Dog wagging tail friendly device

 /*****************************************************************************/
//  Pedometer.ino
//  Hardware:      Grove - 6-Axis Accelerometer&Gyroscope
//  Arduino IDE:   Arduino-1.65
//  Author:        Lambor
//  Date:          Nov,2015
//  Version:       v1.0
//
//  Modified by:
//  Data:
//  Description:
//
//  by www.seeedstudio.com
//
//  This library is free software; you can redistribute it and/or
//  modify it under the terms of the GNU Lesser General Public
//  License as published by the Free Software Foundation; either
//  version 2.1 of the License, or (at your option) any later version.
//
//  This library is distributed in the hope that it will be useful,
//  but WITHOUT ANY WARRANTY; without even the implied warranty of
//  MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the GNU
//  Lesser General Public License for more details.
//
//  You should have received a copy of the GNU Lesser General Public
//  License along with this library; if not, write to the Free Software
//  Foundation, Inc., 51 Franklin St, Fifth Floor, Boston, MA  02110-1301  USA
//
/*******************************************************************************/

#include "LSM6DS3.h"
#include "Wire.h"
int sensorPin = A3;
#define CLEAR_STEP      true
#define NOT_CLEAR_STEP  false
  int flag = 0;
//Create a instance of class LSM6DS3
LSM6DS3 pedometer(I2C_MODE, 0x6A);    //I2C device address 0x6A

void setup() {
    Serial.begin(9600);
      pinMode(sensorPin, OUTPUT);
      pinMode(sensorPin, HIGH);
    while (!Serial);
    if (pedometer.begin() != 0) {
        Serial.println("Device error");
    } else {
        Serial.println("Device OK!");
    }

    //Configure LSM6DS3 as pedometer
    if (0 != config_pedometer(NOT_CLEAR_STEP)) {
        Serial.println("Configure pedometer fail!");
    }
    Serial.println("Success to Configure pedometer!");
}

void loop() {
    uint8_t dataByte = 0;
    uint16_t stepCount = 0;

    pedometer.readRegister(&dataByte, LSM6DS3_ACC_GYRO_STEP_COUNTER_H);
    stepCount = (dataByte << 8) & 0xFFFF;

    pedometer.readRegister(&dataByte, LSM6DS3_ACC_GYRO_STEP_COUNTER_L);
    stepCount |=  dataByte;

  while(stepCount > flag ){
    pinMode(sensorPin, LOW);
    delay(100);
    pinMode(sensorPin, HIGH);
    Serial.println("hello");
    flag = dataByte +1;
  }
    Serial.println(stepCount);
     pinMode(sensorPin, HIGH);
    delay(200);
}

//Setup pedometer mode
int config_pedometer(bool clearStep) {
    uint8_t errorAccumulator = 0;
    uint8_t dataToWrite = 0;  //Temporary variable

    //Setup the accelerometer******************************
    dataToWrite = 0;

    //  dataToWrite |= LSM6DS3_ACC_GYRO_BW_XL_200Hz;
    dataToWrite |= LSM6DS3_ACC_GYRO_FS_XL_2g;
    dataToWrite |= LSM6DS3_ACC_GYRO_ODR_XL_26Hz;


    // Step 1: Configure ODR-26Hz and FS-2g
    errorAccumulator += pedometer.writeRegister(LSM6DS3_ACC_GYRO_CTRL1_XL, dataToWrite);

    // Step 2: Set bit Zen_G, Yen_G, Xen_G, FUNC_EN, PEDO_RST_STEP(1 or 0)
    if (clearStep) {
        errorAccumulator += pedometer.writeRegister(LSM6DS3_ACC_GYRO_CTRL10_C, 0x3E);
    } else {
        errorAccumulator += pedometer.writeRegister(LSM6DS3_ACC_GYRO_CTRL10_C, 0x3C);
    }

    // Step 3:	Enable pedometer algorithm
    errorAccumulator += pedometer.writeRegister(LSM6DS3_ACC_GYRO_TAP_CFG1, 0x40);

    //Step 4:	Step Detector interrupt driven to INT1 pin, set bit INT1_FIFO_OVR
    errorAccumulator += pedometer.writeRegister(LSM6DS3_ACC_GYRO_INT1_CTRL, 0x10);

    return errorAccumulator;
}
