Wild Alert Smart Roadside Reflectors

A smart road reflector and a radar transceiver mesh network, deployed along the jungle roadside to detect animal movement near the road

BeginnerWork in progressOver 1 day99

Things used in this project

Hardware components

RCWL-0516 Microwave Radar Sensor

SparkFun RGB LED Breakout - WS2812B

Seeed Studio XIAO ESP32S3 Sense

Arduino Nano R3

SparkFun Transceiver Breakout - nRF24L01+

Li-Ion Battery 1000mAh

LDR, 5 Mohm

Mini 360 Step-Down Buck Converter

5V Solar Panel

Software apps and online services

Hand tools and fabrication machines

Soldering iron (generic)

Solder Wire, Lead Free

Digilent Mastech MS8217 Autorange Digital Multimeter

Story

Abstract

This project proposes a device designed to prevent nighttime accidents on highways located near forests, open fields, or farmlands. The system consists of three key components:

1.Smart Road Reflectors using WS2812B RGB LEDs

2.Radar Modules for detecting roadside motion

3.Cameras for precise detection in open areas such as large fields or farms

The smart reflectors emit different colored lights — green, cyan, and red — to indicate road status:

Green: Road is clear
Cyan: Motion detected nearby
Red: Immediate danger — stop

By deploying these components as a mesh network along the roadside, the system can accurately indicate how close a human or animal is to the road, thereby enhancing safety and preventing collisions.

Motivation or Idea Formation

Storytime 😇

Once, while traveling from Rajasthan to Delhi on the highway late at night, something happened that changed the way I think forever.

It was around 2:15 AM. I was in the car with my father, cruising at about 80 km/h. The highway passed through a stretch of forest area near the Rajasthan border. The road was quiet, the stars were out, and everything seemed peaceful—until, out of nowhere, a massive blue bull (nilgai) darted across the road.

Before we could react, it collided head-on with our car.

The impact was terrifying.

The animal was thrown into the air and front-flipped—twice—over the top of our vehicle. The sound, the shock, the suddenness… we were numb. The car came to a halt, its front completely shattered. The blue bull lay ahead on the road, severely injured. And my father and I… we were lucky. Thanks to the airbags, we escaped with only minor injuries.

The area was remote—no streetlights, no hospitals, no immediate help.

We quickly called the forest department and explained the situation. About 30 minutes later, a forest officer arrived, accompanied by a vet and a rescue vehicle. They took the injured animal for treatment, and we received first aid. Later, we had our vehicle towed from the spot.

But that moment stayed with me.

The guilt of unintentionally hurting a living being was heavy. I kept thinking: What if we had known an animal was near? What if the car had been warned? What if the animal had a safe way to cross?

Adaptability and practicality of idea

The solar reflectors are often used on Indian highways, and the Wild Alert project cannot overhaul the entire highway infrastructure, as that would be extremely costly. We are aiming to develop this at a very reasonable cost because using depth cameras and advanced technologies like LiDAR wouldn't be practical when considering implementation across thousands of kilometers of national highways. We plan to build the device—including both the radar and reflector components—for around $4–5 per unit. Since a mesh of reflectors and radars is essential for successful implementation, keeping the cost minimal ensures it won’t pose a financial burden on government bodies like the National Highways Authority of India (NHAI).

Tech Stack behind Wild Alert

we search for many ultrasonic sensor which suits the cost and give best results but some of them have limited range of detection and some of them are just too costly

I created a comparison table to determine which sensor best suits this project and finalized the RCWL-0516. It offers a range of up to 20 meters at a cost of just $0.50, supports TTL logic, and consumes only 3mA of power. With a detection angle of around 120–150 degrees—ideal for monitoring the opposite side of roadways—it works through non-metal objects, is compact, and highly sensitive. Since our device operates at night, the radar’s LDR pin helps enable night-time operation and reduces power consumption

RCWL 0516

Credit: Circuit Digest

{ The RCWL 0516 module consists of an ASIC chip RCWL9196 from RCWL. The RCWL9196 comes in a 16-pin SOIC package. The module contains all the complimentary components along with a single transistor-based high-frequency oscillator which generates the microwave signal with a frequency of around 3.175GHz, with a wavelength of 9.45cm and half wavelength of 4.725cm. There is also a power led which indicates the power status of the module. } quoted from Circuit Digest

Credit : Circuit Digest

The RCWL-0516 radar motion sensor includes optional tuning pins RCDS, RGN, and CTM—to customize its detection behavior.

