Light Intensity Monitoring through Bolt IoT WiFi Module

Here we start building this project.

First off,

1} We go to understand basic things about hardware such as physical properties of resistor and temperature sensor LM35.

Make sure the input voltage should be at least 5V and not more than this.

Above connection specifies LDR's one leg is in 3V socket and other is in AP. And resistor which connected relatively regarding to the same picture shown.

2} Make sure everything is ready, it means here - All connections as per shown in Circuit diagram.

3} Download the Bolt App from Playstore or from official site of Bolt.

Install it and see the next step.

Here you should have two Wifi's.

One is for our Bolt IoT Module that is to be connected to the cloud and one which is powered on

Our Bolt module is a Wifi Module

So it is certain that it will have its own hotspot.

We power our phone's Wifi and connect it through Bolt's Wifi.

Next Step...

4} Open Bolt Cloud Dashboard. And Create New Product name it as we learnt in training.

5} After doing all these steps, go and check whether it is connected to cloud or not.

Everything comes as a secondary after the prime work is done.

So here, primary work was making connection with hardware and its components.

6} Go and take sample code of google chart plotting,

Because we know where we have to show data that are captured by hardware module.

This Project is elaborated in video, the link is attached.

https://youtu.be/94kXLKUcXT4

Thank you !
