FutureBoard coded on Kittenblock - Onboard Sensors

Onboard Sensors Blocks​

Sample Program: Buttons​

Pressing the buttons changes the color.

Sample Program: Temperature and Light sensors​

The sensor values are shown on the screen.

Sample Program: Accelerometer and Gyroscope​

Please refer to the following figure for the axis orientation.

The acceleration values are shown on the screen.

Sample Program: Gestures​

The Futureboard can detect 8 gestures:

• 'shake'
• 'freefall'
• 'tilt_up'
• 'tilt_down'
• 'tilt_left'
• 'tilt_right'
• 'face_up'
• 'face_down'

Shake the FutureBoard for a sound.

Sample Program: Gesture Triggers​

Shake the FutureBoard for a sound.

Note: Trigger Events only work when the program is uploaded onto the FutureBoard.

Sample Program: Gyroscope​

Shows the roll and pitch of the FutureBoard.

Sample Program: Magnetic Sensor​

The magnetic sensor has a range of ±800(μT)。

The magnetic strengths are shown on FutureBoard.

The magnetic sensor needs to be calibrated before use.

Sample Program: Compass​

The compass returns a compass bearing, with 0 indicating North.

The compass bearing is shown.