The RCDS pin disables repeated triggering when pulled HIGH, preventing the sensor from continuously detecting motion in a static environment.
The RGN pin allows the connection of an external resistor to reduce the detection range, useful for limiting the sensor’s area of sensitivity.
The CTM pin lets you add an external capacitor to increase the delay time before the sensor can retrigger, providing control over how long it stays active after motion is detected. These pins help fine-tune the sensor for different applications.

One disadvantage of the RCWL-0516 is that it is too sensitive it can be easily triggered by noise. However, I found a method to tackle this issue from a blog on the website Dream Green House

1 / 3 • Some pictures from website Dream Green House

Preventing False Triggering

1 / 2 • Credit: Dream Green House

Another issue with the RCWL-0516 sensor is its 360-degree detection range, which means it can be easily triggered by motion even behind the sensor. To tackle this, a blog post on Dream Green Housesuggested a clever solution: the author glued four layers of tin foil on the outside of an Ariel gel cap, which served as a shield. The central hole of the cap was just the right size for his 3D-printed sensor mount. In theory, this modification should limit the detection to one direction only.His testing confirmed that the approach worked well—the sensor now operates unidirectionally with no false triggering due to noise.

NRF24L01

To connect the radar, reflector, and camera, we incorporate Nordic Semiconductor’s nRF24L01 to create a wireless mesh network that can support up to 125 units in a single mesh

The range of the nRF24L01 is 100 meters, which is sufficient for our use case. It can also achieve a range of over 600 meters with efficient communication of around 1–2 bytes, which is adequate for sending or receiving TTL logic signals. This is achieved using an LNA + SMA antenna designed for the nRF24L01. It supports SPI communication for interfacing with an MCU.

We are using the Arduino Nano as the MCU because it is cheap and easily available in the market. Since this is just a prototype, we can later switch to the ATtiny85 for cost optimization.

Addressable LED

We are using the WS2812B RGB LED module, which operates on 5V and is ideal for battery-powered applications. Each RGB LED draws about 20 mA, making it efficient for low-power projects. The LED colors are used as visual indicators for driver safety:

🔴 Red signals immediate stop, indicating that an animal is crossing the road or there’s a sudden interruption.

🔵 Cyan warns drivers to slow down, suggesting that an animal is nearby.

🟢 Green means the road is clear and safe to drive.

Solar

Credit: Road Sky

We aim to develop a solution that operates independently with low power consumption, using a long-lasting rechargeable battery supported by solar power.

ESP32S3 Sense Cam

Seeed Studio ESP32S3 Sense

We are using the FOMO model from Edge Impulse to detect animals and objects on the road, and then sending a trigger through the NRF radio frequency module.

Getting started with Edge

yet to be written

Device Architecture

We are using NRF radio frequency transceiver modules, ideal for mesh networks as well as low-power applications, and well-suited for sending trigger commands, with a range of 100 to 500 meters

Code

// ReflectorNode.ino
// Arduino Nano: RCWL-0516 + WS2812B + nRF24L01 (RF24Mesh)
// Libraries required:
//   - Adafruit_NeoPixel
//   - SPI
//   - RF24
//   - RF24Network (or RF24Mesh if you want automatic addressing)

// Install via Library Manager: "Adafruit NeoPixel", "RF24", "RF24Network", "RF24Mesh"

#include <Adafruit_NeoPixel.h>
#include <SPI.h>
#include <RF24.h>
#include <RF24Network.h>
#include <RF24Mesh.h>

//// CONFIG ////
#define NUM_LEDS 8               // number of LEDs on single reflector unit
#define LED_PIN 6                // WS2812 data pin
#define MOTION_PIN 2             // RCWL-0516 OUT -> D2 (interrupt capable)
#define LDR_PIN A0               // optional: analog LDR read for night-only operation
#define NIGHT_THRESHOLD 500      // analog value below which it's considered NIGHT (tune)
#define NODE_ID  10              // unique numeric node id for RF24Mesh (set per-device)
#define RF_CE_PIN 7
#define RF_CSN_PIN 8
#define CHANNEL 100              // RF24 channel (0..125)
#define SEND_INTERVAL 2000       // ms between status sends

