Autonomous Salinity Control on Coral Nursery Systems

import os
import gymnasium as gym
from gymnasium import spaces
from stable_baselines3 import PPO
import numpy as np
from stable_baselines3.common.env_util import make_vec_env
import matplotlib.pyplot as plt


# class for the environment
class PondSalinityEnv(gym.Env):
    def __init__(self):
        super().__init__()

        # Observation space: salinity in ppt
        self.observation_space = spaces.Box(
            low=0, high=45, shape=(1,), dtype=np.float32
        )

        # Action space: 3 discrete inflow options
        self.action_space = spaces.Discrete(3)

        self.current_step = 0
        self.max_step = 200
        self.salinity = None

        # System parameters
        self.dt = 1.0      # [h]
        self.V = 1000.0    # [m^3]
        self.C_in = 35.0   # [ppt]
        self.S_env = 34.5  # [ppt]
        self.k = 0.05     # [1/h]

    def reset(self, seed=None, options=None):
        super().reset(seed=seed)
        self.salinity = np.random.uniform(34.25, 34.75)
        self.current_step = 0
        return np.array([self.salinity], dtype=np.float32), {}

    def mapping_value(self, action):
        return {0: 0.0, 1: 0.1, 2: 0.5}[action]

    def step(self, action):
        Q_in = self.mapping_value(action)
        dS = (Q_in * self.C_in / self.V) - self.k * (self.salinity - self.S_env)
        self.salinity += self.dt * dS
        self.salinity = np.clip(self.salinity, 0, 45)

        obs = np.array([self.salinity], dtype=np.float32)
        reward = -abs(self.salinity - self.S_env)

        self.current_step += 1
        terminated = self.current_step >= self.max_step
        truncated = False
        return obs, reward, terminated, truncated, {}

    def render(self):
        print(f"Step={self.current_step} | Salinity={self.salinity:.2f} ppt")

    def close(self):
        pass

#########################################################

# for model training
# Import your environment
env = PondSalinityEnv()

# Wrap with vec_env (needed for PPO)
env = make_vec_env(lambda: PondSalinityEnv(), n_envs=1)

# Define PPO model
model = PPO(
    "MlpPolicy",
    env,
    verbose=1,
    learning_rate=3e-4,
    gamma=0.99,
    n_steps=2048,
    batch_size=64,
    ent_coef=0.01
)

# Train
model.learn(total_timesteps=500_000)

# Save model
model.save("ppo_salinity_1D")

env.close()
#######################################


# for testing the model
# Load model
model = PPO.load("ppo_salinity_1D")

# Create new env instance (not vec_env here)
env = PondSalinityEnv()

# Reset env
obs, _ = env.reset()
print("Initial observation:", obs)

# Logs
salinity_log = []
setpoint_log = []
time_log = []

setpoint = 34.5
n = 200  # shorter horizon for plotting

for t in range(n):
    # action, _ = model.predict(obs, deterministic=True)
    # obs, reward, terminated, truncated, info = env.step(action)

    action, _ = model.predict(obs, deterministic=True)
    obs, reward, terminated, truncated, info = env.step(int(action))

    salinity_log.append(obs[0])   # now obs is 1D
    setpoint_log.append(setpoint)
    time_log.append(t)

    if terminated or truncated:
        break

# Plot
plt.figure(figsize=(10,5))
plt.plot(time_log, salinity_log, label="Actual Salinity")
plt.plot(time_log, setpoint_log, 'r--', label="Desired Salinity (Setpoint)")
plt.xlabel("Time step")
plt.ylabel("Salinity (ppt)")
plt.title("Pond Salinity Control with RL Agent (1D state)")
plt.legend()
plt.grid(True)
plt.show()

########################################
