snake charmer

/*
 * Project capStone_Automatic_Snake_Environment_Care_System
 * Description: This my capstone for the class, it's a system to take care of my snakes environment when i am not available.
 * Author: Johnathan
 * Date: 8/12/2024
 * For comprehensive documentation and examples, please visit:
 * https://docs.particle.io/firmware/best-practices/firmware-template/
 */

// Include Particle Device OS APIs
#include "Particle.h"
#include "Adafruit_BME280.h"
#include "Adafruit_SSD1306.h"
#include "Adafruit_GFX.h"
#include <Adafruit_MQTT.h>
#include "Adafruit_MQTT/Adafruit_MQTT_SPARK.h"
#include "Adafruit_MQTT/Adafruit_MQTT.h"
#include "credentials.h"

///************ Global State (you don't need to change this!) ***   ***************/
  TCPClient TheClient;

// Setup the MQTT client class by passing in the WiFi client and MQTT server and login details.
Adafruit_MQTT_SPARK mqtt(&TheClient,AIO_SERVER,AIO_SERVERPORT,AIO_USERNAME,AIO_KEY);

///****************************** Feeds ***************************************/
// Setup Feeds to publish or subscribe
// Notice MQTT paths for AIO follow the form: <username>/feeds/<feedname>
Adafruit_MQTT_Subscribe capStone = Adafruit_MQTT_Subscribe(&mqtt, AIO_USERNAME "/feeds/capStone");
Adafruit_MQTT_Publish capHumidityfeed = Adafruit_MQTT_Publish(&mqtt, AIO_USERNAME "/feeds/capHumidityfeed");
Adafruit_MQTT_Publish capMoisturefeed = Adafruit_MQTT_Publish(&mqtt, AIO_USERNAME "/feeds/capMoisturefeed");
Adafruit_MQTT_Publish capTempFfeed = Adafruit_MQTT_Publish(&mqtt, AIO_USERNAME "/feeds/capTempFfeed");
Adafruit_MQTT_Publish capWaterSensorfeed = Adafruit_MQTT_Publish(&mqtt, AIO_USERNAME "/feeds/capWaterSensorfeed");

//this is the header, it defines variables which are used in the code.
const int Grove_Water_Sensor = S2;
const int OLED_RESET=-1;
const int hexAddress = 0x76;
Adafruit_BME280 bme ;
Adafruit_SSD1306 display(OLED_RESET);
int subValue;
int water;
int currentTime;
int last150MillisSec;
int last50MillisSec;
int last1000MillisSec;
int moisture;
int lastTempF;
unsigned int last, lastTimeMoist, lastTimetemp, lastTimeHumidity, lastTimeWater;
const int straightWater = 1530;
const int straightAir = 3585;
const int moistSoil = 2800;
const int drySoil = 3200;
float tempC;
float humidity;
float tempF;
float numValue;
bool status;

/************Declare Functions*************/
void MQTT_connect();
bool MQTT_ping();

// setup() runs once, when the device is first turned on.
// the setup is just telling the photon 2 to turn all the stuff on and where it can find the stuff.
void setup() {
  Serial.begin(9600);
  waitFor(Serial.isConnected,10000);

  Serial.printf("\n\n");

  //the pin for the water sensor.
  pinMode(Grove_Water_Sensor,INPUT);

  //the pin for the moisture sensor
  pinMode(A0,INPUT);

  //the pin for the mister
  pinMode(A5, OUTPUT);

  // the display hexaddress, also turns on the display.
  display.begin(SSD1306_SWITCHCAPVCC, 0x3C);

  //pins for both relays
  pinMode(S1, OUTPUT);
  pinMode(D6, OUTPUT);

  //getting the status of the BME to make sure it's working right than printing to serial monitor if it's not.
  status = bme . begin (hexAddress) ;
  if(status == false) {
    Serial.printf("BME280 at address 0x%02X failed to start", hexAddress);
 }

  //tells the display to display something than clear.
  display.display();
  delay(1000);
  display.clearDisplay();

  //tells the display what will be displayed but won't be displayed until the loop.
  display.setTextSize(1);
  display.setTextColor(WHITE);
  display.setCursor(0,0);
  display.printf("tempF %0.2f\n humidity %0.2f\n water %i\n moisture %i ",tempF,humidity,water,moisture);
  display.display();
  display.clearDisplay();

 //Setup MQTT subscription.
 mqtt.subscribe(&capStone);
}

// loop() runs over and over again, as quickly as it can execute.
void loop() {
  MQTT_connect();
  MQTT_ping();