//// Globals ////
Adafruit_NeoPixel strip(NUM_LEDS, LED_PIN, NEO_GRB + NEO_KHZ800);

RF24 radio(RF_CE_PIN, RF_CSN_PIN);
RF24Network network(radio);
RF24Mesh mesh(radio, network);

volatile bool motionTriggered = false;
unsigned long lastSend = 0;
uint8_t proximityLevel = 0; // 0=clear,1=nearby,2=danger

// packet payload
struct Payload {
  uint8_t nodeId;
  uint8_t level;     // 0,1,2
  uint32_t uptime;   // ms
};

void IRAM_ATTR onMotion() {
  motionTriggered = true;
}

void setLEDsForLevel(uint8_t level) {
  // level 0 -> green, 1 -> cyan, 2 -> red
  uint32_t color;
  if (level == 0) color = strip.Color(0,150,0);        // green
  else if (level == 1) color = strip.Color(0,150,150); // cyan
  else color = strip.Color(200,0,0);                   // red

  for (int i=0;i<NUM_LEDS;i++) strip.setPixelColor(i, color);
  strip.show();
}

void setup() {
  Serial.begin(115200);
  strip.begin();
  strip.show();
  pinMode(MOTION_PIN, INPUT);
  attachInterrupt(digitalPinToInterrupt(MOTION_PIN), onMotion, RISING);

  // Setup RF24Mesh
  radio.begin();
  radio.setChannel(CHANNEL);
  radio.setDataRate(RF24_250KBPS);
  mesh.setNodeID(NODE_ID);
  mesh.begin();
  Serial.println("Mesh started");

  // initial LED state
  setLEDsForLevel(0);
}

void loop() {
  mesh.update();
  mesh.DHCP(); // optional if using RF24DHCP

  // check night condition
  bool isNight = true;
  int ldrVal = analogRead(LDR_PIN);
  if (ldrVal > NIGHT_THRESHOLD) isNight = false; // bright -> day

  // if daytime, keep green and low-power
  if (!isNight) {
    proximityLevel = 0;
    setLEDsForLevel(0);
    delay(500);
    return;
  }

  // handle motion trigger
  if (motionTriggered) {
    motionTriggered = false;
    // on first trigger, mark as nearby (1), if repeated within short time escalate to danger (2)
    static unsigned long lastTriggerTime = 0;
    unsigned long now = millis();
    if (now - lastTriggerTime < 3000) {
      proximityLevel = 2; // immediate danger if double-triggered
    } else {
      proximityLevel = 1; // nearby
    }
    lastTriggerTime = now;
    setLEDsForLevel(proximityLevel);
  }

  // degrade level over time (simulate moving away)
  static unsigned long levelSetTime = 0;
  if (proximityLevel != 0) {
    if (levelSetTime == 0) levelSetTime = millis();
    if (millis() - levelSetTime > 8000) { // after 8s reduce
      if (proximityLevel == 2) proximityLevel = 1;
      else proximityLevel = 0;
      setLEDsForLevel(proximityLevel);
      if (proximityLevel == 0) levelSetTime = 0;
      else levelSetTime = millis();
    }
  }

  // periodically broadcast status to mesh (so upstream or other reflectors know)
  if (millis() - lastSend > SEND_INTERVAL) {
    Payload p;
    p.nodeId = NODE_ID;
    p.level = proximityLevel;
    p.uptime = millis();
    if (mesh.write(&p, sizeof(p))) {
      // success
    } else {
      // you can retry or log
    }
    lastSend = millis();
  }

  // process incoming packets
  while (network.available()) {
    RF24NetworkHeader header;
    Payload recv;
    network.peek(header); // peek optional
    if (network.read(header, &recv, sizeof(recv))) {
      // For example: if we receive a danger alert from a camera node, set all LEDs to red
      if (recv.level == 2) {
        proximityLevel = 2;
        setLEDsForLevel(2);
      } else if (recv.level == 1 && proximityLevel < 2) {
        // escalate to at least cyan
        proximityLevel = max<uint8_t>(proximityLevel, 1);
        setLEDsForLevel(proximityLevel);
      }
    }
  }

