WiFi Robot

Controlling a robot via WiFi, using Arduino and Blynk application.

IntermediateFull instructions provided8,162
WiFi Robot

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
ADAFRUIT MOTOR DRIVER SHIELD
×1
ESP8266 ESP-01
Espressif ESP8266 ESP-01
×1
DC motor (generic)
×4
Delrin V Wheel Kit
OpenBuilds Delrin V Wheel Kit
×4
Pocket Solder- 60/40 Rosin Core 0.031" diameter
Pocket Solder- 60/40 Rosin Core 0.031" diameter
×1
Jumper wires (generic)
Jumper wires (generic)
×1
9V battery (generic)
9V battery (generic)
×1
SparkFun Solder-able Breadboard - Mini
SparkFun Solder-able Breadboard - Mini
×1
AMS 1117
This a 3.3 voltage regulator
×1
Capacitor 100 µF
Capacitor 100 µF
×1
Resistor 1k ohm
Resistor 1k ohm
×1
Resistor 2.21k ohm
Resistor 2.21k ohm
×1

Software apps and online services

Blynk
Blynk
Arduino IDE
Arduino IDE

Hand tools and fabrication machines

Soldering iron (generic)
Soldering iron (generic)

Story

Read more

Schematics

Arduino motor driver shield to motors connections

ARDUINO TO WIFI MODULE CONNECTIONS

KINDLY FOLLOW THE SCHEMATICS AS IT IS AND THIS IS A VERY IMPORTNT STEP.

Code

Blynk_v0.3.3.zip

C/C++
do not add the whole library . we just need to add the 'BLYNKESP8266_SoftSer' part
No preview (download only).

Blynk_Release_v0.3.10.zip

C/C++
kindly ad this libarary to the arduino ide. do not miss it.
No preview (download only).

WIFI ROBOT CODE- GITHUB

THIS IS A NORMAL CODE THAT WE USE IN THE ARDUINO IDE. BUT THIS WILL ONLY WORK AFTER ADDING THE RESPECTIVE LIBRARIES.