  // this is our 'wait for incoming subscription packets' busy subloop.
  // it's telling the photon to publish temp, humidity, moisture and the water sensor values to the adafruit dashboard we made.
  Adafruit_MQTT_Subscribe *subscription;
  while ((subscription = mqtt.readSubscription(100))) {
    if (subscription == &capStone) {
      subValue = atoi((char *)capStone.lastread);
    }
    Serial.printf("button %i\n",subValue);
  }

  //this publishes humidity to dashboard
  if((millis()-lastTimeHumidity > 10000)) {
    if(mqtt.Update()) {
      capHumidityfeed.publish(humidity);
      Serial.printf("Publishing humidity %0.2f\n",humidity);
    }
    lastTimeHumidity = millis();
  }

  //this publishes tempF to dashboard
  if((millis()-lastTimetemp > 10000)) {
    if(mqtt.Update()) {
      capTempFfeed.publish(tempF);
      Serial.printf("Publishing tempF %0.2f\n",tempF);
      }
    lastTimetemp = millis();
  }

  //this publishes moisture to dashboard
  if((millis()-lastTimeMoist > 60100)) {
    if(mqtt.Update()) {
      capMoisturefeed.publish(moisture);
      Serial.printf("Publishing moisture %i\n",moisture);
    }
    lastTimeMoist = millis();
  }

  //publishes water sensor readings to dashboard
  if((millis()-lastTimeWater > 60500)) {
    if(mqtt.Update()) {
      capWaterSensorfeed.publish(water);
      Serial.printf("Publishing WaterSensor %i\n",water);
    }
    lastTimeWater = millis();
  }

  //this is just telling it to put the value gotten from the water sensor in a variable called water.
 water=digitalRead(Grove_Water_Sensor);

 //this is the same as the water sensor but for moisture sensor.
 moisture=analogRead(A0);

  //this tells the photon to turn on the pump if water is not detected by the water sensor.
 if(water==0){
  digitalWrite(D6,HIGH);
  delay(1000);
  digitalWrite(D6,LOW);
 }

 //this is telling it to do math to convert Celsius to fahrenheit and to do that every 150 MilliSseconds.
 currentTime = millis ();
 if((currentTime-last150MillisSec)>150) {
  last150MillisSec = millis();
 tempC = bme.readTemperature();
  tempF = 1.8 * tempC + 32.0;
 humidity = bme.readHumidity();
  Serial.printf("tempF %0.2f\n humidity %0.2f\n water %i\n moisture %i ",tempF,humidity,water,moisture);
}

//this tells the photon if the humidity is lower than 40 than turn on the mister that is connected to A5
if(humidity< 40){
  digitalWrite(A5, HIGH);
}
//this tells the photon if the humidity is higher than 60 than turn off the mister that is connected to A5
if(humidity> 60){
  digitalWrite(A5, LOW);
}
//this tells the photon if the tempF is lower than 70 than turn on the relay that has the heat lamp connected.
if(tempF< 75){
  digitalWrite(S1,HIGH);
}
//this tells the photon if the tempF is higher than 85 than turn off the relay that has the heat lamp connected.
if(tempF>85){
  digitalWrite(S1,LOW);
}

  //telling the photon to send temp, humidity, moisture and the water sensor values to the display.
  display.setTextSize(1);
  display.setTextColor(WHITE);
  display.setCursor(0,0);
  display.printf(" tempF %0.2f\n humidity %0.2f\n water %i\n moisture %i ",tempF,humidity,water,moisture);
  display.display();
  display.clearDisplay();


}

//Function to connect and reconnect as necessary to the MQTT server.
//Should be called in the loop function and it will take care if connecting.
void MQTT_connect() {
  int8_t ret;

  // Return if already connected.
  if (mqtt.connected()) {
    return;
  }

  Serial.print("Connecting to MQTT... ");

  while ((ret = mqtt.connect()) != 0) { // connect will return 0 for connected
       Serial.printf("Error Code %s\n",mqtt.connectErrorString(ret));
       Serial.printf("Retrying MQTT connection in 5 seconds...\n");
       mqtt.disconnect();
       delay(5000);  // wait 5 seconds and try again
  }
  Serial.printf("MQTT Connected!\n");
}

//this pings MQTT to make sure the connection does not close we use this a few times in the code.
bool MQTT_ping() {
  static unsigned int last;
  bool pingStatus;

  if ((millis()-last)>120000) {
      Serial.printf("Pinging MQTT \n");
      pingStatus = mqtt.ping();
      if(!pingStatus) {
        Serial.printf("Disconnecting \n");
        mqtt.disconnect();
      }
      last = millis();
  }
  return pingStatus;
}