  // small sleep to lower cpu usage
  delay(50);
}

#include <SPI.h>
#include <RF24.h>
#include <RF24Network.h>
#include <RF24Mesh.h>

#define MOTION_PIN 2        // RCWL-0516 OUT -> D2
#define NODE_ID  15         // unique per radar node
#define RF_CE_PIN 7
#define RF_CSN_PIN 8
#define CHANNEL 100
#define SEND_INTERVAL 2000  // ms

RF24 radio(RF_CE_PIN, RF_CSN_PIN);
RF24Network network(radio);
RF24Mesh mesh(radio, network);

volatile bool motionTriggered = false;
uint8_t proximityLevel = 0; // 0=clear, 1=nearby, 2=danger
unsigned long lastSend = 0;

struct Payload {
  uint8_t nodeId;
  uint8_t level;
  uint32_t uptime;
};

void IRAM_ATTR onMotion() {
  motionTriggered = true;
}

void setup() {
  Serial.begin(115200);
  pinMode(MOTION_PIN, INPUT);
  attachInterrupt(digitalPinToInterrupt(MOTION_PIN), onMotion, RISING);

  radio.begin();
  radio.setChannel(CHANNEL);
  radio.setDataRate(RF24_250KBPS);
  mesh.setNodeID(NODE_ID);
  mesh.begin();
  Serial.println("Radar node started");
}

void loop() {
  mesh.update();
  mesh.DHCP();

  // simple trigger logic
  if (motionTriggered) {
    motionTriggered = false;
    static unsigned long lastTrig = 0;
    unsigned long now = millis();
    if (now - lastTrig < 3000) {
      proximityLevel = 2; // repeated trigger quickly = danger
    } else {
      proximityLevel = 1; // single trigger = nearby
    }
    lastTrig = now;
  }

  // degrade after a while
  static unsigned long lastLevelTime = 0;
  if (proximityLevel > 0) {
    if (lastLevelTime == 0) lastLevelTime = millis();
    if (millis() - lastLevelTime > 8000) {
      proximityLevel = 0;
      lastLevelTime = 0;
    }
  }

  // send status
  if (millis() - lastSend > SEND_INTERVAL) {
    Payload p;
    p.nodeId = NODE_ID;
    p.level = proximityLevel;
    p.uptime = millis();
    mesh.write(&p, sizeof(p));
    lastSend = millis();
    Serial.printf("Sent level %d\n", proximityLevel);
  }

  delay(50);
}

// ESP32CamAlert.ino
// Libraries: esp_camera (builtin), RF24, RF24Network, RF24Mesh
// Board: AI-Thinker ESP32-CAM

#include "esp_camera.h"
#include <WiFi.h> // for prints only
#include <SPI.h>
#include <RF24.h>
#include <RF24Network.h>
#include <RF24Mesh.h>

#define RF_CE 26
#define RF_CSN 27
#define NODE_ID 20
#define SEND_INTERVAL 1500

// RF setup
RF24 radio(RF_CE, RF_CSN);
RF24Network network(radio);
RF24Mesh mesh(radio, network);

struct Payload {
  uint8_t nodeId;
  uint8_t level;
  uint32_t uptime;
};

unsigned long lastSend = 0;
int dangerCounter = 0;

// Minimal camera init for AI thinker
#define PWDN_GPIO_NUM     32
#define RESET_GPIO_NUM    -1
#define XCLK_GPIO_NUM      0
#define SIOD_GPIO_NUM     26
#define SIOC_GPIO_NUM     27
#define Y9_GPIO_NUM       35
#define Y8_GPIO_NUM       34
#define Y7_GPIO_NUM       39
#define Y6_GPIO_NUM       36
#define Y5_GPIO_NUM       21
#define Y4_GPIO_NUM       19
#define Y3_GPIO_NUM       18
#define Y2_GPIO_NUM        5
#define VSYNC_GPIO_NUM    25
#define HREF_GPIO_NUM     23
#define PCLK_GPIO_NUM     22

