekeeping.h>
#include <linux/ktime.h>
#include <linux/moduleparam.h>
#include <linux/hrtimer.h>
#include <linux/interrupt.h>
#include <linux/of.h>



/**
* Code from:  Haochen(Jason) Zhang, Ye Zhou, Konstantinos Alexopoulos
* Class: COMP 424 ELEC 424/553 001
* Final Project: Autonomous Car
* Fall 2023
*
* Interrupt code drawn from:
* https://github.com/Johannes4Linux/Linux_Driver_Tutorial/blob/main/11_gpio_irq/gpio_irq.c
**/



// Init variables
unsigned int irq_number;
static struct gpio_desc *my_enc;
static volatile u64 prev_time;
static volatile u64 curr_time;

static int encoder_val;
module_param(encoder_val, int, 0644);

// Interrupt Handler
static irq_handler_t gpio_irq_handler(unsigned int irq, void *dev_id, struct pt_regs *regs) {

	// Ensure time difference between interrupts is greater than 1 ms
	int enc_val = gpiod_get_value(my_enc);
	curr_time = ktime_get_ns();
	unsigned long elapsed_time = curr_time - prev_time;
	if (enc_val == 1 && elapsed_time > 1000000) {
		prev_time = curr_time;
		encoder_val = elapsed_time;
		printk(KERN_INFO "irq_handler - timing detected: %lu", elapsed_time);
	}

	return (irq_handler_t) IRQ_HANDLED;
}


// probe function
static int enc_probe(struct platform_device *pdev)
{
	//struct gpio_desc *my_btn;
	struct device *dev;
	dev = &pdev->dev;

	printk("enc_probe - RUNNING v5\n");

	// Get button
	my_enc = gpiod_get(dev, "lights2", GPIOD_IN);
	if(IS_ERR(my_enc)) {
		printk("enc_probe - could not gpiod_get_index 0 for btn\n");
		return -1;
	}

	// Setup interrupt & debounce
	irq_number = gpiod_to_irq(my_enc);
	gpiod_set_debounce(my_enc, 1000000);

	if(request_irq(irq_number, (irq_handler_t) gpio_irq_handler, IRQF_TRIGGER_RISING, "my_gpio_irq", NULL) != 0){
		printk("Error!\nCan not request interrupt nr.: %d\n", irq_number);
		return -1;	}
	prev_time = ktime_get_ns();

	printk("enc_probe - SUCCESS\n");
	return 0;
}

// remove function
static void enc_remove(struct platform_device *pdev)
{
	free_irq(irq_number, NULL);
	printk("enc_remove - Freed interrupt & Removing\n");
	return;
}

static struct of_device_id matchy_match[] = {
    { .compatible = "a_second_name", },
	{},
};

// platform driver object
static struct platform_driver my_driver = {
	.probe	 = enc_probe,
	.remove	 = enc_remove,
	.driver	 = {
	       .name  = "The Rock: this name doesn't even matter",
	       .owner = THIS_MODULE,
	       .of_match_table = matchy_match,
	},
};
module_platform_driver(my_driver);

MODULE_ALIAS("platform:my_driver");
MODULE_DESCRIPTION("424\'s finest");
MODULE_AUTHOR("GregoryC, GiovanniM, MatthewK, EmannuelZ");
MODULE_LICENSE("GPL v2");

The Magnificent M.E.G.G. Car