void setup() {
  Serial.begin(115200);
  // camera config
  camera_config_t config;
  config.ledc_channel = LEDC_CHANNEL_0;
  config.ledc_timer   = LEDC_TIMER_0;
  config.pin_d0 = Y2_GPIO_NUM;
  config.pin_d1 = Y3_GPIO_NUM;
  config.pin_d2 = Y4_GPIO_NUM;
  config.pin_d3 = Y5_GPIO_NUM;
  config.pin_d4 = Y6_GPIO_NUM;
  config.pin_d5 = Y7_GPIO_NUM;
  config.pin_d6 = Y8_GPIO_NUM;
  config.pin_d7 = Y9_GPIO_NUM;
  config.pin_xclk = XCLK_GPIO_NUM;
  config.pin_pclk = PCLK_GPIO_NUM;
  config.pin_vsync = VSYNC_GPIO_NUM;
  config.pin_href = HREF_GPIO_NUM;
  config.pin_sscb_sda = SIOD_GPIO_NUM;
  config.pin_sscb_scl = SIOC_GPIO_NUM;
  config.pin_pwdn = PWDN_GPIO_NUM;
  config.pin_reset = RESET_GPIO_NUM;
  config.xclk_freq_hz = 20000000;
  config.pixel_format = PIXFORMAT_GRAYSCALE;
  config.frame_size = FRAMESIZE_QQVGA; // small for fast processing
  config.jpeg_quality = 12;
  config.fb_count = 1;

  esp_err_t err = esp_camera_init(&config);
  if (err != ESP_OK) {
    Serial.printf("Camera init failed: %d\n", err);
  } else {
    Serial.println("Camera OK");
  }

  // RF init
  radio.begin();
  radio.setDataRate(RF24_250KBPS);
  mesh.setNodeID(NODE_ID);
  mesh.begin();
  Serial.println("Mesh started on ESP32-CAM");
}

uint8_t detectMotionSimple() {
  // Very simple pixel-diff method: capture two frames and compare sum difference.
  // Returns 0 no-motion, 1 nearby, 2 danger.
  camera_fb_t * fb1 = esp_camera_fb_get();
  if (!fb1) return 0;
  delay(100);
  camera_fb_t * fb2 = esp_camera_fb_get();
  if (!fb2) {
    esp_camera_fb_return(fb1);
    return 0;
  }

  // compare a few bytes to estimate difference
  size_t len = min((size_t)2000, min(fb1->len, fb2->len));
  uint32_t diff = 0;
  for (size_t i=0;i<len;i+=20) { // sample step to speed up
    diff += abs((int)fb1->buf[i] - (int)fb2->buf[i]);
  }

  esp_camera_fb_return(fb1);
  esp_camera_fb_return(fb2);

  // thresholds (tune in field)
  if (diff > 1500) {
    // large movement
    return 2;
  } else if (diff > 400) {
    return 1;
  } else return 0;
}

void loop() {
  mesh.update();
  mesh.DHCP();

  uint8_t motionLevel = detectMotionSimple();

  if (motionLevel > 0) {
    // aggregate consecutive detections to decide danger
    if (motionLevel == 2) dangerCounter++;
    else dangerCounter = max(0, dangerCounter - 1);
  } else {
    dangerCounter = max(0, dangerCounter - 1);
  }

  uint8_t sendLevel = 0;
  if (dangerCounter >= 2) sendLevel = 2;
  else if (motionLevel == 1) sendLevel = 1;

  if (millis() - lastSend > SEND_INTERVAL && sendLevel > 0) {
    Payload p;
    p.nodeId = NODE_ID;
    p.level = sendLevel;
    p.uptime = millis();
    mesh.write(&p, sizeof(p));
    lastSend = millis();
    Serial.printf("Sent alert level %d\n", sendLevel);
  }

  // handle incoming messages similar to reflector node (optionally)
  while (network.available()) {
    RF24NetworkHeader header;
    Payload recv;
    network.peek(header);
    if (network.read(header, &recv, sizeof(recv))) {
      Serial.printf("Recv from %d level %d\n", recv.nodeId, recv.level);
    }
  }

  delay(200);
}
